20UPGFC0145974

MODULE/FINAL_COLD

Component Information

Serial Number 20UPGFC0145974
ProdDB ID  5f5cbc…0bd6ea
LocalDB ID 660fbdc02fc9f20035147b8d
Component Type fe_chip
Parents 20UPGM24211762  20UPGB43200442 
Children No match.
Flags
Wafer
  Wafer Probing

 Properties

Item Value
Target Iref trim 11
Target Iref trim version 1
Wafer serial number None

 Comments

Date Commented by on which Component Comment
4 days ago pixel (Lawrence Berkeley National Lab - pixel modules) MODULE
20UPGM24211762 		sign-off at MODULE/QC_CROSSCHECK; appended flags: ['INFO_CORE_COLUMN', 'DISABLED_CC_BY_HAND']; next stage: MODULE/PARYLENE_MASKING; comment: Disabled cc 50 by-hand

Test: TUNING QC Passed

(Stage: MODULE/FINAL_COLD)


Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key Data
QC Passed True
Date 2 days ago
component ObjectId 660fbdc02fc9f20035147b8d
Stage MODULE/FINAL_COLD
Test Type TUNING
Institute ObjectId
User Name None
ObjectId of this record 6a2ae2b22da0f186923e172c
ObjectId of RAW record None
Tags No tags
Tuning Config Associated FE Config

Results

Key Data
DCSdata {}
QC_LAYER L2
TUNING_UNTUNED_THRESHOLD_MEAN 2247.543
TUNING_UNTUNED_THRESHOLD_95_LOW 1563.023
TUNING_UNTUNED_THRESHOLD_95_HIGH 3043.206
TUNING_UNTUNED_THRESHOLD_SIGMA 375.249
TUNING_UNTUNED_TDAC_MEAN 0.0
TUNING_UNTUNED_TDAC_SIGMA 0.0
TUNING_UNTUNED_NOISE_MEAN 91.633
TUNING_UNTUNED_NOISE_SIGMA 10.86
TUNING_UNTUNED_NOISE_95_LOW 72.994
TUNING_UNTUNED_NOISE_95_HIGH 112.651
TUNING_UNTUNED_THRESHOLD_FAILED_FITS 3253
TUNING_TUNED_THRESHOLD_MEAN 1497.8
TUNING_TUNED_THRESHOLD_95_LOW 1429.265
TUNING_TUNED_THRESHOLD_95_HIGH 1561.16
TUNING_TUNED_THRESHOLD_SIGMA 38.0
TUNING_TUNED_TDAC_MEAN -1.6
TUNING_TUNED_TDAC_SIGMA 5.175
TUNING_TUNED_NOISE_MEAN 94.244
TUNING_TUNED_NOISE_SIGMA 10.965
TUNING_TUNED_NOISE_95_LOW 74.75
TUNING_TUNED_NOISE_95_HIGH 115.921
TUNING_TUNED_TOT_MEAN 7.4
TUNING_TUNED_TOT_SIGMA 0.3
TUNING_TUNED_TOT_95_LOW 4.71
TUNING_TUNED_TOT_95_HIGH 11.04
TUNING_TUNED_THRESHOLD_FAILED_FITS 3075
TUNING_ANY_ERRORS {'tune_globalthreshold': 1, 'thresholdscan_hr': 96, 'tune_pixelthreshold': 28, 'thresholdscan_hd': 31, 'totscan': 0, 'all': 156}
ANALYSIS_VERSION mqat v2.9.0
YARR_VERSION v1.6.0
MEASUREMENT_DATE 2026-06-11T12:21:29.000+00:00
MEASUREMENT_DURATION 664

Attachments

Filename Contents
output.log Download
0x23a36.log Download
20UPGFC0145974_MODULE__FINAL_COLD_TUNING.zip Download

ProductionDB Record

{}

 Current Stage: Final Cold

Test Type Local Result
ADC Calibration
(ADC_CALIBRATION)		 TestRun Present
Analog Readback
(ANALOG_READBACK)		 TestRun Present
SLDO
(SLDO)		 TestRun Present
VCAL Calibration
(VCAL_CALIBRATION)		 TestRun Present
Injection Capacitance
(INJECTION_CAPACITANCE)		 TestRun Present
Low Power Mode
(LP_MODE)		 No TestRun!
Overvoltage Protection
(OVERVOLTAGE_PROTECTION)		 No TestRun!
Undershunt Protection
(UNDERSHUNT_PROTECTION)		 No TestRun!
Tuning
(TUNING)		 TestRun Present
Minimal Health Test
(MIN_HEALTH_TEST)		 TestRun Present
Pixel Failure Analysis
(PIXEL_FAILURE_ANALYSIS)		 TestRun Present
Data Transmission
(DATA_TRANSMISSION)		 TestRun Present
Cold startup
(COLD_STARTUP)		 No TestRun!

 Candidate TestRuns of this Stage

LDB ID TestRun Code QC Passed Inspector Measurement Date Analysis Date Analysis Version Tags QC Registration
6a2ae3…8cda22 PIXEL_FAILURE_ANALYSIS Pass None N/A 2 days ago 2.9.0 No tags Selected
6a2ae3…9d170f MIN_HEALTH_TEST Pass None N/A 2 days ago 2.9.0 No tags Selected
6a2ae2…3e172c TUNING Pass None N/A 2 days ago 2.9.0 No tags Selected
6a2a3d…8cd9a4 DATA_TRANSMISSION Pass None 2 days ago 2 days ago 2.9.0 ganymede_4 Selected
6a2a3c…3e15be INJECTION_CAPACITANCE Pass None 2 days ago 2 days ago 2.9.0 ganymede_4 Selected
6a2a3b…3e1506 VCAL_CALIBRATION Pass None 2 days ago 2 days ago 2.9.0 ganymede_4 Selected
6a2a39…9d16c9 SLDO Pass None 2 days ago 2 days ago 2.9.0 ganymede_4 Selected
6a2a30…3e1474 ANALOG_READBACK Pass None 2 days ago 2 days ago 2.9.0 ganymede_4 Selected
6a2a16…7456dd ADC_CALIBRATION Pass None 2 days ago 2 days ago 2.9.0 ganymede_4 Selected
