20UPGFC0142211

MODULE/POST_PARYLENE_WARM

Component Information

Serial Number 20UPGFC0142211
ProdDB ID  42ebab…448ae2
LocalDB ID 660d7ca9ec873d0035450f9f
Component Type fe_chip
Parents 20UPGM23210289  20UPGB43200157 
Children No match.
Flags
Wafer
  Wafer Probing

 Properties

Item Value
Wafer serial number None
Target Iref trim None
Target Iref trim version None

 Comments

Scan Result: std_thresholdscan_hr / run 4388 (Stage: MODULE/POST_PARYLENE_WARM)
(ObjectId: 660d7ca9ec873d0035450f9f)


Result Plots

ThresholdDist-0

ThresholdMap-0_0_500_0_0_0

NoiseDist-0

Chi2Map-0_0_500_0_0_0

StatusMap-0_0_500_0_0_0

StatusDist-0_0_500_0_0_0

NoiseMap-0_0_500_0_0_0

Chi2Dist-0_0_500_0_0_0

TimePerFitDist-0_0_500_0_0_0

InjVcalDiff


Details

Scan

Key Data
runNumber 4388
testType std_thresholdscan_hr
stage MODULE/POST_PARYLENE_WARM
component 20UPGM23210289
20UPGFC0142211
20UPGFC0142169
20UPGFC0142232
20UPGFC0142135
startTime 2025-11-06 16:50:40
finishTime 2025-11-06 20:23:56
user fhartanto
site jittereel.dhcp.lbl.gov
targetCharge -1
targetTot -1
ctrlStatus channel_configuration: 16x1
fe_chip_type: RD53A/B/C
firmware_hash: 0x7b14549
firmware_identifier: 0x1030242
firmware_vers: v1.5.0
fmc_card_type: Ohio Card (Display Port)
fpga_card: Trenz TEF1001_R1
lpm_status: 0
rx_speed: 1280Mbps
exec -r /home/fhartanto/Yarr-jittereel/YARR/configs/controller/specCfg-rd53b-16x1-setup3.json -c /home/fhartanto/20UPGM23210289/20UPGM23210289_L2_warm.json -o data -W TUN -s /home/fhartanto/Yarr-jittereel/YARR/configs/scans/itkpixv2/std_thresholdscan_hr.json
stopwatch analysis: 784
