20UPGFC0141702

MODULE/COMPLETE

Component Information

Serial Number	20UPGFC0141702
ProdDB ID	acfa6a…15fbaf
LocalDB ID	660d23155d9bdc0035fd9396
Component Type	fe_chip
Parents	20UPGM24211044 20UPGB43200222
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Target Iref trim	9
Target Iref trim version	1
Wafer serial number	None

Comments

Test: TUNING QC Passed

(Stage: MODULE/FINAL_COLD)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	a month ago
component ObjectId	660d23155d9bdc0035fd9396
Stage	MODULE/FINAL_COLD
Test Type	TUNING
Institute ObjectId
User Name	None
ObjectId of this record	69fba6f81d764442f06c7fc6
ObjectId of RAW record	None
Tags	No tags
Tuning Config	Associated FE Config

Results

Key	Data
DCSdata	{}
QC_LAYER	L2
TUNING_UNTUNED_THRESHOLD_MEAN	2262.067
TUNING_UNTUNED_THRESHOLD_95_LOW	1584.026
TUNING_UNTUNED_THRESHOLD_95_HIGH	3052.285
TUNING_UNTUNED_THRESHOLD_SIGMA	372.238
TUNING_UNTUNED_TDAC_MEAN	0.0
TUNING_UNTUNED_TDAC_SIGMA	0.0
TUNING_UNTUNED_NOISE_MEAN	90.452
TUNING_UNTUNED_NOISE_SIGMA	11.291
TUNING_UNTUNED_NOISE_95_LOW	71.825
TUNING_UNTUNED_NOISE_95_HIGH	111.999
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	205
TUNING_TUNED_THRESHOLD_MEAN	1497.2
TUNING_TUNED_THRESHOLD_95_LOW	1427.993
TUNING_TUNED_THRESHOLD_95_HIGH	1560.878
TUNING_TUNED_THRESHOLD_SIGMA	37.0
TUNING_TUNED_TDAC_MEAN	-1.0
TUNING_TUNED_TDAC_SIGMA	4.705
TUNING_TUNED_NOISE_MEAN	91.869
TUNING_TUNED_NOISE_SIGMA	12.624
TUNING_TUNED_NOISE_95_LOW	72.367
TUNING_TUNED_NOISE_95_HIGH	113.608
TUNING_TUNED_TOT_MEAN	7.3
TUNING_TUNED_TOT_SIGMA	0.3
TUNING_TUNED_TOT_95_LOW	5.0
TUNING_TUNED_TOT_95_HIGH	10.83
TUNING_TUNED_THRESHOLD_FAILED_FITS	9
TUNING_ANY_ERRORS	{'tune_globalthreshold': 32, 'thresholdscan_hr': 954, 'tune_pixelthreshold': 47, 'thresholdscan_hd': 152, 'totscan': 0, 'all': 1185}
ANALYSIS_VERSION	mqat v2.8.1
YARR_VERSION	v1.5.6
MEASUREMENT_DATE	2026-05-07T02:51:58.000+00:00
MEASUREMENT_DURATION	682
