20UPGFC0141702
MODULE/QC_CROSSCHECK
Component Information
| Serial Number | 20UPGFC0141702 |
|---|---|
| ProdDB ID | acfa6a…15fbaf |
| LocalDB ID | 660d23155d9bdc0035fd9396 |
| Component Type | fe_chip |
| Parents | 20UPGM24211044 20UPGB43200222 |
| Children | No match. |
| Flags |
Properties
Comments
Test: PIXEL_FAILURE_ANALYSIS QC Passed
(Stage: MODULE/QC_CROSSCHECK)
Basic View Only: custom view for this TestRun is not prepared.
Metadata
| Key | Data |
|---|---|
| QC Passed | True |
| Date | |
| component ObjectId | 660d23155d9bdc0035fd9396 |
| Stage | MODULE/QC_CROSSCHECK |
| Test Type | PIXEL_FAILURE_ANALYSIS |
| Institute ObjectId | |
| User Name | None |
| ObjectId of this record | 69e2d126ac8d5ca4772736e7 |
| ObjectId of RAW record | None |
| Tags | No tags |
Results
| Key | Data |
|---|---|
| DCSdata | {} |
| QC_LAYER | L2 |
| PIXEL_FAILURE_SOURCE_SCAN_DONE | False |
| PIXEL_FAILURE_COLUMN_DISABLED | 0 |
| PIXEL_FAILURE_DEAD_DIGITAL | 0 |
| PIXEL_FAILURE_BAD_DIGITAL | 0 |
| PIXEL_FAILURE_DEAD_ANALOG | 2 |
| PIXEL_FAILURE_BAD_ANALOG | 3 |
| PIXEL_FAILURE_TUNING_BAD | 20 |
| PIXEL_FAILURE_HIGH_ENC | 4 |
| PIXEL_FAILURE_HIGH_NOISE | 6 |
| PIXEL_FAILURE_MERGED_BUMPS | 0 |
| PIXEL_FAILURE_DISCONNECTED_BUMPS_ZERO_BIAS_SCAN | -1 |
| PIXEL_FAILURE_DISCONNECTED_BUMPS_XTALK_SCAN | 0 |
| PIXEL_FAILURE_DISCONNECTED_BUMPS_SOURCE_SCAN | -1 |
| PIXEL_FAILURE_ELECTRICALLY_FAILED | 35 |
| PIXEL_FAILURE_DISCONNECTED_PIXELS | 0 |
| PIXEL_FAILURE_DISC_PIXEL_ALL_ELEC | 3 |
| PIXEL_FAILURE_FAILING_PIXELS | 35 |
| ANALYSIS_VERSION | mqat v2.8.0rc1.dev12 |
| YARR_VERSION | v1.5.6 |
| MEASUREMENT_DATE | 2026-04-18T06:38:24.000+00:00 |
| MEASUREMENT_DURATION | 675 |
Attachments
| Filename | Contents |
|---|---|
| output.log | Download |
| 0x22986.log | Download |
| 0x22986_TUNING_BAD_Threshold_1d.png |  |
| 0x22986_HIGH_ENC_Noise_1d.png |  |
| 0x22986_PFA_electrical_failures.png |  |
| 0x22986_merged.png |  |
| 0x22986_PFA_MERGED_BUMPS_(dependent).png |  |
| 0x22986_PFA_DISCONNECTED_BUMPS_XTALK_SCAN_(dependent).png |  |
| 0x22986_PIXEL_FAILURE_ANALYSIS_depclassification.png |  |
| 0x22986_PIXEL_FAILURE_ANALYSIS_indepclassification.png |  |
| 0x22986_summary.png |  |
| 20UPGFC0141702_MODULE__QC_CROSSCHECK_PIXEL-FAILURE-ANALYSIS.zip | Download |
.png&mimetype=image/png){kind=link}
.png&mimetype=image/png){kind=link}
