20UPGFC0222565

MODULE/POST_PARYLENE_WARM

Component Information

Serial Number	20UPGFC0222565
ProdDB ID	416808…9305d6
LocalDB ID	67a21cfcd7e33319cc6b7876
Component Type	fe_chip
Parents	20UPGM24831020 20UPGB43000257
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Target Iref trim	14
Target Iref trim version	1
Wafer serial number	None

Comments

Test: SLDO QC Passed

(Stage: MODULE/INITIAL_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	3 months ago
component ObjectId	67a21cfcd7e33319cc6b7876
Stage	MODULE/INITIAL_WARM
Test Type	SLDO
Institute ObjectId
User Name	DanielAceves
ObjectId of this record	692f4ec6d7bf966e0aafbac5
ObjectId of RAW record	692f4ec2d7bf966e0aafba8f
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.7.1
MEASUREMENT_DATE	2025-12-02T18:59:26.000+00:00
MEASUREMENT_DURATION	664
MEASUREMENT_VERSION	2.7.1
YARR_VERSION	v1.5.5
SLDO_ANALOG_OVERHEAD	0.111
SLDO_D_MIN_IIN	5.073
SLDO_A_MIN_IIN	5.737
SLDO_D_SLOPE	0.143
SLDO_A_SLOPE	0.107
SLDO_D_OFFSET	-0.6
SLDO_A_OFFSET	-0.607
SLDO_D_CHI2	0
SLDO_A_CHI2	0
SLDO_CORE_COL_DISABLED	0
SLDO_DIGITAL_OVERHEAD	0.478
SLDO_IINA	0.63
SLDO_IIND	0.916
SLDO_IREF	3.8378589999999995
SLDO_ISHUNTA	0.063
SLDO_ISHUNTD	0.296
SLDO_LINEARITY	0.012
SLDO_NOM_INPUT_CURRENT	6.25
SLDO_VDDA	1.21
SLDO_VDDD	1.19
SLDO_VINA	1.509
SLDO_VINA_VIND	-0.01
SLDO_VIND	1.514
SLDO_VI_OFFSET	0.969
SLDO_VI_SLOPE	0.087
SLDO_VOFFS	0.987

Attachments

Filename	Contents
output.log	Download
