20UPGFC0146103

MODULE/FINAL_COLD

Component Information

Serial Number	20UPGFC0146103
ProdDB ID	95d3da…070cda
LocalDB ID	660fbea6ec873d00354e22cf
Component Type	fe_chip
Parents	20UPGM24211761 20UPGB43200441
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Target Iref trim	7
Target Iref trim version	1
Wafer serial number	None

Comments

Test: TUNING QC Passed

(Stage: MODULE/FINAL_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	2 days ago
component ObjectId	660fbea6ec873d00354e22cf
Stage	MODULE/FINAL_WARM
Test Type	TUNING
Institute ObjectId
User Name	None
ObjectId of this record	6a2a008da2083033ec8cd832
ObjectId of RAW record	None
Tags	No tags
Tuning Config	Associated FE Config

Results

Key	Data
DCSdata	{}
QC_LAYER	L2
TUNING_UNTUNED_THRESHOLD_MEAN	2015.416
TUNING_UNTUNED_THRESHOLD_95_LOW	1459.5
TUNING_UNTUNED_THRESHOLD_95_HIGH	2611.512
TUNING_UNTUNED_THRESHOLD_SIGMA	292.128
TUNING_UNTUNED_TDAC_MEAN	0.0
TUNING_UNTUNED_TDAC_SIGMA	0.0
TUNING_UNTUNED_NOISE_MEAN	97.307
TUNING_UNTUNED_NOISE_SIGMA	10.754
TUNING_UNTUNED_NOISE_95_LOW	78.699
TUNING_UNTUNED_NOISE_95_HIGH	117.445
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	3150
TUNING_TUNED_THRESHOLD_MEAN	1498.5
TUNING_TUNED_THRESHOLD_95_LOW	1434.426
TUNING_TUNED_THRESHOLD_95_HIGH	1558.156
TUNING_TUNED_THRESHOLD_SIGMA	34.0
TUNING_TUNED_TDAC_MEAN	-1.5
TUNING_TUNED_TDAC_SIGMA	4.79
TUNING_TUNED_NOISE_MEAN	99.342
TUNING_TUNED_NOISE_SIGMA	13.19
TUNING_TUNED_NOISE_95_LOW	79.527
TUNING_TUNED_NOISE_95_HIGH	120.71
TUNING_TUNED_TOT_MEAN	7.4
TUNING_TUNED_TOT_SIGMA	0.3
TUNING_TUNED_TOT_95_LOW	5.0
TUNING_TUNED_TOT_95_HIGH	10.27
TUNING_TUNED_THRESHOLD_FAILED_FITS	3082
TUNING_ANY_ERRORS	{'tune_globalthreshold': 8, 'thresholdscan_hr': 270, 'tune_pixelthreshold': 44, 'thresholdscan_hd': 32, 'totscan': 0, 'all': 354}
ANALYSIS_VERSION	mqat v2.9.0
YARR_VERSION	v1.6.0
MEASUREMENT_DATE	2026-06-10T09:51:49.000+00:00
MEASUREMENT_DURATION	657

Attachments

Filename	Contents
output.log	Download
0x23ab7.log	Download
20UPGFC0146103_MODULE__FINAL_WARM_TUNING.zip	Download
