20UPGFC0146105

MODULE/FINAL_COLD

Component Information

Serial Number	20UPGFC0146105
ProdDB ID	d4118a…152676
LocalDB ID	660fbea3ec873d00354e22ca
Component Type	fe_chip
Parents	20UPGM24211762 20UPGB43200442
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Target Iref trim	13
Target Iref trim version	1
Wafer serial number	None

Comments

Date	Commented by	on which Component	Comment
4 days ago	pixel (Lawrence Berkeley National Lab - pixel modules)	MODULE 20UPGM24211762	sign-off at MODULE/QC_CROSSCHECK; appended flags: ['INFO_CORE_COLUMN', 'DISABLED_CC_BY_HAND']; next stage: MODULE/PARYLENE_MASKING; comment: Disabled cc 50 by-hand

Test: TUNING QC Passed

(Stage: MODULE/FINAL_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	2 days ago
component ObjectId	660fbea3ec873d00354e22ca
Stage	MODULE/FINAL_WARM
Test Type	TUNING
Institute ObjectId
User Name	None
ObjectId of this record	6a2a022f2da0f186923e110f
ObjectId of RAW record	None
Tags	No tags
Tuning Config	Associated FE Config

Results

Key	Data
DCSdata	{}
QC_LAYER	L2
TUNING_UNTUNED_THRESHOLD_MEAN	2203.035
TUNING_UNTUNED_THRESHOLD_95_LOW	1624.563
TUNING_UNTUNED_THRESHOLD_95_HIGH	2841.034
TUNING_UNTUNED_THRESHOLD_SIGMA	309.097
TUNING_UNTUNED_TDAC_MEAN	0.0
TUNING_UNTUNED_TDAC_SIGMA	0.0
TUNING_UNTUNED_NOISE_MEAN	97.431
TUNING_UNTUNED_NOISE_SIGMA	10.435
TUNING_UNTUNED_NOISE_95_LOW	78.367
TUNING_UNTUNED_NOISE_95_HIGH	117.851
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	99
TUNING_TUNED_THRESHOLD_MEAN	1497.7
TUNING_TUNED_THRESHOLD_95_LOW	1426.674
TUNING_TUNED_THRESHOLD_95_HIGH	1563.632
TUNING_TUNED_THRESHOLD_SIGMA	36.0
TUNING_TUNED_TDAC_MEAN	-1.0
TUNING_TUNED_TDAC_SIGMA	3.77
TUNING_TUNED_NOISE_MEAN	98.789
TUNING_TUNED_NOISE_SIGMA	10.704
TUNING_TUNED_NOISE_95_LOW	78.955
TUNING_TUNED_NOISE_95_HIGH	119.839
TUNING_TUNED_TOT_MEAN	7.5
TUNING_TUNED_TOT_SIGMA	0.3
TUNING_TUNED_TOT_95_LOW	5.1
TUNING_TUNED_TOT_95_HIGH	10.29
TUNING_TUNED_THRESHOLD_FAILED_FITS	3
TUNING_ANY_ERRORS	{'tune_globalthreshold': 0, 'thresholdscan_hr': 27, 'tune_pixelthreshold': 0, 'thresholdscan_hd': 5, 'totscan': 0, 'all': 32}
ANALYSIS_VERSION	mqat v2.9.0
YARR_VERSION	v1.6.0
MEASUREMENT_DATE	2026-06-10T09:32:01.000+00:00
MEASUREMENT_DURATION	657
