20UPGFC0146089

MODULE/FINAL_COLD

Component Information

Serial Number	20UPGFC0146089
ProdDB ID	7b984c…08d110
LocalDB ID	660fbe94ec873d00354e22ae
Component Type	fe_chip
Parents	20UPGM24211761 20UPGB43200441
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Target Iref trim	8
Target Iref trim version	1
Wafer serial number	None

Comments

Test: ANALOG_READBACK QC Passed

(Stage: MODULE/QC_CROSSCHECK)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	2 weeks ago
component ObjectId	660fbe94ec873d00354e22ae
Stage	MODULE/QC_CROSSCHECK
Test Type	ANALOG_READBACK
Institute ObjectId
User Name	None
ObjectId of this record	6a1b8dbaf1d08a12231b6336
ObjectId of RAW record	6a1b8db4f1d08a12231b6313
Tags	ganymede_3

Results

Key	Data
DCSdata	{}
MEASUREMENT_VERSION	2.8.1.dev0
QC_LAYER	L2
INSTITUTION	LBNL_PIXEL_MODULES
AR_TEMP_NTC	19.67
AR_TEMP_EXT	20.009
AR_TEMP_ASLDO	29.674
AR_TEMP_DSLDO	30.96
AR_TEMP_ACB	28.71
AR_TEMP_NF_ASLDO	1.258
AR_TEMP_NF_DSLDO	1.258
AR_TEMP_NF_ACB	1.257
AR_TEMP_POLY_TOP	-999
AR_TEMP_POLY_BOTTOM	-999
AR_TEMP_NF_TOP	-999
AR_TEMP_NF_BOTTOM	-999
AR_IREF	3.8e-06
AR_GADC	0.815
AR_VCALDAC	0.817
AR_VREFCORE	0.462
AR_VREFOVP	2.017
AR_NOMINAL_SETTINGS	[3.8e-06, 8.49e-05, 4.65e-05, 4e-06, 3.74e-05, 1.92e-05, 0.0, 3.59e-05, 7e-05, -999, 0.0, 0.0, 4.38e-05, 6.11e-05, 4.94e-05, 8.22e-05, 6.05e-05, 7.29e-05, 8.21e-05, 8.22e-05, 6.35e-05, 4.63e-05, 4.68e-05, 6.58e-05, 4.52e-05, 4.64e-05, -999, -999, 0.6406924, 0.0892932, 0.9185918, 0.3128846, 0.8149357, -999, -999, 0.8170914, 1.1851034, 0.1067247, 0.1028367, 0.0366552, 0.0385968, 0.0392717, 0.2304377, 0.2338697, 0.2464507, 0.6298057, -999, 0.6277877, -999, 0.5870817, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, 0.0172003, 0.4624717, 2.0174995, 1.5011308, 1.1912134, 0.5891077, 0.9887308, 1.5090668, 1.2093154, 0.5998547]
AR_VDDA_VS_TRIM	[0.946, 0.969, 0.991, 1.014, 1.037, 1.061, 1.082, 1.105, 1.125, 1.148, 1.168, 1.19, 1.214, 1.237, 1.257, 1.28]
AR_VDDD_VS_TRIM	[0.995, 1.018, 1.043, 1.065, 1.09, 1.113, 1.138, 1.161, 1.186, 1.209, 1.235, 1.258, 1.282, 1.305, 1.332, 1.355]
AR_VDDA_TRIM	11
AR_VDDD_TRIM	9
AR_ROSC_SLOPE	[776.9125076359614, 1186.80086452869, 770.3126841792975, 1192.9946286497232, 842.1832079903263, 1413.8298171881472, 989.1303300972926, 1443.7942249838006, 1201.473626209601, 1205.67510555417, 1395.5123164403328, 1395.9904514084024, 1223.4980135687456, 1230.137126884969, 1405.286944743556, 1403.127452137865, 1401.1651962916933, 1414.59439661396, 1646.7919239105022, 1650.0016777391413, 1380.269804079314, 1374.2283176625408, 1705.8149655489, 1707.2050586516873, 858.9947191267515, 860.7675144467761, 1035.82442533236, 1039.022236483023, 1028.7711642363033, 1039.0512978197573, 1199.1265551672698, 1243.778952091437, 1168.360907253171, 1229.8205591829399, 1585.7007412854975, 1586.2842353141182, 1595.2014352595254, 1582.2021948084212, 1593.0818358193246, 1587.132328965454, 1584.9141220046297, 1581.188311978198]
AR_ROSC_OFFSET	[-451.73727139026266, -681.526626784224, -461.9347920548057, -702.5774373265239, -554.72234548645, -933.6933509386961, -678.5529605188055, -983.6938043952018, -720.473836162289, -738.2523678620541, -831.162809623292, -831.4534108388162, -758.423173330946, -764.2510931676882, -851.6220852145098, -848.4695596194623, -933.8037235450967, -947.0620003864617, -1097.551043110225, -1096.1436209886072, -953.8300007053567, -956.628658300517, -1158.4511570692873, -1161.9865617367523, -544.7678521004841, -545.1241907898296, -663.6027935158605, -669.5447876716881, -650.5095212012268, -651.8413444430028, -574.8097728370327, -585.3878133563414, -642.1523161876199, -669.5501164385536, -1053.594091823864, -1060.1667641516926, -1064.0651316170083, -1057.2698963353955, -1059.2304423306068, -1054.6040254268282, -1053.6036916291828, -1055.2169288648518]
AR_ROSC_MAX_RESIDUAL	[2.478149899761399, 4.147287812983221, 2.308053268408173, 3.8873866816123863, 1.1582891949453706, 1.9365934383814682, 1.225869370983296, 1.9252114477488604, 3.7032656441274767, 3.5749941729838777, 4.298741371609112, 4.280199387765968, 3.1805419566342334, 3.2659829063850476, 4.083982790214162, 4.068330066895717, 1.8744128607986499, 1.928945795965783, 2.0923807787426774, 2.118129385840102, 1.5913086961896301, 1.3231373779995428, 2.2561573023235932, 2.2377716827263696, 1.6728913415661175, 1.734400183973038, 1.8848815599159934, 1.9314467642227, 2.219019000754916, 2.2450209238910364, 5.102697754169229, 5.487032098723026, 3.6697014355646047, 3.769499949722279, 2.0678553870336613, 2.0640150965050097, 2.0302852787741523, 1.9298079768427567, 2.085775313570386, 2.073475774581895, 2.0585065498189326, 1.9701974886874438]
AR_VDDD_SATURATION	-1.0
AR_VDDA_SATURATION	-1.0
AR_IREF_TRIM	8
ANALYSIS_VERSION	mqat v2.9.0
YARR_VERSION	v1.6.0
MEASUREMENT_DATE	2026-05-31T00:25:03.000+00:00
MEASUREMENT_DURATION	429

Attachments

Filename	Contents
output.log	Download
0x23aa9.log	Download

RAW Results Record

Download RAW

_id

6a1b8db4f1d08a12231b6313

raw

serialNumber

testType

runNumber

results

subtestType

stage

component

dbVersion

address

sys

20UPGFC0146089

ANALOG_READBACK

6a1b8db2f0bb9d1c82cd6969

DCSdata

SensorVoltage	-120.014
SensorCurrent	-2.82e-07
ModuleNTC	19.986218105

Measurements

Vmux0

X	False
Unit	V
Values	0.832136

Vmux3

X	False
Unit	V
Values	0.425746

Vmux4

X	False
Unit	V
Values	0.609752

Vmux5

X	False
Unit	V
Values	0.123925

Vmux6

X	False
Unit	V
Values	0.120037
