20UPGFC0145956

MODULE/FINAL_COLD

Component Information

Serial Number 20UPGFC0145956
ProdDB ID  309a63…a186e8
LocalDB ID 660fbda62fc9f20035147b3b
Component Type fe_chip
Parents 20UPGM24211761  20UPGB43200441 
Children No match.
Flags
Wafer
  Wafer Probing

 Properties

Item Value
Target Iref trim 10
Target Iref trim version 1
Wafer serial number None

 Comments


Test: PIXEL_FAILURE_ANALYSIS QC Passed

(Stage: MODULE/FINAL_COLD)


Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key Data
QC Passed True
Date a day ago
component ObjectId 660fbda62fc9f20035147b3b
Stage MODULE/FINAL_COLD
Test Type PIXEL_FAILURE_ANALYSIS
Institute ObjectId
User Name None
ObjectId of this record 6a2ae56b6d59f1b8609d18bc
ObjectId of RAW record None
Tags No tags

Results

Key Data
DCSdata {}
QC_LAYER L2
PIXEL_FAILURE_ANY_ERRORS {'digitalscan': 0, 'analogscan': 0, 'thresholdscan_hd': 284, 'noisescan': 0, 'mergedbumpscan': 0, 'discbumpscan': 2, 'all': 286}
PIXEL_FAILURE_SOURCE_SCAN_DONE False
PIXEL_FAILURE_COLUMN_DISABLED 0
PIXEL_FAILURE_DEAD_DIGITAL 0
PIXEL_FAILURE_BAD_DIGITAL 0
PIXEL_FAILURE_DEAD_ANALOG 1
PIXEL_FAILURE_BAD_ANALOG 1
PIXEL_FAILURE_TUNING_BAD 29
PIXEL_FAILURE_HIGH_ENC 5
PIXEL_FAILURE_HIGH_NOISE 8
PIXEL_FAILURE_MERGED_BUMPS 0
PIXEL_FAILURE_DISCONNECTED_BUMPS_ZERO_BIAS_SCAN -1
PIXEL_FAILURE_DISCONNECTED_BUMPS_XTALK_SCAN 1
PIXEL_FAILURE_DISCONNECTED_BUMPS_SOURCE_SCAN -1
PIXEL_FAILURE_ELECTRICALLY_FAILED 44
PIXEL_FAILURE_DISCONNECTED_PIXELS 1
PIXEL_FAILURE_DISC_PIXEL_ALL_ELEC 2
PIXEL_FAILURE_FAILING_PIXELS 45
ANALYSIS_VERSION mqat v2.9.0
YARR_VERSION v1.6.0
MEASUREMENT_DATE 2026-06-11T13:55:47.000+00:00
MEASUREMENT_DURATION 665

Attachments

Filename Contents
output.log Download
0x23a24.log Download
20UPGFC0145956_MODULE__FINAL_COLD_PIXEL-FAILURE-ANALYSIS.zip Download
