20UPGFC0145956

MODULE/FINAL_COLD

Component Information

Serial Number 20UPGFC0145956
ProdDB ID  309a63…a186e8
LocalDB ID 660fbda62fc9f20035147b3b
Component Type fe_chip
Parents 20UPGM24211761  20UPGB43200441 
Children No match.
Flags
Wafer
  Wafer Probing

 Properties

Item Value
Target Iref trim 10
Target Iref trim version 1
Wafer serial number None

 Comments


Test: TUNING QC Passed

(Stage: MODULE/FINAL_COLD)


Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key Data
QC Passed True
Date a day ago
component ObjectId 660fbda62fc9f20035147b3b
Stage MODULE/FINAL_COLD
Test Type TUNING
Institute ObjectId
User Name None
ObjectId of this record 6a2ae45f6d59f1b8609d17c4
ObjectId of RAW record None
Tags No tags
Tuning Config Associated FE Config

Results

Key Data
DCSdata {}
QC_LAYER L2
TUNING_UNTUNED_THRESHOLD_MEAN 2851.742
TUNING_UNTUNED_THRESHOLD_95_LOW 2036.515
TUNING_UNTUNED_THRESHOLD_95_HIGH 3835.917
TUNING_UNTUNED_THRESHOLD_SIGMA 456.348
TUNING_UNTUNED_TDAC_MEAN 0.0
TUNING_UNTUNED_TDAC_SIGMA 0.0
TUNING_UNTUNED_NOISE_MEAN 99.999
TUNING_UNTUNED_NOISE_SIGMA 13.061
TUNING_UNTUNED_NOISE_95_LOW 78.064
TUNING_UNTUNED_NOISE_95_HIGH 125.074
TUNING_UNTUNED_THRESHOLD_FAILED_FITS 394
TUNING_TUNED_THRESHOLD_MEAN 1500.4
TUNING_TUNED_THRESHOLD_95_LOW 1425.774
TUNING_TUNED_THRESHOLD_95_HIGH 1569.964
TUNING_TUNED_THRESHOLD_SIGMA 39.0
TUNING_TUNED_TDAC_MEAN -1.4
TUNING_TUNED_TDAC_SIGMA 4.373
TUNING_TUNED_NOISE_MEAN 97.456
TUNING_TUNED_NOISE_SIGMA 11.635
TUNING_TUNED_NOISE_95_LOW 76.477
TUNING_TUNED_NOISE_95_HIGH 120.324
TUNING_TUNED_TOT_MEAN 7.4
TUNING_TUNED_TOT_SIGMA 0.3
TUNING_TUNED_TOT_95_LOW 5.0
TUNING_TUNED_TOT_95_HIGH 11.07
TUNING_TUNED_THRESHOLD_FAILED_FITS 4
TUNING_ANY_ERRORS {'tune_globalthreshold': 23, 'thresholdscan_hr': 694, 'tune_pixelthreshold': 44, 'thresholdscan_hd': 86, 'totscan': 0, 'all': 847}
ANALYSIS_VERSION mqat v2.9.0
YARR_VERSION v1.6.0
MEASUREMENT_DATE 2026-06-11T13:39:10.000+00:00
MEASUREMENT_DURATION 658

Attachments

Filename Contents
output.log Download
0x23a24.log Download
20UPGFC0145956_MODULE__FINAL_COLD_TUNING.zip Download
