20UPGFC0142169

MODULE/POST_PARYLENE_COLD

Component Information

Serial Number 20UPGFC0142169
ProdDB ID  182223…17909a
LocalDB ID 660d7c69ec873d0035450eba
Component Type fe_chip
Parents 20UPGM23210289  20UPGB43200157 
Children No match.
Flags
Wafer
  Wafer Probing

 Properties

Item Value
Wafer serial number None
Target Iref trim None
Target Iref trim version None

 Comments


Test: MIN_HEALTH_TEST QC Failed

(Stage: MODULE/POST_PARYLENE_WARM)


Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key Data
QC Passed False
Date a month ago
component ObjectId 660d7c69ec873d0035450eba
Stage MODULE/POST_PARYLENE_WARM
Test Type MIN_HEALTH_TEST
Institute ObjectId
User Name None
ObjectId of this record 69a5fe213884923f11f716ce
ObjectId of RAW record None
Tags No tags

Results

Key Data
DCSdata {}
QC_LAYER L2
MIN_HEALTH_THRESHOLD_MEAN 1576.35
MIN_HEALTH_THRESHOLD_SIGMA 85.24
MIN_HEALTH_NOISE_MEAN 239.68
MIN_HEALTH_NOISE_SIGMA 43.37
MIN_HEALTH_TOT_MEAN 6.08
MIN_HEALTH_TOT_SIGMA 1.62
MIN_HEALTH_COLUMN_DISABLED 6144
MIN_HEALTH_DEAD_DIGITAL 4
MIN_HEALTH_BAD_DIGITAL 0
MIN_HEALTH_DEAD_ANALOG 12
MIN_HEALTH_BAD_ANALOG 27
MIN_HEALTH_THRESHOLD_FAILED_FITS 154
MIN_HEALTH_HIGH_ENC 12904
MIN_HEALTH_BAD_ANALOG_INTEGRATED 6187
MIN_HEALTH_THRESHOLD_FAILED_FITS_INDEPENDENT 6334
MIN_HEALTH_HIGH_ENC_INDEPENDENT 12908
ANALYSIS_VERSION mqat v2.8.0rc1.dev12
YARR_VERSION v1.5.5
MEASUREMENT_DATE 2026-03-03T04:00:00.000+00:00
MEASUREMENT_DURATION 506
