20UPGFC0141752

MODULE/QC_STATUS

Component Information

Serial Number	20UPGFC0141752
ProdDB ID	338a2f…5192eb
LocalDB ID	660d235b5d9bdc0035fd9412
Component Type	fe_chip
Parents	20UPGM24210028 20UPGB43200226
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Target Iref trim	7
Target Iref trim version	1
Wafer serial number	None

Comments

Test: MIN_HEALTH_TEST QC Passed

(Stage: MODULE/QC_CROSSCHECK)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	a month ago
component ObjectId	660d235b5d9bdc0035fd9412
Stage	MODULE/QC_CROSSCHECK
Test Type	MIN_HEALTH_TEST
Institute ObjectId
User Name	None
ObjectId of this record	6a02478c1f68f7138e53e4fb
ObjectId of RAW record	None
Tags	No tags

Results

Key	Data
DCSdata	{}
QC_LAYER	L2
MIN_HEALTH_ANY_ERRORS	{'digitalscan': 0, 'analogscan': 0, 'thresholdscan_hr': 8, 'totscan': 0, 'all': 8}
MIN_HEALTH_THRESHOLD_MEAN	2204.99
MIN_HEALTH_THRESHOLD_SIGMA	305.15
MIN_HEALTH_NOISE_MEAN	101.63
MIN_HEALTH_NOISE_SIGMA	11.17
MIN_HEALTH_TOT_MEAN	10.43
MIN_HEALTH_TOT_SIGMA	2.0
MIN_HEALTH_COLUMN_DISABLED	0
MIN_HEALTH_DEAD_DIGITAL	0
MIN_HEALTH_BAD_DIGITAL	0
MIN_HEALTH_DEAD_ANALOG	3
MIN_HEALTH_BAD_ANALOG	0
MIN_HEALTH_THRESHOLD_FAILED_FITS	71
MIN_HEALTH_HIGH_ENC	0
MIN_HEALTH_BAD_ANALOG_INTEGRATED	3
MIN_HEALTH_THRESHOLD_FAILED_FITS_INDEPENDENT	74
MIN_HEALTH_HIGH_ENC_INDEPENDENT	0
ANALYSIS_VERSION	mqat v2.8.1
YARR_VERSION	v1.5.6
MEASUREMENT_DATE	2026-05-12T03:18:27.000+00:00
MEASUREMENT_DURATION	381
