Component Information

Serial Number 20UPGFC0141739
ProdDB ID  9d92c1…32a3e2
LocalDB ID 660d234feeb7490035a471b8
Component Type fe_chip
Parents 20UPGM24211149  20UPGB43200223 
Children No match.
Flags
Wafer
  Wafer Probing

 Properties

Item Value
Target Iref trim 11
Target Iref trim version 1
Wafer serial number None

 Comments

Scan Result: std_noisescan / run 997 (Stage: MODULE/QC_CROSSCHECK)
(ObjectId: 660d234feeb7490035a471b8)


Result Plots

Occupancy

TotMap

TagDist

NoiseOccupancy

NoiseMask

TotDist


Details

Scan

Key Data
runNumber 997
testType std_noisescan
stage MODULE/QC_CROSSCHECK
component 20UPGM24211149
20UPGFC0141739
20UPGFC0141610
20UPGFC0141718
20UPGFC0141704
startTime 2026-05-11 22:10:56
finishTime 2026-05-11 22:12:08
user pixqc
site jittereel.dhcp.lbl.gov
targetCharge -1
targetTot -1
FeDataProcessorLog 0x2292a: {'Any errors': 0, 'Chip tag bitflips': 0, 'Chip unrecognized tags': 0, 'Corrupt streams': 0, 'Split events count': 0, 'Unfinished streams (no EOS)': 0, 'Unfinished streams (w/ EOS)': 0}
0x22988: {'Any errors': 0, 'Chip tag bitflips': 0, 'Chip unrecognized tags': 0, 'Corrupt streams': 0, 'Split events count': 0, 'Unfinished streams (no EOS)': 0, 'Unfinished streams (w/ EOS)': 0}
0x22996: {'Any errors': 0, 'Chip tag bitflips': 0, 'Chip unrecognized tags': 0, 'Corrupt streams': 0, 'Split events count': 0, 'Unfinished streams (no EOS)': 0, 'Unfinished streams (w/ EOS)': 0}
0x229ab: {'Any errors': 0, 'Chip tag bitflips': 0, 'Chip unrecognized tags': 0, 'Corrupt streams': 0, 'Split events count': 0, 'Unfinished streams (no EOS)': 0, 'Unfinished streams (w/ EOS)': 0}
ctrlStatus channel_configuration: 16x1
fe_chip_type: RD53A/B/C
firmware_hash: 0x7b14549
firmware_identifier: 0x1030242
firmware_vers: v1.5.0
fmc_card_type: Ohio Card (Display Port)
fpga_card: Trenz TEF1001_R1
lpm_status: 0
rx_speed: 1280Mbps
exec -r /opt/local/pixqc/common_configs/specCfg-rd53b-16x1-setup2.json -c /opt/local/pixqc/20UPGM24211149/20UPGM24211149_L2_warm.json -o /opt/local/pixqc/20UPGM24211149/data -W PFA -s /opt/local/pixqc/qc_software/YARR/configs/scans/itkpixv2/std_noisescan.json
stopwatch analysis: 681
config: 1176
processing: 0
scan: 64001
yarr_version build_flags:
build_time: 2026-03-06 00:03:45 UTC
build_type:
git_branch: HEAD
git_date: 2026-03-02 18:18:35 +0000
git_hash: ceab17cbc44ec321798e7456f1368aa297f71f91
git_subject: Merge branch 'yarr_version_update' into 'master'
git_tag: v1.5.6
