Database for ITk Pixel Module

Serial Number	20UPGFC0134182
ProdDB ID	480325…ea5378
LocalDB ID	65d90f819960840042821a74
Component Type	fe_chip
Parents	20UPIM13602206 20UPGB43000019
Children	No match.
Flags

Item	Value
Wafer serial number	None

Key	Data
QC Passed	True
Date	a year ago
component ObjectId	65d90f819960840042821a74
Stage	MODULE/INITIAL_WARM
Test Type	VCAL_CALIBRATION
Institute ObjectId
User Name	None
ObjectId of this record	6705d076ecb4e51d971a0fd5
ObjectId of RAW record	6705d072ecb4e51d971a0fc6
Tags	No tags
