20UPGFC0223190

MODULE/POST_PARYLENE_COLD

Component Information

Serial Number	20UPGFC0223190
ProdDB ID	d05794…b32c91
LocalDB ID	67a21eb589d864a1f41149d7
Component Type	fe_chip
Parents	20UPGM24830014 20UPGB43000293
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Target Iref trim	10
Target Iref trim version	1
Wafer serial number	None

Comments

Test: TUNING QC Passed

(Stage: MODULE/POST_PARYLENE_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	2 months ago
component ObjectId	67a21eb589d864a1f41149d7
Stage	MODULE/POST_PARYLENE_WARM
Test Type	TUNING
Institute ObjectId
User Name	DanielAceves
ObjectId of this record	69bd961cf97f394ea371eabf
ObjectId of RAW record	None
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.8.1
MEASUREMENT_DATE	2026-03-20T17:36:56.000+00:00
MEASUREMENT_DURATION	693
YARR_VERSION	v1.5.6
TUNING_ANY_ERRORS	{'tune_globalthreshold': 0, 'thresholdscan_hr': 4, 'tune_pixelthreshold': 0, 'thresholdscan_hd': 1, 'totscan': 0, 'all': 5}
TUNING_TUNED_NOISE_95_HIGH	119.387
TUNING_TUNED_NOISE_95_LOW	79.062
TUNING_TUNED_NOISE_MEAN	98.777
TUNING_TUNED_NOISE_SIGMA	10.571
TUNING_TUNED_TDAC_MEAN	-1.2
TUNING_TUNED_TDAC_SIGMA	3.812
TUNING_TUNED_THRESHOLD_95_HIGH	1565.092
TUNING_TUNED_THRESHOLD_95_LOW	1434.589
TUNING_TUNED_THRESHOLD_FAILED_FITS	2
TUNING_TUNED_THRESHOLD_MEAN	1501.9
TUNING_TUNED_THRESHOLD_SIGMA	34
TUNING_TUNED_TOT_95_HIGH	10.07
TUNING_TUNED_TOT_95_LOW	5.38
TUNING_TUNED_TOT_MEAN	7.4
TUNING_TUNED_TOT_SIGMA	0.3
TUNING_UNTUNED_NOISE_95_HIGH	117.857
TUNING_UNTUNED_NOISE_95_LOW	78.763
TUNING_UNTUNED_NOISE_MEAN	97.907
TUNING_UNTUNED_NOISE_SIGMA	10.362
TUNING_UNTUNED_TDAC_MEAN	0
TUNING_UNTUNED_TDAC_SIGMA	0
TUNING_UNTUNED_THRESHOLD_95_HIGH	2819.582
TUNING_UNTUNED_THRESHOLD_95_LOW	1656.452
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	90
TUNING_UNTUNED_THRESHOLD_MEAN	2216.56
TUNING_UNTUNED_THRESHOLD_SIGMA	295.32

Attachments

Filename	Contents
0x367d6_L2_warm.json	Download
output.log	Download
0x367d6.log	Download
20UPGFC0223190_MODULE__POST_PARYLENE_WARM_TUNING.zip	Download
