20UPGFC0223192

MODULE/POST_PARYLENE_COLD

Component Information

Serial Number	20UPGFC0223192
ProdDB ID	4b2ed4…398f0c
LocalDB ID	67a21eb489d864a1f41149c5
Component Type	fe_chip
Parents	20UPGM24830014 20UPGB43000293
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Target Iref trim	9
Target Iref trim version	1
Wafer serial number	None

Comments

Test: ANALOG_READBACK QC Passed

(Stage: MODULE/POST_PARYLENE_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	2 months ago
component ObjectId	67a21eb489d864a1f41149c5
Stage	MODULE/POST_PARYLENE_WARM
Test Type	ANALOG_READBACK
Institute ObjectId
User Name	DanielAceves
ObjectId of this record	69bd7dc7f97f394ea371e823
ObjectId of RAW record	69bd7dc3f97f394ea371e800
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.8.1
MEASUREMENT_DATE	2026-03-20T16:30:01.000+00:00
MEASUREMENT_DURATION	237
MEASUREMENT_VERSION	2.8.0
YARR_VERSION	v1.5.6
AR_IREF_TRIM	9
AR_IREF	4.1e-06
AR_GADC	0.838
AR_NOMINAL_SETTINGS	[4.1e-06, 8.92e-05, 4.95e-05, 4.2e-06, 3.97e-05, 2.04e-05, 0, 3.91e-05, 7.19e-05, -999, 0, 0, 4.79e-05, 6.64e-05, 5.19e-05, 8.75e-05, 7.13e-05, 7.8e-05, 8.67e-05, 8.75e-05, 7.33e-05, 4.7e-05, 4.83e-05, 7.22e-05, 4.82e-05, 4.84e-05, -999, -999, 0.648442, 0.0525793, 0.9043857, 0.2608896, 0.8377301, -999, -999, 0.835525, 1.1857104, 0.123997, 0.1179486, 0.1764576, 0.0398403, 0.0392999, 0.183876, 0.1855221, 0.1863581, 0.6325486, -999, 0.628776, -999, 0.5910131, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, 0.0173446, 0.4600562, 2.0353283, 1.5236268, 1.1895492, 0.5843934, 0.9956684, 1.5274312, 1.192139, 0.5867507]
AR_ROSC_MAX_RESIDUAL	[2.901925159472482, 4.762692823410576, 2.6988567818469704, 4.667599125739818, 2.198930215734613, 3.7269272746548836, 2.3332446512123353, 4.032918765192729, 4.266329207349384, 4.413820267014474, 5.164272566967766, 5.243436474388129, 4.316099445476148, 4.292559550791792, 5.155842476459831, 5.2178418195921905, 3.765270380271167, 3.762856134587897, 4.252237600845968, 4.294286765618885, 3.6229005993507317, 3.46320325718152, 4.5717330298474055, 4.523111670308225, 2.7167293764127667, 2.715490242158643, 3.013276831913147, 3.0782838597573274, 3.1774700485947074, 5.608537309891409, 5.040155841910223, 5.83264927232563, 4.438949565392091, 4.87436637677644, 4.118341961638578, 4.121313385333005, 4.261238800030352, 4.128149501572697, 4.091929987862127, 4.220898862228137, 4.156323710295328, 4.056411101091222]
AR_ROSC_OFFSET	[-353.7151813108951, -557.218895451211, -371.133654750029, -572.7743960205568, -475.7962073172943, -823.5469296893523, -605.8907508305965, -874.8658190199178, -588.1579360016874, -574.8682275883697, -696.1752977324165, -692.1461028175987, -613.4817311429789, -625.0329521636047, -709.3070233103255, -702.7233464181714, -817.3153723725247, -832.9106747359702, -980.2884599829531, -975.672707508342, -843.133594420891, -855.353796707566, -1033.7960041999072, -1034.8716458063127, -472.97643469485394, -467.7320096530108, -582.9869074758847, -576.1458017899814, -560.4002552126851, -560.3758337534622, -432.6065993500884, -437.2898296156141, -509.76968979042823, -540.8908281900382, -944.4617378742507, -943.957206471657, -940.4575959028116, -938.6754093978034, -938.7190439736037, -935.1521685949547, -940.8684552380802, -940.6864114527481]
AR_ROSC_SLOPE	[666.8536980310593, 1041.4701386783554, 666.6207911417603, 1048.1710482526669, 744.8322398869401, 1283.9499507617295, 889.6838859005069, 1324.6033648439238, 1034.1495174795075, 1037.875386321862, 1231.2182050099339, 1235.796274788404, 1066.3135259047028, 1068.498989978231, 1244.386092550789, 1242.7259630547258, 1260.8755241425238, 1274.9651030587384, 1500.0140551948548, 1501.4107352465778, 1251.5495576812148, 1248.104671015407, 1553.339106148733, 1557.0644671398973, 766.8471650179079, 768.2254465728239, 931.1241649090473, 929.7442966790579, 919.3395874717079, 916.7519220077404, 1007.3129484288195, 1073.74906287868, 1011.6074218682955, 1084.1672125780399, 1438.8404706011863, 1443.4760961297302, 1443.8898721848504, 1444.6717433606957, 1440.1943207575976, 1441.7179690971373, 1444.0744499214945, 1443.079534339808]
AR_TEMP_ACB	28.093
AR_TEMP_ASLDO	29.362
AR_TEMP_DSLDO	30.486
AR_TEMP_EXT	19.97
AR_TEMP_NF_ACB	1.253
AR_TEMP_NF_ASLDO	1.255
AR_TEMP_NF_BOTTOM	-999
AR_TEMP_NF_DSLDO	1.254
AR_TEMP_NF_TOP	-999
AR_TEMP_NTC	21.953
AR_TEMP_POLY_BOTTOM	-999
AR_TEMP_POLY_TOP	-999
AR_VCALDAC	0.836
AR_VDDA_SATURATION	-1
AR_VDDA_TRIM	6
AR_VDDA_VS_TRIM	[1.042, 1.068, 1.092, 1.117, 1.139, 1.165, 1.188, 1.214, 1.243, 1.268, 1.292, 1.317, 1.339, 1.364, 1.389, 1.415]
AR_VDDD_SATURATION	14
AR_VDDD_TRIM	4
AR_VDDD_VS_TRIM	[1.092, 1.117, 1.145, 1.168, 1.192, 1.217, 1.245, 1.27, 1.296, 1.322, 1.35, 1.375, 1.399, 1.424, 1.433, 1.434]
AR_VREFCORE	0.46
AR_VREFOVP	2.035

Attachments

Filename	Contents
output.log	Download
0x367d8.log	Download

RAW Results Record

Download RAW

_id

69bd7dc3f97f394ea371e800

raw

serialNumber

testType

runNumber

results

subtestType

stage

component

dbVersion

address

sys

20UPGFC0223192

ANALOG_READBACK

69bd7da0844bb5a1929d9dcb

DCSdata

SensorVoltage	-120.0
SensorCurrent	8.3e-08
ModuleNTC	19.97

Measurements

Vmux0

X	False
Unit	V
Values	0.8550747

Vmux3

X	False
Unit	V
Values	0.4351071

Vmux4

X	False
Unit	V
Values	0.6101998

Vmux5

X	False
Unit	V
Values	0.1413416

Vmux6

X	False
Unit	V
Values	0.1352932

Vmux7

X	False
Unit	V
Values	0.1938022

Vmux8

X	False
Unit	V
Values	0.05718491

Vmux9

X	False
Unit	V
Values	0.05664449

Vmux10

X	False
Unit	V
Values	0.2012206

Vmux11

X	False
Unit	V
Values	0.2028667

Vmux12

X	False
Unit	V
Values	0.2037027

Vmux13

X	False
Unit	V
Values	0.6498932

Vmux15

X	False
Unit	V
Values	0.6461206

Vmux17

X	False
Unit	V
Values	0.6083577

Vmux31

X	False
Unit	V
Values	0.4774008

Vmux32

X	False
Unit	V
Values	0.6285543

Vmux33

X	False
Unit	V
Values	0.3982513

Vmux34

X	False
Unit	V
Values	0.6121192

Vmux35

X	False
Unit	V
Values	0.601738

Vmux36

X	False
Unit	V
Values	0.2662617

Vmux37

X	False
Unit	V
Values	0.3992024

Vmux38

X	False
Unit	V
Values	0.6134141

Vmux39

X	False
Unit	V
Values	0.6040953

Vmux63

X	False
Unit	V
Values	0.08555711

Vmux30

X	False
Unit	V
Values	0.0173446

Imux0

X	False
Unit	V
Values	0.05590815

Imux1

X	False
Unit	V
Values	0.9065004

Imux2

X	False
Unit	V
Values	0.5101214

Imux3

X	False
Unit	V
Values	0.05682639

Imux4

X	False
Unit	V
Values	0.4115118

Imux5

X	False
Unit	V
Values	0.2192724

Imux6

X	False
Unit	V
Values	0.01489895

Imux7

X	False
Unit	V
Values	0.405893

Imux8

X	False
Unit	V
Values	0.7341103

Imux10

X	False
Unit	V
Values	0.01490127

Imux11

X	False
Unit	V
Values	0.01490097

Imux12

X	False
Unit	V
Values	0.4942261

Imux13

X	False
Unit	V
Values	0.6793584

Imux14

X	False
Unit	V
Values	0.5336769

Imux15

X	False
Unit	V
Values	0.8903214

Imux16

X	False
Unit	V
Values	0.728187

Imux17

X	False
Unit	V
Values	0.7946572

Imux18

X	False
Unit	V
Values	0.8817407

Imux19

X	False
Unit	V
Values	0.4798204

Imux20

X	False
Unit	V
Values	0.7478644

Imux21

X	False
Unit	V
Values	0.4849643

Imux22

X	False
Unit	V
Values	0.4981337

Imux23

X	False
Unit	V
Values	0.7368777

Imux24

X	False
Unit	V
Values	0.4964304

Imux25

X	False
Unit	V
Values	0.4990172

Imux28

X	False
Unit	V
Values	0.324028

Imux29

X	False
Unit	V
Values	0.03925554

Imux30

X	False
Unit	V
Values	0.4399301

Imux31

X	False
Unit	V
Values	0.1340944

Imux63

X	False
Unit	V
Values	0.01488507

Metadata

FirmwareVersion

FirmwareIdentifier

ChannelConfig

SoftwareVersion

ChipConfigs

ITKPIXV2

GlobalConfig

AiRegionRow	0
AuroraActiveLanes	1
AuroraAltOutput0	0
AuroraAltOutput1	0
AuroraCBSend	0
AuroraCBWait0	4095
AuroraCBWait1	0
AuroraCCSend	3
AuroraCCWait	25
AuroraEnPrbs	0
AuroraInitWait	32
AuroraSendAlt	0
AutoRead0	134
AutoRead1	135
AutoRead2	137
AutoRead3	138
AutoRead4	140
AutoRead5	151
AutoRead6	152
AutoRead7	156
BcidCnt	0
BitFlipErrCnt	0
BitFlipWngCnt	0
CapMeasEn	0
CapMeasEnPar	0
CdrClkSel	0
CdrCp	40
CdrCpBuff	200
CdrCpFd	400
CdrPhaseDetSel	0
CdrVco	1023
CdrVcoBuff	500
ChSyncLockThr	31
ChipIdSense	0
Clk160En	7
Clk40En	7
ClkAuroraEn	7
ClkDataMergeEn	7
CmdErrCnt	0
CmlBias0	800
CmlBias1	400
CmlBias2	0
DataDecodingValues	0
DataEnBcid	0
DataEnBinaryRo	0
DataEnCrc	0
DataEnL1id	0
DataEnRaw	0
DataMaxHits	0
DataMaxTot	0
DataMergeEn	0
DataMergeEnBond	0
DataMergeEnClkGate	0
DataMergeFixedMode	0
DataMergeGpoSel	0
DataMergeInMux0	0
DataMergeInMux1	1
DataMergeInMux2	2
DataMergeInMux3	3
DataMergeInPol	0
DataMergeManChoice	0
DataMergeManMode	0
DataMergeOutMux0	0
DataMergeOutMux1	1
DataMergeOutMux2	2
DataMergeOutMux3	3
DataMergeSelClk	0
DataReadDelay	0
DiffComp	500
DiffFbCapEn	0
DiffLcc	200
DiffLccEn	1
DiffPreComp	350
DiffPreampL	550
DiffPreampM	550
DiffPreampR	550
DiffPreampT	550
DiffPreampTL	550
DiffPreampTR	550
DiffTh1L	261
DiffTh1M	261
DiffTh1R	261
DiffTh2	50
DiffVff	88
EfuseConfig	3855
EfuseReadData0	55320
EfuseReadData1	9063
EfuseWriteData0	0
EfuseWriteData1	0
EnChipId	0
EnCoreCol0	65535
EnCoreCol1	65535
EnCoreCol2	65535
EnCoreCol3	63
EnCoreColCal0	0
EnCoreColCal1	0
EnCoreColCal2	0
EnCoreColCal3	0
EnHitsRemoval0	0
EnHitsRemoval1	0
EnHitsRemoval2	0
EnHitsRemoval3	0
EnIsoHitsRemoval0	0
EnIsoHitsRemoval1	0
EnIsoHitsRemoval2	0
EnIsoHitsRemoval3	0
ErrWngMask	0
EvenMask	0
FineDelayClk	0
FineDelayData	0
GatedHitOrCnt0	0
GatedHitOrCnt1	0
GcrDefaultConfig	44149
GcrDefaultConfigB	21386
GlobalConfigSeuCnt	0
GlobalPulseConf	0
GlobalPulseWidth	10
GpCmosDs	0
GpCmosEn	1
GpCmosRoute	34
GpLvdsBias	7
GpLvdsEn	15
GpLvdsPad0	0
GpLvdsPad1	1
GpLvdsPad2	33
GpLvdsPad3	35
GpValReg	5
HitOrCnt0	0
HitOrCnt1	0
HitOrCnt2	0
HitOrCnt3	0
HitOrMask0	0
HitOrMask1	0
HitOrMask2	0
HitOrMask3	0
InjAnaMode	0
InjDigEn	0
InjFineDelay	5
InjVcalHigh	864
InjVcalMed	200
InjVcalRange	1
IrefTrimSense	0
Latency	500
LinComp	110
LinCompTa	110
LinFc	20
LinGdacL	408
LinGdacM	408
LinGdacR	408
LinKrumCurr	50
LinLdac	100
LinPreampL	300
LinPreampM	300
LinPreampR	300
LinPreampT	300
LinPreampTL	300
LinPreampTR	300
LinRefKrum	300
LockLossCnt	0
MonAdcTrim	0
MonSensAcbDem	0
MonSensAcbEn	0
MonSensAcbSelBias	0
MonSensSldoAnaDem	0
MonSensSldoAnaEn	0
MonSensSldoAnaSelBias	0
MonSensSldoDigDem	0
MonSensSldoDigEn	0
MonSensSldoDigSelBias	0
MonitorEnable	1
MonitorI	63
MonitorV	32
MonitoringDataAdc	0
NtcDac	100
NumOfEventsInStream	0
OddMask	0
PixAutoRow	1
PixBroadcast	0
PixConfMode	1
PixDefaultConfig	40162
PixDefaultConfigB	25373
PixEnSeuCount	0
PixHitSampleMode	0
PixPortal	36189
PixRegionCol	199
PixRegionRow	0
PixelSeuCntCnt	0
PtotCoreColEn0	0
PtotCoreColEn1	0
PtotCoreColEn2	0
PtotCoreColEn3	0
RdWrFifoErrCnt	0
ReadTrigCnt	0
ReadTrigLatency	0
RingOscAClear	0
RingOscAEn	0
RingOscAOut	0
RingOscARoute	0
RingOscBClear	0
RingOscBEnBl	0
RingOscBEnBr	0
RingOscBEnCapA	0
RingOscBEnFf	0
RingOscBEnLvt	0
RingOscBOut	0
RingOscBRoute	0
RstCoreCol0	0
RstCoreCol1	0
RstCoreCol2	0
RstCoreCol3	0
SelfTrigDeadtime	64
SelfTrigDelay	512
SelfTrigDigThr	1
SelfTrigDigThrEn	0
SelfTrigEn	0
SelfTrigMulti	4
SelfTrigPattern	65534
SerEnLane	15
SerEnTap	1
SerInvTap	1
SerSelOut0	1
SerSelOut1	3
SerSelOut2	3
SerSelOut3	3
ServiceBlockEn	1
ServiceBlockPeriod	50
SkippedTrigCnt	0
SldoEnUndershuntA	0
SldoEnUndershuntD	0
SldoTrimA	6
SldoTrimD	4
TotEn6b4b	0
TotEn80	0
TotEnPtoa	0
TotEnPtot	0
TotPtotLatency	500
TrigCnt	0
TruncTimeoutConf	0
TwoLevelTrig	0
VrefIn	1
VrefRsensBot	0
VrefRsensTop	0

Parameter

ADCcalPar	8.0 0.192 10000.0
ChipId	15
EnforceNameIdCheck	True
InjCap	7.24
IrefTrim	9
KSenseInA	20975.477
KSenseInD	21277.408
KSenseShuntA	21575.0
KSenseShuntD	21885.0
KShuntA	997.444
KShuntD	959.164
Name	0x367d8
NfACB	1.253255
NfASLDO	1.2549406
NfDSLDO	1.2538121
NtcCalPar	0.0007489 0.0002769 7.0595e-08
VcalPar	-2.0 0.2

SoftwareType

ChipID

Name

0x367d8

Institution

ANL_PIXEL_MODULES

ModuleSN

20UPGM24830014

TimeStart

1774024201

TimeEnd

1774024438

useCalibAdc

False

comment

property

YARR_VERSION	v1.5.6
ANALOG_READBACK_MEASUREMENT_VERSION	2.8.0

AR_VMEAS

MODULE/POST_PARYLENE_WARM

67a21eb489d864a1f41149c5

1.01

64657cef8d79bac1f3f00578

mts	2026-03-20 17:02:59.185000
cts	2026-03-20 17:02:59.185000
rev	0

20UPGFC0223192

ANALOG_READBACK

69bd7da0844bb5a1929d9dcc

DCSdata

SensorVoltage	-120.0
SensorCurrent	8.3e-08
ModuleNTC	20.03

Measurements

Vmux2

X	False
Unit	V
Values	0.1385913 0.1385913 0.1385913 0.1385913 0.1385913 0.1385913 0.1385913 0.1385913 0.1385913 0.1385913 0.1385913 0.1385913 0.1385913 0.1385913 0.1385913 0.1385913 0.1385913 0.1385913 0.1385913 0.1385913 0.1385913 0.1385913 0.1385913 0.1385913 0.1385913 0.1385913 0.1385913 0.1385913 0.1385913 0.1385913 0.1385913 0.1385913

Vmux30

X	False
Unit	V
Values	0.01735127 0.01735127 0.01735127 0.01735127 0.01735127 0.01735127 0.01735127 0.01735127 0.01735127 0.01735127 0.01735127 0.01735127 0.01735127 0.01735127 0.01735127 0.01735127 0.01735127 0.01735127 0.01735127 0.01735127 0.01735127 0.01735127 0.01735127 0.01735127 0.01735127 0.01735127 0.01735127 0.01735127 0.01735127 0.01735127 0.01735127 0.01735127

Imux9

X	False
Unit	V
Values	0.1228467 0.1228467 0.1228467 0.1228467 0.1228467 0.1228467 0.1228467 0.1228467 0.1228467 0.1228467 0.1228467 0.1228467 0.1228467 0.1228467 0.1228467 0.1228467 0.1228467 0.1228467 0.1228467 0.1228467 0.1228467 0.1228467 0.1228467 0.1228467 0.1228467 0.1228467 0.1228467 0.1228467 0.1228467 0.1228467 0.1228467 0.1228467

Imux63

X	False
Unit	V
Values	0.01489011 0.01489011 0.01489011 0.01489011 0.01489011 0.01489011 0.01489011 0.01489011 0.01489011 0.01489011 0.01489011 0.01489011 0.01489011 0.01489011 0.01489011 0.01489011 0.01489011 0.01489011 0.01489011 0.01489011 0.01489011 0.01489011 0.01489011 0.01489011 0.01489011 0.01489011 0.01489011 0.01489011 0.01489011 0.01489011 0.01489011 0.01489011

Vmux14

X	False
Unit	V
Values	0.2267168 0.2275721 0.2271077 0.2265199 0.227066 0.2280182 0.2289397 0.2290654 0.2274807 0.2265041 0.2278644 0.2283572 0.2279217 0.2274908 0.2279269 0.2288296 0.3163716 0.3163134 0.31636 0.3163848 0.3163351 0.3162968 0.3162426 0.3162145 0.3163304 0.3164153 0.3163076 0.3163 0.3162997 0.3163302 0.3162876 0.3162238

Vmux16

X	False
Unit	V
Values	0.2256682 0.2251488 0.2236593 0.225797 0.2244849 0.2242346 0.2246815 0.2252632 0.2259043 0.2242084 0.2246047 0.2244076 0.2237255 0.223318 0.2244167 0.2242981 0.3133857 0.3134243 0.3135354 0.3133893 0.3134998 0.3135112 0.3134731 0.3134041 0.313346 0.3135045 0.313475 0.3134856 0.3135219 0.3135407 0.3134766 0.313466

Vmux18

X	False
Unit	V
Values	0.233775 0.2318524 0.2315978 0.2326683 0.2327432 0.2343266 0.232357 0.2321963 0.2334584 0.233243 0.2322789 0.2309482 0.2319392 0.2325594 0.233212 0.2332902 0.3206967 0.3208317 0.320846 0.3207873 0.3207714 0.3206677 0.3208212 0.3208347 0.3207355 0.3207229 0.3207795 0.3208313 0.320753 0.3207515 0.3207132 0.3206898

MonSensSldoAnaSelBias

X	False
Unit	-
Values	0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

MonSensSldoDigSelBias

X	False
Unit	-
Values	0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

MonSensAcbSelBias

X	False
Unit	-
Values	0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

MonSensSldoAnaDem

X	False
Unit	-
Values	0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

MonSensSldoDigDem

X	False
Unit	-
Values	0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

MonSensAcbDem

X	False
Unit	-
Values	0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

TExtExtNTC

X	False
Unit	C
Values	19.97 19.97 19.97 19.97 19.97 19.97 19.97 19.97 19.97 19.97 19.97 19.97 19.97 19.97 19.97 19.97 19.97 19.97 19.97 19.97 19.97 19.97 19.97 19.97 19.97 19.97 19.97 19.97 19.97 19.97 19.97 19.97

Metadata

FirmwareVersion

FirmwareIdentifier

ChannelConfig

SoftwareVersion

ChipConfigs

ITKPIXV2

GlobalConfig

AiRegionRow	0
AuroraActiveLanes	1
AuroraAltOutput0	0
AuroraAltOutput1	0
AuroraCBSend	0
AuroraCBWait0	4095
AuroraCBWait1	0
AuroraCCSend	3
AuroraCCWait	25
AuroraEnPrbs	0
AuroraInitWait	32
AuroraSendAlt	0
AutoRead0	134
AutoRead1	135
AutoRead2	137
AutoRead3	138
AutoRead4	140
AutoRead5	151
AutoRead6	152
AutoRead7	156
BcidCnt	0
BitFlipErrCnt	0
BitFlipWngCnt	0
CapMeasEn	0
CapMeasEnPar	0
CdrClkSel	0
CdrCp	40
CdrCpBuff	200
CdrCpFd	400
CdrPhaseDetSel	0
CdrVco	1023
CdrVcoBuff	500
ChSyncLockThr	31
ChipIdSense	0
Clk160En	7
Clk40En	7
ClkAuroraEn	7
ClkDataMergeEn	7
CmdErrCnt	0
CmlBias0	800
CmlBias1	400
CmlBias2	0
DataDecodingValues	0
DataEnBcid	0
DataEnBinaryRo	0
DataEnCrc	0
DataEnL1id	0
DataEnRaw	0
DataMaxHits	0
DataMaxTot	0
DataMergeEn	0
DataMergeEnBond	0
DataMergeEnClkGate	0
DataMergeFixedMode	0
DataMergeGpoSel	0
DataMergeInMux0	0
DataMergeInMux1	1
DataMergeInMux2	2
DataMergeInMux3	3
DataMergeInPol	0
DataMergeManChoice	0
DataMergeManMode	0
DataMergeOutMux0	0
DataMergeOutMux1	1
DataMergeOutMux2	2
DataMergeOutMux3	3
DataMergeSelClk	0
DataReadDelay	0
DiffComp	500
DiffFbCapEn	0
DiffLcc	200
DiffLccEn	1
DiffPreComp	350
DiffPreampL	550
DiffPreampM	550
DiffPreampR	550
DiffPreampT	550
DiffPreampTL	550
DiffPreampTR	550
DiffTh1L	261
DiffTh1M	261
DiffTh1R	261
DiffTh2	50
DiffVff	88
EfuseConfig	3855
EfuseReadData0	55320
EfuseReadData1	9063
EfuseWriteData0	0
EfuseWriteData1	0
EnChipId	0
EnCoreCol0	65535
EnCoreCol1	65535
EnCoreCol2	65535
EnCoreCol3	63
EnCoreColCal0	0
EnCoreColCal1	0
EnCoreColCal2	0
EnCoreColCal3	0
EnHitsRemoval0	0
EnHitsRemoval1	0
EnHitsRemoval2	0
EnHitsRemoval3	0
EnIsoHitsRemoval0	0
EnIsoHitsRemoval1	0
EnIsoHitsRemoval2	0
EnIsoHitsRemoval3	0
ErrWngMask	0
EvenMask	0
FineDelayClk	0
FineDelayData	0
GatedHitOrCnt0	0
GatedHitOrCnt1	0
GcrDefaultConfig	44149
GcrDefaultConfigB	21386
GlobalConfigSeuCnt	0
GlobalPulseConf	0
GlobalPulseWidth	10
GpCmosDs	0
GpCmosEn	1
GpCmosRoute	34
GpLvdsBias	7
GpLvdsEn	15
GpLvdsPad0	0
GpLvdsPad1	1
GpLvdsPad2	33
GpLvdsPad3	35
GpValReg	5
HitOrCnt0	0
HitOrCnt1	0
HitOrCnt2	0
HitOrCnt3	0
HitOrMask0	0
HitOrMask1	0
HitOrMask2	0
HitOrMask3	0
InjAnaMode	0
InjDigEn	0
InjFineDelay	5
InjVcalHigh	864
InjVcalMed	200
InjVcalRange	1
IrefTrimSense	0
Latency	500
LinComp	110
LinCompTa	110
LinFc	20
LinGdacL	408
LinGdacM	408
LinGdacR	408
LinKrumCurr	50
LinLdac	100
LinPreampL	300
LinPreampM	300
LinPreampR	300
LinPreampT	300
LinPreampTL	300
LinPreampTR	300
LinRefKrum	300
LockLossCnt	0
MonAdcTrim	0
MonSensAcbDem	0
MonSensAcbEn	0
MonSensAcbSelBias	0
MonSensSldoAnaDem	0
MonSensSldoAnaEn	0
MonSensSldoAnaSelBias	0
MonSensSldoDigDem	0
MonSensSldoDigEn	0
MonSensSldoDigSelBias	0
MonitorEnable	1
MonitorI	63
MonitorV	32
MonitoringDataAdc	0
NtcDac	100
NumOfEventsInStream	0
OddMask	0
PixAutoRow	1
PixBroadcast	0
PixConfMode	1
PixDefaultConfig	40162
PixDefaultConfigB	25373
PixEnSeuCount	0
PixHitSampleMode	0
PixPortal	36189
PixRegionCol	199
PixRegionRow	0
PixelSeuCntCnt	0
PtotCoreColEn0	0
PtotCoreColEn1	0
PtotCoreColEn2	0
PtotCoreColEn3	0
RdWrFifoErrCnt	0
ReadTrigCnt	0
ReadTrigLatency	0
RingOscAClear	0
RingOscAEn	0
RingOscAOut	0
RingOscARoute	0
RingOscBClear	0
RingOscBEnBl	0
RingOscBEnBr	0
RingOscBEnCapA	0
RingOscBEnFf	0
RingOscBEnLvt	0
RingOscBOut	0
RingOscBRoute	0
RstCoreCol0	0
RstCoreCol1	0
RstCoreCol2	0
RstCoreCol3	0
SelfTrigDeadtime	64
SelfTrigDelay	512
SelfTrigDigThr	1
SelfTrigDigThrEn	0
SelfTrigEn	0
SelfTrigMulti	4
SelfTrigPattern	65534
SerEnLane	15
SerEnTap	1
SerInvTap	1
SerSelOut0	1
SerSelOut1	3
SerSelOut2	3
SerSelOut3	3
ServiceBlockEn	1
ServiceBlockPeriod	50
SkippedTrigCnt	0
SldoEnUndershuntA	0
SldoEnUndershuntD	0
SldoTrimA	6
SldoTrimD	4
TotEn6b4b	0
TotEn80	0
TotEnPtoa	0
TotEnPtot	0
TotPtotLatency	500
TrigCnt	0
TruncTimeoutConf	0
TwoLevelTrig	0
VrefIn	1
VrefRsensBot	0
VrefRsensTop	0

Parameter

ADCcalPar	8.0 0.192 10000.0
ChipId	15
EnforceNameIdCheck	True
InjCap	7.24
IrefTrim	9
KSenseInA	20975.477
KSenseInD	21277.408
KSenseShuntA	21575.0
KSenseShuntD	21885.0
KShuntA	997.444
KShuntD	959.164
Name	0x367d8
NfACB	1.253255
NfASLDO	1.2549406
NfDSLDO	1.2538121
NtcCalPar	0.0007489 0.0002769 7.0595e-08
VcalPar	-2.0 0.2

SoftwareType

ChipID

Name

0x367d8

Institution

ANL_PIXEL_MODULES

ModuleSN

20UPGM24830014

TimeStart

1774025707

TimeEnd

1774026145

useCalibAdc

False

comment

property

YARR_VERSION	v1.5.6
ANALOG_READBACK_MEASUREMENT_VERSION	2.8.0

AR_TEMP

MODULE/POST_PARYLENE_WARM

67a21eb489d864a1f41149c5

1.01

64657cef8d79bac1f3f00578

mts	2026-03-20 17:02:59.185000
cts	2026-03-20 17:02:59.185000
rev	0

20UPGFC0223192

ANALOG_READBACK

69bd7da0844bb5a1929d9dcd

DCSdata

SensorVoltage	-120.0
SensorCurrent	8.3e-08
ModuleNTC	20.0

Measurements

Vmux34

X	False
Unit	V
Values	0.5381428 0.5513224 0.5633053 0.5757717 0.5869057 0.5996545 0.6115476 0.6241007 0.6387535 0.6513637 0.6631148 0.6755962 0.6870811 0.699495 0.7117515 0.7246778

Vmux38

X	False
Unit	V
Values	0.5631509 0.5757068 0.589718 0.6014867 0.6131874 0.6259197 0.6399471 0.6521971 0.6654727 0.6780966 0.6923225 0.7046995 0.716852 0.7294439 0.7338903 0.7343415

Vmux30

X	False
Unit	V
Values	0.01734522 0.01734522 0.01734522 0.01734522 0.01734522 0.01734522 0.01734522 0.01734522 0.01734522 0.01734522 0.01734522 0.01734522 0.01734522 0.01734522 0.01734522 0.01734522

Vmux33

X	False
Unit	V
Values	0.39826 0.3981783 0.3982359 0.3982212 0.398166 0.3980903 0.3980771 0.3980536 0.3980411 0.3979857 0.3978792 0.3977387 0.3975268 0.3972099 0.3966536 0.3957792

Vmux37

X	False
Unit	V
Values	0.3990915 0.3990894 0.3990889 0.3990497 0.3991714 0.3991792 0.3990716 0.3989714 0.3987028 0.3983369 0.3975698 0.3967589 0.395532 0.3940129 0.3934116 0.3931813

Imux63

X	False
Unit	V
Values	0.01488913 0.01488913 0.01488913 0.01488913 0.01488913 0.01488913 0.01488913 0.01488913 0.01488913 0.01488913 0.01488913 0.01488913 0.01488913 0.01488913 0.01488913 0.01488913

Imux28

X	False
Unit	V
Values	0.3228848 0.3231447 0.3234142 0.3235785 0.323692 0.3239055 0.3240253 0.3241159 0.3242343 0.3242639 0.3242497 0.3240589 0.3237654 0.3231998 0.3222191 0.3203995

Imux29

X	False
Unit	V
Values	0.05611033 0.05230588 0.0492309 0.04635881 0.04382886 0.04138155 0.03933013 0.03714734 0.03511888 0.03396203 0.03337628 0.03406791 0.03606814 0.04172299 0.05124662 0.069636

Imux30

X	False
Unit	V
Values	0.4389493 0.4394773 0.4397506 0.43986 0.4400995 0.4401399 0.4400159 0.4396999 0.4388036 0.4376123 0.435078 0.4316688 0.4271586 0.4209883 0.4186052 0.4180251

Imux31

X	False
Unit	V
Values	0.1610056 0.1543081 0.1468375 0.1401223 0.1344687 0.1279889 0.1214035 0.1169377 0.1139858 0.1138823 0.1186708 0.129247 0.1456273 0.1702624 0.1801528 0.1819429

SldoTrimA

X	False
Unit	-
Values	0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

SldoTrimD

X	False
Unit	-
Values	0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

ROSC0

X	False
Unit	MHz
Values	369.2 387.8 408.4 425.4 442.467 460.2 479.933 496.6 513.933 530.733 548.6 564.4 578.8 593.333 597.8 598.667

ROSC1

X	False
Unit	MHz
Values	571.4 600.8 633.067 659.4 686.067 714.333 744.6 771.133 798.2 824.267 852.133 877.267 899.133 921.467 928.667 929.6

ROSC2

X	False
Unit	MHz
Values	351.867 370.667 390.667 407.667 424.333 442.533 461.8 478.667 496.067 512.733 530.733 546.733 561.267 575.667 580.067 581.333

ROSC3

X	False
Unit	MHz
Values	563.333 592.733 625.067 651.867 678.533 706.867 737.4 764.0 791.133 817.4 845.533 870.733 893.0 915.6 922.667 924.0

ROSC4

X	False
Unit	MHz
Values	334.133 353.733 375.933 394.067 412.267 432.4 453.4 472.8 492.2 510.8 531.8 550.0 566.4 582.6 588.0 589.267

ROSC5

X	False
Unit	MHz
Values	572.533 606.6 644.467 676.0 707.6 741.6 778.733 811.333 845.0 877.667 912.8 944.4 973.0 1001.27 1010.67 1012.07

ROSC6

X	False
Unit	MHz
Values	362.0 385.533 411.4 433.067 454.8 478.467 504.133 526.533 550.0 572.533 597.267 619.267 639.0 658.667 665.333 666.533

ROSC7

X	False
Unit	MHz
Values	565.267 600.467 639.4 672.0 704.6 740.0 778.467 812.133 846.667 880.667 916.533 949.2 978.333 1007.53 1017.27 1018.6

ROSC8

X	False
Unit	MHz
Values	533.533 562.133 593.067 620.667 646.733 673.933 703.467 730.2 757.267 783.133 811.2 835.933 857.933 880.6 887.667 889.133

ROSC9

X	False
Unit	MHz
Values	550.733 579.533 610.467 638.267 664.333 691.933 721.4 748.4 775.733 801.533 829.667 854.533 876.4 899.0 906.2 907.4

ROSC10

X	False
Unit	MHz
Values	639.267 673.267 710.2 743.0 773.533 806.667 841.667 873.4 905.667 936.6 969.8 999.8 1025.73 1052.2 1060.93 1062.13

ROSC11

X	False
Unit	MHz
Values	648.2 682.133 719.6 752.467 783.067 816.2 851.4 883.467 915.733 946.6 980.267 1010.0 1036.27 1062.8 1071.2 1072.67

ROSC12

X	False
Unit	MHz
Values	543.4 572.667 604.6 633.133 659.467 687.8 717.867 745.6 773.733 800.267 829.4 855.333 878.0 901.2 908.2 909.4

ROSC13

X	False
Unit	MHz
Values	534.333 563.8 595.4 623.733 650.467 678.867 709.267 737.2 764.8 791.467 820.933 846.8 869.267 892.467 900.0 901.2

ROSC14

X	False
Unit	MHz
Values	640.4 674.933 712.2 745.4 776.067 809.4 844.933 877.0 909.6 940.467 975.0 1004.67 1030.93 1057.8 1066.53 1068.07

ROSC15

X	False
Unit	MHz
Values	645.2 679.533 716.867 749.867 780.6 814.133 849.467 881.667 914.133 945.133 979.133 1008.87 1035.4 1062.07 1070.67 1072.0

ROSC16

X	False
Unit	MHz
Values	553.933 586.8 623.333 656.067 686.6 720.067 755.6 788.2 821.333 853.067 888.467 919.267 946.6 974.733 983.8 985.067

ROSC17

X	False
Unit	MHz
Values	553.6 587.133 624.0 656.6 687.6 721.8 757.933 790.467 823.867 856.133 891.533 923.2 950.8 979.267 988.333 989.667

ROSC18

X	False
Unit	MHz
Values	651.2 690.6 733.8 772.333 808.867 848.333 890.867 929.667 968.733 1006.8 1048.53 1085.47 1118.2 1152.2 1162.67 1164.13

ROSC19

X	False
Unit	MHz
Values	657.333 696.867 739.867 778.667 815.2 854.533 897.133 935.933 975.2 1013.33 1055.2 1092.2 1124.93 1158.6 1169.13 1170.73

ROSC20

X	False
Unit	MHz
Values	517.933 550.867 587.0 619.467 649.933 682.667 717.667 750.2 783.2 815.0 849.867 880.667 907.733 935.8 944.733 946.133

ROSC21

X	False
Unit	MHz
Values	502.6 535.0 570.733 602.8 633.2 666.067 701.533 733.4 766.533 797.867 833.067 863.533 890.733 918.667 927.8 929.267

ROSC22

X	False
Unit	MHz
Values	655.733 696.067 741.0 781.2 819.0 859.933 904.0 944.0 985.067 1024.13 1067.6 1105.13 1139.53 1174.0 1185.2 1186.67

ROSC23

X	False
Unit	MHz
Values	658.6 699.4 744.267 784.6 822.133 863.533 907.6 947.267 988.667 1028.0 1071.67 1109.13 1143.73 1178.2 1189.27 1191.27

ROSC24

X	False
Unit	MHz
Values	359.933 380.667 402.933 423.2 442.067 462.4 484.467 503.933 524.067 543.6 564.4 583.067 599.867 616.533 621.867 622.733

ROSC25

X	False
Unit	MHz
Values	366.667 387.267 409.867 430.267 449.0 469.467 491.267 510.667 531.0 550.533 571.933 590.267 606.867 623.733 629.2 629.867

ROSC26

X	False
Unit	MHz
Values	429.133 453.533 480.8 505.2 528.0 552.6 578.8 602.867 627.267 650.733 676.867 699.6 719.467 740.067 746.667 748.0

ROSC27

X	False
Unit	MHz
Values	435.067 459.6 487.0 506.467 533.667 558.267 584.4 607.933 632.667 655.6 681.8 704.4 724.467 745.067 751.667 752.733

ROSC28

X	False
Unit	MHz
Values	438.533 462.867 489.8 514.133 536.267 560.8 587.133 610.867 634.933 658.133 683.533 705.667 725.533 746.0 752.133 753.333

ROSC29

X	False
Unit	MHz
Values	435.133 460.133 487.267 511.733 534.267 558.733 585.2 608.867 633.2 656.533 659.667 704.467 724.333 744.733 750.8 752.0

ROSC30

X	False
Unit	MHz
Values	658.133 687.0 717.733 745.0 770.533 797.533 826.8 852.467 878.8 903.733 931.4 954.867 975.8 997.067 1004.0 1005.0

ROSC31

X	False
Unit	MHz
Values	724.533 755.467 788.8 818.067 845.4 874.8 905.467 933.133 961.267 987.667 1016.87 1041.53 1064.0 1086.4 1093.33 1094.67

ROSC32

X	False
Unit	MHz
Values	587.4 615.333 645.4 672.867 697.733 724.933 753.533 780.133 806.733 831.8 859.933 883.867 904.8 926.867 933.333 934.533

ROSC33

X	False
Unit	MHz
Values	634.6 664.733 697.133 726.4 753.333 782.8 813.533 841.733 870.267 896.867 926.6 952.6 975.267 998.6 1005.73 1006.93

ROSC34

X	False
Unit	MHz
Values	620.733 658.067 699.533 736.933 771.6 809.733 850.2 887.267 925.2 961.8 1001.73 1037.33 1068.4 1100.93 1110.87 1112.6

ROSC35

X	False
Unit	MHz
Values	626.067 663.933 705.267 742.733 778.2 815.6 856.333 893.933 931.8 968.2 1008.53 1044.0 1075.4 1108.2 1118.0 1119.73

ROSC36

X	False
Unit	MHz
Values	629.867 667.533 709.267 746.933 781.8 819.933 860.8 898.0 935.733 972.467 1012.8 1048.13 1079.6 1111.93 1121.8 1123.8

ROSC37

X	False
Unit	MHz
Values	632.733 670.533 711.933 749.4 784.333 822.467 863.467 900.733 938.867 975.133 1015.2 1050.93 1082.33 1115.0 1125.13 1126.73

ROSC38

X	False
Unit	MHz
Values	627.867 665.667 706.667 744.4 778.733 816.933 857.533 895.133 932.6 969.4 1009.2 1044.73 1076.07 1108.6 1118.67 1120.33

ROSC39

X	False
Unit	MHz
Values	632.8 670.533 712.067 749.8 784.333 822.667 863.4 900.6 938.067 974.867 1015.0 1050.4 1082.0 1114.2 1124.07 1126.0

ROSC40

X	False
Unit	MHz
Values	629.933 667.467 709.2 746.533 781.4 819.733 860.4 897.733 935.6 972.2 1012.6 1047.93 1079.4 1111.87 1121.8 1123.8

ROSC41

X	False
Unit	MHz
Values	629.133 666.867 708.2 745.267 780.6 818.467 859.267 896.733 934.467 970.867 1011.13 1046.67 1078.4 1110.67 1120.8 1122.6

Metadata

FirmwareVersion

FirmwareIdentifier

ChannelConfig

SoftwareVersion

ChipConfigs

ITKPIXV2

GlobalConfig

AiRegionRow	0
AuroraActiveLanes	1
AuroraAltOutput0	0
AuroraAltOutput1	0
AuroraCBSend	0
AuroraCBWait0	4095
AuroraCBWait1	0
AuroraCCSend	3
AuroraCCWait	25
AuroraEnPrbs	0
AuroraInitWait	32
AuroraSendAlt	0
AutoRead0	134
AutoRead1	135
AutoRead2	137
AutoRead3	138
AutoRead4	140
AutoRead5	151
AutoRead6	152
AutoRead7	156
BcidCnt	0
BitFlipErrCnt	0
BitFlipWngCnt	0
CapMeasEn	0
CapMeasEnPar	0
CdrClkSel	0
CdrCp	40
CdrCpBuff	200
CdrCpFd	400
CdrPhaseDetSel	0
CdrVco	1023
CdrVcoBuff	500
ChSyncLockThr	31
ChipIdSense	0
Clk160En	7
Clk40En	7
ClkAuroraEn	7
ClkDataMergeEn	7
CmdErrCnt	0
CmlBias0	800
CmlBias1	400
CmlBias2	0
DataDecodingValues	0
DataEnBcid	0
DataEnBinaryRo	0
DataEnCrc	0
DataEnL1id	0
DataEnRaw	0
DataMaxHits	0
DataMaxTot	0
DataMergeEn	0
DataMergeEnBond	0
DataMergeEnClkGate	0
DataMergeFixedMode	0
DataMergeGpoSel	0
DataMergeInMux0	0
DataMergeInMux1	1
DataMergeInMux2	2
DataMergeInMux3	3
DataMergeInPol	0
DataMergeManChoice	0
DataMergeManMode	0
DataMergeOutMux0	0
DataMergeOutMux1	1
DataMergeOutMux2	2
DataMergeOutMux3	3
DataMergeSelClk	0
DataReadDelay	0
DiffComp	500
DiffFbCapEn	0
DiffLcc	200
DiffLccEn	1
DiffPreComp	350
DiffPreampL	550
DiffPreampM	550
DiffPreampR	550
DiffPreampT	550
DiffPreampTL	550
DiffPreampTR	550
DiffTh1L	261
DiffTh1M	261
DiffTh1R	261
DiffTh2	50
DiffVff	88
EfuseConfig	3855
EfuseReadData0	55320
EfuseReadData1	9063
EfuseWriteData0	0
EfuseWriteData1	0
EnChipId	0
EnCoreCol0	65535
EnCoreCol1	65535
EnCoreCol2	65535
EnCoreCol3	63
EnCoreColCal0	0
EnCoreColCal1	0
EnCoreColCal2	0
EnCoreColCal3	0
EnHitsRemoval0	0
EnHitsRemoval1	0
EnHitsRemoval2	0
EnHitsRemoval3	0
EnIsoHitsRemoval0	0
EnIsoHitsRemoval1	0
EnIsoHitsRemoval2	0
EnIsoHitsRemoval3	0
ErrWngMask	0
EvenMask	0
FineDelayClk	0
FineDelayData	0
GatedHitOrCnt0	0
GatedHitOrCnt1	0
GcrDefaultConfig	44149
GcrDefaultConfigB	21386
GlobalConfigSeuCnt	0
GlobalPulseConf	0
GlobalPulseWidth	10
GpCmosDs	0
GpCmosEn	1
GpCmosRoute	34
GpLvdsBias	7
GpLvdsEn	15
GpLvdsPad0	0
GpLvdsPad1	1
GpLvdsPad2	33
GpLvdsPad3	35
GpValReg	5
HitOrCnt0	0
HitOrCnt1	0
HitOrCnt2	0
HitOrCnt3	0
HitOrMask0	0
HitOrMask1	0
HitOrMask2	0
HitOrMask3	0
InjAnaMode	0
InjDigEn	0
InjFineDelay	5
InjVcalHigh	864
InjVcalMed	200
InjVcalRange	1
IrefTrimSense	0
Latency	500
LinComp	110
LinCompTa	110
LinFc	20
LinGdacL	408
LinGdacM	408
LinGdacR	408
LinKrumCurr	50
LinLdac	100
LinPreampL	300
LinPreampM	300
LinPreampR	300
LinPreampT	300
LinPreampTL	300
LinPreampTR	300
LinRefKrum	300
LockLossCnt	0
MonAdcTrim	0
MonSensAcbDem	0
MonSensAcbEn	0
MonSensAcbSelBias	0
MonSensSldoAnaDem	0
MonSensSldoAnaEn	0
MonSensSldoAnaSelBias	0
MonSensSldoDigDem	0
MonSensSldoDigEn	0
MonSensSldoDigSelBias	0
MonitorEnable	1
MonitorI	63
MonitorV	32
MonitoringDataAdc	0
NtcDac	100
NumOfEventsInStream	0
OddMask	0
PixAutoRow	1
PixBroadcast	0
PixConfMode	1
PixDefaultConfig	40162
PixDefaultConfigB	25373
PixEnSeuCount	0
PixHitSampleMode	0
PixPortal	36189
PixRegionCol	199
PixRegionRow	0
PixelSeuCntCnt	0
PtotCoreColEn0	0
PtotCoreColEn1	0
PtotCoreColEn2	0
PtotCoreColEn3	0
RdWrFifoErrCnt	0
ReadTrigCnt	0
ReadTrigLatency	0
RingOscAClear	0
RingOscAEn	0
RingOscAOut	0
RingOscARoute	0
RingOscBClear	0
RingOscBEnBl	0
RingOscBEnBr	0
RingOscBEnCapA	0
RingOscBEnFf	0
RingOscBEnLvt	0
RingOscBOut	0
RingOscBRoute	0
RstCoreCol0	0
RstCoreCol1	0
RstCoreCol2	0
RstCoreCol3	0
SelfTrigDeadtime	64
SelfTrigDelay	512
SelfTrigDigThr	1
SelfTrigDigThrEn	0
SelfTrigEn	0
SelfTrigMulti	4
SelfTrigPattern	65534
SerEnLane	15
SerEnTap	1
SerInvTap	1
SerSelOut0	1
SerSelOut1	3
SerSelOut2	3
SerSelOut3	3
ServiceBlockEn	1
ServiceBlockPeriod	50
SkippedTrigCnt	0
SldoEnUndershuntA	0
SldoEnUndershuntD	0
SldoTrimA	6
SldoTrimD	4
TotEn6b4b	0
TotEn80	0
TotEnPtoa	0
TotEnPtot	0
TotPtotLatency	500
TrigCnt	0
TruncTimeoutConf	0
TwoLevelTrig	0
VrefIn	1
VrefRsensBot	0
VrefRsensTop	0

Parameter

ADCcalPar	8.0 0.192 10000.0
ChipId	15
EnforceNameIdCheck	True
InjCap	7.24
IrefTrim	9
KSenseInA	20975.477
KSenseInD	21277.408
KSenseShuntA	21575.0
KSenseShuntD	21885.0
KShuntA	997.444
KShuntD	959.164
Name	0x367d8
NfACB	1.253255
NfASLDO	1.2549406
NfDSLDO	1.2538121
NtcCalPar	0.0007489 0.0002769 7.0595e-08
VcalPar	-2.0 0.2

SoftwareType

ChipID

Name

0x367d8

Institution

ANL_PIXEL_MODULES

ModuleSN

20UPGM24830014

TimeStart

1774024438

TimeEnd

1774025706

useCalibAdc

False

comment

property

YARR_VERSION	v1.5.6
ANALOG_READBACK_MEASUREMENT_VERSION	2.8.0

AR_VDD

MODULE/POST_PARYLENE_WARM

67a21eb489d864a1f41149c5

1.01

64657cef8d79bac1f3f00578

mts	2026-03-20 17:02:59.185000
cts	2026-03-20 17:02:59.185000
rev	0

20UPGFC0223192

ANALOG_READBACK

69bd7da0844bb5a1929d9dce

DCSdata

Measurements

IrefTrimSense

X	False
Unit	-
Values	9.0

Metadata

FirmwareVersion

FirmwareIdentifier

ChannelConfig

SoftwareVersion

ChipConfigs

ITKPIXV2

GlobalConfig

AiRegionRow	0
AuroraActiveLanes	1
AuroraAltOutput0	0
AuroraAltOutput1	0
AuroraCBSend	0
AuroraCBWait0	4095
AuroraCBWait1	0
AuroraCCSend	3
AuroraCCWait	25
AuroraEnPrbs	0
AuroraInitWait	32
AuroraSendAlt	0
AutoRead0	134
AutoRead1	135
AutoRead2	137
AutoRead3	138
AutoRead4	140
AutoRead5	151
AutoRead6	152
AutoRead7	156
BcidCnt	0
BitFlipErrCnt	0
BitFlipWngCnt	0
CapMeasEn	0
CapMeasEnPar	0
CdrClkSel	0
CdrCp	40
CdrCpBuff	200
CdrCpFd	400
CdrPhaseDetSel	0
CdrVco	1023
CdrVcoBuff	500
ChSyncLockThr	31
ChipIdSense	0
Clk160En	7
Clk40En	7
ClkAuroraEn	7
ClkDataMergeEn	7
CmdErrCnt	0
CmlBias0	800
CmlBias1	400
CmlBias2	0
DataDecodingValues	0
DataEnBcid	0
DataEnBinaryRo	0
DataEnCrc	0
DataEnL1id	0
DataEnRaw	0
DataMaxHits	0
DataMaxTot	0
DataMergeEn	0
DataMergeEnBond	0
DataMergeEnClkGate	0
DataMergeFixedMode	0
DataMergeGpoSel	0
DataMergeInMux0	0
DataMergeInMux1	1
DataMergeInMux2	2
DataMergeInMux3	3
DataMergeInPol	0
DataMergeManChoice	0
DataMergeManMode	0
DataMergeOutMux0	0
DataMergeOutMux1	1
DataMergeOutMux2	2
DataMergeOutMux3	3
DataMergeSelClk	0
DataReadDelay	0
DiffComp	500
DiffFbCapEn	0
DiffLcc	200
DiffLccEn	1
DiffPreComp	350
DiffPreampL	550
DiffPreampM	550
DiffPreampR	550
DiffPreampT	550
DiffPreampTL	550
DiffPreampTR	550
DiffTh1L	261
DiffTh1M	261
DiffTh1R	261
DiffTh2	50
DiffVff	88
EfuseConfig	3855
EfuseReadData0	55320
EfuseReadData1	9063
EfuseWriteData0	0
EfuseWriteData1	0
EnChipId	0
EnCoreCol0	65535
EnCoreCol1	65535
EnCoreCol2	65535
EnCoreCol3	63
EnCoreColCal0	0
EnCoreColCal1	0
EnCoreColCal2	0
EnCoreColCal3	0
EnHitsRemoval0	0
EnHitsRemoval1	0
EnHitsRemoval2	0
EnHitsRemoval3	0
EnIsoHitsRemoval0	0
EnIsoHitsRemoval1	0
EnIsoHitsRemoval2	0
EnIsoHitsRemoval3	0
ErrWngMask	0
EvenMask	0
FineDelayClk	0
FineDelayData	0
GatedHitOrCnt0	0
GatedHitOrCnt1	0
GcrDefaultConfig	44149
GcrDefaultConfigB	21386
GlobalConfigSeuCnt	0
GlobalPulseConf	0
GlobalPulseWidth	10
GpCmosDs	0
GpCmosEn	1
GpCmosRoute	34
GpLvdsBias	7
GpLvdsEn	15
GpLvdsPad0	0
GpLvdsPad1	1
GpLvdsPad2	33
GpLvdsPad3	35
GpValReg	5
HitOrCnt0	0
HitOrCnt1	0
HitOrCnt2	0
HitOrCnt3	0
HitOrMask0	0
HitOrMask1	0
HitOrMask2	0
HitOrMask3	0
InjAnaMode	0
InjDigEn	0
InjFineDelay	5
InjVcalHigh	864
InjVcalMed	200
InjVcalRange	1
IrefTrimSense	0
Latency	500
LinComp	110
LinCompTa	110
LinFc	20
LinGdacL	408
LinGdacM	408
LinGdacR	408
LinKrumCurr	50
LinLdac	100
LinPreampL	300
LinPreampM	300
LinPreampR	300
LinPreampT	300
LinPreampTL	300
LinPreampTR	300
LinRefKrum	300
LockLossCnt	0
MonAdcTrim	0
MonSensAcbDem	0
MonSensAcbEn	0
MonSensAcbSelBias	0
MonSensSldoAnaDem	0
MonSensSldoAnaEn	0
MonSensSldoAnaSelBias	0
MonSensSldoDigDem	0
MonSensSldoDigEn	0
MonSensSldoDigSelBias	0
MonitorEnable	1
MonitorI	63
MonitorV	32
MonitoringDataAdc	0
NtcDac	100
NumOfEventsInStream	0
OddMask	0
PixAutoRow	1
PixBroadcast	0
PixConfMode	1
PixDefaultConfig	40162
PixDefaultConfigB	25373
PixEnSeuCount	0
PixHitSampleMode	0
PixPortal	36189
PixRegionCol	199
PixRegionRow	0
PixelSeuCntCnt	0
PtotCoreColEn0	0
PtotCoreColEn1	0
PtotCoreColEn2	0
PtotCoreColEn3	0
RdWrFifoErrCnt	0
ReadTrigCnt	0
ReadTrigLatency	0
RingOscAClear	0
RingOscAEn	0
RingOscAOut	0
RingOscARoute	0
RingOscBClear	0
RingOscBEnBl	0
RingOscBEnBr	0
RingOscBEnCapA	0
RingOscBEnFf	0
RingOscBEnLvt	0
RingOscBOut	0
RingOscBRoute	0
RstCoreCol0	0
RstCoreCol1	0
RstCoreCol2	0
RstCoreCol3	0
SelfTrigDeadtime	64
SelfTrigDelay	512
SelfTrigDigThr	1
SelfTrigDigThrEn	0
SelfTrigEn	0
SelfTrigMulti	4
SelfTrigPattern	65534
SerEnLane	15
SerEnTap	1
SerInvTap	1
SerSelOut0	1
SerSelOut1	3
SerSelOut2	3
SerSelOut3	3
ServiceBlockEn	1
ServiceBlockPeriod	50
SkippedTrigCnt	0
SldoEnUndershuntA	0
SldoEnUndershuntD	0
SldoTrimA	6
SldoTrimD	4
TotEn6b4b	0
TotEn80	0
TotEnPtoa	0
TotEnPtot	0
TotPtotLatency	500
TrigCnt	0
TruncTimeoutConf	0
TwoLevelTrig	0
VrefIn	1
VrefRsensBot	0
VrefRsensTop	0

Parameter

ADCcalPar	8.0 0.192 10000.0
ChipId	15
EnforceNameIdCheck	True
InjCap	7.24
IrefTrim	9
KSenseInA	20975.477
KSenseInD	21277.408
KSenseShuntA	21575.0
KSenseShuntD	21885.0
KShuntA	997.444
KShuntD	959.164
Name	0x367d8
NfACB	1.253255
NfASLDO	1.2549406
NfDSLDO	1.2538121
NtcCalPar	0.0007489 0.0002769 7.0595e-08
VcalPar	-2.0 0.2

SoftwareType

ChipID

Name

0x367d8

Institution

ANL_PIXEL_MODULES

ModuleSN

20UPGM24830014

TimeStart

1774025706

TimeEnd

1774025707

comment

property

YARR_VERSION	v1.5.6
ANALOG_READBACK_MEASUREMENT_VERSION	2.8.0

AR_REGISTER

MODULE/POST_PARYLENE_WARM

67a21eb489d864a1f41149c5

1.01

64657cef8d79bac1f3f00578

mts	2026-03-20 17:02:59.185000
cts	2026-03-20 17:02:59.185000
rev	0

rawHash

031b7c9f978ffff734ee8208014e5ef0

stage

MODULE/POST_PARYLENE_WARM

ProductionDB Record

Expand ProductionDB Record

69d71954b3d4daa62c39db91

state

ready

stateTs

2026-04-09T03:13:24.488Z

stateUserIdentity

4728-7541-1

date

2026-03-20T17:03:00.000Z

testType

id	6393a07c15838700361eebef
code	ANALOG_READBACK
name	Analog Readback
state	active

institution

id	5d318624df98f200097386d5
code	ANL
name	Argonne National Laboratory

user

id	6526ef19d2e4250042313864
userIdentity	4728-7541-1
firstName	Daniel
middleName
lastName	Aceves

runNumber

69bd7dc7f97f394ea371e823

passed

True

problems

False

properties

code	name	dataType	valueType	required	value	rangeMin	rangeMax
ANALYSIS_VERSION	Analog Readback Analysis Version	string	None	True	2.8.1	None	None
MEASUREMENT_DATE	Date measurement performed	datetime	None	False	2026-03-20T16:30:01.000+00:00	None	None
MEASUREMENT_DURATION	Measurement duration	integer	None	False	237	None	None
MEASUREMENT_VERSION	Measurement version	string	None	False	2.8.0	None	None
YARR_VERSION	Yarr Version	string	None	False	v1.5.6	None	None

results

code AR_IREF_TRIM
name Wirebonded Iref trim on ITkPix v2 chip
order 23
dataType integer
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 9
associateChild None
code AR_IREF
name AR_IREF (A)
order 24
dataType float
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 4.1e-06
associateChild None
code AR_GADC
name AR_GADC (V)
order 25
dataType float
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 0.838
associateChild None

code	AR_NOMINAL_SETTINGS
name	Analog readback at nominal settings
dataType	float
valueType	array
arrayDimensions	1
additional	None
rangeMin	None
rangeMax	None
value	4.1e-06 8.92e-05 4.95e-05 4.2e-06 3.97e-05 2.04e-05 0 3.91e-05 7.19e-05 -999 0 0 4.79e-05 6.64e-05 5.19e-05 8.75e-05 7.13e-05 7.8e-05 8.67e-05 8.75e-05 7.33e-05 4.7e-05 4.83e-05 7.22e-05 4.82e-05 4.84e-05 -999 -999 0.648442 0.0525793 0.9043857 0.2608896 0.8377301 -999 -999 0.835525 1.1857104 0.123997 0.1179486 0.1764576 0.0398403 0.0392999 0.183876 0.1855221 0.1863581 0.6325486 -999 0.628776 -999 0.5910131 -999 -999 -999 -999 -999 -999 -999 -999 -999 -999 -999 -999 0.0173446 0.4600562 2.0353283 1.5236268 1.1895492 0.5843934 0.9956684 1.5274312 1.192139 0.5867507
associateChild	None

code	AR_ROSC_MAX_RESIDUAL
name	Ring Oscillator Max Residual
dataType	float
valueType	array
arrayDimensions	1
additional	None
rangeMin	None
rangeMax	None
value	2.901925159472482 4.762692823410576 2.6988567818469704 4.667599125739818 2.198930215734613 3.7269272746548836 2.3332446512123353 4.032918765192729 4.266329207349384 4.413820267014474 5.164272566967766 5.243436474388129 4.316099445476148 4.292559550791792 5.155842476459831 5.2178418195921905 3.765270380271167 3.762856134587897 4.252237600845968 4.294286765618885 3.6229005993507317 3.46320325718152 4.5717330298474055 4.523111670308225 2.7167293764127667 2.715490242158643 3.013276831913147 3.0782838597573274 3.1774700485947074 5.608537309891409 5.040155841910223 5.83264927232563 4.438949565392091 4.87436637677644 4.118341961638578 4.121313385333005 4.261238800030352 4.128149501572697 4.091929987862127 4.220898862228137 4.156323710295328 4.056411101091222
associateChild	None

code	AR_ROSC_OFFSET
name	Ring Oscillator Offset
dataType	float
valueType	array
arrayDimensions	1
additional	None
rangeMin	None
rangeMax	None
value	-353.7151813108951 -557.218895451211 -371.133654750029 -572.7743960205568 -475.7962073172943 -823.5469296893523 -605.8907508305965 -874.8658190199178 -588.1579360016874 -574.8682275883697 -696.1752977324165 -692.1461028175987 -613.4817311429789 -625.0329521636047 -709.3070233103255 -702.7233464181714 -817.3153723725247 -832.9106747359702 -980.2884599829531 -975.672707508342 -843.133594420891 -855.353796707566 -1033.7960041999072 -1034.8716458063127 -472.97643469485394 -467.7320096530108 -582.9869074758847 -576.1458017899814 -560.4002552126851 -560.3758337534622 -432.6065993500884 -437.2898296156141 -509.76968979042823 -540.8908281900382 -944.4617378742507 -943.957206471657 -940.4575959028116 -938.6754093978034 -938.7190439736037 -935.1521685949547 -940.8684552380802 -940.6864114527481
associateChild	None

code	AR_ROSC_SLOPE
name	Ring Oscillator Slope
dataType	float
valueType	array
arrayDimensions	1
additional	None
rangeMin	None
rangeMax	None
value	666.8536980310593 1041.4701386783554 666.6207911417603 1048.1710482526669 744.8322398869401 1283.9499507617295 889.6838859005069 1324.6033648439238 1034.1495174795075 1037.875386321862 1231.2182050099339 1235.796274788404 1066.3135259047028 1068.498989978231 1244.386092550789 1242.7259630547258 1260.8755241425238 1274.9651030587384 1500.0140551948548 1501.4107352465778 1251.5495576812148 1248.104671015407 1553.339106148733 1557.0644671398973 766.8471650179079 768.2254465728239 931.1241649090473 929.7442966790579 919.3395874717079 916.7519220077404 1007.3129484288195 1073.74906287868 1011.6074218682955 1084.1672125780399 1438.8404706011863 1443.4760961297302 1443.8898721848504 1444.6717433606957 1440.1943207575976 1441.7179690971373 1444.0744499214945 1443.079534339808
associateChild	None

code AR_TEMP_ACB
name Temperature ACB
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 28.093
associateChild None
code AR_TEMP_ASLDO
name Temperature Ana SLDO
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 29.362
associateChild None
code AR_TEMP_DSLDO
name Temperature Dig SLDO
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 30.486
associateChild None
code AR_TEMP_EXT
name Control temperature (external NTC from the FE)
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 19.97
associateChild None
code AR_TEMP_NF_ACB
name Temperature calibration constant (ACB)
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 1.253
associateChild None
code AR_TEMP_NF_ASLDO
name Temperature calibration constant (ana SLDO)
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 1.255
associateChild None
code AR_TEMP_NF_BOTTOM
name Temperature calibration constant (poly bottom)
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value -999
associateChild None
code AR_TEMP_NF_DSLDO
name Temperature calibration constant (dig SLDO)
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 1.254
associateChild None
code AR_TEMP_NF_TOP
name Temperature calibration constant (poly top)
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value -999
associateChild None
code AR_TEMP_NTC
name Temperature NTC
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 21.953
associateChild None
code AR_TEMP_POLY_BOTTOM
name Temperature poly bottom
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value -999
associateChild None
code AR_TEMP_POLY_TOP
name Temperature poly top
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value -999
associateChild None
code AR_VCALDAC
name AR_VCALDAC (V)
order 26
dataType float
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 0.836
associateChild None
code AR_VDDA_SATURATION
name VDDA saturation trim value
dataType integer
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value -1
associateChild None
code AR_VDDA_TRIM
name VDDA Trim
dataType integer
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 6
associateChild None

code	AR_VDDA_VS_TRIM
name	VDDA vs trim
dataType	float
valueType	array
arrayDimensions	1
additional	None
rangeMin	None
rangeMax	None
value	1.042 1.068 1.092 1.117 1.139 1.165 1.188 1.214 1.243 1.268 1.292 1.317 1.339 1.364 1.389 1.415
associateChild	None

code AR_VDDD_SATURATION
name VDDD saturation trim value
dataType integer
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 14
associateChild None
code AR_VDDD_TRIM
name VDDD Trim
dataType integer
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 4
associateChild None

code	AR_VDDD_VS_TRIM
name	VDDD vs trim
dataType	float
valueType	array
arrayDimensions	1
additional	None
rangeMin	None
rangeMax	None
value	1.092 1.117 1.145 1.168 1.192 1.217 1.245 1.27 1.296 1.322 1.35 1.375 1.399 1.424 1.433 1.434
associateChild	None

code AR_VREFCORE
name AR_VREFCORE (V)
order 27
dataType float
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 0.46
associateChild None
code AR_VREFOVP
name AR_VREFOVP (V)
order 28
dataType float
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 2.035
associateChild None

cts

2026-04-09T03:13:24.488Z

sys

cts	2026-04-09T03:13:24.488Z
mts	2026-04-09T03:13:33.646Z
rev	2

defects

comments

None

attachments

code

3664aef3eae9a171d5f25660c0321ded

dateTime

2026-04-09T03:13:24.868Z

title

TestRun_69d71954b3d4daa62c39db91_Attachment_Pack.zip

description

/home/data/viewer/static/cache/thumbnail/TestRun_69d71954b3d4daa62c39db91_Attachment_Pack.zip

contentType

None

type

eos

url

https://eosatlas.cern.ch/eos/atlas/atlascerngroupdisk/det-itk/prod-db/3/6/6/3664aef3eae9a171d5f25660c0321ded?authz=zteos64:MDAwMDAyZjR4nO2RsWvbUBDGscGBeDItZPB0uKV0kfVO0nuybuocurR4Mx6efU-2sK0n5KeWmkILhQaydelWOnbu1L-ihZIhkMmQOV0LmaKYDBkyZ8p9cMOPu-M7vvZ5s90oO9-PP_3d67Yytyi419wUzxvB0Dd27Wu31Dd9asp8Vtqq4Gy98Nk4rx73i9KyxxM_9FWtUKlImzQ02iQaY2SZBlIpMRVhgGz48Gk6ZZYohSdTnXiIKXqDJGZPR5NUYJxIDpLXfxqj4byCwyoHiEAEhEgygEAEagxVxoQRqgGOdn7HMLsmoYhHm2IMLmOTOyqtdX1EqWKKIsQXI6K0LpJYU9VPBn0UY8j1ytDuCnBOUD_jaFFOJOiiIJjbtaO7F9mudJbTLTIzlmBdsSUBrtRTQ2DziZnrZUqP4NWXJy9_Pv5V_P999uMgenPxrvfv5Nt-5_L99uOHt19bz7oPOdxDDnD0-XTbuALkROod

urlCernbox

https://cernbox.cern.ch/files/spaces/eos/atlas/atlascerngroupdisk/det-itk/prod-db/3/6/6/3664aef3eae9a171d5f25660c0321ded

filename

3664aef3eae9a171d5f25660c0321ded

user

id	6526ef19d2e4250042313864
userIdentity	4728-7541-1
firstName	Daniel
middleName
lastName	Aceves

code

9ddfe566cf025a9c93fad3f400108874

dateTime

2026-04-09T03:13:33.548Z

title

RAW

description

RAW

contentType

text/plain

type

file

binaryStoreg02

True

filename

data

user

id	6526ef19d2e4250042313864
userIdentity	4728-7541-1
firstName	Daniel
middleName
lastName	Aceves

components

code

state

stateTs

stateUserIdentity

dummy

completed

completedTs

completedUserIdentity

trashed

trashedTs

trashedUserIdentity

serialNumber

alternativeIdentifier

ancestorMap

project

subproject

componentType

type

properties

testedAtStage

institution

67a21eb489d864a1f41149c5

4b2ed46e65a850dd77a7cc5004398f0c

ready

2025-02-04T14:05:40.556Z

5310-2637-1

False

None

False

None

20UPGFC0223192

None

parent

component

68d2c40ab5f1d1f55a7bf85c

code

0ebf71bfccac6a44d90d68c0edb25266

state

ready

stateTs

2025-09-23T16:00:10.562Z

stateUserIdentity

23-6780-1

dummy

False

completed

False

completedTs

None

completedUserIdentity

None

trashed

False

trashedTs

None

trashedUserIdentity

None

serialNumber

20UPGB43000293

alternativeIdentifier

None

project

code	P
name	Pixels

subproject

code	PG
name	Pixel general

componentType

code	BARE_MODULE
name	Bare Module

type

code	QUAD_BARE_MODULE
name	Quad bare module

testedAtStage

code	MODULE/PARYLENE_UNMASKING
name	Parylene Unmasking

highestLevelParent

component

690e48c344c06a976341e4f7

code

14d6ac889604b9cc7d1a5b02d29ffcec

state

ready

stateTs

2025-11-07T19:30:11.266Z

stateUserIdentity

4561-2270-1

dummy

False

completed

False

completedTs

None

completedUserIdentity

None

trashed

False

trashedTs

None

trashedUserIdentity

None

serialNumber

20UPGM24830014

alternativeIdentifier

ANL_ITkPix_186

project

code	P
name	Pixels

subproject

code	PG
name	Pixel general

componentType

code	MODULE
name	Module

type

code	OUTER_SYSTEM_QUAD_MODULE
name	Outer system quad module

testedAtStage

code	MODULE/PARYLENE_UNMASKING
name	Parylene Unmasking

code	P
name	Pixels

code	PG
name	Pixel general

code	FE_CHIP
name	Front-end Chip

code	ITKPIX_V2
name	ITkpix_V2

code	name	dataType	required	default	value
TARGET_IREF_TRIM	Target Iref trim	integer	False	False	9
TARGET_IREF_TRIM_VERSION	Target Iref trim version	string	False	False	1

code	MODULE/POST_PARYLENE_WARM
name	Post-Parylene Warm
order	15
initial	False
final	False

code	GL
name	Glasgow University

Current Stage: Post-Parylene Cold

Test Type	Local Result
ADC Calibration (ADC_CALIBRATION)	No TestRun!
Analog Readback (ANALOG_READBACK)	No TestRun!
VCAL Calibration (VCAL_CALIBRATION)	No TestRun!
Low Power Mode (LP_MODE)	No TestRun!
Data Transmission (DATA_TRANSMISSION)	No TestRun!
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No TestRun!
Undershunt Protection (UNDERSHUNT_PROTECTION)	No TestRun!
SLDO (SLDO)	No TestRun!
Minimal Health Test (MIN_HEALTH_TEST)	No TestRun!
Tuning (TUNING)	No TestRun!
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No TestRun!
Injection Capacitance (INJECTION_CAPACITANCE)	No TestRun!

Candidate TestRuns of this Stage

LDB ID	TestRun Code	QC Passed	Inspector	Measurement Date	Analysis Date	Analysis Version	Tags	QC Registration
69bd83…71e98e	LP_MODE	Pass	DanielAceves	3 months ago	2 months ago	2.8.1	No tags	Selected
69bdaa…71ec97	PIXEL_FAILURE_ANALYSIS	Pass	DanielAceves	N/A	2 months ago	2.8.1	No tags	Selected
69bd96…71eb14	TUNING	Pass	DanielAceves	N/A	2 months ago	2.8.1	No tags	Selected
69bd91…71ea20	MIN_HEALTH_TEST	Pass	DanielAceves	N/A	2 months ago	2.8.1	No tags	Selected
69bd82…71e963	INJECTION_CAPACITANCE	Pass	DanielAceves	3 months ago	2 months ago	2.8.1	No tags	Selected
69bd81…71e913	DATA_TRANSMISSION	Pass	DanielAceves	3 months ago	2 months ago	2.8.1	No tags	Selected
69bd81…71e8d3	VCAL_CALIBRATION	Pass	DanielAceves	3 months ago	2 months ago	2.8.1	No tags	Selected
69bd80…71e873	SLDO	Pass	DanielAceves	3 months ago	2 months ago	2.8.1	No tags	Selected
69bd7d…71e823	ANALOG_READBACK	Pass	DanielAceves	3 months ago	2 months ago	2.8.1	No tags	Selected
69bd75…71e773	ADC_CALIBRATION	Pass	DanielAceves	3 months ago	2 months ago	2.8.1	No tags	Selected

Past QC Stages and Results

Post-Parylene Warm (MODULE/POST_PARYLENE_WARM)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	Registered	Registered
Analog Readback (ANALOG_READBACK)	Registered	Registered
Data Transmission (DATA_TRANSMISSION)	Registered	Registered
Injection Capacitance (INJECTION_CAPACITANCE)	Registered	Registered
Low Power Mode (LP_MODE)	Registered	Registered
Minimal Health Test (MIN_HEALTH_TEST)	Registered	Registered
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	Registered	Registered
SLDO (SLDO)	Registered	Registered
Tuning (TUNING)	Registered	Registered
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	Registered	Registered

Wirebond Protection (alt) (MODULE/WIREBOND_PROTECTION)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Parylene Unmasking (MODULE/PARYLENE_UNMASKING)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Parylene Coating (MODULE/PARYLENE_COATING)

Parylene Masking (MODULE/PARYLENE_MASKING)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Initial Cold (MODULE/INITIAL_COLD)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

QC cross-check (module swapping) (MODULE/QC_CROSSCHECK)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Initial Warm (MODULE/INITIAL_WARM)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	Registered	Registered
Analog Readback (ANALOG_READBACK)	Registered	Registered
Data Transmission (DATA_TRANSMISSION)	Registered	Registered
Injection Capacitance (INJECTION_CAPACITANCE)	Registered	Registered
Low Power Mode (LP_MODE)	Registered	Registered
Minimal Health Test (MIN_HEALTH_TEST)	Registered	Registered
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	Registered	Registered
SLDO (SLDO)	Registered	Registered
Tuning (TUNING)	Registered	Registered
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	Registered	Registered

Wire Bonding (MODULE/WIREBONDING)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Bare module to module PCB assembly (MODULE/ASSEMBLY)

Initial state to associate flex to bare module (MODULE/INIT)

Reception at ITk institute (BAREMODULERECEPTION)

Test	Local Result	ProdDB Record
Analog Readback (ANALOG_READBACK)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A

Bare module assembly (BAREMODULEASSEMBLY)

Not to be used for detector (UNUSABLE)

Hybridisation (HYBRIDISATION)

Testing on wafer (TESTONWAFER)

Test	Local Result	ProdDB Record
Electrical FE chip tests (FECHIP_TEST)	Registered	Registered

LocalDB Test ID	Stage	Test Name	Inspector	Measurement Date	Analysis Date	Tags	QC Registration
69bd83…71e98e	MODULE/POST_PARYLENE_WARM	LP_MODE	DanielAceves	3 months ago	2 months ago	No tags	Selected
69bdaa…71ec97	MODULE/POST_PARYLENE_WARM	PIXEL_FAILURE_ANALYSIS	DanielAceves	N/A	2 months ago	No tags	Selected
69bd96…71eb14	MODULE/POST_PARYLENE_WARM	TUNING	DanielAceves	N/A	2 months ago	No tags	Selected
69bd91…71ea20	MODULE/POST_PARYLENE_WARM	MIN_HEALTH_TEST	DanielAceves	N/A	2 months ago	No tags	Selected
69bd82…71e963	MODULE/POST_PARYLENE_WARM	INJECTION_CAPACITANCE	DanielAceves	3 months ago	2 months ago	No tags	Selected
69bd81…71e913	MODULE/POST_PARYLENE_WARM	DATA_TRANSMISSION	DanielAceves	3 months ago	2 months ago	No tags	Selected
69bd81…71e8d3	MODULE/POST_PARYLENE_WARM	VCAL_CALIBRATION	DanielAceves	3 months ago	2 months ago	No tags	Selected
69bd80…71e873	MODULE/POST_PARYLENE_WARM	SLDO	DanielAceves	3 months ago	2 months ago	No tags	Selected
69bd7d…71e823	MODULE/POST_PARYLENE_WARM	ANALOG_READBACK	DanielAceves	3 months ago	2 months ago	No tags	Selected
69bd75…71e773	MODULE/POST_PARYLENE_WARM	ADC_CALIBRATION	DanielAceves	3 months ago	2 months ago	No tags	Selected
6931ed…aff02b	MODULE/INITIAL_WARM	PIXEL_FAILURE_ANALYSIS	Simpson,Liana Rae	N/A	3 months ago	No tags	Selected
6931ec…afef34	MODULE/INITIAL_WARM	TUNING	Simpson,Liana Rae	N/A	3 months ago	No tags	Selected
6931ec…afeea6	MODULE/INITIAL_WARM	MIN_HEALTH_TEST	Simpson,Liana Rae	N/A	3 months ago	No tags	Selected
692f6b…afcdde	MODULE/INITIAL_WARM	INJECTION_CAPACITANCE	Simpson,Liana Rae	6 months ago	3 months ago	No tags	Selected
692f6b…afcdaa	MODULE/INITIAL_WARM	DATA_TRANSMISSION	Simpson,Liana Rae	6 months ago	3 months ago	No tags	Selected
692f6c…afce6b	MODULE/INITIAL_WARM	LP_MODE	Simpson,Liana Rae	6 months ago	3 months ago	No tags	Selected
692f6a…afcd52	MODULE/INITIAL_WARM	VCAL_CALIBRATION	Simpson,Liana Rae	6 months ago	3 months ago	No tags	Selected
692f69…afcc6f	MODULE/INITIAL_WARM	SLDO	Simpson,Liana Rae	6 months ago	3 months ago	No tags	Selected
692f66…afcba7	MODULE/INITIAL_WARM	ANALOG_READBACK	Simpson,Liana Rae	6 months ago	3 months ago	No tags	Selected
692f5f…afc793	MODULE/INITIAL_WARM	ADC_CALIBRATION	Simpson,Liana Rae	6 months ago	3 months ago	No tags	Selected
67a21f…115ac3	TESTONWAFER	FECHIP_TEST	DimaManeuski	N/A	a year ago	No tags	Selected

Stage: MODULE/POST_PARYLENE_COLD

Mode: warm

Index	Revision ID	Timestamp	Message
HEAD	6a15...d955d2	2 weeks ago	downloaded from ITkPD : code = eb54cfaaf034205c3975ad64d5be22a4, description = {"_id":"69bb26a727d3ddc5179db98a","serialNumber":"20UPGFC0223192","stage":"MODULE/POST_PARYLENE_WARM","branch":"warm","current_revision_id":"69bd8c5e251c9b4ec87a6725"}

Mode: cold

Index	Revision ID	Timestamp	Message
HEAD	6a15...d955d4	2 weeks ago	downloaded from ITkPD : code = a03d6ce3d97665436211aaa58476aa41, description = {"_id":"6920c736d7bf966e0aaf23ee","serialNumber":"20UPGFC0223192","stage":"MODULE/INITIAL_WARM","branch":"cold","current_revision_id":"6920c736d7bf966e0aaf23ef"}

Mode: LP

Index	Revision ID	Timestamp	Message
HEAD	6a15...d955d6	2 weeks ago	downloaded from ITkPD : code = 1e7b90592d2ba63e62aa80ef57dbd003, description = {"_id":"6920c736d7bf966e0aaf23f6","serialNumber":"20UPGFC0223192","stage":"MODULE/INITIAL_WARM","branch":"LP","current_revision_id":"692f6c71d7bf966e0aafce6c"}

Stage	Tests
TESTONWAFER	Electrical FE chip tests (FECHIP_TEST)
HYBRIDISATION
UNUSABLE
BAREMODULEASSEMBLY
BAREMODULERECEPTION	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK)
MODULE/INIT
MODULE/ASSEMBLY
MODULE/WIREBONDING	ADC Calibration (ADC_CALIBRATION) Data Transmission (DATA_TRANSMISSION) VCAL Calibration (VCAL_CALIBRATION) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) SLDO (SLDO) Low Power Mode (LP_MODE) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/INITIAL_WARM	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Low Power Mode (LP_MODE) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) Data Transmission (DATA_TRANSMISSION) Injection Capacitance (INJECTION_CAPACITANCE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
MODULE/QC_CROSSCHECK	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Low Power Mode (LP_MODE) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) Data Transmission (DATA_TRANSMISSION) Injection Capacitance (INJECTION_CAPACITANCE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
MODULE/INITIAL_COLD	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Injection Capacitance (INJECTION_CAPACITANCE) Tuning (TUNING) Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Low Power Mode (LP_MODE) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) Data Transmission (DATA_TRANSMISSION)
MODULE/PARYLENE_MASKING	ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) SLDO (SLDO) Low Power Mode (LP_MODE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE) Data Transmission (DATA_TRANSMISSION)
MODULE/PARYLENE_COATING
MODULE/PARYLENE_UNMASKING	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Tuning (TUNING) Data Transmission (DATA_TRANSMISSION) ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) SLDO (SLDO) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE)
MODULE/WIREBOND_PROTECTION	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Tuning (TUNING) ADC Calibration (ADC_CALIBRATION) Low Power Mode (LP_MODE) VCAL Calibration (VCAL_CALIBRATION) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE) SLDO (SLDO) Data Transmission (DATA_TRANSMISSION)
MODULE/POST_PARYLENE_WARM	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Data Transmission (DATA_TRANSMISSION) Injection Capacitance (INJECTION_CAPACITANCE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Low Power Mode (LP_MODE)
MODULE/POST_PARYLENE_COLD	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) VCAL Calibration (VCAL_CALIBRATION) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) SLDO (SLDO) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/THERMAL_CYCLES	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Tuning (TUNING) Data Transmission (DATA_TRANSMISSION) SLDO (SLDO) ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE) Cold startup (COLD_STARTUP)
MODULE/LONG_TERM_STABILITY_TEST	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) SLDO (SLDO) Tuning (TUNING) ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/FINAL_WARM	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Undershunt Protection (UNDERSHUNT_PROTECTION) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Data Transmission (DATA_TRANSMISSION) Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Tuning (TUNING) Low Power Mode (LP_MODE) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/FINAL_COLD	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) Tuning (TUNING) Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Data Transmission (DATA_TRANSMISSION) Cold startup (COLD_STARTUP)
MODULE/FINAL_METROLOGY	Data Transmission (DATA_TRANSMISSION) ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) SLDO (SLDO) Injection Capacitance (INJECTION_CAPACITANCE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Injection Capacitance (INJECTION_CAPACITANCE) Analog Readback (ANALOG_READBACK)
MODULE/QC_STATUS
MODULE/UNHAPPY	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) VCAL Calibration (VCAL_CALIBRATION) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Low Power Mode (LP_MODE) Injection Capacitance (INJECTION_CAPACITANCE) SLDO (SLDO) Data Transmission (DATA_TRANSMISSION)
MODULE/NOTCONSIDEREDINYIELDS	ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) SLDO (SLDO) Undershunt Protection (UNDERSHUNT_PROTECTION) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Analog Readback (ANALOG_READBACK) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Low Power Mode (LP_MODE) Injection Capacitance (INJECTION_CAPACITANCE) Data Transmission (DATA_TRANSMISSION)
MODULE/GRAVEYARD
MODULE/COMPLETE
MODULE/RECEPTION	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Data Transmission (DATA_TRANSMISSION) Tuning (TUNING)
MODULE/TAB_CUTTING	Minimal Health Test (MIN_HEALTH_TEST)
LLS/PRE_TC_WARM	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Low Power Mode (LP_MODE) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
LLS/PRE_TC_COLD	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
LLS/POST_TC_WARM	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
LLS/POST_TC_COLD	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
LLS/RECEPTION	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
OB_LOADED_MODULE_CELL/INIT
OB_LOADED_MODULE_CELL/ASSEMBLY
OB_LOADED_MODULE_CELL/WIREBOND_PROTECTION
OB_LOADED_MODULE_CELL/THERMAL_CYCLES
OB_LOADED_MODULE_CELL/FINAL_WARM	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
OB_LOADED_MODULE_CELL/FINAL_COLD	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
OB_LOADED_MODULE_CELL/THERMAL_COLD
OB_LOADED_MODULE_CELL/THERMAL_WARM
OB_LOADED_MODULE_CELL/ENVELOPE_CHECK
OB_LOADED_MODULE_CELL/QC_STATUS
OB_LOADED_MODULE_CELL/UNHAPPY
OB_LOADED_MODULE_CELL/GRAVEYARD
OB_LOADED_MODULE_CELL/COMPLETE
OB_LOADED_MODULE_CELL/RECEPTION	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) SLDO (SLDO)
OB_LOADED_MODULE_CELL/TAB_CUTTING	Minimal Health Test (MIN_HEALTH_TEST)
OB_LOADED_MODULE_CELL/PIGTAIL_INSERTION
TEST_AFTER_LOADED_LOCAL_SUPPORT_ASSEMBLY	OB:Loaded local support QC electrical connectivity (OBLoadedLocalSupportQC_ElectricalConnectivity) OB:Loaded local support QC electrical performance (OBLoadedLocalSupportQC_ElectricalPerformance) OB:Loaded local support reception at the integration site (OBLoadedLocalSupport_IntegrationSite) OB:Loaded local support QC electrical low power (OBLoadedLocalSupport_QCElectricalLowPower)
TEST_JM_OEC_FE

20UPGFC0223192

MODULE/POST_PARYLENE_COLD

Component Information

Wafer

Properties

Comments

Test: ANALOG_READBACK QC Passed

(Stage: MODULE/POST_PARYLENE_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Results

Attachments

RAW Results Record

ProductionDB Record

Current Stage: Post-Parylene Cold

Candidate TestRuns of this Stage

Past QC Stages and Results

Post-Parylene Warm (MODULE/POST_PARYLENE_WARM)

Wirebond Protection (alt) (MODULE/WIREBOND_PROTECTION)

Parylene Unmasking (MODULE/PARYLENE_UNMASKING)

Parylene Coating (MODULE/PARYLENE_COATING)

Parylene Masking (MODULE/PARYLENE_MASKING)

Initial Cold (MODULE/INITIAL_COLD)

QC cross-check (module swapping) (MODULE/QC_CROSSCHECK)

Initial Warm (MODULE/INITIAL_WARM)

Wire Bonding (MODULE/WIREBONDING)

Bare module to module PCB assembly (MODULE/ASSEMBLY)

Initial state to associate flex to bare module (MODULE/INIT)

Reception at ITk institute (BAREMODULERECEPTION)

Bare module assembly (BAREMODULEASSEMBLY)

Not to be used for detector (UNUSABLE)

Hybridisation (HYBRIDISATION)

Testing on wafer (TESTONWAFER)

All Registered QC Tests

Config Revisions

Stage: MODULE/POST_PARYLENE_COLD

Mode: warm

Mode: cold

Mode: LP

Check QC Flow

Back to top page of this component
