Database for ITk Pixel Module

Serial Number	20UPGFC0230279
ProdDB ID	1adc6b…92178a
LocalDB ID	670e5cade1231800423b5004
Component Type	fe_chip
Parents	20UPGM23622030 20UPGB43347167
Children	No match.
Flags

Item	Value
Target Iref trim	14
Target Iref trim version	1
Wafer serial number	None

Key	Data
QC Passed	True
Date	4 months ago
component ObjectId	670e5cade1231800423b5004
Stage	MODULE/INITIAL_WARM
Test Type	PIXEL_FAILURE_ANALYSIS
Institute ObjectId
User Name	Shift-LeaderHayashi-REPIC-KEK
ObjectId of this record	693665396e8c589ff5360190
ObjectId of RAW record	None
Tags	No tags

Key	Data
ANALYSIS_VERSION	mqat v2.7.1
MEASUREMENT_DATE	2025-12-07T20:22:30.000+00:00
MEASUREMENT_DURATION	910
YARR_VERSION	v1.5.5
PIXEL_FAILURE_BAD_ANALOG	0
PIXEL_FAILURE_BAD_DIGITAL	0
PIXEL_FAILURE_COLUMN_DISABLED	0
PIXEL_FAILURE_DEAD_ANALOG	2
PIXEL_FAILURE_DEAD_DIGITAL	0
PIXEL_FAILURE_DISCONNECTED_BUMPS_SOURCE_SCAN	-1
PIXEL_FAILURE_DISCONNECTED_BUMPS_XTALK_SCAN	0
PIXEL_FAILURE_DISCONNECTED_BUMPS_ZERO_BIAS_SCAN	-1
PIXEL_FAILURE_DISCONNECTED_PIXELS	0
PIXEL_FAILURE_DISC_PIXEL_ALL_ELEC	2
PIXEL_FAILURE_ELECTRICALLY_FAILED	12
PIXEL_FAILURE_FAILING_PIXELS	12
PIXEL_FAILURE_HIGH_ENC	0
PIXEL_FAILURE_HIGH_NOISE	5
PIXEL_FAILURE_MERGED_BUMPS	0
PIXEL_FAILURE_SOURCE_SCAN_DONE	False
PIXEL_FAILURE_TUNING_BAD	5

Filename	Contents
output.log	Download
0x38387.log	Download
20UPGFC0230279_MODULE__INITIAL_WARM_PIXEL-FAILURE-ANALYSIS.zip	Download

Expand ProductionDB Record
