20UPGFC0230279

MODULE/PARYLENE_UNMASKING

Component Information

Serial Number	20UPGFC0230279
ProdDB ID	1adc6b…92178a
LocalDB ID	670e5cade1231800423b5004
Component Type	fe_chip
Parents	20UPGM23622030 20UPGB43347167
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Target Iref trim	14
Target Iref trim version	1
Wafer serial number	None

Comments

Test: ANALOG_READBACK QC Passed

(Stage: MODULE/INITIAL_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	4 months ago
component ObjectId	670e5cade1231800423b5004
Stage	MODULE/INITIAL_WARM
Test Type	ANALOG_READBACK
Institute ObjectId
User Name	Shift-LeaderHayashi-REPIC-KEK
ObjectId of this record	693657d4ec9c78c6fb7f4705
ObjectId of RAW record	693657c8ec9c78c6fb7f46d5
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.7.1
MEASUREMENT_DATE	2025-12-08T04:04:22.000+00:00
MEASUREMENT_DURATION	174
MEASUREMENT_VERSION	2.7.1
YARR_VERSION	v1.5.5
AR_IREF_TRIM	14
AR_IREF	3.9e-06
AR_GADC	0.835
AR_NOMINAL_SETTINGS	[3.9e-06, 8.59e-05, 4.73e-05, 3.9e-06, 3.89e-05, 1.93e-05, 0, 3.73e-05, 7.23e-05, -999, 0, 0, 4.74e-05, 6.85e-05, 5.35e-05, 8.65e-05, 6.67e-05, 7.79e-05, 9.16e-05, 8.65e-05, 6.43e-05, 4.8e-05, 4.75e-05, 6.65e-05, 4.83e-05, 4.79e-05, -999, -999, 0.6402291, 0.045717, 0.9254684, 0.3036914, 0.8345312, -999, -999, 0.83975, 1.218875, 0.1185312, 0.1119062, 0.0370312, 0.0404375, 0.0409063, 0.2551563, 0.2429062, 0.2520938, 0.6390312, -999, 0.635625, -999, 0.5895937, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, 0.018375, 0.466125, 1.9401412, 1.508625, 1.221, 0.6014688, 0.9945, 1.5145, 1.2149375, 0.5980938]
AR_ROSC_MAX_RESIDUAL	[3.824057193651451, 6.250510927559857, 3.479623814156672, 6.08249908965687, 2.8921061135437367, 4.922575999488036, 3.239429552718076, 5.241232169403627, 5.624321193523741, 5.803092925061868, 6.754935082591002, 6.7277243281708285, 5.569413248409991, 5.4687673348894394, 6.584220042301053, 6.639355725636368, 5.136149228011174, 4.829627031526817, 5.519477922103642, 5.531720782761075, 4.494066606470612, 4.452579884603358, 5.9581271978039, 6.0152796330608105, 3.345573748645632, 3.4484700549349623, 4.026038021896788, 3.924296033551889, 4.274416810331145, 4.12449575982149, 6.605376411940469, 7.413666666916513, 5.6761282514856175, 6.055548884925679, 5.369770538293138, 5.2132864577887155, 5.291282830984538, 5.377749773960335, 5.333758300449466, 5.387508613032827, 5.40375440863922, 5.4652178578548805]
AR_ROSC_OFFSET	[-396.69215480893195, -610.986073017539, -411.5893414565036, -634.2537543340575, -513.4509549657321, -878.084494016272, -644.8630708496603, -947.8934314814002, -640.9159222077152, -647.3391045042769, -765.2138496081095, -777.721563040413, -671.5474090875756, -680.5292811075734, -784.4899821281344, -787.3809920836788, -885.3942646497607, -882.6882723227588, -1046.2139749246073, -1042.5135842789061, -903.0465233620697, -913.6334510810982, -1117.341870292447, -1118.2259671146307, -520.5369372216339, -515.3942783794909, -624.9469718370069, -626.7126278651202, -604.9816520071339, -614.6692698067286, -490.92232894033407, -514.0200577721065, -568.0402351287626, -599.9958385495905, -1008.4019984244287, -1005.5307967600908, -1005.689518671077, -1007.9571183831885, -1008.8431681014828, -1015.8687685374086, -1006.8631068841498, -1009.9027806636525]
AR_ROSC_SLOPE	[721.3988941220722, 1132.7257581104639, 716.1354103646064, 1138.9370200586, 795.0598322958786, 1368.2829217749195, 954.2286897274879, 1425.0924458587479, 1121.2207824631978, 1133.029914614449, 1337.8993100347557, 1345.9261796714666, 1152.9019962448253, 1154.226267466928, 1352.4429354935971, 1353.3814220490497, 1368.7930099421544, 1354.2551936877526, 1606.9538527420577, 1603.4480209226638, 1337.874738540396, 1335.874158525749, 1676.5795025484067, 1680.373310307021, 834.3348564732635, 831.8898322130009, 1004.8685628985287, 1003.8235291255497, 1002.018594754321, 999.2764276650622, 1096.8926255783351, 1176.6201058612291, 1103.239838657583, 1173.1489403239593, 1549.229921109071, 1537.3243625397517, 1541.240310880509, 1547.5016440474176, 1544.8802399905276, 1556.4514315583992, 1547.1782318430471, 1554.5389915586484]
AR_TEMP_ACB	25.077
AR_TEMP_ASLDO	25.676
AR_TEMP_DSLDO	26.938
AR_TEMP_EXT	19.97
AR_TEMP_NF_ACB	1.258
AR_TEMP_NF_ASLDO	1.259
AR_TEMP_NF_BOTTOM	-999
AR_TEMP_NF_DSLDO	1.259
AR_TEMP_NF_TOP	-999
AR_TEMP_NTC	20.75
AR_TEMP_POLY_BOTTOM	-999
AR_TEMP_POLY_TOP	-999
AR_VCALDAC	0.84
AR_VDDA_SATURATION	-1
AR_VDDA_TRIM	7
AR_VDDA_VS_TRIM	[1.032, 1.055, 1.08, 1.103, 1.127, 1.15, 1.176, 1.198, 1.221, 1.244, 1.268, 1.292, 1.315, 1.339, 1.364, 1.387]
AR_VDDD_SATURATION	14
AR_VDDD_TRIM	6
AR_VDDD_VS_TRIM	[1.041, 1.067, 1.089, 1.114, 1.141, 1.166, 1.191, 1.216, 1.246, 1.271, 1.295, 1.321, 1.35, 1.376, 1.391, 1.392]
AR_VREFCORE	0.466
AR_VREFOVP	1.94
