20UPIM13602236 (ANL_ITkPix_33)

MODULE/INITIAL_WARM

View QC Summary

Component Information

Serial Number 20UPIM13602236
ProdDB ID  fcb530…bf8473
LocalDB ID 66b4ff4a7806260043470f6b
Component Type MODULE
Parents No match.
Children 20UPGB43000013 Bare Module 20UPGFC0134228 FE Chip 20UPGPQ3602236 PCB 20UPGFC0134231 FE Chip 20UPGFC0134229 FE Chip 20UPGFC0134227 FE Chip
Flags
Distribution of chips on wafer

 Properties

Item Value
FE chip version 3
PCB-Bare Orientation isNormal True
Alternative ID ANL_ITkPix_33
Wirebond protection roof presence None
Rank None

 Comments


Test: IV_MEASURE QC Passed

(Stage: MODULE/INITIAL_WARM)


Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key Data
QC Passed True
Date a month ago
component ObjectId 66b4ff4a7806260043470f6b
Stage MODULE/INITIAL_WARM
Test Type IV_MEASURE
Institute ObjectId
User Name None
ObjectId of this record 68f80a1f30e2807838791bc4
ObjectId of RAW record 68f80a1c30e2807838791bbd
Tags ganymede_4

Results

Key Data
DCSdata {}
MEASUREMENT_VERSION 2.6.0
QC_LAYER L1
INSTITUTION LBNL_PIXEL_MODULES
MODULE_SN 20UPIM13602236
IV_ARRAY {'time': [3.074781894683838, 9.695030927658081, 16.319754123687744, 22.945127248764038, 29.525466203689575, 36.15300989151001, 42.730117082595825, 49.3650541305542, 55.95617127418518, 62.54623603820801, 69.30171227455139, 75.95804953575134, 82.57136034965515, 89.12759733200073, 95.77615547180176, 102.39298868179321, 108.97177290916443, 115.60213947296143, 122.25303792953491, 128.80660009384155, 135.40412044525146, 142.034987449646, 148.6631143093109, 155.27483415603638, 161.90115809440613, 168.52704668045044, 175.15522861480713, 181.75939798355103, 188.38409042358398, 194.96911907196045, 201.5356273651123, 208.14118432998657, 214.75914216041565, 221.38629698753357, 228.02023029327393, 234.63940405845642, 241.21739172935486, 247.81108832359314, 254.57092428207397, 261.15562438964844, 267.807776927948], 'voltage': [0.012, 5.03, 10.036, 15.018, 19.936, 24.998, 29.994, 35.0, 39.992, 45.006, 49.99, 55.0, 59.98, 64.996, 69.984, 74.992, 79.984, 84.992, 89.992, 94.994, 99.992, 104.99, 109.988, 114.984, 119.994, 125.0, 130.004, 135.002, 140.002, 144.996, 150.002, 154.994, 160.006, 164.996, 170.006, 174.994, 179.998, 184.986, 189.996, 194.986, 199.994], 'current': [0.03, 0.0325, 0.04000000000000001, 0.05900000000000001, 0.07, 0.0775, 0.08850000000000002, 0.097, 0.096, 0.1055, 0.112, 0.1135, 0.12, 0.128, 0.134, 0.138, 0.14850000000000002, 0.154, 0.161, 0.1645, 0.171, 0.17400000000000004, 0.185, 0.1875, 0.1985, 0.20400000000000001, 0.207, 0.21650000000000005, 0.2235, 0.2315, 0.24400000000000002, 0.247, 0.2595, 0.263, 0.275, 0.28500000000000003, 0.2895, 0.2995, 0.30600000000000005, 0.3175, 0.3245], 'sigma current': [0.0, 0.0, 6.6174449004242214e-18, 6.6174449004242214e-18, 0.0, 0.0, 1.3234889800848443e-17, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 2.6469779601696886e-17, 0.0, 0.0, 0.0, 0.0, 0.0, 2.6469779601696886e-17, 2.6469779601696886e-17, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0, 0.0], 'temperature': [17.4375, 17.473, 17.2484, 17.4621, 17.503, 17.4812, 17.7317, 17.7018, 17.6909, 17.9213, 17.8374, 17.8618, 18.094, 18.0751, 18.2794, 18.2499, 18.4319, 18.3918, 18.536, 18.4987, 18.6319, 18.5733, 18.6983, 18.6664, 18.7249, 18.7434, 18.7594, 18.8256, 18.7726, 18.8547, 19.0106, 18.9235, 19.0712, 18.9816, 19.0975, 19.0949, 19.1212, 19.087, 19.1317, 19.2683, 19.1843], 'humidity': []}
BREAKDOWN_VOLTAGE -999
BREAKDOWN_REDUCTION 0.0
NO_BREAKDOWN_VOLTAGE_OBSERVED True
MAXIMUM_VOLTAGE 199.994
LEAK_CURRENT 0.20617479325924576
LEAK_INCREASE_FACTOR 0.0
LEAK_PER_AREA 0.01
ANALYSIS_VERSION mqat v2.6.4
TEMP 18.42
HUM 0
MEASUREMENT_DATE 2025-10-21T22:26:17.000+00:00
MEASUREMENT_DURATION 400

Attachments

Filename Contents
output.log Download

RAW Results Record

Download RAW
