20UPGFC0156341

MODULE/POST_PARYLENE_COLD

Component Information

Serial Number	20UPGFC0156341
ProdDB ID	3ed1fa…82cbed
LocalDB ID	66146a09ec873d00355a58f0
Component Type	fe_chip
Parents	20UPIM13710116 20UPGB43000045
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Wafer serial number	None
Target Iref trim	None
Target Iref trim version	None

Comments

Test: ANALOG_READBACK QC Passed

(Stage: MODULE/POST_PARYLENE_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	4 months ago
component ObjectId	66146a09ec873d00355a58f0
Stage	MODULE/POST_PARYLENE_WARM
Test Type	ANALOG_READBACK
Institute ObjectId
User Name	None
ObjectId of this record	688d0daeb23cfb8a0b24690b
ObjectId of RAW record	688d0da6b23cfb8a0b2468e8
Tags	No tags

Results

Key	Data
DCSdata	{}
MEASUREMENT_VERSION	2.6.0
QC_LAYER	L1
INSTITUTION	LBNL_PIXEL_MODULES
AR_TEMP_NTC	21.18
AR_TEMP_EXT	19.996
AR_TEMP_ASLDO	27.97
AR_TEMP_DSLDO	30.12
AR_TEMP_ACB	27.311
AR_TEMP_NF_ASLDO	1.256
AR_TEMP_NF_DSLDO	1.255
AR_TEMP_NF_ACB	1.255
AR_TEMP_POLY_TOP	-999
AR_TEMP_POLY_BOTTOM	-999
AR_TEMP_NF_TOP	-999
AR_TEMP_NF_BOTTOM	-999
AR_IREF	3.8e-06
AR_GADC	0.791
AR_VCALDAC	0.793
AR_VREFCORE	0.454
AR_VREFOVP	2.012
AR_NOMINAL_SETTINGS	[3.8e-06, 8.32e-05, 4.6e-05, 4.1e-06, 3.75e-05, 1.92e-05, -0.0, 3.7e-05, 6.98e-05, -999, -0.0, 0.0, 2.65e-05, 6.01e-05, 4.9e-05, 8.21e-05, 5.79e-05, 7.87e-05, 7.57e-05, 8.21e-05, 6.47e-05, 2.87e-05, 2.95e-05, 6.29e-05, 2.85e-05, 2.81e-05, -999, -999, 0.6918662, 0.0787087, 0.9140889, 0.5581305, 0.7908794, -999, -999, 0.7934168, 1.1825888, 0.1092074, 0.1046694, 0.0362443, 0.0369978, 0.0391692, 0.2226594, 0.2512064, 0.2427434, 0.6281934, -999, 0.6240744, -999, 0.5948584, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, 0.0184476, 0.4538414, 2.012297, 1.4668856, 1.1897588, 0.5856424, 0.9726856, 1.4756736, 1.1980568, 0.5887884]
AR_VDDA_VS_TRIM	[0.997, 1.023, 1.047, 1.072, 1.093, 1.118, 1.143, 1.168, 1.19, 1.215, 1.239, 1.264, 1.285, 1.31, 1.334, 1.36]
AR_VDDD_VS_TRIM	[1.005, 1.027, 1.053, 1.074, 1.102, 1.124, 1.149, 1.171, 1.197, 1.219, 1.244, 1.267, 1.294, 1.318, 1.344, 1.352]
AR_VDDA_TRIM	8
AR_VDDD_TRIM	8
AR_ROSC_SLOPE	[723.8256691687861, 1126.94673044214, 715.5337011289433, 1135.508610130169, 774.0343076321401, 1339.1699177125977, 945.3266043918966, 1382.0892100563597, 1125.8902241566464, 1125.0463827379215, 1333.9415888794997, 1332.3323679529171, 1158.086053432403, 1154.5775967506752, 1344.3161669520935, 1342.1749672186543, 1327.2061572698246, 1318.522907490677, 1580.262161273555, 1570.9399437468578, 1314.702701058552, 1319.842277954387, 1637.7584466956278, 1637.2292691037808, 811.8124594188479, 813.6355845157204, 987.4471563875862, 976.5535671182686, 973.792439489036, 982.3865882919671, 1111.3096451924666, 1178.7244256576173, 1090.8970036656574, 1160.6817369741264, 1510.4583268979145, 1500.8784166246135, 1509.0606742768548, 1504.6781396717076, 1510.1201038536028, 1497.7389486441082, 1509.489626021682, 1510.99037507442]
AR_ROSC_OFFSET	[-405.32983752525524, -634.9507720667036, -414.56786784367256, -644.6197672398223, -495.6594581438303, -857.5962910331788, -644.2585573440188, -927.2714859640204, -663.4042514462782, -652.6178617116904, -779.1402912820835, -774.6232087097287, -693.3640361048368, -698.3106095196, -793.3134362199133, -796.3159640898218, -857.7333479691467, -855.383110546439, -1021.7671229808234, -1020.8105283741794, -897.7025048914674, -903.0368137568572, -1110.25753279479, -1104.6850843577506, -508.4401806234807, -516.9357986879257, -621.8590038698649, -615.3840081273089, -603.3568434777679, -605.6474143171786, -525.3144165372253, -538.8792408004252, -585.6454352565855, -616.7952205412425, -976.9496630639455, -978.916757886269, -980.2199132516391, -977.1903025002301, -985.3570195084659, -973.9212707064935, -979.3069628150606, -981.6125722425213]
AR_ROSC_MAX_RESIDUAL	[3.9561453630544214, 6.378564484328236, 3.7004230054250167, 6.34518248283588, 3.0506297621975835, 5.208233357878218, 3.500693784176472, 5.312920793286993, 5.564656875156598, 5.616898150235362, 6.77608464954092, 6.778471598246766, 5.494847314748964, 5.41423438410349, 6.719874133996761, 6.5694935406559125, 4.80219460457126, 4.843198809116131, 5.669405529044206, 5.610940135034629, 4.508137506640156, 4.513673824462312, 5.911346561000606, 5.739288787117127, 3.4060565090478265, 3.2803349405962883, 3.9922721549783593, 3.8548499045837255, 4.056064200515471, 4.054813829442651, 6.684794302258022, 7.424849981345519, 5.486222394000338, 5.953519201215182, 5.457518145048352, 5.326132751954823, 5.443000269019183, 5.340180458103628, 5.37421734043024, 5.274240217606975, 5.4954982665941445, 5.392547815276687]
AR_VDDD_SATURATION	-1.0
AR_VDDA_SATURATION	-1.0
AR_IREF_TRIM	7
ANALYSIS_VERSION	mqat v2.6.4
