Database for ITk Pixel Module

Serial Number	20UPGFC0146775
ProdDB ID	a43afb…2c4b2b
LocalDB ID	6610032c2fc9f2003515ab89
Component Type	fe_chip
Parents	20UPGM24210577 20UPGB43200364
Children	No match.
Flags

Item	Value
Wafer serial number	None
Target Iref trim	None
Target Iref trim version	None

Key	Data
QC Passed	True
Date	2 months ago
component ObjectId	6610032c2fc9f2003515ab89
Stage	MODULE/INITIAL_WARM
Test Type	INJECTION_CAPACITANCE
Institute ObjectId
User Name	DanielAceves
ObjectId of this record	68dec9e112752b66da91008b
ObjectId of RAW record	68dec9df12752b66da910080
Tags	No tags

Key	Data
ANALYSIS_VERSION	mqat v2.6.4
MEASUREMENT_DATE	None
MEASUREMENT_DURATION	None
MEASUREMENT_VERSION	2.6.0
YARR_VERSION	None
INJ_CAPACITANCE	6.67

Filename	Contents
output.log	Download

_id

68dec9df12752b66da910080

raw

serialNumber

testType

runNumber

results

subtestType

stage

component

dbVersion

address

sys

20UPGFC0146775

INJECTION_CAPACITANCE

68dec9cc9b7ba1efb992f5ce

DCSdata

SensorVoltage	-120.0
SensorCurrent	4.5e-07
ModuleNTC	20.0

Measurements

Vmux4

X	False
Unit	V
Values	0.6099705 0.6101891 0.6101779 0.6103413 0.6101302

Vmux30

X	False
Unit	V
Values	0.0174447 0.0174447 0.0174447 0.0174447 0.0174447

Imux10

X	False
Unit	V
Values	0.1084079 0.1084676 0.1084272 0.1083936 0.108389

Imux11

X	False
Unit	V
Values	0.03127778 0.0312711 0.03127859 0.03127608 0.03126314

Imux63

X	False
Unit	V
Values	0.01504805 0.01504805 0.01504805 0.01504805 0.01504805

Metadata

FirmwareVersion

FirmwareIdentifier

ChannelConfig

SoftwareVersion

ChipConfigs

ITKPIXV2

GlobalConfig

AiRegionRow	0
AuroraActiveLanes	1
AuroraAltOutput0	0
AuroraAltOutput1	0
AuroraCBSend	0
AuroraCBWait0	4095
AuroraCBWait1	0
AuroraCCSend	3
AuroraCCWait	25
AuroraEnPrbs	0
AuroraInitWait	32
AuroraSendAlt	0
AutoRead0	134
AutoRead1	135
AutoRead2	137
AutoRead3	138
AutoRead4	140
AutoRead5	151
AutoRead6	152
AutoRead7	156
BcidCnt	0
BitFlipErrCnt	0
BitFlipWngCnt	0
CapMeasEn	0
CapMeasEnPar	0
CdrClkSel	0
CdrCp	40
CdrCpBuff	200
CdrCpFd	400
CdrPhaseDetSel	0
CdrVco	1023
CdrVcoBuff	500
ChSyncLockThr	31
ChipIdSense	0
Clk160En	7
Clk40En	7
ClkAuroraEn	7
ClkDataMergeEn	7
CmdErrCnt	0
CmlBias0	800
CmlBias1	400
CmlBias2	0
DataDecodingValues	0
DataEnBcid	0
DataEnBinaryRo	0
DataEnCrc	0
DataEnL1id	0
DataEnRaw	0
DataMaxHits	0
DataMaxTot	0
DataMergeEn	0
DataMergeEnBond	0
DataMergeEnClkGate	0
DataMergeFixedMode	0
DataMergeGpoSel	0
DataMergeInMux0	0
DataMergeInMux1	1
DataMergeInMux2	2
DataMergeInMux3	3
DataMergeInPol	0
DataMergeManChoice	0
DataMergeManMode	0
DataMergeOutMux0	1
DataMergeOutMux1	2
DataMergeOutMux2	3
DataMergeOutMux3	0
DataMergeSelClk	0
DataReadDelay	0
DiffComp	500
DiffFbCapEn	0
DiffLcc	200
DiffLccEn	1
DiffPreComp	350
DiffPreampL	550
DiffPreampM	550
DiffPreampR	550
DiffPreampT	550
DiffPreampTL	550
DiffPreampTR	550
DiffTh1L	350
DiffTh1M	350
DiffTh1R	350
DiffTh2	50
DiffVff	60
EfuseConfig	3855
EfuseReadData0	22300
EfuseReadData1	8765
EfuseWriteData0	0
EfuseWriteData1	0
EnChipId	0
EnCoreCol0	65535
EnCoreCol1	65535
EnCoreCol2	65535
EnCoreCol3	63
EnCoreColCal0	0
EnCoreColCal1	0
EnCoreColCal2	0
EnCoreColCal3	0
EnHitsRemoval0	0
EnHitsRemoval1	0
EnHitsRemoval2	0
EnHitsRemoval3	0
EnIsoHitsRemoval0	0
EnIsoHitsRemoval1	0
EnIsoHitsRemoval2	0
EnIsoHitsRemoval3	0
ErrWngMask	0
EvenMask	0
FineDelayClk	0
FineDelayData	0
GatedHitOrCnt0	0
GatedHitOrCnt1	0
GcrDefaultConfig	44149
GcrDefaultConfigB	21386
GlobalConfigSeuCnt	0
GlobalPulseConf	0
GlobalPulseWidth	10
GpCmosDs	0
GpCmosEn	1
GpCmosRoute	34
GpLvdsBias	7
GpLvdsEn	15
GpLvdsPad0	0
GpLvdsPad1	1
GpLvdsPad2	33
GpLvdsPad3	35
GpValReg	5
HitOrCnt0	0
HitOrCnt1	0
HitOrCnt2	0
HitOrCnt3	0
HitOrMask0	0
HitOrMask1	0
HitOrMask2	0
HitOrMask3	0
InjAnaMode	0
InjDigEn	0
InjFineDelay	5
InjVcalHigh	200
InjVcalMed	200
InjVcalRange	1
IrefTrimSense	0
Latency	500
LinComp	110
LinCompTa	110
LinFc	20
LinGdacL	408
LinGdacM	408
LinGdacR	408
LinKrumCurr	50
LinLdac	100
LinPreampL	300
LinPreampM	300
LinPreampR	300
LinPreampT	300
LinPreampTL	300
LinPreampTR	300
LinRefKrum	300
LockLossCnt	0
MonAdcTrim	0
MonSensAcbDem	0
MonSensAcbEn	0
MonSensAcbSelBias	0
MonSensSldoAnaDem	0
MonSensSldoAnaEn	0
MonSensSldoAnaSelBias	0
MonSensSldoDigDem	0
MonSensSldoDigEn	0
MonSensSldoDigSelBias	0
MonitorEnable	1
MonitorI	63
MonitorV	32
MonitoringDataAdc	0
NtcDac	100
NumOfEventsInStream	0
OddMask	0
PixAutoRow	1
PixBroadcast	0
PixConfMode	1
PixDefaultConfig	40162
PixDefaultConfigB	25373
PixEnSeuCount	0
PixHitSampleMode	0
PixPortal	0
PixRegionCol	199
PixRegionRow	0
PixelSeuCntCnt	0
PtotCoreColEn0	0
PtotCoreColEn1	0
PtotCoreColEn2	0
PtotCoreColEn3	0
RdWrFifoErrCnt	0
ReadTrigCnt	0
ReadTrigLatency	0
RingOscAClear	0
RingOscAEn	0
RingOscAOut	0
RingOscARoute	0
RingOscBClear	0
RingOscBEnBl	0
RingOscBEnBr	0
RingOscBEnCapA	0
RingOscBEnFf	0
RingOscBEnLvt	0
RingOscBOut	0
RingOscBRoute	0
RstCoreCol0	0
RstCoreCol1	0
RstCoreCol2	0
RstCoreCol3	0
SelfTrigDeadtime	64
SelfTrigDelay	512
SelfTrigDigThr	1
SelfTrigDigThrEn	0
SelfTrigEn	0
SelfTrigMulti	4
SelfTrigPattern	65534
SerEnLane	15
SerEnTap	1
SerInvTap	1
SerSelOut0	3
SerSelOut1	3
SerSelOut2	3
SerSelOut3	1
ServiceBlockEn	1
ServiceBlockPeriod	50
SkippedTrigCnt	0
SldoEnUndershuntA	0
SldoEnUndershuntD	0
SldoTrimA	7
SldoTrimD	7
TotEn6b4b	0
TotEn80	0
TotEnPtoa	0
TotEnPtot	0
TotPtotLatency	500
TrigCnt	0
TruncTimeoutConf	0
TwoLevelTrig	0
VrefIn	1
VrefRsensBot	0
VrefRsensTop	0

Parameter

ADCcalPar	12.0 0.189 10000.0
ChipId	14
EnforceNameIdCheck	True
InjCap	7.501
IrefTrim	9
KSenseInA	20553.506
KSenseInD	21487.574
KSenseShuntA	21141.0
KSenseShuntD	22102.0
KShuntA	989.777
KShuntD	989.071
Name	0x23d57
NfACB	1.2611291
NfASLDO	1.2627146
NfDSLDO	1.2616719
NtcCalPar	0.0007489 0.0002769 7.0595e-08
VcalPar	-1.0 0.2

SoftwareType

ChipID

Name

0x23d57

Institution

ANL_PIXEL_MODULES

ModuleSN

20UPGM24210577

TimeStart

1759431024

TimeEnd

1759431116

comment

property

YARR_VERSION	v1.5.5
INJECTION_CAPACITANCE_MEASUREMENT_VERSION	2.6.0

MODULE/INITIAL_WARM

6610032c2fc9f2003515ab89

1.01

64657cef8d79bac1f3f00578

mts	2025-10-02 18:52:15.569000
cts	2025-10-02 18:52:15.569000
rev	0

rawHash

dcf8707869a97779e0752d1645e45f5d

stage

MODULE/INITIAL_WARM
