20UPGFC0146117

MODULE/FINAL_COLD

Component Information

Serial Number	20UPGFC0146117
ProdDB ID	fddce8…d38918
LocalDB ID	660fbeb2ec873d00354e22e0
Component Type	fe_chip
Parents	20UPGM24211761 20UPGB43200441
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Target Iref trim	9
Target Iref trim version	1
Wafer serial number	None

Comments

Test: TUNING QC Passed

(Stage: MODULE/FINAL_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	5 days ago
component ObjectId	660fbeb2ec873d00354e22e0
Stage	MODULE/FINAL_WARM
Test Type	TUNING
Institute ObjectId
User Name	None
ObjectId of this record	6a2a0086a2083033ec8cd7cc
ObjectId of RAW record	None
Tags	No tags
Tuning Config	Associated FE Config

Results

Key	Data
DCSdata	{}
QC_LAYER	L2
TUNING_UNTUNED_THRESHOLD_MEAN	2418.822
TUNING_UNTUNED_THRESHOLD_95_LOW	1807.923
TUNING_UNTUNED_THRESHOLD_95_HIGH	3089.319
TUNING_UNTUNED_THRESHOLD_SIGMA	325.606
TUNING_UNTUNED_TDAC_MEAN	0.0
TUNING_UNTUNED_TDAC_SIGMA	0.0
TUNING_UNTUNED_NOISE_MEAN	101.082
TUNING_UNTUNED_NOISE_SIGMA	11.43
TUNING_UNTUNED_NOISE_95_LOW	80.935
TUNING_UNTUNED_NOISE_95_HIGH	122.68
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	3151
TUNING_TUNED_THRESHOLD_MEAN	1503.9
TUNING_TUNED_THRESHOLD_95_LOW	1437.739
TUNING_TUNED_THRESHOLD_95_HIGH	1565.203
TUNING_TUNED_THRESHOLD_SIGMA	34.0
TUNING_TUNED_TDAC_MEAN	-1.6
TUNING_TUNED_TDAC_SIGMA	4.669
TUNING_TUNED_NOISE_MEAN	102.095
TUNING_TUNED_NOISE_SIGMA	11.138
TUNING_TUNED_NOISE_95_LOW	81.736
TUNING_TUNED_NOISE_95_HIGH	123.711
TUNING_TUNED_TOT_MEAN	7.3
TUNING_TUNED_TOT_SIGMA	0.3
TUNING_TUNED_TOT_95_LOW	5.0
TUNING_TUNED_TOT_95_HIGH	10.14
TUNING_TUNED_THRESHOLD_FAILED_FITS	3079
TUNING_ANY_ERRORS	{'tune_globalthreshold': 0, 'thresholdscan_hr': 124, 'tune_pixelthreshold': 8, 'thresholdscan_hd': 26, 'totscan': 0, 'all': 158}
ANALYSIS_VERSION	mqat v2.9.0
YARR_VERSION	v1.6.0
MEASUREMENT_DATE	2026-06-10T09:51:49.000+00:00
MEASUREMENT_DURATION	657

Attachments

Filename	Contents
output.log	Download
0x23ac5.log	Download
20UPGFC0146117_MODULE__FINAL_WARM_TUNING.zip	Download
