20UPGFC0146117

MODULE/FINAL_COLD

Component Information

Serial Number	20UPGFC0146117
ProdDB ID	fddce8…d38918
LocalDB ID	660fbeb2ec873d00354e22e0
Component Type	fe_chip
Parents	20UPGM24211761 20UPGB43200441
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Target Iref trim	9
Target Iref trim version	1
Wafer serial number	None

Comments

Test: TUNING QC Passed

(Stage: MODULE/QC_CROSSCHECK)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	a week ago
component ObjectId	660fbeb2ec873d00354e22e0
Stage	MODULE/QC_CROSSCHECK
Test Type	TUNING
Institute ObjectId
User Name	None
ObjectId of this record	6a22094fa9167d9dd0fe5435
ObjectId of RAW record	None
Tags	No tags
Tuning Config	Associated FE Config

Results

Key	Data
DCSdata	{}
QC_LAYER	L2
TUNING_UNTUNED_THRESHOLD_MEAN	2423.182
TUNING_UNTUNED_THRESHOLD_95_LOW	1811.448
TUNING_UNTUNED_THRESHOLD_95_HIGH	3095.052
TUNING_UNTUNED_THRESHOLD_SIGMA	326.286
TUNING_UNTUNED_TDAC_MEAN	0.0
TUNING_UNTUNED_TDAC_SIGMA	0.0
TUNING_UNTUNED_NOISE_MEAN	101.061
TUNING_UNTUNED_NOISE_SIGMA	11.468
TUNING_UNTUNED_NOISE_95_LOW	81.028
TUNING_UNTUNED_NOISE_95_HIGH	122.662
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	3176
TUNING_TUNED_THRESHOLD_MEAN	1503.0
TUNING_TUNED_THRESHOLD_95_LOW	1436.958
TUNING_TUNED_THRESHOLD_95_HIGH	1564.41
TUNING_TUNED_THRESHOLD_SIGMA	34.0
TUNING_TUNED_TDAC_MEAN	-1.5
TUNING_TUNED_TDAC_SIGMA	4.678
TUNING_TUNED_NOISE_MEAN	102.074
TUNING_TUNED_NOISE_SIGMA	11.233
TUNING_TUNED_NOISE_95_LOW	81.568
TUNING_TUNED_NOISE_95_HIGH	124.105
TUNING_TUNED_TOT_MEAN	7.3
TUNING_TUNED_TOT_SIGMA	0.3
TUNING_TUNED_TOT_95_LOW	5.0
TUNING_TUNED_TOT_95_HIGH	10.11
TUNING_TUNED_THRESHOLD_FAILED_FITS	3079
TUNING_ANY_ERRORS	{'tune_globalthreshold': 0, 'thresholdscan_hr': 49, 'tune_pixelthreshold': 2, 'thresholdscan_hd': 9, 'totscan': 0, 'all': 60}
ANALYSIS_VERSION	mqat v2.9.0
YARR_VERSION	v1.6.0
MEASUREMENT_DATE	2026-06-05T05:39:36.000+00:00
MEASUREMENT_DURATION	656

Attachments

Filename	Contents
output.log	Download
0x23ac5.log	Download
20UPGFC0146117_MODULE__QC_CROSSCHECK_TUNING.zip	Download
