20UPGFC0146117

MODULE/FINAL_COLD

Component Information

Serial Number	20UPGFC0146117
ProdDB ID	fddce8…d38918
LocalDB ID	660fbeb2ec873d00354e22e0
Component Type	fe_chip
Parents	20UPGM24211761 20UPGB43200441
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Target Iref trim	9
Target Iref trim version	1
Wafer serial number	None

Comments

Test: ANALOG_READBACK QC Passed

(Stage: MODULE/QC_CROSSCHECK)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	2 weeks ago
component ObjectId	660fbeb2ec873d00354e22e0
Stage	MODULE/QC_CROSSCHECK
Test Type	ANALOG_READBACK
Institute ObjectId
User Name	None
ObjectId of this record	6a21ebd53414dfb500e5273a
ObjectId of RAW record	6a21ebcd3414dfb500e52717
Tags	ganymede_3

Results

Key	Data
DCSdata	{}
MEASUREMENT_VERSION	2.8.1.dev0
QC_LAYER	L2
INSTITUTION	LBNL_PIXEL_MODULES
AR_TEMP_NTC	20.105
AR_TEMP_EXT	20.002
AR_TEMP_ASLDO	25.199
AR_TEMP_DSLDO	26.59
AR_TEMP_ACB	24.454
AR_TEMP_NF_ASLDO	1.258
AR_TEMP_NF_DSLDO	1.257
AR_TEMP_NF_ACB	1.257
AR_TEMP_POLY_TOP	-999
AR_TEMP_POLY_BOTTOM	-999
AR_TEMP_NF_TOP	-999
AR_TEMP_NF_BOTTOM	-999
AR_IREF	3.7e-06
AR_GADC	0.819
AR_VCALDAC	0.822
AR_VREFCORE	0.46
AR_VREFOVP	1.979
AR_NOMINAL_SETTINGS	[3.7e-06, 8.69e-05, 4.65e-05, 3.9e-06, 3.75e-05, 1.99e-05, 0.0, 3.7e-05, 6.96e-05, -999, 0.0, 0.0, 4.53e-05, 6.43e-05, 5.07e-05, 8.64e-05, 6.36e-05, 7.46e-05, 8.49e-05, 8.64e-05, 6.49e-05, 4.57e-05, 4.54e-05, 6.29e-05, 4.66e-05, 4.67e-05, -999, -999, 0.6273993, 0.0480896, 0.902475, 0.2514552, 0.8189694, -999, -999, 0.8215348, 1.2191848, 0.1185654, 0.1134094, 0.0343414, 0.0385033, 0.0405728, 0.2441024, 0.2411154, 0.2393574, 0.6374054, -999, 0.6355424, -999, 0.5965844, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, 0.0171776, 0.4598254, 1.9787639, 1.5010976, 1.2258888, 0.6102654, 0.9922416, 1.5081016, 1.2338608, 0.6066494]
AR_VDDA_VS_TRIM	[0.982, 1.006, 1.031, 1.056, 1.081, 1.106, 1.13, 1.154, 1.176, 1.203, 1.226, 1.25, 1.274, 1.298, 1.322, 1.346]
AR_VDDD_VS_TRIM	[1.012, 1.035, 1.059, 1.083, 1.107, 1.132, 1.155, 1.179, 1.209, 1.232, 1.256, 1.281, 1.305, 1.33, 1.355, 1.381]
AR_VDDA_TRIM	9
AR_VDDD_TRIM	8
AR_ROSC_SLOPE	[731.688133509887, 1131.505155959029, 731.531952741022, 1137.0362092381872, 783.7020399848136, 1352.2157891825334, 944.8242498636071, 1390.5557346388396, 1137.294729802396, 1134.8686945492366, 1335.5272522770676, 1336.7612011677136, 1166.176213742454, 1169.567358071595, 1346.3951120922236, 1343.9989488636102, 1328.7368657595307, 1327.1660531971063, 1586.3247407653134, 1579.0134201668798, 1330.9098581734909, 1316.4158146419065, 1638.425708231543, 1635.154335218068, 819.9094948574284, 816.7633522383234, 989.597433668977, 988.7412333295568, 988.3940000361872, 989.8694360353576, 1121.993396233471, 1183.789038190392, 1103.8637097601822, 1171.3549007545496, 1517.45576332212, 1519.0674240496867, 1519.3162722209636, 1512.2731227403187, 1517.049684616879, 1516.814609181033, 1518.5193395817864, 1524.127212749114]
AR_ROSC_OFFSET	[-419.3519703502073, -645.7632454197966, -438.05310782064026, -661.2073713287316, -520.1715135311871, -890.1657468649975, -650.3489069756413, -948.9734976698137, -679.6159735680011, -678.1141346548354, -797.6571960541726, -796.3478980970841, -710.3301954533503, -714.0308083473849, -816.217742461366, -808.2971466707426, -883.9131102827725, -879.0451666208022, -1058.2304869704017, -1055.7685467856118, -917.5252648221568, -918.7755503599311, -1126.2043326023831, -1126.5423429874772, -529.5112371844951, -522.4034539421373, -635.7198981273846, -640.7097101242797, -621.5199575166731, -626.4447911975064, -551.0268044848658, -560.3011984878158, -601.4343734014157, -634.811687677203, -1013.1122889630415, -1013.6740236923787, -1015.0089477474726, -1011.7127619001269, -1018.5802484870616, -1011.6712127678833, -1012.6986145148438, -1012.4674978950308]
AR_ROSC_MAX_RESIDUAL	[3.006255132866274, 5.073684508719176, 2.870236887455439, 4.876345300623198, 1.75209234698689, 3.210565539939739, 2.069935910680624, 3.1984677177706047, 4.257553082507882, 4.313716631239048, 5.111376011757122, 5.152469254733242, 4.074738297175626, 4.121004637679472, 4.930434289445103, 4.996984334882363, 2.9617741324892117, 2.979170640269209, 3.2192178805044764, 3.10019051256702, 2.7283926009680926, 2.4921928222145566, 3.131680722227239, 3.2357220797435047, 2.147474883290647, 2.1609003554589523, 2.5226890114656872, 2.4699574155896036, 2.8740421341582105, 2.7943453215172216, 5.3234213343525765, 5.9255211047281104, 4.193471136730679, 4.47222969138368, 3.1703015595942943, 3.184574841064598, 3.1490747030312725, 3.054473395051259, 3.151311942243732, 3.1763330263382534, 3.1740294629244215, 3.138152481684072]
AR_VDDD_SATURATION	-1.0
AR_VDDA_SATURATION	-1.0
AR_IREF_TRIM	9
ANALYSIS_VERSION	mqat v2.9.0
YARR_VERSION	v1.6.0
MEASUREMENT_DATE	2026-06-04T19:53:56.000+00:00
MEASUREMENT_DURATION	593

Attachments

Filename	Contents
output.log	Download
0x23ac5.log	Download

RAW Results Record

Download RAW

_id

6a21ebcd3414dfb500e52717

raw

serialNumber

testType

runNumber

results

subtestType

stage

component

dbVersion

address

sys

20UPGFC0146117

ANALOG_READBACK

6a21ebb0abde234a6c5af393

DCSdata

SensorVoltage	-120.012
SensorCurrent	-2.96e-07
ModuleNTC	19.893215819

Measurements

Vmux0

X	False
Unit	V
Values	0.836147

Vmux3

X	False
Unit	V
Values	0.427945

Vmux4

X	False
Unit	V
Values	0.62677

Vmux5

X	False
Unit	V
Values	0.135743

Vmux6

X	False
Unit	V
Values	0.130587
