20UPGFC0146117

MODULE/FINAL_COLD

Component Information

Serial Number	20UPGFC0146117
ProdDB ID	fddce8…d38918
LocalDB ID	660fbeb2ec873d00354e22e0
Component Type	fe_chip
Parents	20UPGM24211761 20UPGB43200441
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Target Iref trim	9
Target Iref trim version	1
Wafer serial number	None

Comments

Test: ANALOG_READBACK QC Passed

(Stage: MODULE/INITIAL_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	3 months ago
component ObjectId	660fbeb2ec873d00354e22e0
Stage	MODULE/INITIAL_WARM
Test Type	ANALOG_READBACK
Institute ObjectId
User Name	DavidJiang
ObjectId of this record	690d22b54f9fcd332811a655
ObjectId of RAW record	690d22b04f9fcd332811a631
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.6.4
MEASUREMENT_DATE	2025-11-06T20:28:58.000+00:00
MEASUREMENT_DURATION	227
MEASUREMENT_VERSION	2.6.0
YARR_VERSION	v1.5.5
AR_IREF_TRIM	9
AR_IREF	3.7e-06
AR_GADC	0.818
AR_NOMINAL_SETTINGS	[3.7e-06, 8.59e-05, 4.65e-05, 3.9e-06, 3.75e-05, 1.99e-05, 0, 3.71e-05, 6.92e-05, -999, 0, 0, 4.53e-05, 6.4e-05, 5.06e-05, 8.58e-05, 6.32e-05, 7.4e-05, 8.43e-05, 8.58e-05, 6.45e-05, 4.56e-05, 4.53e-05, 6.26e-05, 4.65e-05, 4.67e-05, -999, -999, 0.6356693, 0.0574828, 0.9039507, 0.2619351, 0.817735, -999, -999, 0.8201443, 1.1966421, 0.1177104, 0.1136881, 0.0343394, 0.0384587, 0.0404021, 0.242347, 0.2394636, 0.2373648, 0.6302104, -999, 0.6286336, -999, 0.5961618, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, 0.017233, 0.4597092, 1.9809849, 1.5021734, 1.2024261, 0.598631, 0.9918994, 1.508861, 1.2086645, 0.5946386]
AR_ROSC_MAX_RESIDUAL	[3.021134066758833, 5.009241409893805, 2.893506838634558, 4.860573895152653, 1.7558890343924074, 3.290579894417834, 2.063283725698114, 3.344078753842704, 4.180600172660767, 4.176982961876847, 4.958160971910672, 5.030326121172391, 3.9928617498156287, 4.104213051242027, 4.833614025117884, 4.8321069522757405, 2.8840988373125103, 2.877607721384258, 3.211815809185039, 3.0949572075269676, 2.6496361342783903, 2.4808014879102687, 3.137777728076843, 3.1894369607840867, 2.1024221975449713, 2.191344560027674, 2.475780016094012, 2.408506865773284, 2.805426063419031, 2.7419431645589967, 5.2977531149033785, 5.954307787603999, 4.164091576732451, 4.4322070571617465, 3.0631941877261726, 3.067792882829358, 3.026951356197853, 2.94153771438293, 2.9408236278297757, 2.9462108328575507, 3.0158152753699436, 3.008884643596771]
AR_ROSC_OFFSET	[-416.44206630163416, -640.1764480810982, -435.5007411991835, -655.162926333035, -515.6915119613278, -882.7525622898521, -644.0012897657558, -938.1302754857817, -671.6960551033577, -672.3568051487276, -789.2519799382962, -788.4085093962709, -702.8187287467537, -706.9836402863878, -807.1240083945116, -799.4095592547282, -875.3876230146204, -871.4880228982298, -1048.940393991984, -1046.444008236634, -906.5366145206347, -908.1265900445051, -1112.6697400679113, -1113.057438365093, -524.1540863037629, -517.5473598399863, -628.8610591656209, -635.3404840635818, -616.6603457255513, -622.1146117970195, -545.5019070245569, -553.5211151571464, -593.2682185255825, -626.5816111060161, -1003.2362434201992, -1002.3452672960442, -1006.754445376079, -1001.7395265506324, -1009.1103800671656, -1003.7001829011332, -1003.1887309617026, -1003.6780621284122]
AR_ROSC_SLOPE	[728.5423631509927, 1125.6403999580805, 728.8042702885502, 1130.8819270674405, 779.1397293035412, 1344.3316143795298, 939.6713320955531, 1381.2233647878911, 1130.0900556332274, 1129.0735157691095, 1327.3477059417044, 1328.8529463332213, 1158.9482352949992, 1162.6616266571687, 1337.673334928735, 1335.5299009132868, 1320.4223892987168, 1319.5962131254125, 1576.8457874610385, 1569.1918278815451, 1321.6947705703997, 1307.3573988895266, 1626.5459263041403, 1623.3102107195436, 814.8573381057946, 812.4066537573394, 983.1301688155413, 983.6500172637188, 983.5621595544255, 985.4909252318964, 1115.724170311941, 1176.20577420251, 1094.854938568777, 1162.0180569724698, 1507.4790169098837, 1508.0368807612485, 1510.6048277334332, 1502.2039094059066, 1507.4358620390447, 1508.4736360749498, 1509.0987523392023, 1515.0021184805923]
AR_TEMP_ACB	28.568
AR_TEMP_ASLDO	29.214
AR_TEMP_DSLDO	30.407
AR_TEMP_EXT	20
AR_TEMP_NF_ACB	1.257
AR_TEMP_NF_ASLDO	1.258
AR_TEMP_NF_BOTTOM	-999
AR_TEMP_NF_DSLDO	1.257
AR_TEMP_NF_TOP	-999
AR_TEMP_NTC	21.834
AR_TEMP_POLY_BOTTOM	-999
AR_TEMP_POLY_TOP	-999
AR_VCALDAC	0.82
AR_VDDA_SATURATION	-1
AR_VDDA_TRIM	9
AR_VDDA_VS_TRIM	[0.983, 1.008, 1.033, 1.057, 1.081, 1.106, 1.13, 1.155, 1.178, 1.202, 1.225, 1.251, 1.275, 1.299, 1.323, 1.346]
AR_VDDD_SATURATION	-1
AR_VDDD_TRIM	8
AR_VDDD_VS_TRIM	[1.011, 1.036, 1.058, 1.084, 1.108, 1.132, 1.156, 1.178, 1.209, 1.232, 1.256, 1.28, 1.306, 1.331, 1.356, 1.38]
AR_VREFCORE	0.46
AR_VREFOVP	1.981

Attachments

Filename	Contents
output.log	Download
0x23ac5.log	Download

RAW Results Record

Download RAW

_id

690d22b04f9fcd332811a631

raw

serialNumber

testType

runNumber

results

subtestType

stage

component

dbVersion

address

sys

20UPGFC0146117

ANALOG_READBACK

690d0c5f2b7c742a94063edd

DCSdata

SensorVoltage	-120.0
SensorCurrent	3.99e-07
ModuleNTC	19.81

Measurements

Vmux0

X	False
Unit	V
Values	0.834968

Vmux3

X	False
Unit	V
Values	0.4273052

Vmux4

X	False
Unit	V
Values	0.6155541

Vmux5

X	False
Unit	V
Values	0.1349435

Vmux6

X	False
Unit	V
Values	0.1309212

Vmux7

X	False
Unit	V
Values	0.05157242

Vmux8

X	False
Unit	V
Values	0.05569174

Vmux9

X	False
Unit	V
Values	0.05763516

Vmux10

X	False
Unit	V
Values	0.2595801

Vmux11

X	False
Unit	V
Values	0.2566967

Vmux12

X	False
Unit	V
Values	0.2545979

Vmux13

X	False
Unit	V
Values	0.6474434

Vmux15

X	False
Unit	V
Values	0.6458666

Vmux17

X	False
Unit	V
Values	0.6133949

Vmux31

X	False
Unit	V
Values	0.4769423

Vmux32

X	False
Unit	V
Values	0.6121234

Vmux33

X	False
Unit	V
Values	0.3927764

Vmux34

X	False
Unit	V
Values	0.6184461

Vmux35

X	False
Unit	V
Values	0.615864

Vmux36

X	False
Unit	V
Values	0.2652079

Vmux37

X	False
Unit	V
Values	0.3944483

Vmux38

X	False
Unit	V
Values	0.6215653

Vmux39

X	False
Unit	V
Values	0.6118716

Vmux63

X	False
Unit	V
Values	0.07016029

Vmux30

X	False
Unit	V
Values	0.01723305

Imux0

X	False
Unit	V
Values	0.05221193

Imux1

X	False
Unit	V
Values	0.8743334

Imux2

X	False
Unit	V
Values	0.4796986

Imux3

X	False
Unit	V
Values	0.05361823

Imux4

X	False
Unit	V
Values	0.3900292

Imux5

X	False
Unit	V
Values	0.2136948

Imux6

X	False
Unit	V
Values	0.01487041

Imux7

X	False
Unit	V
Values	0.3854466

Imux8

X	False
Unit	V
Values	0.7071871

Imux10

X	False
Unit	V
Values	0.0148733

Imux11

X	False
Unit	V
Values	0.01487438

Imux12

X	False
Unit	V
Values	0.467486

Imux13

X	False
Unit	V
Values	0.6546662

Imux14

X	False
Unit	V
Values	0.5213003

Imux15

X	False
Unit	V
Values	0.8725217

Imux16

X	False
Unit	V
Values	0.6473041

Imux17

X	False
Unit	V
Values	0.755167

Imux18

X	False
Unit	V
Values	0.8581243

Imux19

X	False
Unit	V
Values	0.4781906

Imux20

X	False
Unit	V
Values	0.6602852

Imux21

X	False
Unit	V
Values	0.4709239

Imux22

X	False
Unit	V
Values	0.467939

Imux23

X	False
Unit	V
Values	0.6404534

Imux24

X	False
Unit	V
Values	0.4803347

Imux25

X	False
Unit	V
Values	0.4815301

Imux28

X	False
Unit	V
Values	0.3160718

Imux29

X	False
Unit	V
Values	0.0413316

Imux30

X	False
Unit	V
Values	0.4376592

Imux31

X	False
Unit	V
Values	0.1339647

Imux63

X	False
Unit	V
Values	0.01484915

Metadata

FirmwareVersion

FirmwareIdentifier

ChannelConfig

SoftwareVersion

ChipConfigs

ITKPIXV2

GlobalConfig

AiRegionRow	0
AuroraActiveLanes	1
AuroraAltOutput0	0
AuroraAltOutput1	0
AuroraCBSend	0
AuroraCBWait0	4095
AuroraCBWait1	0
AuroraCCSend	3
AuroraCCWait	25
AuroraEnPrbs	0
AuroraInitWait	32
AuroraSendAlt	0
AutoRead0	134
AutoRead1	135
AutoRead2	137
AutoRead3	138
AutoRead4	140
AutoRead5	151
AutoRead6	152
AutoRead7	156
BcidCnt	0
BitFlipErrCnt	0
BitFlipWngCnt	0
CapMeasEn	0
CapMeasEnPar	0
CdrClkSel	0
CdrCp	40
CdrCpBuff	200
CdrCpFd	400
CdrPhaseDetSel	0
CdrVco	1023
CdrVcoBuff	500
ChSyncLockThr	31
ChipIdSense	0
Clk160En	7
Clk40En	7
ClkAuroraEn	7
ClkDataMergeEn	7
CmdErrCnt	0
CmlBias0	800
CmlBias1	400
CmlBias2	0
DataDecodingValues	0
DataEnBcid	0
DataEnBinaryRo	0
DataEnCrc	0
DataEnL1id	0
DataEnRaw	0
DataMaxHits	0
DataMaxTot	0
DataMergeEn	0
DataMergeEnBond	0
DataMergeEnClkGate	0
DataMergeFixedMode	0
DataMergeGpoSel	0
DataMergeInMux0	0
DataMergeInMux1	1
DataMergeInMux2	2
DataMergeInMux3	3
DataMergeInPol	0
DataMergeManChoice	0
DataMergeManMode	0
DataMergeOutMux0	0
DataMergeOutMux1	1
DataMergeOutMux2	2
DataMergeOutMux3	3
DataMergeSelClk	0
DataReadDelay	0
DiffComp	500
DiffFbCapEn	0
DiffLcc	200
DiffLccEn	1
DiffPreComp	350
DiffPreampL	550
DiffPreampM	550
DiffPreampR	550
DiffPreampT	550
DiffPreampTL	550
DiffPreampTR	550
DiffTh1L	350
DiffTh1M	350
DiffTh1R	350
DiffTh2	50
DiffVff	60
EfuseConfig	3855
EfuseReadData0	50448
EfuseReadData1	8762
EfuseWriteData0	0
EfuseWriteData1	0
EnChipId	0
EnCoreCol0	65535
EnCoreCol1	65535
EnCoreCol2	65535
EnCoreCol3	61
EnCoreColCal0	0
EnCoreColCal1	0
EnCoreColCal2	0
EnCoreColCal3	0
EnHitsRemoval0	0
EnHitsRemoval1	0
EnHitsRemoval2	0
EnHitsRemoval3	0
EnIsoHitsRemoval0	0
EnIsoHitsRemoval1	0
EnIsoHitsRemoval2	0
EnIsoHitsRemoval3	0
ErrWngMask	0
EvenMask	0
FineDelayClk	0
FineDelayData	0
GatedHitOrCnt0	0
GatedHitOrCnt1	0
GcrDefaultConfig	44149
GcrDefaultConfigB	21386
GlobalConfigSeuCnt	0
GlobalPulseConf	0
GlobalPulseWidth	10
GpCmosDs	0
GpCmosEn	1
GpCmosRoute	34
GpLvdsBias	7
GpLvdsEn	15
GpLvdsPad0	0
GpLvdsPad1	1
GpLvdsPad2	33
GpLvdsPad3	35
GpValReg	5
HitOrCnt0	0
HitOrCnt1	0
HitOrCnt2	0
HitOrCnt3	0
HitOrMask0	0
HitOrMask1	0
HitOrMask2	0
HitOrMask3	0
InjAnaMode	0
InjDigEn	0
InjFineDelay	5
InjVcalHigh	200
InjVcalMed	200
InjVcalRange	1
IrefTrimSense	0
Latency	500
LinComp	110
LinCompTa	110
LinFc	20
LinGdacL	408
LinGdacM	408
LinGdacR	408
LinKrumCurr	50
LinLdac	100
LinPreampL	300
LinPreampM	300
LinPreampR	300
LinPreampT	300
LinPreampTL	300
LinPreampTR	300
LinRefKrum	300
LockLossCnt	0
MonAdcTrim	0
MonSensAcbDem	0
MonSensAcbEn	0
MonSensAcbSelBias	0
MonSensSldoAnaDem	0
MonSensSldoAnaEn	0
MonSensSldoAnaSelBias	0
MonSensSldoDigDem	0
MonSensSldoDigEn	0
MonSensSldoDigSelBias	0
MonitorEnable	1
MonitorI	63
MonitorV	32
MonitoringDataAdc	0
NtcDac	100
NumOfEventsInStream	0
OddMask	0
PixAutoRow	1
PixBroadcast	0
PixConfMode	1
PixDefaultConfig	40162
PixDefaultConfigB	25373
PixEnSeuCount	0
PixHitSampleMode	0
PixPortal	0
PixRegionCol	199
PixRegionRow	0
PixelSeuCntCnt	0
PtotCoreColEn0	0
PtotCoreColEn1	0
PtotCoreColEn2	0
PtotCoreColEn3	0
RdWrFifoErrCnt	0
ReadTrigCnt	0
ReadTrigLatency	0
RingOscAClear	0
RingOscAEn	0
RingOscAOut	0
RingOscARoute	0
RingOscBClear	0
RingOscBEnBl	0
RingOscBEnBr	0
RingOscBEnCapA	0
RingOscBEnFf	0
RingOscBEnLvt	0
RingOscBOut	0
RingOscBRoute	0
RstCoreCol0	0
RstCoreCol1	0
RstCoreCol2	0
RstCoreCol3	0
SelfTrigDeadtime	64
SelfTrigDelay	512
SelfTrigDigThr	1
SelfTrigDigThrEn	0
SelfTrigEn	0
SelfTrigMulti	4
SelfTrigPattern	65534
SerEnLane	15
SerEnTap	1
SerInvTap	1
SerSelOut0	1
SerSelOut1	3
SerSelOut2	3
SerSelOut3	3
ServiceBlockEn	1
ServiceBlockPeriod	50
SkippedTrigCnt	0
SldoEnUndershuntA	0
SldoEnUndershuntD	0
SldoTrimA	9
SldoTrimD	8
TotEn6b4b	0
TotEn80	0
TotEnPtoa	0
TotEnPtot	0
TotPtotLatency	500
TrigCnt	0
TruncTimeoutConf	0
TwoLevelTrig	0
VrefIn	1
VrefRsensBot	0
VrefRsensTop	0

Parameter

ADCcalPar	14.0 0.187 10000.0
ChipId	15
EnforceNameIdCheck	True
InjCap	7.963
IrefTrim	8
KSenseInA	21102.97
KSenseInD	21379.594
KSenseShuntA	21706.0
KSenseShuntD	21990.0
KShuntA	999.845
KShuntD	991.518
Name	0x23ac5
NfACB	1.2572807
NfASLDO	1.2576808
NfDSLDO	1.2571379
NtcCalPar	0.0007489 0.0002769 7.0595e-08
VcalPar	16.868 0.198

SoftwareType

ChipID

Name

0x23ac5

Institution

ANL_PIXEL_MODULES

ModuleSN

20UPGM24211761

TimeStart

1762460938

TimeEnd

1762461165

useCalibAdc

False

comment

property

YARR_VERSION	v1.5.5
ANALOG_READBACK_MEASUREMENT_VERSION	2.6.0

AR_VMEAS

MODULE/INITIAL_WARM

660fbeb2ec873d00354e22e0

1.01

64657cef8d79bac1f3f00578

mts	2025-11-06 22:35:28.831000
cts	2025-11-06 22:35:28.831000
rev	0

20UPGFC0146117

ANALOG_READBACK

690d0c5f2b7c742a94063ede

DCSdata

SensorVoltage	-120.0
SensorCurrent	3.93e-07
ModuleNTC	19.91

Measurements

Vmux2

X	False
Unit	V
Values	0.134972 0.134972 0.134972 0.134972 0.134972 0.134972 0.134972 0.134972 0.134972 0.134972 0.134972 0.134972 0.134972 0.134972 0.134972 0.134972 0.134972 0.134972 0.134972 0.134972 0.134972 0.134972 0.134972 0.134972 0.134972 0.134972 0.134972 0.134972 0.134972 0.134972 0.134972 0.134972

Vmux30

X	False
Unit	V
Values	0.0172704 0.0172704 0.0172704 0.0172704 0.0172704 0.0172704 0.0172704 0.0172704 0.0172704 0.0172704 0.0172704 0.0172704 0.0172704 0.0172704 0.0172704 0.0172704 0.0172704 0.0172704 0.0172704 0.0172704 0.0172704 0.0172704 0.0172704 0.0172704 0.0172704 0.0172704 0.0172704 0.0172704 0.0172704 0.0172704 0.0172704 0.0172704

Imux9

X	False
Unit	V
Values	0.1192091 0.1192091 0.1192091 0.1192091 0.1192091 0.1192091 0.1192091 0.1192091 0.1192091 0.1192091 0.1192091 0.1192091 0.1192091 0.1192091 0.1192091 0.1192091 0.1192091 0.1192091 0.1192091 0.1192091 0.1192091 0.1192091 0.1192091 0.1192091 0.1192091 0.1192091 0.1192091 0.1192091 0.1192091 0.1192091 0.1192091 0.1192091

Imux63

X	False
Unit	V
Values	0.01488908 0.01488908 0.01488908 0.01488908 0.01488908 0.01488908 0.01488908 0.01488908 0.01488908 0.01488908 0.01488908 0.01488908 0.01488908 0.01488908 0.01488908 0.01488908 0.01488908 0.01488908 0.01488908 0.01488908 0.01488908 0.01488908 0.01488908 0.01488908 0.01488908 0.01488908 0.01488908 0.01488908 0.01488908 0.01488908 0.01488908 0.01488908

Vmux14

X	False
Unit	V
Values	0.2229747 0.2238546 0.2237876 0.2226257 0.2255844 0.2250932 0.2248787 0.2248918 0.2231454 0.2253469 0.2238503 0.2237828 0.2241228 0.2251298 0.2241172 0.2248508 0.3131786 0.3130938 0.3130475 0.3131059 0.3128786 0.3128867 0.3128847 0.3129202 0.3130268 0.3128999 0.3129857 0.3130501 0.3130571 0.3129369 0.313072 0.3130412

Vmux16

X	False
Unit	V
Values	0.226022 0.2242365 0.2253484 0.2245162 0.224702 0.2249563 0.2233818 0.2258956 0.2243249 0.2236062 0.2252389 0.2243984 0.223539 0.2244099 0.2236093 0.2241223 0.313467 0.3135794 0.3135076 0.3135763 0.3135126 0.313513 0.3136095 0.3134773 0.3136032 0.3136842 0.3135665 0.3136317 0.3136749 0.3136259 0.3136705 0.3136279

Vmux18

X	False
Unit	V
Values	0.2331632 0.2322116 0.2306291 0.2322669 0.2335337 0.233798 0.2323429 0.2319415 0.2333245 0.2329283 0.2322909 0.2331526 0.2315241 0.2330297 0.2329322 0.2326505 0.3210737 0.3211732 0.3212587 0.3211905 0.3210833 0.3210859 0.3211955 0.3211886 0.321104 0.3211561 0.3211377 0.3210958 0.3211987 0.3211319 0.321088 0.3211032

MonSensSldoAnaSelBias

X	False
Unit	-
Values	0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

MonSensSldoDigSelBias

X	False
Unit	-
Values	0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

MonSensAcbSelBias

X	False
Unit	-
Values	0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

MonSensSldoAnaDem

X	False
Unit	-
Values	0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

MonSensSldoDigDem

X	False
Unit	-
Values	0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

MonSensAcbDem

X	False
Unit	-
Values	0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

TExtExtNTC

X	False
Unit	C
Values	20.0 20.0 20.0 20.0 20.0 20.0 20.0 20.0 20.0 20.0 20.0 20.0 20.0 20.0 20.0 20.0 20.0 20.0 20.0 20.0 20.0 20.0 20.0 20.0 20.0 20.0 20.0 20.0 20.0 20.0 20.0 20.0

Metadata

FirmwareVersion

FirmwareIdentifier

ChannelConfig

SoftwareVersion

ChipConfigs

ITKPIXV2

GlobalConfig

AiRegionRow	0
AuroraActiveLanes	1
AuroraAltOutput0	0
AuroraAltOutput1	0
AuroraCBSend	0
AuroraCBWait0	4095
AuroraCBWait1	0
AuroraCCSend	3
AuroraCCWait	25
AuroraEnPrbs	0
AuroraInitWait	32
AuroraSendAlt	0
AutoRead0	134
AutoRead1	135
AutoRead2	137
AutoRead3	138
AutoRead4	140
AutoRead5	151
AutoRead6	152
AutoRead7	156
BcidCnt	0
BitFlipErrCnt	0
BitFlipWngCnt	0
CapMeasEn	0
CapMeasEnPar	0
CdrClkSel	0
CdrCp	40
CdrCpBuff	200
CdrCpFd	400
CdrPhaseDetSel	0
CdrVco	1023
CdrVcoBuff	500
ChSyncLockThr	31
ChipIdSense	0
Clk160En	7
Clk40En	7
ClkAuroraEn	7
ClkDataMergeEn	7
CmdErrCnt	0
CmlBias0	800
CmlBias1	400
CmlBias2	0
DataDecodingValues	0
DataEnBcid	0
DataEnBinaryRo	0
DataEnCrc	0
DataEnL1id	0
DataEnRaw	0
DataMaxHits	0
DataMaxTot	0
DataMergeEn	0
DataMergeEnBond	0
DataMergeEnClkGate	0
DataMergeFixedMode	0
DataMergeGpoSel	0
DataMergeInMux0	0
DataMergeInMux1	1
DataMergeInMux2	2
DataMergeInMux3	3
DataMergeInPol	0
DataMergeManChoice	0
DataMergeManMode	0
DataMergeOutMux0	0
DataMergeOutMux1	1
DataMergeOutMux2	2
DataMergeOutMux3	3
DataMergeSelClk	0
DataReadDelay	0
DiffComp	500
DiffFbCapEn	0
DiffLcc	200
DiffLccEn	1
DiffPreComp	350
DiffPreampL	550
DiffPreampM	550
DiffPreampR	550
DiffPreampT	550
DiffPreampTL	550
DiffPreampTR	550
DiffTh1L	350
DiffTh1M	350
DiffTh1R	350
DiffTh2	50
DiffVff	60
EfuseConfig	3855
EfuseReadData0	50448
EfuseReadData1	8762
EfuseWriteData0	0
EfuseWriteData1	0
EnChipId	0
EnCoreCol0	65535
EnCoreCol1	65535
EnCoreCol2	65535
EnCoreCol3	61
EnCoreColCal0	0
EnCoreColCal1	0
EnCoreColCal2	0
EnCoreColCal3	0
EnHitsRemoval0	0
EnHitsRemoval1	0
EnHitsRemoval2	0
EnHitsRemoval3	0
EnIsoHitsRemoval0	0
EnIsoHitsRemoval1	0
EnIsoHitsRemoval2	0
EnIsoHitsRemoval3	0
ErrWngMask	0
EvenMask	0
FineDelayClk	0
FineDelayData	0
GatedHitOrCnt0	0
GatedHitOrCnt1	0
GcrDefaultConfig	44149
GcrDefaultConfigB	21386
GlobalConfigSeuCnt	0
GlobalPulseConf	0
GlobalPulseWidth	10
GpCmosDs	0
GpCmosEn	1
GpCmosRoute	34
GpLvdsBias	7
GpLvdsEn	15
GpLvdsPad0	0
GpLvdsPad1	1
GpLvdsPad2	33
GpLvdsPad3	35
GpValReg	5
HitOrCnt0	0
HitOrCnt1	0
HitOrCnt2	0
HitOrCnt3	0
HitOrMask0	0
HitOrMask1	0
HitOrMask2	0
HitOrMask3	0
InjAnaMode	0
InjDigEn	0
InjFineDelay	5
InjVcalHigh	200
InjVcalMed	200
InjVcalRange	1
IrefTrimSense	0
Latency	500
LinComp	110
LinCompTa	110
LinFc	20
LinGdacL	408
LinGdacM	408
LinGdacR	408
LinKrumCurr	50
LinLdac	100
LinPreampL	300
LinPreampM	300
LinPreampR	300
LinPreampT	300
LinPreampTL	300
LinPreampTR	300
LinRefKrum	300
LockLossCnt	0
MonAdcTrim	0
MonSensAcbDem	0
MonSensAcbEn	0
MonSensAcbSelBias	0
MonSensSldoAnaDem	0
MonSensSldoAnaEn	0
MonSensSldoAnaSelBias	0
MonSensSldoDigDem	0
MonSensSldoDigEn	0
MonSensSldoDigSelBias	0
MonitorEnable	1
MonitorI	63
MonitorV	32
MonitoringDataAdc	0
NtcDac	100
NumOfEventsInStream	0
OddMask	0
PixAutoRow	1
PixBroadcast	0
PixConfMode	1
PixDefaultConfig	40162
PixDefaultConfigB	25373
PixEnSeuCount	0
PixHitSampleMode	0
PixPortal	0
PixRegionCol	199
PixRegionRow	0
PixelSeuCntCnt	0
PtotCoreColEn0	0
PtotCoreColEn1	0
PtotCoreColEn2	0
PtotCoreColEn3	0
RdWrFifoErrCnt	0
ReadTrigCnt	0
ReadTrigLatency	0
RingOscAClear	0
RingOscAEn	0
RingOscAOut	0
RingOscARoute	0
RingOscBClear	0
RingOscBEnBl	0
RingOscBEnBr	0
RingOscBEnCapA	0
RingOscBEnFf	0
RingOscBEnLvt	0
RingOscBOut	0
RingOscBRoute	0
RstCoreCol0	0
RstCoreCol1	0
RstCoreCol2	0
RstCoreCol3	0
SelfTrigDeadtime	64
SelfTrigDelay	512
SelfTrigDigThr	1
SelfTrigDigThrEn	0
SelfTrigEn	0
SelfTrigMulti	4
SelfTrigPattern	65534
SerEnLane	15
SerEnTap	1
SerInvTap	1
SerSelOut0	1
SerSelOut1	3
SerSelOut2	3
SerSelOut3	3
ServiceBlockEn	1
ServiceBlockPeriod	50
SkippedTrigCnt	0
SldoEnUndershuntA	0
SldoEnUndershuntD	0
SldoTrimA	9
SldoTrimD	8
TotEn6b4b	0
TotEn80	0
TotEnPtoa	0
TotEnPtot	0
TotPtotLatency	500
TrigCnt	0
TruncTimeoutConf	0
TwoLevelTrig	0
VrefIn	1
VrefRsensBot	0
VrefRsensTop	0

Parameter

ADCcalPar	14.0 0.187 10000.0
ChipId	15
EnforceNameIdCheck	True
InjCap	7.963
IrefTrim	8
KSenseInA	21102.97
KSenseInD	21379.594
KSenseShuntA	21706.0
KSenseShuntD	21990.0
KShuntA	999.845
KShuntD	991.518
Name	0x23ac5
NfACB	1.2572807
NfASLDO	1.2576808
NfDSLDO	1.2571379
NtcCalPar	0.0007489 0.0002769 7.0595e-08
VcalPar	16.868 0.198

SoftwareType

ChipID

Name

0x23ac5

Institution

ANL_PIXEL_MODULES

ModuleSN

20UPGM24211761

TimeStart

1762462397

TimeEnd

1762462815

useCalibAdc

False

comment

property

YARR_VERSION	v1.5.5
ANALOG_READBACK_MEASUREMENT_VERSION	2.6.0

AR_TEMP

MODULE/INITIAL_WARM

660fbeb2ec873d00354e22e0

1.01

64657cef8d79bac1f3f00578

mts	2025-11-06 22:35:28.831000
cts	2025-11-06 22:35:28.831000
rev	0

20UPGFC0146117

ANALOG_READBACK

690d0c5f2b7c742a94063edf

DCSdata

SensorVoltage	-120.0
SensorCurrent	3.98e-07
ModuleNTC	20.0

Measurements

Vmux34

X	False
Unit	V
Values	0.5086406 0.5210986 0.5335204 0.5457676 0.5578444 0.57031 0.5822546 0.5948771 0.6063651 0.6184351 0.6298066 0.6425847 0.654665 0.6668581 0.6788224 0.6904558

Vmux38

X	False
Unit	V
Values	0.5228879 0.535034 0.5464704 0.5592111 0.5710249 0.5831522 0.5952053 0.6064251 0.6215123 0.6333836 0.6451438 0.6574576 0.6701718 0.6826599 0.6951812 0.7072826

Vmux30

X	False
Unit	V
Values	0.01723539 0.01723539 0.01723539 0.01723539 0.01723539 0.01723539 0.01723539 0.01723539 0.01723539 0.01723539 0.01723539 0.01723539 0.01723539 0.01723539 0.01723539 0.01723539

Vmux33

X	False
Unit	V
Values	0.3926952 0.3926418 0.3927679 0.3927328 0.39269 0.3927939 0.3928125 0.3928081 0.3928464 0.3927967 0.3927186 0.3927016 0.3926918 0.3924857 0.3922252 0.3918934

Vmux37

X	False
Unit	V
Values	0.3944567 0.3944932 0.3945127 0.3944898 0.3943802 0.3945026 0.394469 0.394424 0.3944191 0.3942599 0.3941423 0.3939503 0.3934107 0.3926264 0.3914377 0.3894372

Imux63

X	False
Unit	V
Values	0.0148569 0.0148569 0.0148569 0.0148569 0.0148569 0.0148569 0.0148569 0.0148569 0.0148569 0.0148569 0.0148569 0.0148569 0.0148569 0.0148569 0.0148569 0.0148569

Imux28

X	False
Unit	V
Values	0.3139374 0.3144303 0.3148542 0.315169 0.3153214 0.3155233 0.3156999 0.3158095 0.3159997 0.3160342 0.3160637 0.3160467 0.3159298 0.3158253 0.3154253 0.3147143

Imux29

X	False
Unit	V
Values	0.0679958 0.06323304 0.05901822 0.05569776 0.05257172 0.0497617 0.0474984 0.04501869 0.04299895 0.04140856 0.0396148 0.03860136 0.03849762 0.03946812 0.04237969 0.04883321

Imux30

X	False
Unit	V
Values	0.4345854 0.4354732 0.4363754 0.4367619 0.4371256 0.4375247 0.4377087 0.4377091 0.43782 0.4375215 0.4369759 0.435785 0.4339992 0.4311404 0.426344 0.4187354

Imux31

X	False
Unit	V
Values	0.1841273 0.178385 0.1722159 0.1659297 0.1595982 0.153235 0.1469234 0.1410059 0.1343546 0.1295468 0.1264591 0.1251171 0.1276948 0.1332883 0.1518882 0.1832151

SldoTrimA

X	False
Unit	-
Values	0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

SldoTrimD

X	False
Unit	-
Values	0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

ROSC0

X	False
Unit	MHz
Values	315.933 334.733 353.6 372.533 390.667 409.933 427.933 445.467 467.867 484.933 501.2 518.6 535.667 551.867 567.8 582.733

ROSC1

X	False
Unit	MHz
Values	490.4 520.4 549.2 578.933 607.067 637.0 664.867 692.067 726.333 752.867 778.133 804.467 830.667 855.6 880.4 903.0

ROSC2

X	False
Unit	MHz
Values	297.333 316.2 334.733 353.867 371.867 391.0 409.067 426.667 448.8 466.0 482.533 499.867 516.733 533.333 549.4 564.133

ROSC3

X	False
Unit	MHz
Values	481.067 510.733 539.933 569.533 598.133 627.867 655.733 683.133 717.6 743.867 769.4 796.333 822.6 847.733 872.6 895.533

ROSC4

X	False
Unit	MHz
Values	270.667 289.667 308.4 327.8 346.667 366.733 385.667 404.2 428.467 446.533 464.6 483.467 502.667 520.867 538.667 555.467

ROSC5

X	False
Unit	MHz
Values	473.6 506.4 539.067 572.533 605.333 639.933 672.667 705.0 746.267 778.0 808.933 841.667 873.867 905.467 936.467 964.8

ROSC6

X	False
Unit	MHz
Values	304.267 327.467 350.067 373.333 396.133 420.2 442.667 465.4 494.4 516.667 538.333 561.133 584.0 606.0 627.733 648.0

ROSC7

X	False
Unit	MHz
Values	455.533 489.467 523.067 557.0 590.467 625.933 659.933 692.933 735.4 768.2 800.133 833.733 866.933 899.333 930.8 960.2

ROSC8

X	False
Unit	MHz
Values	465.267 493.933 522.933 551.867 580.867 609.467 637.667 665.067 699.2 725.133 751.933 778.533 804.733 830.867 855.333 879.333

ROSC9

X	False
Unit	MHz
Values	463.467 492.133 521.4 550.133 579.067 607.8 635.733 663.2 697.533 723.0 749.867 776.533 802.733 828.933 853.267 877.333

ROSC10

X	False
Unit	MHz
Values	545.733 579.933 613.867 647.933 682.067 715.8 749.0 780.667 821.133 851.2 882.8 913.933 944.933 975.6 1004.47 1032.33

ROSC11

X	False
Unit	MHz
Values	548.067 582.267 616.267 650.4 684.4 718.533 751.267 783.8 823.8 853.933 885.533 916.867 947.8 978.4 1007.13 1035.2

ROSC12

X	False
Unit	MHz
Values	463.533 493.133 522.467 552.067 581.6 610.733 639.733 667.8 702.667 729.133 756.933 784.2 811.533 838.467 863.467 888.267

ROSC13

X	False
Unit	MHz
Values	463.267 492.333 522.067 551.867 581.4 611.067 640.067 668.267 703.2 729.867 757.333 784.933 812.0 838.933 864.267 889.2

ROSC14

X	False
Unit	MHz
Values	538.933 572.467 607.133 641.333 675.533 709.133 742.8 775.067 815.533 846.0 877.933 909.2 940.667 971.467 1000.53 1029.07

ROSC15

X	False
Unit	MHz
Values	544.2 578.333 612.467 646.533 680.933 714.667 748.133 780.4 820.4 851.067 882.8 914.133 945.6 976.467 1005.33 1033.8

ROSC16

X	False
Unit	MHz
Values	457.267 489.267 521.533 554.0 586.6 619.533 652.267 684.267 724.067 754.6 786.333 818.133 849.933 881.4 911.133 940.533

ROSC17

X	False
Unit	MHz
Values	460.6 492.2 524.667 556.867 589.8 622.4 654.933 687.067 726.667 757.467 789.267 821.267 852.867 884.2 914.133 943.067

ROSC18

X	False
Unit	MHz
Values	542.867 580.867 619.467 658.2 697.2 736.133 774.933 813.133 860.8 897.067 935.4 973.333 1011.6 1049.27 1084.67 1120.07

ROSC19

X	False
Unit	MHz
Values	538.0 575.6 613.733 652.6 690.933 729.867 768.467 806.4 854.067 889.933 928.0 966.133 1004.0 1041.8 1077.0 1112.13

ROSC20

X	False
Unit	MHz
Values	428.133 459.867 492.0 524.267 556.6 589.533 621.667 654.2 694.267 724.6 756.467 788.6 820.667 852.6 881.933 911.4

ROSC21

X	False
Unit	MHz
Values	412.533 443.467 475.267 506.933 539.133 571.733 603.667 635.133 675.133 705.333 736.667 768.667 800.267 831.8 861.2 890.4

ROSC22

X	False
Unit	MHz
Values	530.0 568.8 608.533 647.933 688.2 728.467 768.533 807.8 856.733 894.6 934.067 973.467 1012.73 1051.93 1088.53 1124.93

ROSC23

X	False
Unit	MHz
Values	526.2 565.0 604.533 644.267 683.933 724.733 764.6 803.533 852.6 890.267 929.533 969.267 1008.07 1047.07 1083.4 1120.2

ROSC24

X	False
Unit	MHz
Values	297.4 317.533 338.0 358.067 378.267 398.867 418.8 438.533 463.2 482.067 501.6 521.4 540.4 559.933 577.867 595.867

ROSC25

X	False
Unit	MHz
Values	301.467 321.467 341.867 361.867 382.333 402.667 422.733 442.467 466.933 485.867 505.267 524.667 543.867 563.2 581.067 598.933

ROSC26

X	False
Unit	MHz
Values	362.667 386.667 411.133 435.4 460.067 484.6 508.667 532.8 562.467 585.133 608.667 632.333 655.667 678.933 700.733 722.733

ROSC27

X	False
Unit	MHz
Values	356.867 380.533 405.2 429.533 454.067 479.0 503.2 526.533 556.333 579.333 602.733 626.467 649.933 672.933 695.2 717.067

ROSC28

X	False
Unit	MHz
Values	374.533 398.667 423.933 448.267 472.933 497.667 521.6 545.867 575.467 598.2 621.667 645.267 668.467 691.533 713.267 734.8

ROSC29

X	False
Unit	MHz
Values	371.2 395.667 420.133 444.733 469.533 494.333 518.6 542.533 572.333 594.867 618.6 642.333 665.6 688.733 710.533 732.0

ROSC30

X	False
Unit	MHz
Values	574.333 603.933 633.733 662.667 691.867 720.6 748.333 775.533 809.2 834.667 860.867 886.733 912.4 937.267 960.733 983.8

ROSC31

X	False
Unit	MHz
Values	626.6 657.733 689.2 720.133 751.133 781.667 810.533 839.533 875.267 901.667 929.333 956.667 983.4 1009.73 1033.87 1057.87

ROSC32

X	False
Unit	MHz
Values	508.2 535.867 564.133 592.0 620.267 648.067 675.333 701.733 734.8 760.267 786.0 812.067 837.267 862.6 885.933 909.0

ROSC33

X	False
Unit	MHz
Values	542.333 572.067 601.667 631.533 661.333 690.867 719.8 747.8 783.133 809.533 837.667 864.8 892.0 918.667 943.267 967.733

ROSC34

X	False
Unit	MHz
Values	518.8 554.8 591.8 628.467 666.067 703.4 740.533 776.867 822.467 857.267 893.6 930.2 966.4 1002.87 1036.67 1070.27

ROSC35

X	False
Unit	MHz
Values	520.4 556.4 592.933 630.067 667.533 704.8 742.133 778.333 824.0 858.867 895.467 932.0 967.733 1004.53 1038.13 1072.07

ROSC36

X	False
Unit	MHz
Values	518.6 554.933 591.467 628.267 665.867 703.333 740.4 776.867 822.333 857.667 894.333 931.0 966.933 1003.4 1037.33 1071.2

ROSC37

X	False
Unit	MHz
Values	515.2 551.333 587.533 624.333 661.533 698.667 735.6 772.2 817.467 852.067 888.467 925.0 960.933 997.2 1031.4 1064.67

ROSC38

X	False
Unit	MHz
Values	513.133 549.267 585.733 622.667 660.0 697.2 734.533 770.667 816.2 851.4 887.867 924.267 960.333 996.8 1031.13 1064.47

ROSC39

X	False
Unit	MHz
Values	519.533 555.8 592.4 629.133 666.733 703.6 740.933 777.267 823.133 858.0 894.4 931.0 967.333 1003.6 1037.93 1071.27

ROSC40

X	False
Unit	MHz
Values	520.8 556.533 593.667 630.2 667.733 705.133 742.467 778.533 824.4 859.267 895.933 932.333 968.467 1005.0 1039.13 1072.6

ROSC41

X	False
Unit	MHz
Values	526.067 562.133 599.333 636.333 674.0 711.4 748.8 785.067 830.867 866.0 902.8 939.467 975.6 1012.4 1046.8 1080.13

Metadata

FirmwareVersion

FirmwareIdentifier

ChannelConfig

SoftwareVersion

ChipConfigs

ITKPIXV2

GlobalConfig

AiRegionRow	0
AuroraActiveLanes	1
AuroraAltOutput0	0
AuroraAltOutput1	0
AuroraCBSend	0
AuroraCBWait0	4095
AuroraCBWait1	0
AuroraCCSend	3
AuroraCCWait	25
AuroraEnPrbs	0
AuroraInitWait	32
AuroraSendAlt	0
AutoRead0	134
AutoRead1	135
AutoRead2	137
AutoRead3	138
AutoRead4	140
AutoRead5	151
AutoRead6	152
AutoRead7	156
BcidCnt	0
BitFlipErrCnt	0
BitFlipWngCnt	0
CapMeasEn	0
CapMeasEnPar	0
CdrClkSel	0
CdrCp	40
CdrCpBuff	200
CdrCpFd	400
CdrPhaseDetSel	0
CdrVco	1023
CdrVcoBuff	500
ChSyncLockThr	31
ChipIdSense	0
Clk160En	7
Clk40En	7
ClkAuroraEn	7
ClkDataMergeEn	7
CmdErrCnt	0
CmlBias0	800
CmlBias1	400
CmlBias2	0
DataDecodingValues	0
DataEnBcid	0
DataEnBinaryRo	0
DataEnCrc	0
DataEnL1id	0
DataEnRaw	0
DataMaxHits	0
DataMaxTot	0
DataMergeEn	0
DataMergeEnBond	0
DataMergeEnClkGate	0
DataMergeFixedMode	0
DataMergeGpoSel	0
DataMergeInMux0	0
DataMergeInMux1	1
DataMergeInMux2	2
DataMergeInMux3	3
DataMergeInPol	0
DataMergeManChoice	0
DataMergeManMode	0
DataMergeOutMux0	0
DataMergeOutMux1	1
DataMergeOutMux2	2
DataMergeOutMux3	3
DataMergeSelClk	0
DataReadDelay	0
DiffComp	500
DiffFbCapEn	0
DiffLcc	200
DiffLccEn	1
DiffPreComp	350
DiffPreampL	550
DiffPreampM	550
DiffPreampR	550
DiffPreampT	550
DiffPreampTL	550
DiffPreampTR	550
DiffTh1L	350
DiffTh1M	350
DiffTh1R	350
DiffTh2	50
DiffVff	60
EfuseConfig	3855
EfuseReadData0	50448
EfuseReadData1	8762
EfuseWriteData0	0
EfuseWriteData1	0
EnChipId	0
EnCoreCol0	65535
EnCoreCol1	65535
EnCoreCol2	65535
EnCoreCol3	61
EnCoreColCal0	0
EnCoreColCal1	0
EnCoreColCal2	0
EnCoreColCal3	0
EnHitsRemoval0	0
EnHitsRemoval1	0
EnHitsRemoval2	0
EnHitsRemoval3	0
EnIsoHitsRemoval0	0
EnIsoHitsRemoval1	0
EnIsoHitsRemoval2	0
EnIsoHitsRemoval3	0
ErrWngMask	0
EvenMask	0
FineDelayClk	0
FineDelayData	0
GatedHitOrCnt0	0
GatedHitOrCnt1	0
GcrDefaultConfig	44149
GcrDefaultConfigB	21386
GlobalConfigSeuCnt	0
GlobalPulseConf	0
GlobalPulseWidth	10
GpCmosDs	0
GpCmosEn	1
GpCmosRoute	34
GpLvdsBias	7
GpLvdsEn	15
GpLvdsPad0	0
GpLvdsPad1	1
GpLvdsPad2	33
GpLvdsPad3	35
GpValReg	5
HitOrCnt0	0
HitOrCnt1	0
HitOrCnt2	0
HitOrCnt3	0
HitOrMask0	0
HitOrMask1	0
HitOrMask2	0
HitOrMask3	0
InjAnaMode	0
InjDigEn	0
InjFineDelay	5
InjVcalHigh	200
InjVcalMed	200
InjVcalRange	1
IrefTrimSense	0
Latency	500
LinComp	110
LinCompTa	110
LinFc	20
LinGdacL	408
LinGdacM	408
LinGdacR	408
LinKrumCurr	50
LinLdac	100
LinPreampL	300
LinPreampM	300
LinPreampR	300
LinPreampT	300
LinPreampTL	300
LinPreampTR	300
LinRefKrum	300
LockLossCnt	0
MonAdcTrim	0
MonSensAcbDem	0
MonSensAcbEn	0
MonSensAcbSelBias	0
MonSensSldoAnaDem	0
MonSensSldoAnaEn	0
MonSensSldoAnaSelBias	0
MonSensSldoDigDem	0
MonSensSldoDigEn	0
MonSensSldoDigSelBias	0
MonitorEnable	1
MonitorI	63
MonitorV	32
MonitoringDataAdc	0
NtcDac	100
NumOfEventsInStream	0
OddMask	0
PixAutoRow	1
PixBroadcast	0
PixConfMode	1
PixDefaultConfig	40162
PixDefaultConfigB	25373
PixEnSeuCount	0
PixHitSampleMode	0
PixPortal	0
PixRegionCol	199
PixRegionRow	0
PixelSeuCntCnt	0
PtotCoreColEn0	0
PtotCoreColEn1	0
PtotCoreColEn2	0
PtotCoreColEn3	0
RdWrFifoErrCnt	0
ReadTrigCnt	0
ReadTrigLatency	0
RingOscAClear	0
RingOscAEn	0
RingOscAOut	0
RingOscARoute	0
RingOscBClear	0
RingOscBEnBl	0
RingOscBEnBr	0
RingOscBEnCapA	0
RingOscBEnFf	0
RingOscBEnLvt	0
RingOscBOut	0
RingOscBRoute	0
RstCoreCol0	0
RstCoreCol1	0
RstCoreCol2	0
RstCoreCol3	0
SelfTrigDeadtime	64
SelfTrigDelay	512
SelfTrigDigThr	1
SelfTrigDigThrEn	0
SelfTrigEn	0
SelfTrigMulti	4
SelfTrigPattern	65534
SerEnLane	15
SerEnTap	1
SerInvTap	1
SerSelOut0	1
SerSelOut1	3
SerSelOut2	3
SerSelOut3	3
ServiceBlockEn	1
ServiceBlockPeriod	50
SkippedTrigCnt	0
SldoEnUndershuntA	0
SldoEnUndershuntD	0
SldoTrimA	9
SldoTrimD	8
TotEn6b4b	0
TotEn80	0
TotEnPtoa	0
TotEnPtot	0
TotPtotLatency	500
TrigCnt	0
TruncTimeoutConf	0
TwoLevelTrig	0
VrefIn	1
VrefRsensBot	0
VrefRsensTop	0

Parameter

ADCcalPar	14.0 0.187 10000.0
ChipId	15
EnforceNameIdCheck	True
InjCap	7.963
IrefTrim	8
KSenseInA	21102.97
KSenseInD	21379.594
KSenseShuntA	21706.0
KSenseShuntD	21990.0
KShuntA	999.845
KShuntD	991.518
Name	0x23ac5
NfACB	1.2572807
NfASLDO	1.2576808
NfDSLDO	1.2571379
NtcCalPar	0.0007489 0.0002769 7.0595e-08
VcalPar	16.868 0.198

SoftwareType

ChipID

Name

0x23ac5

Institution

ANL_PIXEL_MODULES

ModuleSN

20UPGM24211761

TimeStart

1762461165

TimeEnd

1762462397

useCalibAdc

False

comment

property

YARR_VERSION	v1.5.5
ANALOG_READBACK_MEASUREMENT_VERSION	2.6.0

AR_VDD

MODULE/INITIAL_WARM

660fbeb2ec873d00354e22e0

1.01

64657cef8d79bac1f3f00578

mts	2025-11-06 22:35:28.831000
cts	2025-11-06 22:35:28.831000
rev	0

20UPGFC0146117

ANALOG_READBACK

690d0c5f2b7c742a94063ee0

DCSdata

Measurements

IrefTrimSense

X	False
Unit	-
Values	9.0

Metadata

FirmwareVersion

FirmwareIdentifier

ChannelConfig

SoftwareVersion

ChipConfigs

ITKPIXV2

GlobalConfig

AiRegionRow	0
AuroraActiveLanes	1
AuroraAltOutput0	0
AuroraAltOutput1	0
AuroraCBSend	0
AuroraCBWait0	4095
AuroraCBWait1	0
AuroraCCSend	3
AuroraCCWait	25
AuroraEnPrbs	0
AuroraInitWait	32
AuroraSendAlt	0
AutoRead0	134
AutoRead1	135
AutoRead2	137
AutoRead3	138
AutoRead4	140
AutoRead5	151
AutoRead6	152
AutoRead7	156
BcidCnt	0
BitFlipErrCnt	0
BitFlipWngCnt	0
CapMeasEn	0
CapMeasEnPar	0
CdrClkSel	0
CdrCp	40
CdrCpBuff	200
CdrCpFd	400
CdrPhaseDetSel	0
CdrVco	1023
CdrVcoBuff	500
ChSyncLockThr	31
ChipIdSense	0
Clk160En	7
Clk40En	7
ClkAuroraEn	7
ClkDataMergeEn	7
CmdErrCnt	0
CmlBias0	800
CmlBias1	400
CmlBias2	0
DataDecodingValues	0
DataEnBcid	0
DataEnBinaryRo	0
DataEnCrc	0
DataEnL1id	0
DataEnRaw	0
DataMaxHits	0
DataMaxTot	0
DataMergeEn	0
DataMergeEnBond	0
DataMergeEnClkGate	0
DataMergeFixedMode	0
DataMergeGpoSel	0
DataMergeInMux0	0
DataMergeInMux1	1
DataMergeInMux2	2
DataMergeInMux3	3
DataMergeInPol	0
DataMergeManChoice	0
DataMergeManMode	0
DataMergeOutMux0	0
DataMergeOutMux1	1
DataMergeOutMux2	2
DataMergeOutMux3	3
DataMergeSelClk	0
DataReadDelay	0
DiffComp	500
DiffFbCapEn	0
DiffLcc	200
DiffLccEn	1
DiffPreComp	350
DiffPreampL	550
DiffPreampM	550
DiffPreampR	550
DiffPreampT	550
DiffPreampTL	550
DiffPreampTR	550
DiffTh1L	350
DiffTh1M	350
DiffTh1R	350
DiffTh2	50
DiffVff	60
EfuseConfig	3855
EfuseReadData0	50448
EfuseReadData1	8762
EfuseWriteData0	0
EfuseWriteData1	0
EnChipId	0
EnCoreCol0	65535
EnCoreCol1	65535
EnCoreCol2	65535
EnCoreCol3	61
EnCoreColCal0	0
EnCoreColCal1	0
EnCoreColCal2	0
EnCoreColCal3	0
EnHitsRemoval0	0
EnHitsRemoval1	0
EnHitsRemoval2	0
EnHitsRemoval3	0
EnIsoHitsRemoval0	0
EnIsoHitsRemoval1	0
EnIsoHitsRemoval2	0
EnIsoHitsRemoval3	0
ErrWngMask	0
EvenMask	0
FineDelayClk	0
FineDelayData	0
GatedHitOrCnt0	0
GatedHitOrCnt1	0
GcrDefaultConfig	44149
GcrDefaultConfigB	21386
GlobalConfigSeuCnt	0
GlobalPulseConf	0
GlobalPulseWidth	10
GpCmosDs	0
GpCmosEn	1
GpCmosRoute	34
GpLvdsBias	7
GpLvdsEn	15
GpLvdsPad0	0
GpLvdsPad1	1
GpLvdsPad2	33
GpLvdsPad3	35
GpValReg	5
HitOrCnt0	0
HitOrCnt1	0
HitOrCnt2	0
HitOrCnt3	0
HitOrMask0	0
HitOrMask1	0
HitOrMask2	0
HitOrMask3	0
InjAnaMode	0
InjDigEn	0
InjFineDelay	5
InjVcalHigh	200
InjVcalMed	200
InjVcalRange	1
IrefTrimSense	0
Latency	500
LinComp	110
LinCompTa	110
LinFc	20
LinGdacL	408
LinGdacM	408
LinGdacR	408
LinKrumCurr	50
LinLdac	100
LinPreampL	300
LinPreampM	300
LinPreampR	300
LinPreampT	300
LinPreampTL	300
LinPreampTR	300
LinRefKrum	300
LockLossCnt	0
MonAdcTrim	0
MonSensAcbDem	0
MonSensAcbEn	0
MonSensAcbSelBias	0
MonSensSldoAnaDem	0
MonSensSldoAnaEn	0
MonSensSldoAnaSelBias	0
MonSensSldoDigDem	0
MonSensSldoDigEn	0
MonSensSldoDigSelBias	0
MonitorEnable	1
MonitorI	63
MonitorV	32
MonitoringDataAdc	0
NtcDac	100
NumOfEventsInStream	0
OddMask	0
PixAutoRow	1
PixBroadcast	0
PixConfMode	1
PixDefaultConfig	40162
PixDefaultConfigB	25373
PixEnSeuCount	0
PixHitSampleMode	0
PixPortal	0
PixRegionCol	199
PixRegionRow	0
PixelSeuCntCnt	0
PtotCoreColEn0	0
PtotCoreColEn1	0
PtotCoreColEn2	0
PtotCoreColEn3	0
RdWrFifoErrCnt	0
ReadTrigCnt	0
ReadTrigLatency	0
RingOscAClear	0
RingOscAEn	0
RingOscAOut	0
RingOscARoute	0
RingOscBClear	0
RingOscBEnBl	0
RingOscBEnBr	0
RingOscBEnCapA	0
RingOscBEnFf	0
RingOscBEnLvt	0
RingOscBOut	0
RingOscBRoute	0
RstCoreCol0	0
RstCoreCol1	0
RstCoreCol2	0
RstCoreCol3	0
SelfTrigDeadtime	64
SelfTrigDelay	512
SelfTrigDigThr	1
SelfTrigDigThrEn	0
SelfTrigEn	0
SelfTrigMulti	4
SelfTrigPattern	65534
SerEnLane	15
SerEnTap	1
SerInvTap	1
SerSelOut0	1
SerSelOut1	3
SerSelOut2	3
SerSelOut3	3
ServiceBlockEn	1
ServiceBlockPeriod	50
SkippedTrigCnt	0
SldoEnUndershuntA	0
SldoEnUndershuntD	0
SldoTrimA	9
SldoTrimD	8
TotEn6b4b	0
TotEn80	0
TotEnPtoa	0
TotEnPtot	0
TotPtotLatency	500
TrigCnt	0
TruncTimeoutConf	0
TwoLevelTrig	0
VrefIn	1
VrefRsensBot	0
VrefRsensTop	0

Parameter

ADCcalPar	14.0 0.187 10000.0
ChipId	15
EnforceNameIdCheck	True
InjCap	7.963
IrefTrim	8
KSenseInA	21102.97
KSenseInD	21379.594
KSenseShuntA	21706.0
KSenseShuntD	21990.0
KShuntA	999.845
KShuntD	991.518
Name	0x23ac5
NfACB	1.2572807
NfASLDO	1.2576808
NfDSLDO	1.2571379
NtcCalPar	0.0007489 0.0002769 7.0595e-08
VcalPar	16.868 0.198

SoftwareType

ChipID

Name

0x23ac5

Institution

ANL_PIXEL_MODULES

ModuleSN

20UPGM24211761

TimeStart

1762462397

TimeEnd

1762462397

comment

property

YARR_VERSION	v1.5.5
ANALOG_READBACK_MEASUREMENT_VERSION	2.6.0

AR_REGISTER

MODULE/INITIAL_WARM

660fbeb2ec873d00354e22e0

1.01

64657cef8d79bac1f3f00578

mts	2025-11-06 22:35:28.831000
cts	2025-11-06 22:35:28.831000
rev	0

rawHash

af915779b20ddbff23c00102858121eb

stage

MODULE/INITIAL_WARM

ProductionDB Record

Expand ProductionDB Record

69b8e92e484777dd851a5d85

state

ready

stateTs

2026-03-17T05:39:58.865Z

stateUserIdentity

3339-2662-1

date

2025-11-06T22:35:00.000Z

testType

id	6393a07c15838700361eebef
code	ANALOG_READBACK
name	Analog Readback
state	active

institution

id	5d318624df98f200097386d5
code	ANL
name	Argonne National Laboratory

user

id	67ee104c69bd7fedf75bb0e4
userIdentity	3339-2662-1
firstName	David
middleName
lastName	Jiang

runNumber

690d22b54f9fcd332811a655

passed

True

problems

False

properties

code	name	dataType	valueType	required	value	rangeMin	rangeMax
ANALYSIS_VERSION	Analog Readback Analysis Version	string	None	True	2.6.4	None	None
MEASUREMENT_DATE	Date measurement performed	datetime	None	False	2025-11-06T20:28:58.000+00:00	None	None
MEASUREMENT_DURATION	Measurement duration	integer	None	False	227	None	None
MEASUREMENT_VERSION	Measurement version	string	None	False	2.6.0	None	None
YARR_VERSION	Yarr Version	string	None	False	v1.5.5	None	None

results

code AR_IREF_TRIM
name Wirebonded Iref trim on ITkPix v2 chip
order 23
dataType integer
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 9
associateChild None
code AR_IREF
name AR_IREF (A)
order 24
dataType float
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 3.7e-06
associateChild None
code AR_GADC
name AR_GADC (V)
order 25
dataType float
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 0.818
associateChild None

code	AR_NOMINAL_SETTINGS
name	Analog readback at nominal settings
dataType	float
valueType	array
arrayDimensions	1
additional	None
rangeMin	None
rangeMax	None
value	3.7e-06 8.59e-05 4.65e-05 3.9e-06 3.75e-05 1.99e-05 0 3.71e-05 6.92e-05 -999 0 0 4.53e-05 6.4e-05 5.06e-05 8.58e-05 6.32e-05 7.4e-05 8.43e-05 8.58e-05 6.45e-05 4.56e-05 4.53e-05 6.26e-05 4.65e-05 4.67e-05 -999 -999 0.6356693 0.0574828 0.9039507 0.2619351 0.817735 -999 -999 0.8201443 1.1966421 0.1177104 0.1136881 0.0343394 0.0384587 0.0404021 0.242347 0.2394636 0.2373648 0.6302104 -999 0.6286336 -999 0.5961618 -999 -999 -999 -999 -999 -999 -999 -999 -999 -999 -999 -999 0.017233 0.4597092 1.9809849 1.5021734 1.2024261 0.598631 0.9918994 1.508861 1.2086645 0.5946386
associateChild	None

code	AR_ROSC_MAX_RESIDUAL
name	Ring Oscillator Max Residual
dataType	float
valueType	array
arrayDimensions	1
additional	None
rangeMin	None
rangeMax	None
value	3.021134066758833 5.009241409893805 2.893506838634558 4.860573895152653 1.7558890343924074 3.290579894417834 2.063283725698114 3.344078753842704 4.180600172660767 4.176982961876847 4.958160971910672 5.030326121172391 3.9928617498156287 4.104213051242027 4.833614025117884 4.8321069522757405 2.8840988373125103 2.877607721384258 3.211815809185039 3.0949572075269676 2.6496361342783903 2.4808014879102687 3.137777728076843 3.1894369607840867 2.1024221975449713 2.191344560027674 2.475780016094012 2.408506865773284 2.805426063419031 2.7419431645589967 5.2977531149033785 5.954307787603999 4.164091576732451 4.4322070571617465 3.0631941877261726 3.067792882829358 3.026951356197853 2.94153771438293 2.9408236278297757 2.9462108328575507 3.0158152753699436 3.008884643596771
associateChild	None

code	AR_ROSC_OFFSET
name	Ring Oscillator Offset
dataType	float
valueType	array
arrayDimensions	1
additional	None
rangeMin	None
rangeMax	None
value	-416.44206630163416 -640.1764480810982 -435.5007411991835 -655.162926333035 -515.6915119613278 -882.7525622898521 -644.0012897657558 -938.1302754857817 -671.6960551033577 -672.3568051487276 -789.2519799382962 -788.4085093962709 -702.8187287467537 -706.9836402863878 -807.1240083945116 -799.4095592547282 -875.3876230146204 -871.4880228982298 -1048.940393991984 -1046.444008236634 -906.5366145206347 -908.1265900445051 -1112.6697400679113 -1113.057438365093 -524.1540863037629 -517.5473598399863 -628.8610591656209 -635.3404840635818 -616.6603457255513 -622.1146117970195 -545.5019070245569 -553.5211151571464 -593.2682185255825 -626.5816111060161 -1003.2362434201992 -1002.3452672960442 -1006.754445376079 -1001.7395265506324 -1009.1103800671656 -1003.7001829011332 -1003.1887309617026 -1003.6780621284122
associateChild	None

code	AR_ROSC_SLOPE
name	Ring Oscillator Slope
dataType	float
valueType	array
arrayDimensions	1
additional	None
rangeMin	None
rangeMax	None
value	728.5423631509927 1125.6403999580805 728.8042702885502 1130.8819270674405 779.1397293035412 1344.3316143795298 939.6713320955531 1381.2233647878911 1130.0900556332274 1129.0735157691095 1327.3477059417044 1328.8529463332213 1158.9482352949992 1162.6616266571687 1337.673334928735 1335.5299009132868 1320.4223892987168 1319.5962131254125 1576.8457874610385 1569.1918278815451 1321.6947705703997 1307.3573988895266 1626.5459263041403 1623.3102107195436 814.8573381057946 812.4066537573394 983.1301688155413 983.6500172637188 983.5621595544255 985.4909252318964 1115.724170311941 1176.20577420251 1094.854938568777 1162.0180569724698 1507.4790169098837 1508.0368807612485 1510.6048277334332 1502.2039094059066 1507.4358620390447 1508.4736360749498 1509.0987523392023 1515.0021184805923
associateChild	None

code AR_TEMP_ACB
name Temperature ACB
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 28.568
associateChild None
code AR_TEMP_ASLDO
name Temperature Ana SLDO
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 29.214
associateChild None
code AR_TEMP_DSLDO
name Temperature Dig SLDO
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 30.407
associateChild None
code AR_TEMP_EXT
name Control temperature (external NTC from the FE)
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 20
associateChild None
code AR_TEMP_NF_ACB
name Temperature calibration constant (ACB)
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 1.257
associateChild None
code AR_TEMP_NF_ASLDO
name Temperature calibration constant (ana SLDO)
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 1.258
associateChild None
code AR_TEMP_NF_BOTTOM
name Temperature calibration constant (poly bottom)
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value -999
associateChild None
code AR_TEMP_NF_DSLDO
name Temperature calibration constant (dig SLDO)
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 1.257
associateChild None
code AR_TEMP_NF_TOP
name Temperature calibration constant (poly top)
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value -999
associateChild None
code AR_TEMP_NTC
name Temperature NTC
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value 21.834
associateChild None
code AR_TEMP_POLY_BOTTOM
name Temperature poly bottom
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value -999
associateChild None
code AR_TEMP_POLY_TOP
name Temperature poly top
dataType float
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value -999
associateChild None
code AR_VCALDAC
name AR_VCALDAC (V)
order 26
dataType float
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 0.82
associateChild None
code AR_VDDA_SATURATION
name VDDA saturation trim value
dataType integer
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value -1
associateChild None
code AR_VDDA_TRIM
name VDDA Trim
dataType integer
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 9
associateChild None

code	AR_VDDA_VS_TRIM
name	VDDA vs trim
dataType	float
valueType	array
arrayDimensions	1
additional	None
rangeMin	None
rangeMax	None
value	0.983 1.008 1.033 1.057 1.081 1.106 1.13 1.155 1.178 1.202 1.225 1.251 1.275 1.299 1.323 1.346
associateChild	None

code AR_VDDD_SATURATION
name VDDD saturation trim value
dataType integer
valueType single
arrayDimensions None
additional None
rangeMin None
rangeMax None
value -1
associateChild None
code AR_VDDD_TRIM
name VDDD Trim
dataType integer
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 8
associateChild None

code	AR_VDDD_VS_TRIM
name	VDDD vs trim
dataType	float
valueType	array
arrayDimensions	1
additional	None
rangeMin	None
rangeMax	None
value	1.011 1.036 1.058 1.084 1.108 1.132 1.156 1.178 1.209 1.232 1.256 1.28 1.306 1.331 1.356 1.38
associateChild	None

code AR_VREFCORE
name AR_VREFCORE (V)
order 27
dataType float
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 0.46
associateChild None
code AR_VREFOVP
name AR_VREFOVP (V)
order 28
dataType float
valueType single
arrayDimensions None
additional False
rangeMin None
rangeMax None
value 1.981
associateChild None

cts

2026-03-17T05:39:58.865Z

sys

cts	2026-03-17T05:39:58.865Z
mts	2026-03-17T05:40:06.182Z
rev	2

defects

comments

None

attachments

code

e03758312bddab4d4bca54beae14c6b7

dateTime

2026-03-17T05:39:59.215Z

title

TestRun_69b8e92e484777dd851a5d85_Attachment_Pack.zip

description

/home/data/viewer/static/cache/thumbnail/TestRun_69b8e92e484777dd851a5d85_Attachment_Pack.zip

contentType

None

type

eos

url

https://eosatlas.cern.ch/eos/atlas/atlascerngroupdisk/det-itk/prod-db/e/0/3/e03758312bddab4d4bca54beae14c6b7?authz=zteos64:MDAwMDAyZjR4nO2RP0sDQRDFTUSRICiWKWQIFjaX273_GRCsU1hIGgkpdm_3LkeS2-Nur0mjoJW1hZ_ANoh-iFQB_Qpim1JLPYOFhbWVU7zix3vDDK_xUm_U8t2768unzeZGokeZaNWn2WHN6plSFSbTY_atoczTOFdlJpJiZAqpjcpuZrkShuCmNIlpm5LYvhvY1OJCMO4Ih4fMdbhkkjqhx_3uASEB5xEJDDdizKA0ogazoshgTkWp33GF1Tld1Pq9YQndMgVwgFhIKboBWMTyBlAmAqlDvYD2V_cOIP4iNvH702wAOhEy1ZgrpduUBpaNDgnc4z5iVA26tKJeuxO0KRlAyiYSV1tApAjVMxpHOXeBZRnCUBUafw8KNWFJij9ILBVCUQqFBHTOQomgUi6HbBzhHty8x_ez-eyKvj4syrOtHf92__xiLSJL4-jjbbt10vzv4Q96gMfl_Hn9E4X96-w%3d

urlCernbox

https://cernbox.cern.ch/files/spaces/eos/atlas/atlascerngroupdisk/det-itk/prod-db/e/0/3/e03758312bddab4d4bca54beae14c6b7

filename

e03758312bddab4d4bca54beae14c6b7

user

id	67ee104c69bd7fedf75bb0e4
userIdentity	3339-2662-1
firstName	David
middleName
lastName	Jiang

code

fdda24478616a2661dd25377a17eda0f

dateTime

2026-03-17T05:40:06.045Z

title

RAW

description

RAW

contentType

text/plain

type

file

binaryStoreg02

True

filename

data

user

id	67ee104c69bd7fedf75bb0e4
userIdentity	3339-2662-1
firstName	David
middleName
lastName	Jiang

components

code

state

stateTs

stateUserIdentity

dummy

completed

completedTs

completedUserIdentity

trashed

trashedTs

trashedUserIdentity

serialNumber

alternativeIdentifier

ancestorMap

project

subproject

componentType

type

properties

testedAtStage

institution

660fbeb2ec873d00354e22e0

fddce8b2baa3c6843d64584a65d38918

ready

2024-04-05T09:04:50.429Z

5310-2637-1

False

None

False

None

20UPGFC0146117

None

parent

component

683ecb8ad71df4c2775e1f29

code

88d0df7250a5743e1413669cfec92aa6

state

ready

stateTs

2025-06-03T10:16:42.959Z

stateUserIdentity

23-6780-1

dummy

False

completed

False

completedTs

None

completedUserIdentity

None

trashed

False

trashedTs

None

trashedUserIdentity

None

serialNumber

20UPGB43200441

alternativeIdentifier

None

project

code	P
name	Pixels

subproject

code	PG
name	Pixel general

componentType

code	BARE_MODULE
name	Bare Module

type

code	QUAD_BARE_MODULE
name	Quad bare module

testedAtStage

code	MODULE/POST_PARYLENE_COLD
name	Post-Parylene Cold

highestLevelParent

component

689ce9a34352ea8e9ff68678

code

da08d9a012077f1e54f8317419d64efb

state

ready

stateTs

2025-08-13T19:38:11.115Z

stateUserIdentity

1294-8027-1

dummy

False

completed

False

completedTs

None

completedUserIdentity

None

trashed

False

trashedTs

None

trashedUserIdentity

None

serialNumber

20UPGM24211761

alternativeIdentifier

ANL_ITkPix_140

project

code	P
name	Pixels

subproject

code	PG
name	Pixel general

componentType

code	MODULE
name	Module

type

code	OUTER_SYSTEM_QUAD_MODULE
name	Outer system quad module

testedAtStage

code	MODULE/POST_PARYLENE_COLD
name	Post-Parylene Cold

code	P
name	Pixels

code	PG
name	Pixel general

code	FE_CHIP
name	Front-end Chip

code	ITKPIX_V2
name	ITkpix_V2

code	name	dataType	required	default	value
TARGET_IREF_TRIM	Target Iref trim	integer	False	False	9
TARGET_IREF_TRIM_VERSION	Target Iref trim version	string	False	False	1

code	MODULE/INITIAL_WARM
name	Initial Warm
order	8
initial	False
final	False

code	GL
name	Glasgow University

Current Stage: Final Cold

Test Type	Local Result
ADC Calibration (ADC_CALIBRATION)	TestRun Present
Analog Readback (ANALOG_READBACK)	TestRun Present
SLDO (SLDO)	TestRun Present
VCAL Calibration (VCAL_CALIBRATION)	TestRun Present
Injection Capacitance (INJECTION_CAPACITANCE)	TestRun Present
Low Power Mode (LP_MODE)	No TestRun!
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No TestRun!
Undershunt Protection (UNDERSHUNT_PROTECTION)	No TestRun!
Tuning (TUNING)	TestRun Present
Minimal Health Test (MIN_HEALTH_TEST)	TestRun Present
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	TestRun Present
Data Transmission (DATA_TRANSMISSION)	TestRun Present
Cold startup (COLD_STARTUP)	No TestRun!

Candidate TestRuns of this Stage

LDB ID	TestRun Code	QC Passed	Inspector	Measurement Date	Analysis Date	Analysis Version	Tags	QC Registration
690d23…11a97b	PIXEL_FAILURE_ANALYSIS	Pass	DavidJiang	N/A	3 months ago	2.6.4	No tags	Selected
690d23…11a8a4	TUNING	Pass	DavidJiang	N/A	3 months ago	2.6.4	No tags	Selected
690d22…11a6de	MIN_HEALTH_TEST	Pass	DavidJiang	N/A	3 months ago	2.6.4	No tags	Selected
690d22…11a818	INJECTION_CAPACITANCE	Pass	DavidJiang	7 months ago	3 months ago	2.6.4	No tags	Selected
690d22…11a7c8	DATA_TRANSMISSION	Pass	DavidJiang	7 months ago	3 months ago	2.6.4	No tags	Selected
690d23…11a843	LP_MODE	Pass	DavidJiang	7 months ago	3 months ago	2.6.4	No tags	Selected
690d22…11a788	VCAL_CALIBRATION	Pass	DavidJiang	7 months ago	3 months ago	2.6.4	No tags	Selected
690d22…11a6ab	SLDO	Pass	DavidJiang	7 months ago	3 months ago	2.6.4	No tags	Selected
690d22…11a655	ANALOG_READBACK	Pass	DavidJiang	7 months ago	3 months ago	2.6.4	No tags	Selected
690d22…11a5a3	ADC_CALIBRATION	Pass	DavidJiang	7 months ago	3 months ago	2.6.4	No tags	Selected

Past QC Stages and Results

Final Warm (MODULE/FINAL_WARM)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	Registered	Registered
Analog Readback (ANALOG_READBACK)	Registered	Registered
Data Transmission (DATA_TRANSMISSION)	Registered	Registered
Injection Capacitance (INJECTION_CAPACITANCE)	Registered	Registered
Low Power Mode (LP_MODE)	Registered	Registered
Minimal Health Test (MIN_HEALTH_TEST)	Registered	Registered
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	Registered	Registered
SLDO (SLDO)	Registered	Registered
Tuning (TUNING)	Registered	Registered
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	Registered	Registered

Long Term Stability Test (MODULE/LONG_TERM_STABILITY_TEST)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Thermal Cycles (MODULE/THERMAL_CYCLES)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Cold startup (COLD_STARTUP)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Post-Parylene Cold (MODULE/POST_PARYLENE_COLD)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Post-Parylene Warm (MODULE/POST_PARYLENE_WARM)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	Registered	Registered
Analog Readback (ANALOG_READBACK)	Registered	Registered
Data Transmission (DATA_TRANSMISSION)	Registered	Registered
Injection Capacitance (INJECTION_CAPACITANCE)	Registered	Registered
Low Power Mode (LP_MODE)	Registered	Registered
Minimal Health Test (MIN_HEALTH_TEST)	Registered	Registered
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	Registered	Registered
SLDO (SLDO)	Registered	Registered
Tuning (TUNING)	Registered	Registered
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	Registered	Registered

Wirebond Protection (alt) (MODULE/WIREBOND_PROTECTION)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Parylene Unmasking (MODULE/PARYLENE_UNMASKING)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Parylene Coating (MODULE/PARYLENE_COATING)

Parylene Masking (MODULE/PARYLENE_MASKING)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Initial Cold (MODULE/INITIAL_COLD)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

QC cross-check (module swapping) (MODULE/QC_CROSSCHECK)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	Registered	Registered
Analog Readback (ANALOG_READBACK)	Registered	Registered
Data Transmission (DATA_TRANSMISSION)	Registered	Registered
Injection Capacitance (INJECTION_CAPACITANCE)	Registered	Registered
Low Power Mode (LP_MODE)	Registered	Registered
Minimal Health Test (MIN_HEALTH_TEST)	Registered	Registered
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	Registered	Registered
SLDO (SLDO)	Registered	Registered
Tuning (TUNING)	Registered	Registered
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	Registered	Registered

Initial Warm (MODULE/INITIAL_WARM)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	Registered	Registered
Analog Readback (ANALOG_READBACK)	Registered	Registered
Data Transmission (DATA_TRANSMISSION)	Registered	Registered
Injection Capacitance (INJECTION_CAPACITANCE)	Registered	Registered
Low Power Mode (LP_MODE)	Registered	Registered
Minimal Health Test (MIN_HEALTH_TEST)	Registered	Registered
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	Registered	Registered
SLDO (SLDO)	Registered	Registered
Tuning (TUNING)	Registered	Registered
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	Registered	Registered

Wire Bonding (MODULE/WIREBONDING)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Bare module to module PCB assembly (MODULE/ASSEMBLY)

Initial state to associate flex to bare module (MODULE/INIT)

Reception at ITk institute (BAREMODULERECEPTION)

Test	Local Result	ProdDB Record
Analog Readback (ANALOG_READBACK)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A

Bare module assembly (BAREMODULEASSEMBLY)

Not to be used for detector (UNUSABLE)

Hybridisation (HYBRIDISATION)

Testing on wafer (TESTONWAFER)

Test	Local Result	ProdDB Record
Electrical FE chip tests (FECHIP_TEST)	Registered	Registered

LocalDB Test ID	Stage	Test Name	Inspector	Measurement Date	Analysis Date	Tags	QC Registration
6a2ae6…bbba2f	MODULE/FINAL_COLD	PIXEL_FAILURE_ANALYSIS	None	N/A	a day ago	No tags	Selected
6a2ae5…9d18b6	MODULE/FINAL_COLD	PIXEL_FAILURE_ANALYSIS	None	N/A	a day ago	No tags
6a2ae5…7458b2	MODULE/FINAL_COLD	PIXEL_FAILURE_ANALYSIS	None	N/A	a day ago	No tags
6a2ae4…bbb9c0	MODULE/FINAL_COLD	MIN_HEALTH_TEST	None	N/A	a day ago	No tags	Selected
6a2ae4…9d17bb	MODULE/FINAL_COLD	TUNING	None	N/A	a day ago	No tags	Selected
6a2a56…8cd9ce	MODULE/FINAL_COLD	DATA_TRANSMISSION	None	2 days ago	2 days ago	ganymede_3	Selected
6a2a56…74578f	MODULE/FINAL_COLD	INJECTION_CAPACITANCE	None	2 days ago	2 days ago	ganymede_3	Selected
6a2a3c…3e154e	MODULE/FINAL_COLD	VCAL_CALIBRATION	None	2 days ago	2 days ago	ganymede_3	Selected
6a2a3a…bbb8e4	MODULE/FINAL_COLD	SLDO	None	2 days ago	2 days ago	ganymede_3	Selected
6a2a32…8cd944	MODULE/FINAL_COLD	ANALOG_READBACK	None	2 days ago	2 days ago	ganymede_3	Selected
6a2a17…3e1342	MODULE/FINAL_COLD	ADC_CALIBRATION	None	2 days ago	2 days ago	ganymede_3	Selected
6a2a10…3e12f0	MODULE/FINAL_COLD	ADC_CALIBRATION	None	2 days ago	2 days ago	ganymede_3
6a2a00…8cd7cc	MODULE/FINAL_WARM	TUNING	None	N/A	2 days ago	No tags	Selected
6a2a00…bbb4b0	MODULE/FINAL_WARM	PIXEL_FAILURE_ANALYSIS	None	N/A	2 days ago	No tags	Selected
6a2a00…8cd729	MODULE/FINAL_WARM	MIN_HEALTH_TEST	None	N/A	2 days ago	No tags	Selected
6a29e8…017c01	MODULE/FINAL_WARM	DATA_TRANSMISSION	None	3 days ago	2 days ago	ganymede_3	Selected
6a29b3…e92c77	MODULE/FINAL_WARM	TUNING	None	N/A	2 days ago	No tags
6a29b2…8e9898	MODULE/FINAL_WARM	PIXEL_FAILURE_ANALYSIS	None	N/A	2 days ago	No tags
6a29b1…e92bce	MODULE/FINAL_WARM	MIN_HEALTH_TEST	None	N/A	2 days ago	No tags
6a28cc…0177f3	MODULE/FINAL_WARM	LP_MODE	None	3 days ago	3 days ago	ganymede_3	Selected
6a28c7…01775c	MODULE/FINAL_WARM	INJECTION_CAPACITANCE	None	3 days ago	3 days ago	ganymede_3	Selected
6a28c3…e926e9	MODULE/FINAL_WARM	VCAL_CALIBRATION	None	3 days ago	3 days ago	ganymede_3	Selected
6a28c0…8e9705	MODULE/FINAL_WARM	SLDO	None	3 days ago	3 days ago	ganymede_3	Selected
6a28b5…8e9647	MODULE/FINAL_WARM	ANALOG_READBACK	None	3 days ago	3 days ago	ganymede_3	Selected
6a289a…18999e	MODULE/FINAL_WARM	ADC_CALIBRATION	None	3 days ago	3 days ago	ganymede_3	Selected
6a2209…e52876	MODULE/QC_CROSSCHECK	PIXEL_FAILURE_ANALYSIS	None	N/A	a week ago	No tags	Selected
6a2209…fe5435	MODULE/QC_CROSSCHECK	TUNING	None	N/A	a week ago	No tags	Selected
6a2208…d1a27b	MODULE/QC_CROSSCHECK	MIN_HEALTH_TEST	None	N/A	a week ago	No tags	Selected
6a21fa…8ab64c	MODULE/QC_CROSSCHECK	DATA_TRANSMISSION	None	a week ago	a week ago	ganymede_3	Selected
6a21f5…f73d75	MODULE/QC_CROSSCHECK	LP_MODE	None	a week ago	a week ago	ganymede_3	Selected
6a21f4…e527f2	MODULE/QC_CROSSCHECK	INJECTION_CAPACITANCE	None	a week ago	a week ago	ganymede_3	Selected
6a21f3…fe52ba	MODULE/QC_CROSSCHECK	VCAL_CALIBRATION	None	a week ago	a week ago	ganymede_3	Selected
6a21f1…8ab608	MODULE/QC_CROSSCHECK	SLDO	None	a week ago	a week ago	ganymede_3	Selected
6a21eb…e5273a	MODULE/QC_CROSSCHECK	ANALOG_READBACK	None	a week ago	a week ago	ganymede_3	Selected
6a21d7…f73c6c	MODULE/QC_CROSSCHECK	ADC_CALIBRATION	None	a week ago	a week ago	ganymede_3	Selected
6a20a2…dad763	MODULE/QC_CROSSCHECK	DATA_TRANSMISSION	None	a week ago	a week ago	ganymede_3
6a20a1…dad6f5	MODULE/QC_CROSSCHECK	LP_MODE	None	a week ago	a week ago	ganymede_3
6a20a0…4161b3	MODULE/QC_CROSSCHECK	INJECTION_CAPACITANCE	None	a week ago	a week ago	ganymede_3
6a20a0…41615e	MODULE/QC_CROSSCHECK	VCAL_CALIBRATION	None	a week ago	a week ago	ganymede_3
6a209e…9dae30	MODULE/QC_CROSSCHECK	SLDO	None	a week ago	a week ago	ganymede_3
6a208b…f71084	MODULE/QC_CROSSCHECK	ADC_CALIBRATION	None	a week ago	a week ago	ganymede_3
6a1e1b…8bfb8c	MODULE/QC_CROSSCHECK	DATA_TRANSMISSION	None	a week ago	a week ago	ganymede_3
6a1e1a…8bfb68	MODULE/QC_CROSSCHECK	LP_MODE	None	a week ago	a week ago	ganymede_3
6a1e1a…8bfb44	MODULE/QC_CROSSCHECK	INJECTION_CAPACITANCE	None	a week ago	a week ago	ganymede_3
6a1e19…40849e	MODULE/QC_CROSSCHECK	VCAL_CALIBRATION	None	a week ago	a week ago	ganymede_3
6a1e18…acd15c	MODULE/QC_CROSSCHECK	SLDO	None	a week ago	a week ago	ganymede_3
6a1e15…8bfb10	MODULE/QC_CROSSCHECK	ANALOG_READBACK	None	a week ago	a week ago	ganymede_3
6a1e0b…8bfa78	MODULE/QC_CROSSCHECK	ADC_CALIBRATION	None	a week ago	a week ago	ganymede_3
6a1dff…84105a	MODULE/QC_CROSSCHECK	ADC_CALIBRATION	None	a week ago	a week ago	ganymede_3
6a1b95…9ca922	MODULE/QC_CROSSCHECK	DATA_TRANSMISSION	None	a week ago	a week ago	ganymede_3
6a1b95…1b63fc	MODULE/QC_CROSSCHECK	LP_MODE	None	a week ago	a week ago	ganymede_3
6a1b94…1b63d8	MODULE/QC_CROSSCHECK	INJECTION_CAPACITANCE	None	a week ago	a week ago	ganymede_3
6a1b93…0e5fa5	MODULE/QC_CROSSCHECK	VCAL_CALIBRATION	None	a week ago	a week ago	ganymede_3
6a1b92…9ca8fb	MODULE/QC_CROSSCHECK	SLDO	None	a week ago	a week ago	ganymede_3
6a1b8d…1b63a2	MODULE/QC_CROSSCHECK	ANALOG_READBACK	None	a week ago	a week ago	ganymede_3
6a1b7f…9ca8b4	MODULE/QC_CROSSCHECK	ADC_CALIBRATION	None	a week ago	a week ago	ganymede_3
6a1a70…9ca804	MODULE/QC_CROSSCHECK	INJECTION_CAPACITANCE	None	2 weeks ago	2 weeks ago	ganymede_3
6a1a70…184ed8	MODULE/QC_CROSSCHECK	VCAL_CALIBRATION	None	2 weeks ago	2 weeks ago	ganymede_3
6a1a6e…9ca78b	MODULE/QC_CROSSCHECK	SLDO	None	2 weeks ago	2 weeks ago	ganymede_3
6a1a6a…1b625e	MODULE/QC_CROSSCHECK	ANALOG_READBACK	None	2 weeks ago	2 weeks ago	ganymede_3
6a1a4e…9ca6ba	MODULE/QC_CROSSCHECK	ADC_CALIBRATION	None	2 weeks ago	2 weeks ago	ganymede_3
6a18a6…652130	MODULE/THERMAL_CYCLES	ADC_CALIBRATION	None	2 weeks ago	2 weeks ago	ganymede_3
6a1782…d957bd	MODULE/THERMAL_CYCLES	INJECTION_CAPACITANCE	None	2 weeks ago	2 weeks ago	ganymede_3
6a1781…bb4c9a	MODULE/THERMAL_CYCLES	VCAL_CALIBRATION	None	2 weeks ago	2 weeks ago	ganymede_3
6a177f…d95784	MODULE/THERMAL_CYCLES	SLDO	None	2 weeks ago	2 weeks ago	ganymede_3
6a1779…bb4ba2	MODULE/THERMAL_CYCLES	ANALOG_READBACK	None	2 weeks ago	2 weeks ago	ganymede_3
6a1765…d9572f	MODULE/THERMAL_CYCLES	ADC_CALIBRATION	None	2 weeks ago	2 weeks ago	ganymede_3
6a1756…c32ce0	MODULE/THERMAL_CYCLES	ADC_CALIBRATION	None	2 weeks ago	2 weeks ago	ganymede_3
699756…792551	MODULE/POST_PARYLENE_WARM	LP_MODE	DavidJiang	4 months ago	3 months ago	No tags	Selected
699768…64e780	MODULE/POST_PARYLENE_WARM	PIXEL_FAILURE_ANALYSIS	DavidJiang	N/A	3 months ago	No tags	Selected
699768…64e6a9	MODULE/POST_PARYLENE_WARM	TUNING	DavidJiang	N/A	3 months ago	No tags	Selected
699768…64e5ec	MODULE/POST_PARYLENE_WARM	MIN_HEALTH_TEST	DavidJiang	N/A	3 months ago	No tags	Selected
699755…792526	MODULE/POST_PARYLENE_WARM	INJECTION_CAPACITANCE	DavidJiang	4 months ago	3 months ago	No tags	Selected
699754…7924d6	MODULE/POST_PARYLENE_WARM	DATA_TRANSMISSION	DavidJiang	4 months ago	3 months ago	No tags	Selected
699754…792496	MODULE/POST_PARYLENE_WARM	VCAL_CALIBRATION	DavidJiang	4 months ago	3 months ago	No tags	Selected
699753…792436	MODULE/POST_PARYLENE_WARM	SLDO	DavidJiang	4 months ago	3 months ago	No tags	Selected
699750…7923e6	MODULE/POST_PARYLENE_WARM	ANALOG_READBACK	DavidJiang	4 months ago	3 months ago	No tags	Selected
699749…792336	MODULE/POST_PARYLENE_WARM	ADC_CALIBRATION	DavidJiang	4 months ago	3 months ago	No tags	Selected
690d23…11a97b	MODULE/INITIAL_WARM	PIXEL_FAILURE_ANALYSIS	DavidJiang	N/A	3 months ago	No tags	Selected
690d23…11a8a4	MODULE/INITIAL_WARM	TUNING	DavidJiang	N/A	3 months ago	No tags	Selected
690d22…11a6de	MODULE/INITIAL_WARM	MIN_HEALTH_TEST	DavidJiang	N/A	3 months ago	No tags	Selected
690d22…11a818	MODULE/INITIAL_WARM	INJECTION_CAPACITANCE	DavidJiang	7 months ago	3 months ago	No tags	Selected
690d22…11a7c8	MODULE/INITIAL_WARM	DATA_TRANSMISSION	DavidJiang	7 months ago	3 months ago	No tags	Selected
690d23…11a843	MODULE/INITIAL_WARM	LP_MODE	DavidJiang	7 months ago	3 months ago	No tags	Selected
690d22…11a788	MODULE/INITIAL_WARM	VCAL_CALIBRATION	DavidJiang	7 months ago	3 months ago	No tags	Selected
690d22…11a6ab	MODULE/INITIAL_WARM	SLDO	DavidJiang	7 months ago	3 months ago	No tags	Selected
690d22…11a655	MODULE/INITIAL_WARM	ANALOG_READBACK	DavidJiang	7 months ago	3 months ago	No tags	Selected
690d22…11a5a3	MODULE/INITIAL_WARM	ADC_CALIBRATION	DavidJiang	7 months ago	3 months ago	No tags	Selected
660fc0…149dc2	TESTONWAFER	FECHIP_TEST	DimaManeuski	N/A	a year ago	No tags	Selected

Run	Date	Test Type	Stage	User	Site	Tags	Status
1999	2 days ago	std_mergedbumpscan	MODULE/FINAL_COLD	pixqc	jittereel.dhcp.lbl.gov	PFA	Pass
1998	2 days ago	std_discbumpscan	MODULE/FINAL_COLD	pixqc	jittereel.dhcp.lbl.gov	PFA	Pass
1997	2 days ago	std_noisescan	MODULE/FINAL_COLD	pixqc	jittereel.dhcp.lbl.gov	PFA	Pass
1996	2 days ago	std_totscan	MODULE/FINAL_COLD	pixqc	jittereel.dhcp.lbl.gov	PFA	Pass
1995	2 days ago	std_thresholdscan_hd	MODULE/FINAL_COLD	pixqc	jittereel.dhcp.lbl.gov	PFA	Pass
1994	2 days ago	std_analogscan	MODULE/FINAL_COLD	pixqc	jittereel.dhcp.lbl.gov	PFA	Pass
1993	2 days ago	std_digitalscan	MODULE/FINAL_COLD	pixqc	jittereel.dhcp.lbl.gov	PFA	Pass
1991	2 days ago	std_totscan	MODULE/FINAL_COLD	pixqc	jittereel.dhcp.lbl.gov	TUN	Pass
1990	2 days ago	std_thresholdscan_hd	MODULE/FINAL_COLD	pixqc	jittereel.dhcp.lbl.gov	TUN	Pass
1989	2 days ago	std_tune_pixelthreshold	MODULE/FINAL_COLD	pixqc	jittereel.dhcp.lbl.gov	TUN	Pass
1988	2 days ago	std_tune_globalthreshold	MODULE/FINAL_COLD	pixqc	jittereel.dhcp.lbl.gov	TUN	Pass
1987	2 days ago	std_tune_globalpreamp	MODULE/FINAL_COLD	pixqc	jittereel.dhcp.lbl.gov	TUN	Pass
1986	2 days ago	std_tune_globalthreshold	MODULE/FINAL_COLD	pixqc	jittereel.dhcp.lbl.gov	TUN	Pass
1985	2 days ago	std_totscan	MODULE/FINAL_COLD	pixqc	jittereel.dhcp.lbl.gov	TUN	Pass
1984	2 days ago	std_thresholdscan_hr	MODULE/FINAL_COLD	pixqc	jittereel.dhcp.lbl.gov	TUN	Pass
1982	2 days ago	std_totscan	MODULE/FINAL_COLD	pixqc	jittereel.dhcp.lbl.gov	MHT	Pass
1981	2 days ago	std_thresholdscan_hr	MODULE/FINAL_COLD	pixqc	jittereel.dhcp.lbl.gov	MHT	Pass
1980	2 days ago	std_analogscan	MODULE/FINAL_COLD	pixqc	jittereel.dhcp.lbl.gov	MHT	Pass
1979	2 days ago	std_digitalscan	MODULE/FINAL_COLD	pixqc	jittereel.dhcp.lbl.gov	MHT	Pass
1867	3 days ago	std_mergedbumpscan	MODULE/FINAL_WARM	pixqc	jittereel.dhcp.lbl.gov	PFA	Pass
1864	3 days ago	std_discbumpscan	MODULE/FINAL_WARM	pixqc	jittereel.dhcp.lbl.gov	PFA	Pass
1861	3 days ago	std_noisescan	MODULE/FINAL_WARM	pixqc	jittereel.dhcp.lbl.gov	PFA	Pass
1857	3 days ago	std_totscan	MODULE/FINAL_WARM	pixqc	jittereel.dhcp.lbl.gov	PFA	Pass
1853	3 days ago	std_thresholdscan_hd	MODULE/FINAL_WARM	pixqc	jittereel.dhcp.lbl.gov	PFA	Pass
1849	3 days ago	std_analogscan	MODULE/FINAL_WARM	pixqc	jittereel.dhcp.lbl.gov	PFA	Pass
1845	3 days ago	std_digitalscan	MODULE/FINAL_WARM	pixqc	jittereel.dhcp.lbl.gov	PFA	Pass
1836	3 days ago	std_totscan	MODULE/FINAL_WARM	pixqc	jittereel.dhcp.lbl.gov	TUN	Pass
1832	3 days ago	std_thresholdscan_hd	MODULE/FINAL_WARM	pixqc	jittereel.dhcp.lbl.gov	TUN	Pass
1829	3 days ago	std_tune_pixelthreshold	MODULE/FINAL_WARM	pixqc	jittereel.dhcp.lbl.gov	TUN	Pass
1825	3 days ago	std_tune_globalthreshold	MODULE/FINAL_WARM	pixqc	jittereel.dhcp.lbl.gov	TUN	Pass
1821	3 days ago	std_tune_globalpreamp	MODULE/FINAL_WARM	pixqc	jittereel.dhcp.lbl.gov	TUN	Pass
1817	3 days ago	std_tune_globalthreshold	MODULE/FINAL_WARM	pixqc	jittereel.dhcp.lbl.gov	TUN	Pass
1813	3 days ago	std_totscan	MODULE/FINAL_WARM	pixqc	jittereel.dhcp.lbl.gov	TUN	Pass
1809	3 days ago	std_thresholdscan_hr	MODULE/FINAL_WARM	pixqc	jittereel.dhcp.lbl.gov	TUN	Pass
1800	3 days ago	std_totscan	MODULE/FINAL_WARM	pixqc	jittereel.dhcp.lbl.gov	MHT	Pass
1796	3 days ago	std_thresholdscan_hr	MODULE/FINAL_WARM	pixqc	jittereel.dhcp.lbl.gov	MHT	Pass
1793	3 days ago	std_analogscan	MODULE/FINAL_WARM	pixqc	jittereel.dhcp.lbl.gov	MHT	Pass
1789	3 days ago	std_digitalscan	MODULE/FINAL_WARM	pixqc	jittereel.dhcp.lbl.gov	MHT	Pass
1709	a week ago	std_mergedbumpscan	MODULE/QC_CROSSCHECK	pixqc	jittereel.dhcp.lbl.gov	PFA	Pass
1708	a week ago	std_discbumpscan	MODULE/QC_CROSSCHECK	pixqc	jittereel.dhcp.lbl.gov	PFA	Pass
1707	a week ago	std_noisescan	MODULE/QC_CROSSCHECK	pixqc	jittereel.dhcp.lbl.gov	PFA	Pass
1706	a week ago	std_totscan	MODULE/QC_CROSSCHECK	pixqc	jittereel.dhcp.lbl.gov	PFA	Pass
1705	a week ago	std_thresholdscan_hd	MODULE/QC_CROSSCHECK	pixqc	jittereel.dhcp.lbl.gov	PFA	Pass
1704	a week ago	std_analogscan	MODULE/QC_CROSSCHECK	pixqc	jittereel.dhcp.lbl.gov	PFA	Pass
1703	a week ago	std_digitalscan	MODULE/QC_CROSSCHECK	pixqc	jittereel.dhcp.lbl.gov	PFA	Pass
1701	a week ago	std_totscan	MODULE/QC_CROSSCHECK	pixqc	jittereel.dhcp.lbl.gov	TUN	Pass
1700	a week ago	std_thresholdscan_hd	MODULE/QC_CROSSCHECK	pixqc	jittereel.dhcp.lbl.gov	TUN	Pass
1699	a week ago	std_tune_pixelthreshold	MODULE/QC_CROSSCHECK	pixqc	jittereel.dhcp.lbl.gov	TUN	Pass
1698	a week ago	std_tune_globalthreshold	MODULE/QC_CROSSCHECK	pixqc	jittereel.dhcp.lbl.gov	TUN	Pass
1697	a week ago	std_tune_globalpreamp	MODULE/QC_CROSSCHECK	pixqc	jittereel.dhcp.lbl.gov	TUN	Pass
1696	a week ago	std_tune_globalthreshold	MODULE/QC_CROSSCHECK	pixqc	jittereel.dhcp.lbl.gov	TUN	Pass
1694	a week ago	std_totscan	MODULE/QC_CROSSCHECK	pixqc	jittereel.dhcp.lbl.gov	TUN	Pass
1692	a week ago	std_thresholdscan_hr	MODULE/QC_CROSSCHECK	pixqc	jittereel.dhcp.lbl.gov	TUN	Pass
1687	a week ago	std_totscan	MODULE/QC_CROSSCHECK	pixqc	jittereel.dhcp.lbl.gov	MHT	Pass
1685	a week ago	std_thresholdscan_hr	MODULE/QC_CROSSCHECK	pixqc	jittereel.dhcp.lbl.gov	MHT	Pass
1683	a week ago	std_analogscan	MODULE/QC_CROSSCHECK	pixqc	jittereel.dhcp.lbl.gov	MHT	Pass
1681	a week ago	std_digitalscan	MODULE/QC_CROSSCHECK	pixqc	jittereel.dhcp.lbl.gov	MHT	Pass
1625	a week ago	std_totscan	MODULE/QC_CROSSCHECK	pixqc	jittereel.dhcp.lbl.gov	MHT	Pass
1624	a week ago	std_thresholdscan_hr	MODULE/QC_CROSSCHECK	pixqc	jittereel.dhcp.lbl.gov	MHT	Pass
1623	a week ago	std_analogscan	MODULE/QC_CROSSCHECK	pixqc	jittereel.dhcp.lbl.gov	MHT	Pass
1622	a week ago	std_digitalscan	MODULE/QC_CROSSCHECK	pixqc	jittereel.dhcp.lbl.gov	MHT	Pass
1620	a week ago	std_totscan	MODULE/QC_CROSSCHECK	pixqc	jittereel.dhcp.lbl.gov	MHT	Pass
1619	a week ago	std_thresholdscan_hr	MODULE/QC_CROSSCHECK	pixqc	jittereel.dhcp.lbl.gov	MHT	Pass
1618	a week ago	std_analogscan	MODULE/QC_CROSSCHECK	pixqc	jittereel.dhcp.lbl.gov	MHT	Pass
1616	a week ago	std_digitalscan	MODULE/QC_CROSSCHECK	pixqc	jittereel.dhcp.lbl.gov	MHT	Pass
1610	a week ago	std_totscan	MODULE/QC_CROSSCHECK	pixqc	jittereel.dhcp.lbl.gov	MHT	Pass
1609	a week ago	std_thresholdscan_hr	MODULE/QC_CROSSCHECK	pixqc	jittereel.dhcp.lbl.gov	MHT	Pass
1608	a week ago	std_analogscan	MODULE/QC_CROSSCHECK	pixqc	jittereel.dhcp.lbl.gov	MHT	Pass
1607	a week ago	std_digitalscan	MODULE/QC_CROSSCHECK	pixqc	jittereel.dhcp.lbl.gov	MHT	Pass

Stage: MODULE/FINAL_COLD

Mode: warm

Index	Revision ID	Timestamp	Message
HEAD	6a2a...9d160b	2 days ago	downloaded from ITkPD : code = 6f16e6be6991e749a804e4cb61354bcf, description = {"_id":"6a2891e21b95443ad3794b6f","serialNumber":"20UPGFC0146117","stage":"MODULE/FINAL_WARM","branch":"warm","current_revision_id":"6a29e80b66f3d07de1017c09"}
HEAD^1	6a2a...bbb66b	2 days ago	downloaded from ITkPD : code = 574cfb834f9f26120b7fdfafa9fdfb56, description = {"_id":"6a1f3b5e3728ff7b06582948","serialNumber":"20UPGFC0146117","stage":"MODULE/QC_CROSSCHECK","branch":"warm","current_revision_id":"6a2205c36f04e298c8e2e31f"}

Mode: cold

Index	Revision ID	Timestamp	Message
HEAD	6a2a...d1055d	2 days ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^1	6a2a...2f8d12	2 days ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^2	6a2a...9af3bd	2 days ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^3	6a2a...00c33d	2 days ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^4	6a2a...fbc514	2 days ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^5	6a2a...6bef31	2 days ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^6	6a2a...7b1aea	2 days ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^7	6a2a...79878e	2 days ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^8	6a2a...68bc68	2 days ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^9	6a2a...614c35	2 days ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^10	6a2a...6287ea	2 days ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^11	6a2a...57e1e2	2 days ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^12	6a2a...3d1704	2 days ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^13	6a2a...00a1b2	2 days ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^14	6a2a...fc7d1d	2 days ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^15	6a2a...7895d9	2 days ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^16	6a2a...f9bf20	2 days ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^17	6a2a...8cd9cf	2 days ago	config revision by DATA-TRANSMISSION with RAW data 6a2a563ba2083033ec8cd9c7 and analysis result 6a2a563ea2083033ec8cd9ce
HEAD^18	6a2a...745790	2 days ago	config revision by INJECTION-CAPACITANCE with RAW data 6a2a560c3437adbb7d745784 and analysis result 6a2a56103437adbb7d74578f
HEAD^19	6a2a...3e154f	2 days ago	config revision by VCAL-CALIBRATION with RAW data 6a2a3cb32da0f186923e153f and analysis result 6a2a3cb72da0f186923e154e
HEAD^20	6a2a...bbb8e5	2 days ago	config revision by SLDO with RAW data 6a2a3a494a7e8678e2bbb8d9 and analysis result 6a2a3a4e4a7e8678e2bbb8e4
HEAD^21	6a2a...8cd945	2 days ago	config revision by ANALOG-READBACK with RAW data 6a2a326ba2083033ec8cd921 and analysis result 6a2a3271a2083033ec8cd944
HEAD^22	6a2a...3e1343	2 days ago	config revision by ADC-CALIBRATION with RAW data 6a2a17e22da0f186923e133b and analysis result 6a2a17e52da0f186923e1342
HEAD^23	6a2a...3e12f1	2 days ago	config revision by ADC-CALIBRATION with RAW data 6a2a10c52da0f186923e12e9 and analysis result 6a2a10c82da0f186923e12f0
HEAD^24	6a2a...9d160c	2 days ago	downloaded from ITkPD : code = e3fde11ec84be08dfae394fca12c4acd, description = {"_id":"68b7131f8428c598c033607c","serialNumber":"20UPGFC0146117","stage":"MODULE/INITIAL_WARM","branch":"cold","current_revision_id":"68b7131f8428c598c033607d"}
HEAD^25	6a2a...bbb66d	2 days ago	downloaded from ITkPD : code = e3fde11ec84be08dfae394fca12c4acd, description = {"_id":"68b7131f8428c598c033607c","serialNumber":"20UPGFC0146117","stage":"MODULE/INITIAL_WARM","branch":"cold","current_revision_id":"68b7131f8428c598c033607d"}

Mode: LP

Index	Revision ID	Timestamp	Message
HEAD	6a2a...9d160d	2 days ago	downloaded from ITkPD : code = 859cf0bf544e79bea44d24bc376d7b77, description = {"_id":"68b7131f8428c598c0336084","serialNumber":"20UPGFC0146117","stage":"MODULE/INITIAL_WARM","branch":"LP","current_revision_id":"690d23024f9fcd332811a844"}
HEAD^1	6a2a...bbb66f	2 days ago	downloaded from ITkPD : code = 859cf0bf544e79bea44d24bc376d7b77, description = {"_id":"68b7131f8428c598c0336084","serialNumber":"20UPGFC0146117","stage":"MODULE/INITIAL_WARM","branch":"LP","current_revision_id":"690d23024f9fcd332811a844"}

Stage: MODULE/FINAL_WARM

Mode: warm

Index	Revision ID	Timestamp	Message
HEAD	6a29...017c09	2 days ago	config revision by DATA-TRANSMISSION with RAW data 6a29e80566f3d07de1017bfa and analysis result 6a29e80a66f3d07de1017c01
HEAD^1	6a28...78d11c	3 days ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^2	6a28...fbe5b0	3 days ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^3	6a28...87b8fe	3 days ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^4	6a28...a548c0	3 days ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^5	6a28...c57351	3 days ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^6	6a28...969188	3 days ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^7	6a28...0514f9	3 days ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^8	6a28...5c02e3	3 days ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^9	6a28...f20fbb	3 days ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^10	6a28...858e60	3 days ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^11	6a28...e1a817	3 days ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^12	6a28...7b0577	3 days ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^13	6a28...b8ad30	3 days ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^14	6a28...ff9fe7	3 days ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^15	6a28...94a157	3 days ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^16	6a28...207dfd	3 days ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^17	6a28...017785	3 days ago	config revision by INJECTION-CAPACITANCE with RAW data 6a28c6c966f3d07de1017724 and analysis result 6a28c7a266f3d07de101775c
HEAD^18	6a28...261789	3 days ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^19	6a28...a175a5	3 days ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^20	6a28...e926fa	3 days ago	config revision by VCAL-CALIBRATION with RAW data 6a28c36c3b97c76890e926c0 and analysis result 6a28c3d53b97c76890e926e9
HEAD^21	6a28...8e9710	3 days ago	config revision by SLDO with RAW data 6a28bf99e4d82762eb8e96f7 and analysis result 6a28c027e4d82762eb8e9705
HEAD^22	6a28...8e964f	3 days ago	config revision by ANALOG-READBACK with RAW data 6a28b576e4d82762eb8e9624 and analysis result 6a28b580e4d82762eb8e9647
HEAD^23	6a28...1899a6	3 days ago	config revision by ADC-CALIBRATION with RAW data 6a289ab6382a2f15c9189997 and analysis result 6a289abd382a2f15c918999e
HEAD^24	6a28...794b77	3 days ago	downloaded from ITkPD : code = 574cfb834f9f26120b7fdfafa9fdfb56, description = {"_id":"6a1f3b5e3728ff7b06582948","serialNumber":"20UPGFC0146117","stage":"MODULE/QC_CROSSCHECK","branch":"warm","current_revision_id":"6a2205c36f04e298c8e2e31f"}

Mode: cold

Index	Revision ID	Timestamp	Message
HEAD	6a28...794b79	3 days ago	downloaded from ITkPD : code = e3fde11ec84be08dfae394fca12c4acd, description = {"_id":"68b7131f8428c598c033607c","serialNumber":"20UPGFC0146117","stage":"MODULE/INITIAL_WARM","branch":"cold","current_revision_id":"68b7131f8428c598c033607d"}

Mode: LP

Index	Revision ID	Timestamp	Message
HEAD	6a28...0177f4	3 days ago	config revision by LP-MODE with RAW data 6a28c98366f3d07de10177d4 and analysis result 6a28cc1066f3d07de10177f3
HEAD^1	6a28...794b7b	3 days ago	downloaded from ITkPD : code = 859cf0bf544e79bea44d24bc376d7b77, description = {"_id":"68b7131f8428c598c0336084","serialNumber":"20UPGFC0146117","stage":"MODULE/INITIAL_WARM","branch":"LP","current_revision_id":"690d23024f9fcd332811a844"}

Stage: MODULE/QC_CROSSCHECK

Mode: warm

Index	Revision ID	Timestamp	Message
HEAD	6a22...e2e31f	a week ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^1	6a22...b332a3	a week ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^2	6a22...695bee	a week ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^3	6a22...1e0dbb	a week ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^4	6a22...e682ca	a week ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^5	6a22...230282	a week ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^6	6a22...f77f1b	a week ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^7	6a22...d3fe6b	a week ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^8	6a22...d95f86	a week ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^9	6a22...3b25cd	a week ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^10	6a22...499470	a week ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^11	6a22...fa9839	a week ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^12	6a22...fdae1f	a week ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^13	6a21...847bf5	a week ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^14	6a21...dbe054	a week ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^15	6a21...75fd66	a week ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^16	6a21...f64ec0	a week ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^17	6a21...8ab653	a week ago	config revision by DATA-TRANSMISSION with RAW data 6a21fa5b094558da248ab645 and analysis result 6a21fa61094558da248ab64c
HEAD^18	6a21...e527f9	a week ago	config revision by INJECTION-CAPACITANCE with RAW data 6a21f4d03414dfb500e527e7 and analysis result 6a21f4d53414dfb500e527f2
HEAD^19	6a21...fe52c1	a week ago	config revision by VCAL-CALIBRATION with RAW data 6a21f3d8a9167d9dd0fe52ab and analysis result 6a21f3dea9167d9dd0fe52ba
HEAD^20	6a21...8ab60f	a week ago	config revision by SLDO with RAW data 6a21f1e9094558da248ab5fd and analysis result 6a21f1ef094558da248ab608
HEAD^21	6a21...e52741	a week ago	config revision by ANALOG-READBACK with RAW data 6a21ebcd3414dfb500e52717 and analysis result 6a21ebd53414dfb500e5273a
HEAD^22	6a21...f73c73	a week ago	config revision by ADC-CALIBRATION with RAW data 6a21d7c3ae36c5cf13f73c65 and analysis result 6a21d7c9ae36c5cf13f73c6c
HEAD^23	6a20...eca471	a week ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^24	6a20...714722	a week ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^25	6a20...61c7e1	a week ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^26	6a20...293fdb	a week ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^27	6a20...111ee3	a week ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^28	6a20...63cf7c	a week ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^29	6a20...1d9dcd	a week ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^30	6a20...9b33f4	a week ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^31	6a20...a0645c	a week ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^32	6a20...5fce3a	a week ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^33	6a20...c4971b	a week ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^34	6a20...5f34bb	a week ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^35	6a20...dad779	a week ago	config revision by DATA-TRANSMISSION with RAW data 6a20a201785945eeb4dad74c and analysis result 6a20a237785945eeb4dad763
HEAD^36	6a20...4161bb	a week ago	config revision by INJECTION-CAPACITANCE with RAW data 6a20a0f168536ecf5c4161a8 and analysis result 6a20a0f768536ecf5c4161b3
HEAD^37	6a20...416166	a week ago	config revision by VCAL-CALIBRATION with RAW data 6a20a02168536ecf5c41614f and analysis result 6a20a02768536ecf5c41615e
HEAD^38	6a20...9dae38	a week ago	config revision by SLDO with RAW data 6a209ea6108389284b9dae25 and analysis result 6a209eac108389284b9dae30
HEAD^39	6a20...f7108c	a week ago	config revision by ADC-CALIBRATION with RAW data 6a208bacbc7ef76a51f7107d and analysis result 6a208bb2bc7ef76a51f71084
HEAD^40	6a1f...582950	a week ago	downloaded from ITkPD : code = 59b534f86abaddae7455792db572c7b9, description = {"_id":"69960035f6ae188f06791f9b","serialNumber":"20UPGFC0146117","stage":"MODULE/POST_PARYLENE_WARM","branch":"warm","current_revision_id":"6997dc929236ab1732677c75"}

Mode: cold

Index	Revision ID	Timestamp	Message
HEAD	6a1f...582952	a week ago	downloaded from ITkPD : code = e3fde11ec84be08dfae394fca12c4acd, description = {"_id":"68b7131f8428c598c033607c","serialNumber":"20UPGFC0146117","stage":"MODULE/INITIAL_WARM","branch":"cold","current_revision_id":"68b7131f8428c598c033607d"}

Mode: LP

Index	Revision ID	Timestamp	Message
HEAD	6a21...f73d76	a week ago	config revision by LP-MODE with RAW data 6a21f5cdae36c5cf13f73d6e and analysis result 6a21f5d1ae36c5cf13f73d75
HEAD^1	6a20...dad6f6	a week ago	config revision by LP-MODE with RAW data 6a20a1ae785945eeb4dad6ee and analysis result 6a20a1b2785945eeb4dad6f5
HEAD^2	6a1f...582954	a week ago	downloaded from ITkPD : code = 859cf0bf544e79bea44d24bc376d7b77, description = {"_id":"68b7131f8428c598c0336084","serialNumber":"20UPGFC0146117","stage":"MODULE/INITIAL_WARM","branch":"LP","current_revision_id":"690d23024f9fcd332811a844"}

Stage: MODULE/LONG_TERM_STABILITY_TEST

Mode: warm

Index	Revision ID	Timestamp	Message
HEAD	6a15...3d6ce0	2 weeks ago	downloaded from ITkPD : code = 59b534f86abaddae7455792db572c7b9, description = {"_id":"69960035f6ae188f06791f9b","serialNumber":"20UPGFC0146117","stage":"MODULE/POST_PARYLENE_WARM","branch":"warm","current_revision_id":"6997dc929236ab1732677c75"}

Mode: cold

Index	Revision ID	Timestamp	Message
HEAD	6a15...3d6ce2	2 weeks ago	downloaded from ITkPD : code = e3fde11ec84be08dfae394fca12c4acd, description = {"_id":"68b7131f8428c598c033607c","serialNumber":"20UPGFC0146117","stage":"MODULE/INITIAL_WARM","branch":"cold","current_revision_id":"68b7131f8428c598c033607d"}

Mode: LP

Index	Revision ID	Timestamp	Message
HEAD	6a15...3d6ce4	2 weeks ago	downloaded from ITkPD : code = 859cf0bf544e79bea44d24bc376d7b77, description = {"_id":"68b7131f8428c598c0336084","serialNumber":"20UPGFC0146117","stage":"MODULE/INITIAL_WARM","branch":"LP","current_revision_id":"690d23024f9fcd332811a844"}

Stage	Tests
TESTONWAFER	Electrical FE chip tests (FECHIP_TEST)
HYBRIDISATION
UNUSABLE
BAREMODULEASSEMBLY
BAREMODULERECEPTION	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK)
MODULE/INIT
MODULE/ASSEMBLY
MODULE/WIREBONDING	ADC Calibration (ADC_CALIBRATION) Data Transmission (DATA_TRANSMISSION) VCAL Calibration (VCAL_CALIBRATION) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) SLDO (SLDO) Low Power Mode (LP_MODE) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/INITIAL_WARM	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Low Power Mode (LP_MODE) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) Data Transmission (DATA_TRANSMISSION) Injection Capacitance (INJECTION_CAPACITANCE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
MODULE/QC_CROSSCHECK	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Low Power Mode (LP_MODE) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) Data Transmission (DATA_TRANSMISSION) Injection Capacitance (INJECTION_CAPACITANCE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
MODULE/INITIAL_COLD	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Injection Capacitance (INJECTION_CAPACITANCE) Tuning (TUNING) Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Low Power Mode (LP_MODE) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) Data Transmission (DATA_TRANSMISSION)
MODULE/PARYLENE_MASKING	ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) SLDO (SLDO) Low Power Mode (LP_MODE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE) Data Transmission (DATA_TRANSMISSION)
MODULE/PARYLENE_COATING
MODULE/PARYLENE_UNMASKING	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Tuning (TUNING) Data Transmission (DATA_TRANSMISSION) ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) SLDO (SLDO) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE)
MODULE/WIREBOND_PROTECTION	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Tuning (TUNING) ADC Calibration (ADC_CALIBRATION) Low Power Mode (LP_MODE) VCAL Calibration (VCAL_CALIBRATION) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE) SLDO (SLDO) Data Transmission (DATA_TRANSMISSION)
MODULE/POST_PARYLENE_WARM	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Data Transmission (DATA_TRANSMISSION) Injection Capacitance (INJECTION_CAPACITANCE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Low Power Mode (LP_MODE)
MODULE/POST_PARYLENE_COLD	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) VCAL Calibration (VCAL_CALIBRATION) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) SLDO (SLDO) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/THERMAL_CYCLES	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Tuning (TUNING) Data Transmission (DATA_TRANSMISSION) SLDO (SLDO) ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE) Cold startup (COLD_STARTUP)
MODULE/LONG_TERM_STABILITY_TEST	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) SLDO (SLDO) Tuning (TUNING) ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/FINAL_WARM	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Undershunt Protection (UNDERSHUNT_PROTECTION) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Data Transmission (DATA_TRANSMISSION) Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Tuning (TUNING) Low Power Mode (LP_MODE) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/FINAL_COLD	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) Tuning (TUNING) Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Data Transmission (DATA_TRANSMISSION) Cold startup (COLD_STARTUP)
MODULE/FINAL_METROLOGY	Data Transmission (DATA_TRANSMISSION) ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) SLDO (SLDO) Injection Capacitance (INJECTION_CAPACITANCE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Injection Capacitance (INJECTION_CAPACITANCE) Analog Readback (ANALOG_READBACK)
MODULE/QC_STATUS
MODULE/UNHAPPY	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) VCAL Calibration (VCAL_CALIBRATION) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Low Power Mode (LP_MODE) Injection Capacitance (INJECTION_CAPACITANCE) SLDO (SLDO) Data Transmission (DATA_TRANSMISSION)
MODULE/NOTCONSIDEREDINYIELDS	ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) SLDO (SLDO) Undershunt Protection (UNDERSHUNT_PROTECTION) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Analog Readback (ANALOG_READBACK) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Low Power Mode (LP_MODE) Injection Capacitance (INJECTION_CAPACITANCE) Data Transmission (DATA_TRANSMISSION)
MODULE/GRAVEYARD
MODULE/COMPLETE
MODULE/RECEPTION	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Data Transmission (DATA_TRANSMISSION) Tuning (TUNING)
MODULE/TAB_CUTTING	Minimal Health Test (MIN_HEALTH_TEST)
LLS/PRE_TC_WARM	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Low Power Mode (LP_MODE) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
LLS/PRE_TC_COLD	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
LLS/POST_TC_WARM	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
LLS/POST_TC_COLD	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
LLS/RECEPTION	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
OB_LOADED_MODULE_CELL/INIT
OB_LOADED_MODULE_CELL/ASSEMBLY
OB_LOADED_MODULE_CELL/WIREBOND_PROTECTION
OB_LOADED_MODULE_CELL/THERMAL_CYCLES
OB_LOADED_MODULE_CELL/FINAL_WARM	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
OB_LOADED_MODULE_CELL/FINAL_COLD	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
OB_LOADED_MODULE_CELL/THERMAL_COLD
OB_LOADED_MODULE_CELL/THERMAL_WARM
OB_LOADED_MODULE_CELL/ENVELOPE_CHECK
OB_LOADED_MODULE_CELL/QC_STATUS
OB_LOADED_MODULE_CELL/UNHAPPY
OB_LOADED_MODULE_CELL/GRAVEYARD
OB_LOADED_MODULE_CELL/COMPLETE
OB_LOADED_MODULE_CELL/RECEPTION	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) SLDO (SLDO)
OB_LOADED_MODULE_CELL/TAB_CUTTING	Minimal Health Test (MIN_HEALTH_TEST)
OB_LOADED_MODULE_CELL/PIGTAIL_INSERTION
TEST_AFTER_LOADED_LOCAL_SUPPORT_ASSEMBLY	OB:Loaded local support QC electrical connectivity (OBLoadedLocalSupportQC_ElectricalConnectivity) OB:Loaded local support QC electrical performance (OBLoadedLocalSupportQC_ElectricalPerformance) OB:Loaded local support reception at the integration site (OBLoadedLocalSupport_IntegrationSite) OB:Loaded local support QC electrical low power (OBLoadedLocalSupport_QCElectricalLowPower)
TEST_JM_OEC_FE

20UPGFC0146117

MODULE/FINAL_COLD

Component Information

Wafer

Properties

Comments

Test: ANALOG_READBACK QC Passed

(Stage: MODULE/INITIAL_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Results

Attachments

RAW Results Record

ProductionDB Record

Current Stage: Final Cold

Candidate TestRuns of this Stage

Past QC Stages and Results

Final Warm (MODULE/FINAL_WARM)

Long Term Stability Test (MODULE/LONG_TERM_STABILITY_TEST)

Thermal Cycles (MODULE/THERMAL_CYCLES)

Post-Parylene Cold (MODULE/POST_PARYLENE_COLD)

Post-Parylene Warm (MODULE/POST_PARYLENE_WARM)

Wirebond Protection (alt) (MODULE/WIREBOND_PROTECTION)

Parylene Unmasking (MODULE/PARYLENE_UNMASKING)

Parylene Coating (MODULE/PARYLENE_COATING)

Parylene Masking (MODULE/PARYLENE_MASKING)

Initial Cold (MODULE/INITIAL_COLD)

QC cross-check (module swapping) (MODULE/QC_CROSSCHECK)

Initial Warm (MODULE/INITIAL_WARM)

Wire Bonding (MODULE/WIREBONDING)

Bare module to module PCB assembly (MODULE/ASSEMBLY)

Initial state to associate flex to bare module (MODULE/INIT)

Reception at ITk institute (BAREMODULERECEPTION)

Bare module assembly (BAREMODULEASSEMBLY)

Not to be used for detector (UNUSABLE)

Hybridisation (HYBRIDISATION)

Testing on wafer (TESTONWAFER)

All Registered QC Tests

All YARR Scans

Config Revisions

Stage: MODULE/FINAL_COLD

Mode: warm

Mode: cold

Mode: LP

Stage: MODULE/FINAL_WARM

Mode: warm

Mode: cold

Mode: LP

Stage: MODULE/QC_CROSSCHECK

Mode: warm

Mode: cold

Mode: LP

Stage: MODULE/LONG_TERM_STABILITY_TEST

Mode: warm

Mode: cold

Mode: LP

Check QC Flow

Back to top page of this component
