20UPGFC0146067

MODULE/FINAL_COLD

Component Information

Serial Number 20UPGFC0146067
ProdDB ID  0289fc…37db3c
LocalDB ID 660fbe7c2fc9f20035147e37
Component Type fe_chip
Parents 20UPGM24211639  20UPGB43200439 
Children No match.
Flags
Wafer
  Wafer Probing

 Properties

Item Value
Target Iref trim 9
Target Iref trim version 1
Wafer serial number None

 Comments

Date Commented by on which Component Comment
3 days ago pixel (Lawrence Berkeley National Lab - pixel modules) MODULE
20UPGM24211639 		sign-off at MODULE/QC_CROSSCHECK; appended flags: ['INFO_CORE_COLUMN']; next stage: MODULE/PARYLENE_MASKING; comment: Failed 2-1 data transmission. May just be an issue with what version of MQDBT I have. Will proceed with full QC.

Scan Result: std_noisescan / run 1968 (Stage: MODULE/FINAL_COLD)
(ObjectId: 660fbe7c2fc9f20035147e37)


Result Plots

Occupancy

TotMap

TagDist

NoiseOccupancy

NoiseMask

TotDist


Details

Scan

Key Data
runNumber 1968
testType std_noisescan
stage MODULE/FINAL_COLD
component 20UPGM24211639
20UPGFC0146025
20UPGFC0146023
20UPGFC0146067
20UPGFC0146069
startTime 2026-06-11 06:17:50
finishTime 2026-06-11 06:19:02
user pixqc
site jittereel.dhcp.lbl.gov
targetCharge -1
targetTot -1
FeDataProcessorLog 0x23a67: {'Any errors': 0, 'Chip tag bitflips': 0, 'Chip unrecognized tags': 0, 'Corrupt streams': 0, 'Split events count': 0, 'Unfinished streams (no EOS)': 0, 'Unfinished streams (w/ EOS)': 0}
0x23a69: {'Any errors': 0, 'Chip tag bitflips': 0, 'Chip unrecognized tags': 0, 'Corrupt streams': 0, 'Split events count': 0, 'Unfinished streams (no EOS)': 0, 'Unfinished streams (w/ EOS)': 0}
0x23a93: {'Any errors': 0, 'Chip tag bitflips': 0, 'Chip unrecognized tags': 0, 'Corrupt streams': 0, 'Split events count': 0, 'Unfinished streams (no EOS)': 0, 'Unfinished streams (w/ EOS)': 0}
0x23a95: {'Any errors': 0, 'Chip tag bitflips': 0, 'Chip unrecognized tags': 0, 'Corrupt streams': 0, 'Split events count': 0, 'Unfinished streams (no EOS)': 0, 'Unfinished streams (w/ EOS)': 0}
ctrlStatus channel_configuration: 16x1
fe_chip_type: RD53A/B/C
firmware_hash: 0xacb87f4
firmware_identifier: 0x1030242
firmware_vers: v1.6.0
fmc_card_type: Ohio Card (Display Port)
fpga_card: Trenz TEF1001_R1
lpm_status: 0
rx_speed: 1280Mbps
exec -r /opt/local/pixqc/common_configs/specCfg-rd53b-16x1-setup2.json -c /opt/local/pixqc/20UPGM24211639/20UPGM24211639_L2_cold.json -o /opt/local/pixqc/20UPGM24211639/data -W PFA -s /opt/local/pixqc/qc_software/YARR/configs/scans/itkpixv2/std_noisescan.json
stopwatch analysis: 774
config: 1168
processing: 0
scan: 64001
yarr_version build_flags:
build_time: 2026-05-21 19:00:19 UTC
build_type:
git_branch: HEAD
git_date: 2026-05-05 17:05:25 +0000
git_hash: bc51c936e4328c9cffe2ba84e67b13dc909932e6
git_subject: Merge-branch-devel-into-master
git_tag: v1.6.0
QC False
environment False
plots
passed True

Output Data

Data Display Download
Type FE Chip Serial Number
ctrlCfg N/A
dbCfg N/A
siteCfg N/A
userCfg N/A
scanCfg N/A
feCfg.before 20UPGFC0146025
20UPGFC0146023
20UPGFC0146067
20UPGFC0146069
feCfg.after 20UPGFC0146025
20UPGFC0146023
20UPGFC0146067
20UPGFC0146069
Occupancy 20UPGFC0146025
20UPGFC0146023
20UPGFC0146067
20UPGFC0146069
TotMap 20UPGFC0146025
20UPGFC0146023
20UPGFC0146067
20UPGFC0146069
TagDist 20UPGFC0146025
20UPGFC0146023
20UPGFC0146067
20UPGFC0146069
NoiseOccupancy 20UPGFC0146025
20UPGFC0146023
20UPGFC0146067
20UPGFC0146069
NoiseMask 20UPGFC0146025
20UPGFC0146023
20UPGFC0146067
20UPGFC0146069
TotDist 20UPGFC0146025
20UPGFC0146023
20UPGFC0146067
20UPGFC0146069

DCS ### NO DCS DATA ###

 Current Stage: Final Cold

Test Type Local Result
ADC Calibration
(ADC_CALIBRATION)		 TestRun Present
Analog Readback
(ANALOG_READBACK)		 TestRun Present
SLDO
(SLDO)		 TestRun Present
VCAL Calibration
(VCAL_CALIBRATION)		 TestRun Present
Injection Capacitance
(INJECTION_CAPACITANCE)		 TestRun Present
Low Power Mode
(LP_MODE)		 No TestRun!
Overvoltage Protection
(OVERVOLTAGE_PROTECTION)		 No TestRun!
Undershunt Protection
(UNDERSHUNT_PROTECTION)		 No TestRun!
Tuning
(TUNING)		 TestRun Present
Minimal Health Test
(MIN_HEALTH_TEST)		 TestRun Present
Pixel Failure Analysis
(PIXEL_FAILURE_ANALYSIS)		 TestRun Present
Data Transmission
(DATA_TRANSMISSION)		 TestRun Present
Cold startup
(COLD_STARTUP)		 No TestRun!

 Candidate TestRuns of this Stage

LDB ID TestRun Code QC Passed Inspector Measurement Date Analysis Date Analysis Version Tags QC Registration
