Database for ITk Pixel Module

Serial Number	20UPGFC0142690
ProdDB ID	79c0f0…a389f5
LocalDB ID	660dd0e02fc9f200350c25e0
Component Type	fe_chip
Parents	20UPGM23211221 20UPGB43200112
Children	No match.
Flags

Item	Value
Wafer serial number	None

Key	Data
QC Passed	True
Date	5 months ago
component ObjectId	660dd0e02fc9f200350c25e0
Stage	MODULE/INITIAL_WARM
Test Type	TUNING
Institute ObjectId
User Name	MatthiasSaimpert
ObjectId of this record	687ff07ea46785c390cf0edc
ObjectId of RAW record	None
Tags	No tags

Key	Data
DCSdata	{}
QC_LAYER	L2
TUNING_UNTUNED_THRESHOLD_MEAN	2137.957
TUNING_UNTUNED_THRESHOLD_95_LOW	1549.987
TUNING_UNTUNED_THRESHOLD_95_HIGH	2766.174
TUNING_UNTUNED_THRESHOLD_SIGMA	309.0
TUNING_UNTUNED_TDAC_MEAN	0.0
TUNING_UNTUNED_TDAC_SIGMA	0.0
TUNING_UNTUNED_NOISE_MEAN	100.092
TUNING_UNTUNED_NOISE_SIGMA	10.469
TUNING_UNTUNED_NOISE_95_LOW	81.474
TUNING_UNTUNED_NOISE_95_HIGH	119.903
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	69
TUNING_TUNED_THRESHOLD_MEAN	1498.3
TUNING_TUNED_THRESHOLD_95_LOW	1429.357
TUNING_TUNED_THRESHOLD_95_HIGH	1562.497
TUNING_TUNED_THRESHOLD_SIGMA	36.0
TUNING_TUNED_TDAC_MEAN	-1.1
TUNING_TUNED_TDAC_SIGMA	4.154
TUNING_TUNED_NOISE_MEAN	102.419
TUNING_TUNED_NOISE_SIGMA	10.767
TUNING_TUNED_NOISE_95_LOW	82.869
TUNING_TUNED_NOISE_95_HIGH	123.384
TUNING_TUNED_TOT_MEAN	7.5
TUNING_TUNED_TOT_SIGMA	0.3
TUNING_TUNED_TOT_95_LOW	5.27
TUNING_TUNED_TOT_95_HIGH	10.24
TUNING_TUNED_THRESHOLD_FAILED_FITS	2
ANALYSIS_VERSION	mqat v2.6.2
YARR_VERSION	v1.5.3-129-ga089a9a2
MEASUREMENT_DATE	2025-03-20T12:29:08.000+00:00
MEASUREMENT_DURATION	659
