20UPGFC0142508

MODULE/THERMAL_CYCLES

Component Information

Serial Number 20UPGFC0142508
ProdDB ID  c3e6fb…6762ef
LocalDB ID 660dc8abec873d003545b13e
Component Type fe_chip
Parents 20UPGM24211289  20UPGB43200206 
Children No match.
Flags
Wafer
  Wafer Probing

 Properties

Item Value
Target Iref trim 6
Target Iref trim version 1
Wafer serial number None

 Comments


Test: TUNING QC Failed

(Stage: MODULE/POST_PARYLENE_WARM)


Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key Data
QC Passed False
Date 12 hours ago
component ObjectId 660dc8abec873d003545b13e
Stage MODULE/POST_PARYLENE_WARM
Test Type TUNING
Institute ObjectId
User Name None
ObjectId of this record 694344b04ce654a7f0962e97
ObjectId of RAW record None
Tags No tags
Tuning Config Associated FE Config

Results

Key Data
DCSdata {}
QC_LAYER L2
TUNING_UNTUNED_THRESHOLD_MEAN 2129.284
TUNING_UNTUNED_THRESHOLD_95_LOW 1550.036
TUNING_UNTUNED_THRESHOLD_95_HIGH 2750.158
TUNING_UNTUNED_THRESHOLD_SIGMA 305.257
TUNING_UNTUNED_TDAC_MEAN 0.0
TUNING_UNTUNED_TDAC_SIGMA 0.0
TUNING_UNTUNED_NOISE_MEAN 100.045
TUNING_UNTUNED_NOISE_SIGMA 11.059
TUNING_UNTUNED_NOISE_95_LOW 80.86
TUNING_UNTUNED_NOISE_95_HIGH 120.624
TUNING_UNTUNED_THRESHOLD_FAILED_FITS 33858
TUNING_TUNED_THRESHOLD_MEAN 1504.1
TUNING_TUNED_THRESHOLD_95_LOW 1434.006
TUNING_TUNED_THRESHOLD_95_HIGH 1569.403
TUNING_TUNED_THRESHOLD_SIGMA 36.0
TUNING_TUNED_TDAC_MEAN -4.2
TUNING_TUNED_TDAC_SIGMA 6.704
TUNING_TUNED_NOISE_MEAN 102.414
TUNING_TUNED_NOISE_SIGMA 11.36
TUNING_TUNED_NOISE_95_LOW 82.241
TUNING_TUNED_NOISE_95_HIGH 124.156
TUNING_TUNED_TOT_MEAN 5.7
TUNING_TUNED_TOT_SIGMA 0.3
TUNING_TUNED_TOT_95_LOW 0.0
TUNING_TUNED_TOT_95_HIGH 9.87
TUNING_TUNED_THRESHOLD_FAILED_FITS 33793
ANALYSIS_VERSION mqat v2.7.0
YARR_VERSION v1.5.5
MEASUREMENT_DATE 2025-11-07T03:25:45.000+00:00
MEASUREMENT_DURATION 5302

Attachments

Filename Contents
output.log Download
0x22cac.log Download
20UPGFC0142508_MODULE__POST_PARYLENE_WARM_TUNING.zip Download
