20UPGFC0142507

MODULE/THERMAL_CYCLES

Component Information

Serial Number	20UPGFC0142507
ProdDB ID	9e2005…8140a0
LocalDB ID	660dc8a92fc9f200350c0829
Component Type	fe_chip
Parents	20UPGM24211289 20UPGB43200206
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Target Iref trim	7
Target Iref trim version	1
Wafer serial number	None

Comments

Test: TUNING QC Passed

(Stage: MODULE/QC_CROSSCHECK)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	3 months ago
component ObjectId	660dc8a92fc9f200350c0829
Stage	MODULE/QC_CROSSCHECK
Test Type	TUNING
Institute ObjectId
User Name	ElizaHoward
ObjectId of this record	68d5a87e9bee8c25bf87d396
ObjectId of RAW record	None
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.6.4
MEASUREMENT_DATE	2025-09-23T19:23:24.000+00:00
MEASUREMENT_DURATION	666
MEASUREMENT_VERSION	None
YARR_VERSION	v1.5.5
TUNING_TUNED_NOISE_95_HIGH	135.376
TUNING_TUNED_NOISE_95_LOW	90.625
TUNING_TUNED_NOISE_MEAN	112.51
TUNING_TUNED_NOISE_SIGMA	11.872
TUNING_TUNED_TDAC_MEAN	-1.4
TUNING_TUNED_TDAC_SIGMA	5.163
TUNING_TUNED_THRESHOLD_95_HIGH	1567.331
TUNING_TUNED_THRESHOLD_95_LOW	1430.583
TUNING_TUNED_THRESHOLD_FAILED_FITS	6150
TUNING_TUNED_THRESHOLD_MEAN	1501.6
TUNING_TUNED_THRESHOLD_SIGMA	37
TUNING_TUNED_TOT_95_HIGH	10.05
TUNING_TUNED_TOT_95_LOW	0
TUNING_TUNED_TOT_MEAN	7.1
TUNING_TUNED_TOT_SIGMA	0.3
TUNING_UNTUNED_NOISE_95_HIGH	130.921
TUNING_UNTUNED_NOISE_95_LOW	88.105
TUNING_UNTUNED_NOISE_MEAN	108.981
TUNING_UNTUNED_NOISE_SIGMA	12.048
TUNING_UNTUNED_TDAC_MEAN	0
TUNING_UNTUNED_TDAC_SIGMA	0
TUNING_UNTUNED_THRESHOLD_95_HIGH	2934.301
TUNING_UNTUNED_THRESHOLD_95_LOW	1661.362
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	6193
TUNING_UNTUNED_THRESHOLD_MEAN	2272.91
TUNING_UNTUNED_THRESHOLD_SIGMA	324

Attachments

Filename	Contents
0x22cab_L2_default.json	Download
output.log	Download
0x22cab.log	Download
20UPGFC0142507_MODULE__QC_CROSSCHECK_TUNING.zip	Download
