20UPGFC0142445

MODULE/POST_PARYLENE_WARM

Component Information

Serial Number	20UPGFC0142445
ProdDB ID	c46de1…636158
LocalDB ID	660dc84c2fc9f200350c07aa
Component Type	fe_chip
Parents	20UPGM23211141 20UPGB43200202
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Wafer serial number	None
Target Iref trim	None
Target Iref trim version	None

Comments

Test: ANALOG_READBACK QC Passed

(Stage: MODULE/POST_PARYLENE_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	4 weeks ago
component ObjectId	660dc84c2fc9f200350c07aa
Stage	MODULE/POST_PARYLENE_WARM
Test Type	ANALOG_READBACK
Institute ObjectId
User Name	None
ObjectId of this record	6920bc59debdf73f4322bb9a
ObjectId of RAW record	6920bc4ddebdf73f4322bb71
Tags	ganymede_4

Results

Key	Data
DCSdata	{}
MEASUREMENT_VERSION	2.7.2.dev0
QC_LAYER	L2
INSTITUTION	LBNL_PIXEL_MODULES
AR_TEMP_NTC	19.476
AR_TEMP_EXT	20.012
AR_TEMP_ASLDO	26.311
AR_TEMP_DSLDO	27.562
AR_TEMP_ACB	25.442
AR_TEMP_NF_ASLDO	1.258
AR_TEMP_NF_DSLDO	1.259
AR_TEMP_NF_ACB	1.257
AR_TEMP_POLY_TOP	-999
AR_TEMP_POLY_BOTTOM	-999
AR_TEMP_NF_TOP	-999
AR_TEMP_NF_BOTTOM	-999
AR_IREF	3.9e-06
AR_GADC	0.805
AR_VCALDAC	0.809
AR_VREFCORE	0.465
AR_VREFOVP	1.985
AR_NOMINAL_SETTINGS	[3.9e-06, 8.43e-05, 4.81e-05, 4e-06, 3.91e-05, 1.95e-05, 0.0, 3.74e-05, 7.23e-05, -999, 0.0, 0.0, 4.59e-05, 6.24e-05, 5.09e-05, 8.5e-05, 7.31e-05, 7.38e-05, 8.25e-05, 8.5e-05, 7.47e-05, 4.54e-05, 4.7e-05, 7.45e-05, 4.83e-05, 4.76e-05, -999, -999, 0.6416731, 0.0648053, 0.9132332, 0.2946579, 0.8051059, -999, -999, 0.8086838, 1.1956258, 0.1164139, 0.1110529, 0.1720009, 0.040075, 0.0391284, 0.1556259, 0.1566859, 0.1599239, 0.6314879, -999, 0.6304219, -999, 0.5861499, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, 0.0180731, 0.4652209, 1.9848428, 1.5066796, 1.2012658, 0.5942299, 0.9864636, 1.5139116, 1.2093518, 0.6017709]
AR_VDDA_VS_TRIM	[1.036, 1.06, 1.084, 1.108, 1.131, 1.155, 1.179, 1.202, 1.232, 1.256, 1.279, 1.301, 1.325, 1.348, 1.372, 1.396]
AR_VDDD_VS_TRIM	[0.983, 1.005, 1.029, 1.05, 1.071, 1.094, 1.117, 1.14, 1.164, 1.186, 1.209, 1.231, 1.253, 1.275, 1.297, 1.322]
AR_VDDA_TRIM	7
AR_VDDD_TRIM	10
AR_ROSC_SLOPE	[776.9679941997367, 1179.8205327278447, 773.7116250890283, 1185.8977990794663, 832.0116054087546, 1391.9294715595154, 974.5169469788062, 1426.3035330905864, 1196.7816341050284, 1202.7113179092353, 1388.4233037740876, 1390.2142678472887, 1226.137714853785, 1223.9575301567577, 1391.1450528996431, 1397.7268568241134, 1376.5243259583683, 1401.1523518106758, 1628.087257778989, 1623.5352498679524, 1363.8944136293646, 1379.6514080028085, 1665.780312536618, 1673.8940735557087, 846.7041913237349, 853.1866361970731, 1029.8919489445475, 1024.4129288953895, 1027.2089426709724, 1030.9609435962825, 1187.113798225172, 1240.020640987561, 1163.1559433079838, 1220.15640968171, 1568.5362947206054, 1557.9645073807724, 1562.6428645590586, 1563.8282419773327, 1562.6448509577658, 1570.1866251219412, 1561.182875676885, 1555.0353390282455]
AR_ROSC_OFFSET	[-463.52764201836, -693.4316536512578, -470.20236332243866, -715.3059847879945, -550.926290003905, -928.8453448553032, -683.9682782738103, -982.2052845550076, -738.5327301140362, -736.1203384643777, -847.6238696971403, -855.0074843848421, -769.5007694821547, -767.9441342156276, -859.8461069323497, -864.826520714699, -935.0195958928966, -943.2675214354437, -1092.0315390467722, -1086.8134933801264, -958.0613700700013, -960.9005354518465, -1151.7138199710885, -1156.38379665264, -547.3147494808953, -556.4139176200969, -668.0111559096554, -668.2135205110981, -658.4834768333203, -656.8131437944123, -605.7857172072922, -614.5691080004154, -654.0972614607499, -683.353645614585, -1053.762651375849, -1053.9077955274968, -1053.1746718288384, -1054.165074296619, -1052.5352720906988, -1055.5176713897204, -1052.6224331788874, -1048.6426083047234]
AR_ROSC_MAX_RESIDUAL	[2.172348432765646, 6.4934779764023745, 2.038019044612929, 3.3323278110340593, 1.0298683375113438, 1.6518805164951296, 0.9471983786546858, 1.6876773328810062, 2.717357453502669, 2.9119359352168233, 3.3412528004570112, 3.231251013157559, 2.490364885205748, 2.5666214611519202, 3.0586060152447345, 3.1617033949161315, 1.1003512546923817, 1.3234041698993206, 1.4026110546287687, 1.3500997638272656, 0.9441043678362332, 1.1547550289065087, 1.2405870579269809, 1.3593132319980568, 1.1770467499590616, 1.1672691498565648, 1.3484503487426844, 1.345469519354748, 1.5098975926830644, 1.6853155702477558, 3.9667255154481116, 4.429831305888223, 2.6420454189573683, 2.8275025698135607, 1.4411102693061888, 1.3169802763136886, 1.383423696937798, 1.3582476251606295, 1.3738858485712602, 1.3839093591876939, 1.230489845899892, 1.285091659957676]
AR_VDDD_SATURATION	-1.0
AR_VDDA_SATURATION	-1.0
AR_IREF_TRIM	8
ANALYSIS_VERSION	mqat v2.7.0
YARR_VERSION	v1.5.5
MEASUREMENT_DATE	2025-11-21T17:33:40.000+00:00
MEASUREMENT_DURATION	775

Attachments

Filename	Contents
output.log	Download
0x22c6d.log	Download

RAW Results Record

Download RAW

_id

6920bc4ddebdf73f4322bb71

raw

serialNumber

testType

runNumber

results

subtestType

stage

component

dbVersion

address

sys

20UPGFC0142445

ANALOG_READBACK

6920bc21b05aed379019d589

DCSdata

SensorVoltage	-79.998
SensorCurrent	-1.84115e-05
ModuleNTC	20.1948

Measurements

Vmux0

X	False
Unit	V
Values	0.823179

Vmux3

X	False
Unit	V
Values	0.422415

Vmux4

X	False
Unit	V
Values	0.615886

Vmux5

X	False
Unit	V
Values	0.134487

Vmux6

X	False
Unit	V
Values	0.129126

Vmux7

X	False
Unit	V
Values	0.190074

Vmux8

X	False
Unit	V
Values	0.0581481

Vmux9

X	False
Unit	V
Values	0.0572015

Vmux10

X	False
Unit	V
Values	0.173699

Vmux11

X	False
Unit	V
Values	0.174759

Vmux12

X	False
Unit	V
Values	0.177997

Vmux13

X	False
Unit	V
Values	0.649561

Vmux15

X	False
Unit	V
Values	0.648495

Vmux17

X	False
Unit	V
Values	0.604223

Vmux31

X	False
Unit	V
Values	0.483294

Vmux32

X	False
Unit	V
Values	0.614122

Vmux33

X	False
Unit	V
Values	0.394743

Vmux34

X	False
Unit	V
Values	0.618706

Vmux35

X	False
Unit	V
Values	0.612303

Vmux36

X	False
Unit	V
Values	0.264689

Vmux37

X	False
Unit	V
Values	0.396551

Vmux38

X	False
Unit	V
Values	0.622749

Vmux39

X	False
Unit	V
Values	0.619844

Vmux63

X	False
Unit	V
Values	0.0206258

Vmux30

X	False
Unit	V
Values	0.0180731

Imux0

X	False
Unit	V
Values	0.0545061

Imux1

X	False
Unit	V
Values	0.858974

Imux2

X	False
Unit	V
Values	0.496279

Imux3

X	False
Unit	V
Values	0.0552335

Imux4

X	False
Unit	V
Values	0.406892

Imux5

X	False
Unit	V
Values	0.210453

Imux6

X	False
Unit	V
Values	0.0157125

Imux7

X	False
Unit	V
Values	0.389228

Imux8

X	False
Unit	V
Values	0.739089

Imux10

X	False
Unit	V
Values	0.0157136

Imux11

X	False
Unit	V
Values	0.0157143

Imux12

X	False
Unit	V
Values	0.474646

Imux13

X	False
Unit	V
Values	0.640157

Imux14

X	False
Unit	V
Values	0.525012

Imux15

X	False
Unit	V
Values	0.865693

Imux16

X	False
Unit	V
Values	0.746381

Imux17

X	False
Unit	V
Values	0.753942

Imux18

X	False
Unit	V
Values	0.840928

Imux19

X	False
Unit	V
Values	0.483362

Imux20

X	False
Unit	V
Values	0.762978

Imux21

X	False
Unit	V
Values	0.470142

Imux22

X	False
Unit	V
Values	0.485958

Imux23

X	False
Unit	V
Values	0.760473

Imux24

X	False
Unit	V
Values	0.49825

Imux25

X	False
Unit	V
Values	0.491269

Imux28

X	False
Unit	V
Values	0.316615

Imux29

X	False
Unit	V
Values	0.0452548

Imux30

X	False
Unit	V
Values	0.44296

Imux31

X	False
Unit	V
Values	0.149736

Imux63

X	False
Unit	V
Values	0.0157092

Metadata

FirmwareVersion

FirmwareIdentifier

ChannelConfig

SoftwareVersion

ChipConfigs

ITKPIXV2

GlobalConfig

AiRegionRow	0
AuroraActiveLanes	1
AuroraAltOutput0	0
AuroraAltOutput1	0
AuroraCBSend	0
AuroraCBWait0	4095
AuroraCBWait1	0
AuroraCCSend	3
AuroraCCWait	25
AuroraEnPrbs	0
AuroraInitWait	32
AuroraSendAlt	0
AutoRead0	134
AutoRead1	135
AutoRead2	137
AutoRead3	138
AutoRead4	140
AutoRead5	151
AutoRead6	152
AutoRead7	156
BcidCnt	0
BitFlipErrCnt	0
BitFlipWngCnt	0
CapMeasEn	0
CapMeasEnPar	0
CdrClkSel	0
CdrCp	40
CdrCpBuff	200
CdrCpFd	400
CdrPhaseDetSel	0
CdrVco	1023
CdrVcoBuff	500
ChSyncLockThr	31
ChipIdSense	0
Clk160En	7
Clk40En	7
ClkAuroraEn	7
ClkDataMergeEn	7
CmdErrCnt	0
CmlBias0	800
CmlBias1	400
CmlBias2	0
DataDecodingValues	0
DataEnBcid	0
DataEnBinaryRo	0
DataEnCrc	0
DataEnL1id	0
DataEnRaw	0
DataMaxHits	0
DataMaxTot	0
DataMergeEn	0
DataMergeEnBond	0
DataMergeEnClkGate	0
DataMergeFixedMode	0
DataMergeGpoSel	0
DataMergeInMux0	0
DataMergeInMux1	1
DataMergeInMux2	2
DataMergeInMux3	3
DataMergeInPol	0
DataMergeManChoice	0
DataMergeManMode	0
DataMergeOutMux0	1
DataMergeOutMux1	2
DataMergeOutMux2	3
DataMergeOutMux3	0
DataMergeSelClk	0
DataReadDelay	0
DiffComp	500
DiffFbCapEn	0
DiffLcc	200
DiffLccEn	1
DiffPreComp	350
DiffPreampL	550
DiffPreampM	550
DiffPreampR	550
DiffPreampT	550
DiffPreampTL	550
DiffPreampTR	550
DiffTh1L	220
DiffTh1M	220
DiffTh1R	220
DiffTh2	50
DiffVff	100
EfuseConfig	3855
EfuseReadData0	27906
EfuseReadData1	8748
EfuseWriteData0	0
EfuseWriteData1	0
EnChipId	0
EnCoreCol0	65531
EnCoreCol1	65535
EnCoreCol2	65535
EnCoreCol3	63
EnCoreColCal0	0
EnCoreColCal1	0
EnCoreColCal2	0
EnCoreColCal3	0
EnHitsRemoval0	0
EnHitsRemoval1	0
EnHitsRemoval2	0
EnHitsRemoval3	0
EnIsoHitsRemoval0	0
EnIsoHitsRemoval1	0
EnIsoHitsRemoval2	0
EnIsoHitsRemoval3	0
ErrWngMask	0
EvenMask	0
FineDelayClk	0
FineDelayData	0
GatedHitOrCnt0	0
GatedHitOrCnt1	0
GcrDefaultConfig	44149
GcrDefaultConfigB	21386
GlobalConfigSeuCnt	0
GlobalPulseConf	0
GlobalPulseWidth	10
GpCmosDs	0
GpCmosEn	1
GpCmosRoute	34
GpLvdsBias	7
GpLvdsEn	15
GpLvdsPad0	0
GpLvdsPad1	1
GpLvdsPad2	33
GpLvdsPad3	35
GpValReg	5
HitOrCnt0	0
HitOrCnt1	0
HitOrCnt2	0
HitOrCnt3	0
HitOrMask0	0
HitOrMask1	0
HitOrMask2	0
HitOrMask3	0
InjAnaMode	0
InjDigEn	0
InjFineDelay	5
InjVcalHigh	879
InjVcalMed	200
InjVcalRange	1
IrefTrimSense	0
Latency	500
LinComp	110
LinCompTa	110
LinFc	20
LinGdacL	408
LinGdacM	408
LinGdacR	408
LinKrumCurr	50
LinLdac	100
LinPreampL	300
LinPreampM	300
LinPreampR	300
LinPreampT	300
LinPreampTL	300
LinPreampTR	300
LinRefKrum	300
LockLossCnt	0
MonAdcTrim	0
MonSensAcbDem	0
MonSensAcbEn	0
MonSensAcbSelBias	0
MonSensSldoAnaDem	0
MonSensSldoAnaEn	0
MonSensSldoAnaSelBias	0
MonSensSldoDigDem	0
MonSensSldoDigEn	0
MonSensSldoDigSelBias	0
MonitorEnable	1
MonitorI	63
MonitorV	32
MonitoringDataAdc	0
NtcDac	100
NumOfEventsInStream	0
OddMask	0
PixAutoRow	1
PixBroadcast	0
PixConfMode	1
PixDefaultConfig	40162
PixDefaultConfigB	25373
PixEnSeuCount	0
PixHitSampleMode	0
PixPortal	43144
PixRegionCol	199
PixRegionRow	0
PixelSeuCntCnt	0
PtotCoreColEn0	0
PtotCoreColEn1	0
PtotCoreColEn2	0
PtotCoreColEn3	0
RdWrFifoErrCnt	0
ReadTrigCnt	0
ReadTrigLatency	0
RingOscAClear	0
RingOscAEn	0
RingOscAOut	0
RingOscARoute	0
RingOscBClear	0
RingOscBEnBl	0
RingOscBEnBr	0
RingOscBEnCapA	0
RingOscBEnFf	0
RingOscBEnLvt	0
RingOscBOut	0
RingOscBRoute	0
RstCoreCol0	0
RstCoreCol1	0
RstCoreCol2	0
RstCoreCol3	0
SelfTrigDeadtime	64
SelfTrigDelay	512
SelfTrigDigThr	1
SelfTrigDigThrEn	0
SelfTrigEn	0
SelfTrigMulti	4
SelfTrigPattern	65534
SerEnLane	15
SerEnTap	1
SerInvTap	1
SerSelOut0	3
SerSelOut1	3
SerSelOut2	3
SerSelOut3	1
ServiceBlockEn	1
ServiceBlockPeriod	50
SkippedTrigCnt	0
SldoEnUndershuntA	0
SldoEnUndershuntD	0
SldoTrimA	7
SldoTrimD	10
TotEn6b4b	0
TotEn80	0
TotEnPtoa	0
TotEnPtot	0
TotPtotLatency	500
TrigCnt	0
TruncTimeoutConf	0
TwoLevelTrig	0
VrefIn	1
VrefRsensBot	0
VrefRsensTop	0

Parameter

ADCcalPar	14.0 0.185 10000.0
ChipId	14
EnforceNameIdCheck	True
InjCap	7.08
IrefTrim	8
KSenseInA	21324.717
KSenseInD	21374.64
KSenseShuntA	21934.0
KSenseShuntD	21985.0
KShuntA	997.71
KShuntD	975.014
Name	0x22c6d
NfACB	1.2567909
NfASLDO	1.2579336
NfDSLDO	1.2585193
NtcCalPar	0.0007489 0.0002769 7.0595e-08
VcalPar	-0.0 0.2

SoftwareType

ChipID

Name

0x22c6d

Institution

LBNL_PIXEL_MODULES

ModuleSN

20UPGM23211141

TimeStart

1763746420

TimeEnd

1763747195

useCalibAdc

False

comment

property

YARR_VERSION	v1.5.5
ANALOG_READBACK_MEASUREMENT_VERSION	2.7.2.dev0

AR_VMEAS

MODULE/POST_PARYLENE_WARM

660dc84c2fc9f200350c07aa

1.01

64657cef8d79bac1f3f005c0

mts	2025-11-21 19:23:57.087000
cts	2025-11-21 19:23:57.087000
rev	0

20UPGFC0142445

ANALOG_READBACK

6920bc21b05aed379019d58a

DCSdata

SensorVoltage	-80.0
SensorCurrent	-1.9578e-05
ModuleNTC	19.9991

Measurements

Vmux2

X	False
Unit	V
Values	0.143579 0.143579 0.143579 0.143579 0.143579 0.143579 0.143579 0.143579 0.143579 0.143579 0.143579 0.143579 0.143579 0.143579 0.143579 0.143579 0.143579 0.143579 0.143579 0.143579 0.143579 0.143579 0.143579 0.143579 0.143579 0.143579 0.143579 0.143579 0.143579 0.143579 0.143579 0.143579

Vmux30

X	False
Unit	V
Values	0.0180525 0.0180525 0.0180525 0.0180525 0.0180525 0.0180525 0.0180525 0.0180525 0.0180525 0.0180525 0.0180525 0.0180525 0.0180525 0.0180525 0.0180525 0.0180525 0.0180525 0.0180525 0.0180525 0.0180525 0.0180525 0.0180525 0.0180525 0.0180525 0.0180525 0.0180525 0.0180525 0.0180525 0.0180525 0.0180525 0.0180525 0.0180525

Imux9

X	False
Unit	V
Values	0.117125 0.117125 0.117125 0.117125 0.117125 0.117125 0.117125 0.117125 0.117125 0.117125 0.117125 0.117125 0.117125 0.117125 0.117125 0.117125 0.117125 0.117125 0.117125 0.117125 0.117125 0.117125 0.117125 0.117125 0.117125 0.117125 0.117125 0.117125 0.117125 0.117125 0.117125 0.117125

Imux63

X	False
Unit	V
Values	0.0156935 0.0156935 0.0156935 0.0156935 0.0156935 0.0156935 0.0156935 0.0156935 0.0156935 0.0156935 0.0156935 0.0156935 0.0156935 0.0156935 0.0156935 0.0156935 0.0156935 0.0156935 0.0156935 0.0156935 0.0156935 0.0156935 0.0156935 0.0156935 0.0156935 0.0156935 0.0156935 0.0156935 0.0156935 0.0156935 0.0156935 0.0156935

Vmux14

X	False
Unit	V
Values	0.226751 0.227107 0.227361 0.226644 0.228015 0.22803 0.226972 0.227999 0.227933 0.227231 0.226645 0.226622 0.226985 0.226106 0.227349 0.22635 0.315084 0.315107 0.315063 0.315111 0.314961 0.314958 0.315074 0.314987 0.315025 0.315041 0.315066 0.315086 0.31502 0.315104 0.31501 0.315084

Vmux16

X	False
Unit	V
Values	0.230397 0.231289 0.230323 0.228467 0.228447 0.229151 0.228955 0.229696 0.229018 0.230189 0.228774 0.228761 0.229832 0.22944 0.228731 0.229736 0.317675 0.317625 0.317717 0.317837 0.317858 0.317793 0.317822 0.317775 0.31781 0.317764 0.317835 0.31785 0.317771 0.317753 0.317818 0.317719

Vmux18

X	False
Unit	V
Values	0.233614 0.233683 0.234943 0.23332 0.23367 0.233551 0.232602 0.233152 0.233357 0.232818 0.233659 0.23182 0.232878 0.233563 0.233615 0.23221 0.320836 0.320834 0.320745 0.320836 0.320819 0.320887 0.320889 0.320881 0.320875 0.320882 0.320785 0.320991 0.320892 0.320825 0.320841 0.320961

MonSensSldoAnaSelBias

X	False
Unit	-
Values	0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

MonSensSldoDigSelBias

X	False
Unit	-
Values	0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

MonSensAcbSelBias

X	False
Unit	-
Values	0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

MonSensSldoAnaDem

X	False
Unit	-
Values	0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

MonSensSldoDigDem

X	False
Unit	-
Values	0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

MonSensAcbDem

X	False
Unit	-
Values	0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

TExtExtNTC

X	False
Unit	C
Values	20.012 20.012 20.012 20.012 20.012 20.012 20.012 20.012 20.012 20.012 20.012 20.012 20.012 20.012 20.012 20.012 20.012 20.012 20.012 20.012 20.012 20.012 20.012 20.012 20.012 20.012 20.012 20.012 20.012 20.012 20.012 20.012

Metadata

FirmwareVersion

FirmwareIdentifier

ChannelConfig

SoftwareVersion

ChipConfigs

ITKPIXV2

GlobalConfig

AiRegionRow	0
AuroraActiveLanes	1
AuroraAltOutput0	0
AuroraAltOutput1	0
AuroraCBSend	0
AuroraCBWait0	4095
AuroraCBWait1	0
AuroraCCSend	3
AuroraCCWait	25
AuroraEnPrbs	0
AuroraInitWait	32
AuroraSendAlt	0
AutoRead0	134
AutoRead1	135
AutoRead2	137
AutoRead3	138
AutoRead4	140
AutoRead5	151
AutoRead6	152
AutoRead7	156
BcidCnt	0
BitFlipErrCnt	0
BitFlipWngCnt	0
CapMeasEn	0
CapMeasEnPar	0
CdrClkSel	0
CdrCp	40
CdrCpBuff	200
CdrCpFd	400
CdrPhaseDetSel	0
CdrVco	1023
CdrVcoBuff	500
ChSyncLockThr	31
ChipIdSense	0
Clk160En	7
Clk40En	7
ClkAuroraEn	7
ClkDataMergeEn	7
CmdErrCnt	0
CmlBias0	800
CmlBias1	400
CmlBias2	0
DataDecodingValues	0
DataEnBcid	0
DataEnBinaryRo	0
DataEnCrc	0
DataEnL1id	0
DataEnRaw	0
DataMaxHits	0
DataMaxTot	0
DataMergeEn	0
DataMergeEnBond	0
DataMergeEnClkGate	0
DataMergeFixedMode	0
DataMergeGpoSel	0
DataMergeInMux0	0
DataMergeInMux1	1
DataMergeInMux2	2
DataMergeInMux3	3
DataMergeInPol	0
DataMergeManChoice	0
DataMergeManMode	0
DataMergeOutMux0	1
DataMergeOutMux1	2
DataMergeOutMux2	3
DataMergeOutMux3	0
DataMergeSelClk	0
DataReadDelay	0
DiffComp	500
DiffFbCapEn	0
DiffLcc	200
DiffLccEn	1
DiffPreComp	350
DiffPreampL	550
DiffPreampM	550
DiffPreampR	550
DiffPreampT	550
DiffPreampTL	550
DiffPreampTR	550
DiffTh1L	220
DiffTh1M	220
DiffTh1R	220
DiffTh2	50
DiffVff	100
EfuseConfig	3855
EfuseReadData0	27906
EfuseReadData1	8748
EfuseWriteData0	0
EfuseWriteData1	0
EnChipId	0
EnCoreCol0	65531
EnCoreCol1	65535
EnCoreCol2	65535
EnCoreCol3	63
EnCoreColCal0	0
EnCoreColCal1	0
EnCoreColCal2	0
EnCoreColCal3	0
EnHitsRemoval0	0
EnHitsRemoval1	0
EnHitsRemoval2	0
EnHitsRemoval3	0
EnIsoHitsRemoval0	0
EnIsoHitsRemoval1	0
EnIsoHitsRemoval2	0
EnIsoHitsRemoval3	0
ErrWngMask	0
EvenMask	0
FineDelayClk	0
FineDelayData	0
GatedHitOrCnt0	0
GatedHitOrCnt1	0
GcrDefaultConfig	44149
GcrDefaultConfigB	21386
GlobalConfigSeuCnt	0
GlobalPulseConf	0
GlobalPulseWidth	10
GpCmosDs	0
GpCmosEn	1
GpCmosRoute	34
GpLvdsBias	7
GpLvdsEn	15
GpLvdsPad0	0
GpLvdsPad1	1
GpLvdsPad2	33
GpLvdsPad3	35
GpValReg	5
HitOrCnt0	0
HitOrCnt1	0
HitOrCnt2	0
HitOrCnt3	0
HitOrMask0	0
HitOrMask1	0
HitOrMask2	0
HitOrMask3	0
InjAnaMode	0
InjDigEn	0
InjFineDelay	5
InjVcalHigh	879
InjVcalMed	200
InjVcalRange	1
IrefTrimSense	0
Latency	500
LinComp	110
LinCompTa	110
LinFc	20
LinGdacL	408
LinGdacM	408
LinGdacR	408
LinKrumCurr	50
LinLdac	100
LinPreampL	300
LinPreampM	300
LinPreampR	300
LinPreampT	300
LinPreampTL	300
LinPreampTR	300
LinRefKrum	300
LockLossCnt	0
MonAdcTrim	0
MonSensAcbDem	0
MonSensAcbEn	0
MonSensAcbSelBias	0
MonSensSldoAnaDem	0
MonSensSldoAnaEn	0
MonSensSldoAnaSelBias	0
MonSensSldoDigDem	0
MonSensSldoDigEn	0
MonSensSldoDigSelBias	0
MonitorEnable	1
MonitorI	63
MonitorV	32
MonitoringDataAdc	0
NtcDac	100
NumOfEventsInStream	0
OddMask	0
PixAutoRow	1
PixBroadcast	0
PixConfMode	1
PixDefaultConfig	40162
PixDefaultConfigB	25373
PixEnSeuCount	0
PixHitSampleMode	0
PixPortal	43144
PixRegionCol	199
PixRegionRow	0
PixelSeuCntCnt	0
PtotCoreColEn0	0
PtotCoreColEn1	0
PtotCoreColEn2	0
PtotCoreColEn3	0
RdWrFifoErrCnt	0
ReadTrigCnt	0
ReadTrigLatency	0
RingOscAClear	0
RingOscAEn	0
RingOscAOut	0
RingOscARoute	0
RingOscBClear	0
RingOscBEnBl	0
RingOscBEnBr	0
RingOscBEnCapA	0
RingOscBEnFf	0
RingOscBEnLvt	0
RingOscBOut	0
RingOscBRoute	0
RstCoreCol0	0
RstCoreCol1	0
RstCoreCol2	0
RstCoreCol3	0
SelfTrigDeadtime	64
SelfTrigDelay	512
SelfTrigDigThr	1
SelfTrigDigThrEn	0
SelfTrigEn	0
SelfTrigMulti	4
SelfTrigPattern	65534
SerEnLane	15
SerEnTap	1
SerInvTap	1
SerSelOut0	3
SerSelOut1	3
SerSelOut2	3
SerSelOut3	1
ServiceBlockEn	1
ServiceBlockPeriod	50
SkippedTrigCnt	0
SldoEnUndershuntA	0
SldoEnUndershuntD	0
SldoTrimA	7
SldoTrimD	10
TotEn6b4b	0
TotEn80	0
TotEnPtoa	0
TotEnPtot	0
TotPtotLatency	500
TrigCnt	0
TruncTimeoutConf	0
TwoLevelTrig	0
VrefIn	1
VrefRsensBot	0
VrefRsensTop	0

Parameter

ADCcalPar	14.0 0.185 10000.0
ChipId	14
EnforceNameIdCheck	True
InjCap	7.08
IrefTrim	8
KSenseInA	21324.717
KSenseInD	21374.64
KSenseShuntA	21934.0
KSenseShuntD	21985.0
KShuntA	997.71
KShuntD	975.014
Name	0x22c6d
NfACB	1.2567909
NfASLDO	1.2579336
NfDSLDO	1.2585193
NtcCalPar	0.0007489 0.0002769 7.0595e-08
VcalPar	-0.0 0.2

SoftwareType

ChipID

Name

0x22c6d

Institution

LBNL_PIXEL_MODULES

ModuleSN

20UPGM23211141

TimeStart

1763751609

TimeEnd

1763752994

useCalibAdc

False

comment

property

YARR_VERSION	v1.5.5
ANALOG_READBACK_MEASUREMENT_VERSION	2.7.2.dev0

AR_TEMP

MODULE/POST_PARYLENE_WARM

660dc84c2fc9f200350c07aa

1.01

64657cef8d79bac1f3f005c0

mts	2025-11-21 19:23:57.087000
cts	2025-11-21 19:23:57.087000
rev	0

20UPGFC0142445

ANALOG_READBACK

6920bc21b05aed379019d58b

DCSdata

SensorVoltage	-80.0
SensorCurrent	-1.86335e-05
ModuleNTC	20.0094

Measurements

Vmux34

X	False
Unit	V
Values	0.53616 0.548153 0.559954 0.571936 0.583547 0.595651 0.607414 0.61911 0.634054 0.645793 0.657578 0.668715 0.680629 0.692042 0.703973 0.715911

Vmux38

X	False
Unit	V
Values	0.509653 0.520595 0.532317 0.543101 0.553775 0.565227 0.576694 0.588047 0.60007 0.610951 0.622599 0.633715 0.644509 0.655385 0.666544 0.679051

Vmux30

X	False
Unit	V
Values	0.0180329 0.0180329 0.0180329 0.0180329 0.0180329 0.0180329 0.0180329 0.0180329 0.0180329 0.0180329 0.0180329 0.0180329 0.0180329 0.0180329 0.0180329 0.0180329

Vmux33

X	False
Unit	V
Values	0.394857 0.39496 0.394908 0.394948 0.39487 0.394878 0.394892 0.394865 0.394635 0.394684 0.394614 0.394487 0.394325 0.393931 0.393575 0.392675

Vmux37

X	False
Unit	V
Values	0.396431 0.396459 0.396305 0.396516 0.396505 0.396516 0.39661 0.396513 0.396646 0.396582 0.396633 0.396496 0.396348 0.396264 0.396055 0.395594

Imux63

X	False
Unit	V
Values	0.0156753 0.0156753 0.0156753 0.0156753 0.0156753 0.0156753 0.0156753 0.0156753 0.0156753 0.0156753 0.0156753 0.0156753 0.0156753 0.0156753 0.0156753 0.0156753

Imux28

X	False
Unit	V
Values	0.315529 0.315768 0.315963 0.316267 0.316442 0.316471 0.316609 0.31664 0.316796 0.316812 0.316859 0.316678 0.316365 0.315807 0.314754 0.313247

Imux29

X	False
Unit	V
Values	0.0621296 0.0590066 0.0563013 0.0536418 0.051184 0.0490336 0.0468821 0.0454941 0.0436779 0.0424479 0.0417543 0.0424084 0.0445982 0.0497006 0.0586687 0.0763936

Imux30

X	False
Unit	V
Values	0.437378 0.438817 0.440129 0.440855 0.44156 0.441993 0.442252 0.44259 0.442788 0.442825 0.442892 0.442855 0.442586 0.441937 0.440884 0.439187

Imux31

X	False
Unit	V
Values	0.208292 0.202629 0.196478 0.190957 0.185076 0.179374 0.173114 0.167362 0.161123 0.155561 0.149807 0.144928 0.140974 0.137927 0.137341 0.139886

SldoTrimA

X	False
Unit	-
Values	0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

SldoTrimD

X	False
Unit	-
Values	0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

ROSC0

X	False
Unit	MHz
Values	296.933 315.667 333.933 352.267 370.067 388.133 406.667 423.467 443.267 461.0 477.8 494.067 510.067 526.533 542.667 558.533

ROSC1

X	False
Unit	MHz
Values	460.0 488.067 516.4 544.2 571.6 599.333 627.467 652.6 701.4 709.133 734.6 759.533 783.8 808.267 832.867 856.867

ROSC2

X	False
Unit	MHz
Values	287.133 305.733 324.0 342.267 359.867 378.0 396.6 413.067 432.533 449.933 467.067 483.2 499.2 515.733 532.0 547.933

ROSC3

X	False
Unit	MHz
Values	445.333 473.6 502.133 529.8 557.267 584.8 613.0 638.6 668.4 695.467 721.6 746.533 770.8 795.733 820.467 844.6

ROSC4

X	False
Unit	MHz
Values	266.4 285.067 303.8 322.333 340.867 359.733 379.467 397.267 418.533 437.467 456.133 474.0 491.8 510.0 528.067 546.067

ROSC5

X	False
Unit	MHz
Values	438.8 469.467 501.133 532.0 563.333 594.867 627.533 657.533 692.667 724.4 755.867 785.867 815.733 846.067 876.4 906.467

ROSC6

X	False
Unit	MHz
Values	274.267 295.867 317.333 338.733 360.2 382.533 405.333 426.067 450.8 473.267 495.067 516.267 537.467 558.933 580.533 601.667

ROSC7

X	False
Unit	MHz
Values	419.333 451.0 483.067 515.067 546.267 579.0 612.733 642.8 679.067 712.133 744.2 774.667 805.533 836.733 867.667 898.533

ROSC8

X	False
Unit	MHz
Values	433.733 462.333 490.267 517.6 545.333 573.467 601.067 627.8 657.333 683.933 711.733 736.333 760.333 786.267 812.067 837.467

ROSC9

X	False
Unit	MHz
Values	441.533 470.533 498.8 526.4 554.067 582.4 609.867 637.333 666.933 694.0 721.4 746.467 770.067 795.733 821.867 847.533

ROSC10

X	False
Unit	MHz
Values	511.8 545.267 577.867 609.933 641.867 674.667 706.8 737.867 771.933 802.867 834.667 863.8 891.0 921.0 951.2 980.533

ROSC11

X	False
Unit	MHz
Values	506.6 539.8 572.333 604.2 636.333 669.2 701.267 732.133 766.733 797.667 829.267 858.533 885.867 916.2 946.133 975.667

ROSC12

X	False
Unit	MHz
Values	431.933 461.067 490.067 517.467 545.533 574.467 602.4 630.067 660.267 687.533 715.933 741.933 765.867 792.733 819.6 845.667

ROSC13

X	False
Unit	MHz
Values	431.333 460.333 489.133 516.733 544.733 573.667 601.867 629.133 659.4 686.6 714.933 740.533 765.0 791.667 818.067 844.133

ROSC14

X	False
Unit	MHz
Values	502.8 535.933 568.733 600.667 632.4 665.067 697.467 728.4 762.333 793.8 825.533 854.667 882.2 912.333 942.867 972.467

ROSC15

X	False
Unit	MHz
Values	504.133 537.533 570.4 602.4 634.533 667.467 699.8 731.267 765.267 796.4 828.533 858.0 885.667 916.0 945.933 975.933

ROSC16

X	False
Unit	MHz
Values	417.867 448.933 479.467 509.4 540.267 571.867 603.4 634.267 667.733 698.8 731.067 760.867 789.0 819.8 850.867 881.867

ROSC17

X	False
Unit	MHz
Values	433.6 465.2 496.333 527.4 558.333 590.667 622.467 654.067 688.467 720.133 753.133 783.067 811.333 843.067 874.533 905.533

ROSC18

X	False
Unit	MHz
Values	507.933 544.733 580.867 616.933 652.6 690.2 727.533 763.933 803.6 840.533 879.067 913.8 946.933 983.067 1020.53 1056.67

ROSC19

X	False
Unit	MHz
Values	508.733 545.267 581.533 617.067 652.933 690.667 727.467 764.133 803.8 840.333 878.333 913.533 946.6 982.8 1019.47 1055.87

ROSC20

X	False
Unit	MHz
Values	383.333 413.667 443.4 473.133 503.533 534.8 565.533 596.333 629.533 660.533 692.333 722.0 750.4 780.8 811.933 842.8

ROSC21

X	False
Unit	MHz
Values	395.533 426.533 456.533 486.8 517.6 549.133 580.733 611.733 645.2 676.8 709.2 738.6 767.133 798.2 829.2 860.067

ROSC22

X	False
Unit	MHz
Values	485.8 523.133 560.2 596.333 633.467 671.667 709.667 747.067 787.667 825.467 864.333 900.4 934.467 971.933 1009.73 1047.27

ROSC23

X	False
Unit	MHz
Values	489.2 526.867 563.533 600.133 637.333 675.8 714.067 751.4 792.8 830.467 869.467 906.133 940.067 977.6 1015.53 1053.0

ROSC24

X	False
Unit	MHz
Values	283.533 303.133 322.467 341.333 360.4 380.2 399.8 418.667 439.4 458.133 478.0 495.733 513.333 531.8 550.533 569.067

ROSC25

X	False
Unit	MHz
Values	281.0 300.733 319.867 339.133 358.4 378.0 397.467 416.733 437.6 457.0 476.867 494.933 512.4 531.067 549.667 568.533

ROSC26

X	False
Unit	MHz
Values	342.733 366.667 389.8 412.933 436.133 460.067 483.867 506.933 532.0 555.2 578.8 600.933 621.8 644.6 667.333 690.267

ROSC27

X	False
Unit	MHz
Values	337.267 360.733 384.2 406.933 430.133 453.933 477.333 500.2 525.4 548.533 572.2 594.133 614.733 637.2 660.133 682.8

ROSC28

X	False
Unit	MHz
Values	349.267 373.533 396.467 419.667 442.8 466.667 490.533 513.467 538.667 561.733 585.467 607.133 627.8 650.467 673.467 695.933

ROSC29

X	False
Unit	MHz
Values	354.267 378.533 402.0 425.2 448.8 472.733 496.667 519.6 544.8 568.0 591.733 613.533 634.267 656.867 679.733 702.2

ROSC30

X	False
Unit	MHz
Values	554.4 583.933 612.667 640.133 668.267 696.733 724.6 751.4 779.733 806.6 833.4 857.933 881.133 905.8 931.0 955.133

ROSC31

X	False
Unit	MHz
Values	596.6 627.933 658.0 687.267 716.6 745.867 775.2 803.2 833.6 861.067 888.867 914.533 938.333 964.267 990.533 1015.4

ROSC32

X	False
Unit	MHz
Values	485.0 513.067 540.2 567.0 593.533 621.0 647.933 674.133 702.4 728.733 755.0 779.667 802.4 827.667 852.733 877.933

ROSC33

X	False
Unit	MHz
Values	511.533 541.0 569.467 597.6 625.333 654.267 682.467 709.867 739.667 767.267 794.867 820.733 844.667 871.133 897.467 923.333

ROSC34

X	False
Unit	MHz
Values	487.667 523.2 557.6 592.4 627.6 663.333 699.267 734.133 772.733 808.333 844.667 878.867 910.867 945.8 981.467 1015.93

ROSC35

X	False
Unit	MHz
Values	477.133 512.4 547.0 581.2 615.667 651.733 687.267 722.2 760.067 795.6 832.0 865.267 897.133 932.067 967.667 1002.33

ROSC36

X	False
Unit	MHz
Values	482.6 517.667 552.6 586.667 621.467 657.4 693.267 728.267 766.333 802.0 838.4 871.867 903.933 938.933 974.4 1008.87

ROSC37

X	False
Unit	MHz
Values	483.067 517.933 552.8 586.867 621.8 657.667 693.333 728.467 766.6 802.6 838.667 872.667 904.067 939.2 975.133 1009.8

ROSC38

X	False
Unit	MHz
Values	483.067 518.467 553.2 587.4 622.133 658.267 693.733 728.667 767.267 802.6 838.867 872.667 904.267 939.733 974.933 1009.67

ROSC39

X	False
Unit	MHz
Values	487.6 523.133 557.733 592.4 627.267 663.333 699.133 734.4 773.2 808.467 845.333 878.8 910.8 946.133 981.733 1016.73

ROSC40

X	False
Unit	MHz
Values	482.2 516.867 551.667 585.8 620.667 656.0 691.933 726.733 765.0 800.533 837.0 870.733 902.667 937.533 973.2 1008.07

ROSC41

X	False
Unit	MHz
Values	479.6 514.4 549.333 583.4 618.133 653.6 689.0 724.267 762.267 797.267 833.6 867.0 898.667 933.933 968.8 1003.73

Metadata

FirmwareVersion

FirmwareIdentifier

ChannelConfig

SoftwareVersion

ChipConfigs

ITKPIXV2

GlobalConfig

AiRegionRow	0
AuroraActiveLanes	1
AuroraAltOutput0	0
AuroraAltOutput1	0
AuroraCBSend	0
AuroraCBWait0	4095
AuroraCBWait1	0
AuroraCCSend	3
AuroraCCWait	25
AuroraEnPrbs	0
AuroraInitWait	32
AuroraSendAlt	0
AutoRead0	134
AutoRead1	135
AutoRead2	137
AutoRead3	138
AutoRead4	140
AutoRead5	151
AutoRead6	152
AutoRead7	156
BcidCnt	0
BitFlipErrCnt	0
BitFlipWngCnt	0
CapMeasEn	0
CapMeasEnPar	0
CdrClkSel	0
CdrCp	40
CdrCpBuff	200
CdrCpFd	400
CdrPhaseDetSel	0
CdrVco	1023
CdrVcoBuff	500
ChSyncLockThr	31
ChipIdSense	0
Clk160En	7
Clk40En	7
ClkAuroraEn	7
ClkDataMergeEn	7
CmdErrCnt	0
CmlBias0	800
CmlBias1	400
CmlBias2	0
DataDecodingValues	0
DataEnBcid	0
DataEnBinaryRo	0
DataEnCrc	0
DataEnL1id	0
DataEnRaw	0
DataMaxHits	0
DataMaxTot	0
DataMergeEn	0
DataMergeEnBond	0
DataMergeEnClkGate	0
DataMergeFixedMode	0
DataMergeGpoSel	0
DataMergeInMux0	0
DataMergeInMux1	1
DataMergeInMux2	2
DataMergeInMux3	3
DataMergeInPol	0
DataMergeManChoice	0
DataMergeManMode	0
DataMergeOutMux0	1
DataMergeOutMux1	2
DataMergeOutMux2	3
DataMergeOutMux3	0
DataMergeSelClk	0
DataReadDelay	0
DiffComp	500
DiffFbCapEn	0
DiffLcc	200
DiffLccEn	1
DiffPreComp	350
DiffPreampL	550
DiffPreampM	550
DiffPreampR	550
DiffPreampT	550
DiffPreampTL	550
DiffPreampTR	550
DiffTh1L	220
DiffTh1M	220
DiffTh1R	220
DiffTh2	50
DiffVff	100
EfuseConfig	3855
EfuseReadData0	27906
EfuseReadData1	8748
EfuseWriteData0	0
EfuseWriteData1	0
EnChipId	0
EnCoreCol0	65531
EnCoreCol1	65535
EnCoreCol2	65535
EnCoreCol3	63
EnCoreColCal0	0
EnCoreColCal1	0
EnCoreColCal2	0
EnCoreColCal3	0
EnHitsRemoval0	0
EnHitsRemoval1	0
EnHitsRemoval2	0
EnHitsRemoval3	0
EnIsoHitsRemoval0	0
EnIsoHitsRemoval1	0
EnIsoHitsRemoval2	0
EnIsoHitsRemoval3	0
ErrWngMask	0
EvenMask	0
FineDelayClk	0
FineDelayData	0
GatedHitOrCnt0	0
GatedHitOrCnt1	0
GcrDefaultConfig	44149
GcrDefaultConfigB	21386
GlobalConfigSeuCnt	0
GlobalPulseConf	0
GlobalPulseWidth	10
GpCmosDs	0
GpCmosEn	1
GpCmosRoute	34
GpLvdsBias	7
GpLvdsEn	15
GpLvdsPad0	0
GpLvdsPad1	1
GpLvdsPad2	33
GpLvdsPad3	35
GpValReg	5
HitOrCnt0	0
HitOrCnt1	0
HitOrCnt2	0
HitOrCnt3	0
HitOrMask0	0
HitOrMask1	0
HitOrMask2	0
HitOrMask3	0
InjAnaMode	0
InjDigEn	0
InjFineDelay	5
InjVcalHigh	879
InjVcalMed	200
InjVcalRange	1
IrefTrimSense	0
Latency	500
LinComp	110
LinCompTa	110
LinFc	20
LinGdacL	408
LinGdacM	408
LinGdacR	408
LinKrumCurr	50
LinLdac	100
LinPreampL	300
LinPreampM	300
LinPreampR	300
LinPreampT	300
LinPreampTL	300
LinPreampTR	300
LinRefKrum	300
LockLossCnt	0
MonAdcTrim	0
MonSensAcbDem	0
MonSensAcbEn	0
MonSensAcbSelBias	0
MonSensSldoAnaDem	0
MonSensSldoAnaEn	0
MonSensSldoAnaSelBias	0
MonSensSldoDigDem	0
MonSensSldoDigEn	0
MonSensSldoDigSelBias	0
MonitorEnable	1
MonitorI	63
MonitorV	32
MonitoringDataAdc	0
NtcDac	100
NumOfEventsInStream	0
OddMask	0
PixAutoRow	1
PixBroadcast	0
PixConfMode	1
PixDefaultConfig	40162
PixDefaultConfigB	25373
PixEnSeuCount	0
PixHitSampleMode	0
PixPortal	43144
PixRegionCol	199
PixRegionRow	0
PixelSeuCntCnt	0
PtotCoreColEn0	0
PtotCoreColEn1	0
PtotCoreColEn2	0
PtotCoreColEn3	0
RdWrFifoErrCnt	0
ReadTrigCnt	0
ReadTrigLatency	0
RingOscAClear	0
RingOscAEn	0
RingOscAOut	0
RingOscARoute	0
RingOscBClear	0
RingOscBEnBl	0
RingOscBEnBr	0
RingOscBEnCapA	0
RingOscBEnFf	0
RingOscBEnLvt	0
RingOscBOut	0
RingOscBRoute	0
RstCoreCol0	0
RstCoreCol1	0
RstCoreCol2	0
RstCoreCol3	0
SelfTrigDeadtime	64
SelfTrigDelay	512
SelfTrigDigThr	1
SelfTrigDigThrEn	0
SelfTrigEn	0
SelfTrigMulti	4
SelfTrigPattern	65534
SerEnLane	15
SerEnTap	1
SerInvTap	1
SerSelOut0	3
SerSelOut1	3
SerSelOut2	3
SerSelOut3	1
ServiceBlockEn	1
ServiceBlockPeriod	50
SkippedTrigCnt	0
SldoEnUndershuntA	0
SldoEnUndershuntD	0
SldoTrimA	7
SldoTrimD	10
TotEn6b4b	0
TotEn80	0
TotEnPtoa	0
TotEnPtot	0
TotPtotLatency	500
TrigCnt	0
TruncTimeoutConf	0
TwoLevelTrig	0
VrefIn	1
VrefRsensBot	0
VrefRsensTop	0

Parameter

ADCcalPar	14.0 0.185 10000.0
ChipId	14
EnforceNameIdCheck	True
InjCap	7.08
IrefTrim	8
KSenseInA	21324.717
KSenseInD	21374.64
KSenseShuntA	21934.0
KSenseShuntD	21985.0
KShuntA	997.71
KShuntD	975.014
Name	0x22c6d
NfACB	1.2567909
NfASLDO	1.2579336
NfDSLDO	1.2585193
NtcCalPar	0.0007489 0.0002769 7.0595e-08
VcalPar	-0.0 0.2

SoftwareType

ChipID

Name

0x22c6d

Institution

LBNL_PIXEL_MODULES

ModuleSN

20UPGM23211141

TimeStart

1763747195

TimeEnd

1763751604

useCalibAdc

False

comment

property

YARR_VERSION	v1.5.5
ANALOG_READBACK_MEASUREMENT_VERSION	2.7.2.dev0

AR_VDD

MODULE/POST_PARYLENE_WARM

660dc84c2fc9f200350c07aa

1.01

64657cef8d79bac1f3f005c0

mts	2025-11-21 19:23:57.087000
cts	2025-11-21 19:23:57.087000
rev	0

20UPGFC0142445

ANALOG_READBACK

6920bc21b05aed379019d58c

DCSdata

Measurements

IrefTrimSense

X	False
Unit	-
Values	8.0

Metadata

FirmwareVersion

FirmwareIdentifier

ChannelConfig

SoftwareVersion

ChipConfigs

ITKPIXV2

GlobalConfig

AiRegionRow	0
AuroraActiveLanes	1
AuroraAltOutput0	0
AuroraAltOutput1	0
AuroraCBSend	0
AuroraCBWait0	4095
AuroraCBWait1	0
AuroraCCSend	3
AuroraCCWait	25
AuroraEnPrbs	0
AuroraInitWait	32
AuroraSendAlt	0
AutoRead0	134
AutoRead1	135
AutoRead2	137
AutoRead3	138
AutoRead4	140
AutoRead5	151
AutoRead6	152
AutoRead7	156
BcidCnt	0
BitFlipErrCnt	0
BitFlipWngCnt	0
CapMeasEn	0
CapMeasEnPar	0
CdrClkSel	0
CdrCp	40
CdrCpBuff	200
CdrCpFd	400
CdrPhaseDetSel	0
CdrVco	1023
CdrVcoBuff	500
ChSyncLockThr	31
ChipIdSense	0
Clk160En	7
Clk40En	7
ClkAuroraEn	7
ClkDataMergeEn	7
CmdErrCnt	0
CmlBias0	800
CmlBias1	400
CmlBias2	0
DataDecodingValues	0
DataEnBcid	0
DataEnBinaryRo	0
DataEnCrc	0
DataEnL1id	0
DataEnRaw	0
DataMaxHits	0
DataMaxTot	0
DataMergeEn	0
DataMergeEnBond	0
DataMergeEnClkGate	0
DataMergeFixedMode	0
DataMergeGpoSel	0
DataMergeInMux0	0
DataMergeInMux1	1
DataMergeInMux2	2
DataMergeInMux3	3
DataMergeInPol	0
DataMergeManChoice	0
DataMergeManMode	0
DataMergeOutMux0	1
DataMergeOutMux1	2
DataMergeOutMux2	3
DataMergeOutMux3	0
DataMergeSelClk	0
DataReadDelay	0
DiffComp	500
DiffFbCapEn	0
DiffLcc	200
DiffLccEn	1
DiffPreComp	350
DiffPreampL	550
DiffPreampM	550
DiffPreampR	550
DiffPreampT	550
DiffPreampTL	550
DiffPreampTR	550
DiffTh1L	220
DiffTh1M	220
DiffTh1R	220
DiffTh2	50
DiffVff	100
EfuseConfig	3855
EfuseReadData0	27906
EfuseReadData1	8748
EfuseWriteData0	0
EfuseWriteData1	0
EnChipId	0
EnCoreCol0	65531
EnCoreCol1	65535
EnCoreCol2	65535
EnCoreCol3	63
EnCoreColCal0	0
EnCoreColCal1	0
EnCoreColCal2	0
EnCoreColCal3	0
EnHitsRemoval0	0
EnHitsRemoval1	0
EnHitsRemoval2	0
EnHitsRemoval3	0
EnIsoHitsRemoval0	0
EnIsoHitsRemoval1	0
EnIsoHitsRemoval2	0
EnIsoHitsRemoval3	0
ErrWngMask	0
EvenMask	0
FineDelayClk	0
FineDelayData	0
GatedHitOrCnt0	0
GatedHitOrCnt1	0
GcrDefaultConfig	44149
GcrDefaultConfigB	21386
GlobalConfigSeuCnt	0
GlobalPulseConf	0
GlobalPulseWidth	10
GpCmosDs	0
GpCmosEn	1
GpCmosRoute	34
GpLvdsBias	7
GpLvdsEn	15
GpLvdsPad0	0
GpLvdsPad1	1
GpLvdsPad2	33
GpLvdsPad3	35
GpValReg	5
HitOrCnt0	0
HitOrCnt1	0
HitOrCnt2	0
HitOrCnt3	0
HitOrMask0	0
HitOrMask1	0
HitOrMask2	0
HitOrMask3	0
InjAnaMode	0
InjDigEn	0
InjFineDelay	5
InjVcalHigh	879
InjVcalMed	200
InjVcalRange	1
IrefTrimSense	0
Latency	500
LinComp	110
LinCompTa	110
LinFc	20
LinGdacL	408
LinGdacM	408
LinGdacR	408
LinKrumCurr	50
LinLdac	100
LinPreampL	300
LinPreampM	300
LinPreampR	300
LinPreampT	300
LinPreampTL	300
LinPreampTR	300
LinRefKrum	300
LockLossCnt	0
MonAdcTrim	0
MonSensAcbDem	0
MonSensAcbEn	0
MonSensAcbSelBias	0
MonSensSldoAnaDem	0
MonSensSldoAnaEn	0
MonSensSldoAnaSelBias	0
MonSensSldoDigDem	0
MonSensSldoDigEn	0
MonSensSldoDigSelBias	0
MonitorEnable	1
MonitorI	63
MonitorV	32
MonitoringDataAdc	0
NtcDac	100
NumOfEventsInStream	0
OddMask	0
PixAutoRow	1
PixBroadcast	0
PixConfMode	1
PixDefaultConfig	40162
PixDefaultConfigB	25373
PixEnSeuCount	0
PixHitSampleMode	0
PixPortal	43144
PixRegionCol	199
PixRegionRow	0
PixelSeuCntCnt	0
PtotCoreColEn0	0
PtotCoreColEn1	0
PtotCoreColEn2	0
PtotCoreColEn3	0
RdWrFifoErrCnt	0
ReadTrigCnt	0
ReadTrigLatency	0
RingOscAClear	0
RingOscAEn	0
RingOscAOut	0
RingOscARoute	0
RingOscBClear	0
RingOscBEnBl	0
RingOscBEnBr	0
RingOscBEnCapA	0
RingOscBEnFf	0
RingOscBEnLvt	0
RingOscBOut	0
RingOscBRoute	0
RstCoreCol0	0
RstCoreCol1	0
RstCoreCol2	0
RstCoreCol3	0
SelfTrigDeadtime	64
SelfTrigDelay	512
SelfTrigDigThr	1
SelfTrigDigThrEn	0
SelfTrigEn	0
SelfTrigMulti	4
SelfTrigPattern	65534
SerEnLane	15
SerEnTap	1
SerInvTap	1
SerSelOut0	3
SerSelOut1	3
SerSelOut2	3
SerSelOut3	1
ServiceBlockEn	1
ServiceBlockPeriod	50
SkippedTrigCnt	0
SldoEnUndershuntA	0
SldoEnUndershuntD	0
SldoTrimA	7
SldoTrimD	10
TotEn6b4b	0
TotEn80	0
TotEnPtoa	0
TotEnPtot	0
TotPtotLatency	500
TrigCnt	0
TruncTimeoutConf	0
TwoLevelTrig	0
VrefIn	1
VrefRsensBot	0
VrefRsensTop	0

Parameter

ADCcalPar	14.0 0.185 10000.0
ChipId	14
EnforceNameIdCheck	True
InjCap	7.08
IrefTrim	8
KSenseInA	21324.717
KSenseInD	21374.64
KSenseShuntA	21934.0
KSenseShuntD	21985.0
KShuntA	997.71
KShuntD	975.014
Name	0x22c6d
NfACB	1.2567909
NfASLDO	1.2579336
NfDSLDO	1.2585193
NtcCalPar	0.0007489 0.0002769 7.0595e-08
VcalPar	-0.0 0.2

SoftwareType

ChipID

Name

0x22c6d

Institution

LBNL_PIXEL_MODULES

ModuleSN

20UPGM23211141

TimeStart

1763751604

TimeEnd

1763751609

comment

property

YARR_VERSION	v1.5.5
ANALOG_READBACK_MEASUREMENT_VERSION	2.7.2.dev0

AR_REGISTER

MODULE/POST_PARYLENE_WARM

660dc84c2fc9f200350c07aa

1.01

64657cef8d79bac1f3f005c0

mts	2025-11-21 19:23:57.087000
cts	2025-11-21 19:23:57.087000
rev	0

rawHash

99a6dfc6525bad2d66391f83df492979

stage

MODULE/POST_PARYLENE_WARM

ProductionDB Record

{}

Current Stage: Post-Parylene Warm

Test Type	Local Result
ADC Calibration (ADC_CALIBRATION)	TestRun Present
Analog Readback (ANALOG_READBACK)	TestRun Present
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No TestRun!
Undershunt Protection (UNDERSHUNT_PROTECTION)	No TestRun!
SLDO (SLDO)	TestRun Present
VCAL Calibration (VCAL_CALIBRATION)	TestRun Present
Data Transmission (DATA_TRANSMISSION)	TestRun Present
Injection Capacitance (INJECTION_CAPACITANCE)	TestRun Present
Minimal Health Test (MIN_HEALTH_TEST)	TestRun Present
Tuning (TUNING)	TestRun Present
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	TestRun Present
Low Power Mode (LP_MODE)	TestRun Present

Candidate TestRuns of this Stage

LDB ID	TestRun Code	QC Passed	Inspector	Measurement Date	Analysis Date	Analysis Version	Tags	QC Registration
69433e…206204	PIXEL_FAILURE_ANALYSIS	Fail	None	N/A	a day ago	2.7.0	No tags
693a07…5f3660	ADC_CALIBRATION	Pass	None	a week ago	a week ago	2.7.0	ganymede_4	Selected
6920d6…a9c4cf	DATA_TRANSMISSION	Pass	None	3 weeks ago	3 weeks ago	2.7.0	ganymede_4
6920d5…0bad57	LP_MODE	Pass	None	4 weeks ago	3 weeks ago	2.7.0	ganymede_4
6920c8…7f395d	INJECTION_CAPACITANCE	Pass	None	4 weeks ago	4 weeks ago	2.7.0	ganymede_4
6920c6…a9c3e4	VCAL_CALIBRATION	Pass	None	4 weeks ago	4 weeks ago	2.7.0	ganymede_4
6920c4…22bc7c	SLDO	Pass	None	4 weeks ago	4 weeks ago	2.7.0	ganymede_4
6920bc…22bb9a	ANALOG_READBACK	Pass	None	4 weeks ago	4 weeks ago	2.7.0	ganymede_4
6920a2…a57139	ADC_CALIBRATION	Pass	None	4 weeks ago	4 weeks ago	2.7.0	ganymede_4
691e73…136f25	PIXEL_FAILURE_ANALYSIS	Fail	None	N/A	4 weeks ago	2.7.0	No tags
690e82…2edf70	DATA_TRANSMISSION	Pass	None	a month ago	a month ago	2.7.0	No tags
690e82…2edf54	PIXEL_FAILURE_ANALYSIS	Fail	None	N/A	a month ago	2.7.0	No tags
690e82…2edeab	TUNING	Fail	None	N/A	a month ago	2.7.0	No tags
690e82…2edde3	MIN_HEALTH_TEST	Fail	None	N/A	a month ago	2.7.0	No tags
690e82…2edd7f	INJECTION_CAPACITANCE	Pass	None	a month ago	a month ago	2.7.0	No tags
690e82…2edd4f	LP_MODE	Pass	None	a month ago	a month ago	2.7.0	No tags
690e82…2edd13	ANALOG_READBACK	Pass	None	a month ago	a month ago	2.7.0	No tags
690e82…2edc96	VCAL_CALIBRATION	Pass	None	a month ago	a month ago	2.7.0	No tags
690e82…2edc5a	SLDO	Pass	None	a month ago	a month ago	2.7.0	No tags
690e81…2edc2e	ADC_CALIBRATION	Pass	None	a month ago	a month ago	2.7.0	No tags
690e80…69125c	PIXEL_FAILURE_ANALYSIS	Fail	None	N/A	a month ago	2.7.0	No tags
690e80…2edb37	TUNING	Fail	None	N/A	a month ago	2.7.0	No tags
690e7f…9b5f53	MIN_HEALTH_TEST	Fail	None	N/A	a month ago	2.7.0	No tags
690ac4…f94a61	DATA_TRANSMISSION	Pass	None	a month ago	a month ago	2.7.0	ganymede_4
690ac4…acedaf	LP_MODE	Pass	None	a month ago	a month ago	2.7.0	ganymede_4
690ac3…f949f5	INJECTION_CAPACITANCE	Pass	None	a month ago	a month ago	2.7.0	ganymede_4
690abd…993238	VCAL_CALIBRATION	Pass	None	a month ago	a month ago	2.7.0	ganymede_4
690aba…acebc4	SLDO	Pass	None	a month ago	a month ago	2.7.0	ganymede_4
690ab2…acead8	ANALOG_READBACK	Pass	None	a month ago	a month ago	2.7.0	ganymede_4
690a98…f948c5	ADC_CALIBRATION	Pass	None	a month ago	a month ago	2.7.0	ganymede_4
690a93…f94845	ADC_CALIBRATION	Pass	None	a month ago	a month ago	2.7.0	ganymede_4
6902dc…f69aac	DATA_TRANSMISSION	Pass	None	a month ago	a month ago	2.7.0	ganymede_4
6902dc…6daa13	LP_MODE	Pass	None	a month ago	a month ago	2.7.0	ganymede_4
6902db…f699bf	INJECTION_CAPACITANCE	Pass	None	a month ago	a month ago	2.7.0	ganymede_4
6902da…f698a6	VCAL_CALIBRATION	Pass	None	a month ago	a month ago	2.7.0	ganymede_4
6902d7…f6984a	SLDO	Pass	None	a month ago	a month ago	2.7.0	ganymede_4
6902cf…f6967d	ANALOG_READBACK	Pass	None	a month ago	a month ago	2.7.0	ganymede_4
6902b4…6da8a3	ADC_CALIBRATION	Pass	None	a month ago	a month ago	2.7.0	ganymede_4
6902a4…b313ec	ADC_CALIBRATION	Pass	None	a month ago	a month ago	2.7.0rc3	ganymede_4
690178…c4d45f	DATA_TRANSMISSION	Pass	None	a month ago	a month ago	2.7.0rc3	ganymede_4
690178…c4d427	LP_MODE	Pass	None	a month ago	a month ago	2.7.0rc3	ganymede_4
690177…c4d3ec	INJECTION_CAPACITANCE	Pass	None	a month ago	a month ago	2.7.0rc3	ganymede_4
690176…c4d32e	VCAL_CALIBRATION	Pass	None	a month ago	a month ago	2.7.0rc3	ganymede_4
690173…513aad	SLDO	Pass	None	a month ago	a month ago	2.7.0rc3	ganymede_4
69016c…c4d1a7	ANALOG_READBACK	Pass	None	a month ago	a month ago	2.7.0rc3	ganymede_4
690155…5a849b	ADC_CALIBRATION	Pass	None	a month ago	a month ago	2.7.0rc3	ganymede_4

Past QC Stages and Results

Wirebond Protection (alt) (MODULE/WIREBOND_PROTECTION)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Parylene Unmasking (MODULE/PARYLENE_UNMASKING)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Parylene Coating (MODULE/PARYLENE_COATING)

Parylene Masking (MODULE/PARYLENE_MASKING)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Initial Cold (MODULE/INITIAL_COLD)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

QC cross-check (module swapping) (MODULE/QC_CROSSCHECK)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	Registered	Registered
Analog Readback (ANALOG_READBACK)	Registered	Registered
Data Transmission (DATA_TRANSMISSION)	Registered	Registered
Injection Capacitance (INJECTION_CAPACITANCE)	Registered	Registered
Low Power Mode (LP_MODE)	Registered	Registered
Minimal Health Test (MIN_HEALTH_TEST)	Registered	Registered
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	Registered	Registered
SLDO (SLDO)	Registered	Registered
Tuning (TUNING)	Registered	Registered
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	Registered	Registered

Initial Warm (MODULE/INITIAL_WARM)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	Registered	Registered
Analog Readback (ANALOG_READBACK)	Registered	Registered
Data Transmission (DATA_TRANSMISSION)	Registered	Registered
Injection Capacitance (INJECTION_CAPACITANCE)	Registered	Registered
Low Power Mode (LP_MODE)	Registered	Registered
Minimal Health Test (MIN_HEALTH_TEST)	Registered	Registered
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	Registered	Registered
SLDO (SLDO)	Registered	Registered
Tuning (TUNING)	Registered	Registered
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	Registered	Registered

Wire Bonding (MODULE/WIREBONDING)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Bare module to module PCB assembly (MODULE/ASSEMBLY)

Initial state to associate flex to bare module (MODULE/INIT)

Reception at ITk institute (BAREMODULERECEPTION)

Test	Local Result	ProdDB Record
Analog Readback (ANALOG_READBACK)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A

Bare module assembly (BAREMODULEASSEMBLY)

Not to be used for detector (UNUSABLE)

Hybridisation (HYBRIDISATION)

Testing on wafer (TESTONWAFER)

Test	Local Result	ProdDB Record
Electrical FE chip tests (FECHIP_TEST)	Registered	Registered

LocalDB Test ID	Stage	Test Name	Inspector	Measurement Date	Analysis Date	Tags	QC Registration
69433e…206204	MODULE/POST_PARYLENE_WARM	PIXEL_FAILURE_ANALYSIS	None	N/A	a day ago	No tags
693a07…5f3660	MODULE/POST_PARYLENE_WARM	ADC_CALIBRATION	None	a week ago	a week ago	ganymede_4	Selected
6920d6…a9c4cf	MODULE/POST_PARYLENE_WARM	DATA_TRANSMISSION	None	3 weeks ago	3 weeks ago	ganymede_4
6920d5…0bad57	MODULE/POST_PARYLENE_WARM	LP_MODE	None	4 weeks ago	3 weeks ago	ganymede_4
6920c8…7f395d	MODULE/POST_PARYLENE_WARM	INJECTION_CAPACITANCE	None	4 weeks ago	4 weeks ago	ganymede_4
6920c6…a9c3e4	MODULE/POST_PARYLENE_WARM	VCAL_CALIBRATION	None	4 weeks ago	4 weeks ago	ganymede_4
6920c4…22bc7c	MODULE/POST_PARYLENE_WARM	SLDO	None	4 weeks ago	4 weeks ago	ganymede_4
6920bc…22bb9a	MODULE/POST_PARYLENE_WARM	ANALOG_READBACK	None	4 weeks ago	4 weeks ago	ganymede_4
6920a2…a57139	MODULE/POST_PARYLENE_WARM	ADC_CALIBRATION	None	4 weeks ago	4 weeks ago	ganymede_4
691e73…136f25	MODULE/POST_PARYLENE_WARM	PIXEL_FAILURE_ANALYSIS	None	N/A	4 weeks ago	No tags
690e82…2edf70	MODULE/POST_PARYLENE_WARM	DATA_TRANSMISSION	None	a month ago	a month ago	No tags
690e82…2edf54	MODULE/POST_PARYLENE_WARM	PIXEL_FAILURE_ANALYSIS	None	N/A	a month ago	No tags
690e82…2edeab	MODULE/POST_PARYLENE_WARM	TUNING	None	N/A	a month ago	No tags
690e82…2edde3	MODULE/POST_PARYLENE_WARM	MIN_HEALTH_TEST	None	N/A	a month ago	No tags
690e82…2edd7f	MODULE/POST_PARYLENE_WARM	INJECTION_CAPACITANCE	None	a month ago	a month ago	No tags
690e82…2edd4f	MODULE/POST_PARYLENE_WARM	LP_MODE	None	a month ago	a month ago	No tags
690e82…2edd13	MODULE/POST_PARYLENE_WARM	ANALOG_READBACK	None	a month ago	a month ago	No tags
690e82…2edc96	MODULE/POST_PARYLENE_WARM	VCAL_CALIBRATION	None	a month ago	a month ago	No tags
690e82…2edc5a	MODULE/POST_PARYLENE_WARM	SLDO	None	a month ago	a month ago	No tags
690e81…2edc2e	MODULE/POST_PARYLENE_WARM	ADC_CALIBRATION	None	a month ago	a month ago	No tags
690e80…69125c	MODULE/POST_PARYLENE_WARM	PIXEL_FAILURE_ANALYSIS	None	N/A	a month ago	No tags
690e80…2edb37	MODULE/POST_PARYLENE_WARM	TUNING	None	N/A	a month ago	No tags
690e7f…9b5f53	MODULE/POST_PARYLENE_WARM	MIN_HEALTH_TEST	None	N/A	a month ago	No tags
690ac4…f94a61	MODULE/POST_PARYLENE_WARM	DATA_TRANSMISSION	None	a month ago	a month ago	ganymede_4
690ac4…acedaf	MODULE/POST_PARYLENE_WARM	LP_MODE	None	a month ago	a month ago	ganymede_4
690ac3…f949f5	MODULE/POST_PARYLENE_WARM	INJECTION_CAPACITANCE	None	a month ago	a month ago	ganymede_4
690abd…993238	MODULE/POST_PARYLENE_WARM	VCAL_CALIBRATION	None	a month ago	a month ago	ganymede_4
690aba…acebc4	MODULE/POST_PARYLENE_WARM	SLDO	None	a month ago	a month ago	ganymede_4
690ab2…acead8	MODULE/POST_PARYLENE_WARM	ANALOG_READBACK	None	a month ago	a month ago	ganymede_4
690a98…f948c5	MODULE/POST_PARYLENE_WARM	ADC_CALIBRATION	None	a month ago	a month ago	ganymede_4
690a93…f94845	MODULE/POST_PARYLENE_WARM	ADC_CALIBRATION	None	a month ago	a month ago	ganymede_4
6902dc…f69aac	MODULE/POST_PARYLENE_WARM	DATA_TRANSMISSION	None	a month ago	a month ago	ganymede_4
6902dc…6daa13	MODULE/POST_PARYLENE_WARM	LP_MODE	None	a month ago	a month ago	ganymede_4
6902db…f699bf	MODULE/POST_PARYLENE_WARM	INJECTION_CAPACITANCE	None	a month ago	a month ago	ganymede_4
6902da…f698a6	MODULE/POST_PARYLENE_WARM	VCAL_CALIBRATION	None	a month ago	a month ago	ganymede_4
6902d7…f6984a	MODULE/POST_PARYLENE_WARM	SLDO	None	a month ago	a month ago	ganymede_4
6902cf…f6967d	MODULE/POST_PARYLENE_WARM	ANALOG_READBACK	None	a month ago	a month ago	ganymede_4
6902b4…6da8a3	MODULE/POST_PARYLENE_WARM	ADC_CALIBRATION	None	a month ago	a month ago	ganymede_4
6902a4…b313ec	MODULE/POST_PARYLENE_WARM	ADC_CALIBRATION	None	a month ago	a month ago	ganymede_4
690178…c4d45f	MODULE/POST_PARYLENE_WARM	DATA_TRANSMISSION	None	a month ago	a month ago	ganymede_4
690178…c4d427	MODULE/POST_PARYLENE_WARM	LP_MODE	None	a month ago	a month ago	ganymede_4
690177…c4d3ec	MODULE/POST_PARYLENE_WARM	INJECTION_CAPACITANCE	None	a month ago	a month ago	ganymede_4
690176…c4d32e	MODULE/POST_PARYLENE_WARM	VCAL_CALIBRATION	None	a month ago	a month ago	ganymede_4
690173…513aad	MODULE/POST_PARYLENE_WARM	SLDO	None	a month ago	a month ago	ganymede_4
69016c…c4d1a7	MODULE/POST_PARYLENE_WARM	ANALOG_READBACK	None	a month ago	a month ago	ganymede_4
690155…5a849b	MODULE/POST_PARYLENE_WARM	ADC_CALIBRATION	None	a month ago	a month ago	ganymede_4
68d573…87c472	MODULE/QC_CROSSCHECK	PIXEL_FAILURE_ANALYSIS	DanielAceves	N/A	3 months ago	No tags	Selected
68d572…87c3f2	MODULE/QC_CROSSCHECK	TUNING	DanielAceves	N/A	3 months ago	No tags	Selected
68d571…87c2e3	MODULE/QC_CROSSCHECK	MIN_HEALTH_TEST	DanielAceves	N/A	3 months ago	No tags	Selected
68d56a…87c1a5	MODULE/QC_CROSSCHECK	INJECTION_CAPACITANCE	DanielAceves	3 months ago	3 months ago	No tags	Selected
68d56a…87c179	MODULE/QC_CROSSCHECK	DATA_TRANSMISSION	DanielAceves	3 months ago	3 months ago	No tags	Selected
68d56a…87c1c9	MODULE/QC_CROSSCHECK	LP_MODE	DanielAceves	3 months ago	3 months ago	No tags	Selected
68d56a…87c151	MODULE/QC_CROSSCHECK	VCAL_CALIBRATION	DanielAceves	3 months ago	3 months ago	No tags	Selected
68d569…87c115	MODULE/QC_CROSSCHECK	SLDO	DanielAceves	3 months ago	3 months ago	No tags	Selected
68d569…87c0cd	MODULE/QC_CROSSCHECK	ANALOG_READBACK	DanielAceves	3 months ago	3 months ago	No tags	Selected
68d569…87c059	MODULE/QC_CROSSCHECK	ADC_CALIBRATION	DanielAceves	3 months ago	3 months ago	No tags	Selected
68c09c…33bbe9	MODULE/INITIAL_WARM	PIXEL_FAILURE_ANALYSIS	DanielAceves	N/A	3 months ago	No tags	Selected
68c09c…33bb7a	MODULE/INITIAL_WARM	TUNING	DanielAceves	N/A	3 months ago	No tags	Selected
68c09b…33ba98	MODULE/INITIAL_WARM	MIN_HEALTH_TEST	DanielAceves	N/A	3 months ago	No tags	Selected
68c09a…33b85c	MODULE/INITIAL_WARM	INJECTION_CAPACITANCE	DanielAceves	3 months ago	3 months ago	No tags	Selected
68c09a…33b82c	MODULE/INITIAL_WARM	DATA_TRANSMISSION	DanielAceves	3 months ago	3 months ago	No tags	Selected
68c09a…33b884	MODULE/INITIAL_WARM	LP_MODE	DanielAceves	3 months ago	3 months ago	No tags	Selected
68c09a…33b800	MODULE/INITIAL_WARM	VCAL_CALIBRATION	DanielAceves	3 months ago	3 months ago	No tags	Selected
68c09a…33b7c0	MODULE/INITIAL_WARM	SLDO	DanielAceves	3 months ago	3 months ago	No tags	Selected
68c09a…33b774	MODULE/INITIAL_WARM	ANALOG_READBACK	DanielAceves	3 months ago	3 months ago	No tags	Selected
68c09a…33b721	MODULE/INITIAL_WARM	ADC_CALIBRATION	DanielAceves	3 months ago	3 months ago	No tags	Selected
660dc9…45ba4d	TESTONWAFER	FECHIP_TEST	DimaManeuski	N/A	a year ago	No tags	Selected

Run	Date	Test Type	Stage	User	Site	Tags	Status
145	a week ago	std_analogscan	MODULE/POST_PARYLENE_WARM	pixqc	jittereel.dhcp.lbl.gov	MHT	Pass
144	a week ago	std_digitalscan	MODULE/POST_PARYLENE_WARM	pixqc	jittereel.dhcp.lbl.gov	MHT	Pass
127	3 weeks ago	std_analogscan	MODULE/POST_PARYLENE_WARM	pixqc	jittereel.dhcp.lbl.gov	MHT	Pass
124	3 weeks ago	std_digitalscan	MODULE/POST_PARYLENE_WARM	pixqc	jittereel.dhcp.lbl.gov	MHT	Pass
4441	a month ago	std_mergedbumpscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	PFA	Pass
4437	a month ago	std_discbumpscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	PFA	Pass
4433	a month ago	std_noisescan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	PFA	Pass
4429	a month ago	std_totscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	PFA	Pass
4425	a month ago	std_thresholdscan_hd	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	PFA	Pass
4421	a month ago	std_analogscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	PFA	Pass
4417	a month ago	std_digitalscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	PFA	Pass
4413	a month ago	std_totscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	TUN	Pass
4409	a month ago	std_thresholdscan_hd	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	TUN	Pass
4405	a month ago	std_tune_pixelthreshold	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	TUN	Pass
4401	a month ago	std_tune_globalthreshold	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	TUN	Pass
4397	a month ago	std_tune_globalpreamp	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	TUN	Pass
4393	a month ago	std_tune_globalthreshold	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	TUN	Pass
4389	a month ago	std_totscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	TUN	Pass
4385	a month ago	std_thresholdscan_hr	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	TUN	Pass
4381	a month ago	std_totscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	MHT	Pass
4377	a month ago	std_thresholdscan_hr	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	MHT	Pass
4373	a month ago	std_analogscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	MHT	Pass
4369	a month ago	std_digitalscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	MHT	Pass
4358	a month ago	std_analogscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	MHT	Pass
4354	a month ago	std_digitalscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	MHT	Pass
4314	a month ago	std_analogscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	MHT	Pass
4310	a month ago	std_digitalscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	MHT	Pass
4292	a month ago	std_totscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	MHT	Pass
4291	a month ago	std_thresholdscan_hr	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	MHT	Pass
4290	a month ago	std_analogscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	MHT	Pass
4288	a month ago	std_digitalscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	MHT	Pass
4125	a month ago	std_analogscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	MHT	Pass
4124	a month ago	std_digitalscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	MHT	Pass
4056	a month ago	std_analogscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	MHT	Pass
4055	a month ago	std_digitalscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	MHT	Pass

Stage: MODULE/POST_PARYLENE_WARM

Mode: warm

Index	Revision ID	Timestamp	Message
HEAD	693a...879241	a week ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^1	693a...a35611	a week ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^2	693a...5f3668	a week ago	config revision by ADC-CALIBRATION with RAW data 693a078a9a818808f85f3659 and analysis result 693a07909a818808f85f3660
HEAD^3	6920...0c21d0	3 weeks ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^4	6920...52b922	3 weeks ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^5	6920...a9c4d7	3 weeks ago	config revision by DATA-TRANSMISSION with RAW data 6920d5ff37aa05c57ea9c4c8 and analysis result 6920d60437aa05c57ea9c4cf
HEAD^6	6920...7f3965	4 weeks ago	config revision by INJECTION-CAPACITANCE with RAW data 6920c82e59eb6194df7f3952 and analysis result 6920c83459eb6194df7f395d
HEAD^7	6920...a9c3ec	4 weeks ago	config revision by VCAL-CALIBRATION with RAW data 6920c6e137aa05c57ea9c3a5 and analysis result 6920c6eb37aa05c57ea9c3e4
HEAD^8	6920...22bc84	4 weeks ago	config revision by SLDO with RAW data 6920c450debdf73f4322bc71 and analysis result 6920c464debdf73f4322bc7c
HEAD^9	6920...22bbc1	4 weeks ago	config revision by ANALOG-READBACK with RAW data 6920bc4ddebdf73f4322bb71 and analysis result 6920bc59debdf73f4322bb9a
HEAD^10	6920...a57141	4 weeks ago	config revision by ADC-CALIBRATION with RAW data 6920a255b3abf5df24a57132 and analysis result 6920a25eb3abf5df24a57139
HEAD^11	690d...a27229	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^12	690d...cc1256	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^13	690d...6f1987	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^14	690d...1df75f	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^15	690d...f9a6b4	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^16	690d...5bdffb	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^17	690d...1574ed	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^18	690d...e7513c	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^19	690d...9ee446	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^20	690d...6da033	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^21	690d...dbc3b0	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^22	690d...6f4808	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^23	690d...39a0cd	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^24	690c...861bee	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^25	690c...f84c15	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^26	690c...07d72e	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^27	690c...7534e9	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^28	690b...b8790e	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^29	690b...a9e762	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^30	690b...411d36	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^31	690b...95de66	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^32	690a...9416a2	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^33	690a...3f19dc	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^34	690a...12a598	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^35	690a...dd49a6	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^36	690a...f94a68	a month ago	config revision by DATA-TRANSMISSION with RAW data 690ac4b49e9eb4cb71f94a5a and analysis result 690ac4b89e9eb4cb71f94a61
HEAD^37	690a...f949fc	a month ago	config revision by INJECTION-CAPACITANCE with RAW data 690ac3939e9eb4cb71f949ea and analysis result 690ac3999e9eb4cb71f949f5
HEAD^38	690a...99323f	a month ago	config revision by VCAL-CALIBRATION with RAW data 690abd523d2fe659a4993229 and analysis result 690abd583d2fe659a4993238
HEAD^39	690a...acebcb	a month ago	config revision by SLDO with RAW data 690abad52ee93469f0acebb9 and analysis result 690abadb2ee93469f0acebc4
HEAD^40	690a...aceadf	a month ago	config revision by ANALOG-READBACK with RAW data 690ab2cb2ee93469f0acea8a and analysis result 690ab2d32ee93469f0acead8
HEAD^41	690a...f948cc	a month ago	config revision by ADC-CALIBRATION with RAW data 690a98149e9eb4cb71f948be and analysis result 690a981a9e9eb4cb71f948c5
HEAD^42	690a...f9484c	a month ago	config revision by ADC-CALIBRATION with RAW data 690a93cb9e9eb4cb71f9483e and analysis result 690a93d09e9eb4cb71f94845
HEAD^43	6902...5d4179	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^44	6902...470b57	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^45	6902...f69ab3	a month ago	config revision by DATA-TRANSMISSION with RAW data 6902dc5f1f6a7995c5f69aa5 and analysis result 6902dc641f6a7995c5f69aac
HEAD^46	6902...f699c6	a month ago	config revision by INJECTION-CAPACITANCE with RAW data 6902db291f6a7995c5f699b4 and analysis result 6902db2e1f6a7995c5f699bf
HEAD^47	6902...f698ad	a month ago	config revision by VCAL-CALIBRATION with RAW data 6902da0e1f6a7995c5f69897 and analysis result 6902da141f6a7995c5f698a6
HEAD^48	6902...f69851	a month ago	config revision by SLDO with RAW data 6902d77d1f6a7995c5f6983f and analysis result 6902d7831f6a7995c5f6984a
HEAD^49	6902...f69684	a month ago	config revision by ANALOG-READBACK with RAW data 6902cf6b1f6a7995c5f6965a and analysis result 6902cf731f6a7995c5f6967d
HEAD^50	6902...6da8aa	a month ago	config revision by ADC-CALIBRATION with RAW data 6902b41896387c76c66da89c and analysis result 6902b41d96387c76c66da8a3
HEAD^51	6902...b313f3	a month ago	config revision by ADC-CALIBRATION with RAW data 6902a422487f80dab6b313e5 and analysis result 6902a428487f80dab6b313ec
HEAD^52	6901...e29928	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^53	6901...a210dc	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^54	6901...c4d467	a month ago	config revision by DATA-TRANSMISSION with RAW data 6901786faa4113d5eec4d458 and analysis result 69017874aa4113d5eec4d45f
HEAD^55	6901...c4d3f4	a month ago	config revision by INJECTION-CAPACITANCE with RAW data 69017760aa4113d5eec4d3e1 and analysis result 69017765aa4113d5eec4d3ec
HEAD^56	6901...c4d336	a month ago	config revision by VCAL-CALIBRATION with RAW data 6901764aaa4113d5eec4d31f and analysis result 69017650aa4113d5eec4d32e
HEAD^57	6901...513ab5	a month ago	config revision by SLDO with RAW data 690173e286d87b18ae513aa2 and analysis result 690173e886d87b18ae513aad
HEAD^58	6901...c4d1af	a month ago	config revision by ANALOG-READBACK with RAW data 69016cc4aa4113d5eec4d184 and analysis result 69016cccaa4113d5eec4d1a7
HEAD^59	6901...5a84a3	a month ago	config revision by ADC-CALIBRATION with RAW data 69015585ac6cbf99785a8494 and analysis result 6901558bac6cbf99785a849b
HEAD^60	68da...6a2b0b	3 months ago	downloaded from ITkPD : code = cfac092e6cdce87093d4fd06f53c7e4c, description = {"_id":"689e40368428c598c032e347","serialNumber":"20UPGFC0142445","stage":"MODULE/INITIAL_WARM","branch":"warm","current_revision_id":"68c09b950a735050c64b7276"}

Mode: cold

Index	Revision ID	Timestamp	Message
HEAD	68da...6a2b0d	3 months ago	downloaded from ITkPD : code = cc16f7ab6186954bdfd0284196ed3490, description = {"_id":"689e40368428c598c032e34f","serialNumber":"20UPGFC0142445","stage":"MODULE/INITIAL_WARM","branch":"cold","current_revision_id":"68bf12f38428c598c03382a5"}

Mode: LP

Index	Revision ID	Timestamp	Message
HEAD	6920...0bad58	3 weeks ago	config revision by LP-MODE with RAW data 6920d5b0948273b4430bad47 and analysis result 6920d5b5948273b4430bad57
HEAD^1	690a...acedb0	a month ago	config revision by LP-MODE with RAW data 690ac4452ee93469f0aceda8 and analysis result 690ac4492ee93469f0acedaf
HEAD^2	6902...6daa14	a month ago	config revision by LP-MODE with RAW data 6902dc2396387c76c66daa0c and analysis result 6902dc2796387c76c66daa13
HEAD^3	6901...c4d428	a month ago	config revision by LP-MODE with RAW data 69017836aa4113d5eec4d420 and analysis result 6901783aaa4113d5eec4d427
HEAD^4	68da...6a2b0f	3 months ago	downloaded from ITkPD : code = d0b10adbdf7f3151e3e87c336953ed87, description = {"_id":"689e40368428c598c032e357","serialNumber":"20UPGFC0142445","stage":"MODULE/INITIAL_WARM","branch":"LP","current_revision_id":"68c09a6c8428c598c033b885"}

Stage	Tests
TESTONWAFER	Electrical FE chip tests (FECHIP_TEST)
HYBRIDISATION
UNUSABLE
BAREMODULEASSEMBLY
BAREMODULERECEPTION	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK)
MODULE/INIT
MODULE/ASSEMBLY
MODULE/WIREBONDING	ADC Calibration (ADC_CALIBRATION) Data Transmission (DATA_TRANSMISSION) VCAL Calibration (VCAL_CALIBRATION) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) SLDO (SLDO) Low Power Mode (LP_MODE) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/INITIAL_WARM	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Low Power Mode (LP_MODE) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) Data Transmission (DATA_TRANSMISSION) Injection Capacitance (INJECTION_CAPACITANCE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
MODULE/QC_CROSSCHECK	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Low Power Mode (LP_MODE) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) Data Transmission (DATA_TRANSMISSION) Injection Capacitance (INJECTION_CAPACITANCE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
MODULE/INITIAL_COLD	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Injection Capacitance (INJECTION_CAPACITANCE) Tuning (TUNING) Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Low Power Mode (LP_MODE) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) Data Transmission (DATA_TRANSMISSION)
MODULE/PARYLENE_MASKING	ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) SLDO (SLDO) Low Power Mode (LP_MODE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE) Data Transmission (DATA_TRANSMISSION)
MODULE/PARYLENE_COATING
MODULE/PARYLENE_UNMASKING	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Tuning (TUNING) Data Transmission (DATA_TRANSMISSION) ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) SLDO (SLDO) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE)
MODULE/WIREBOND_PROTECTION	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Tuning (TUNING) ADC Calibration (ADC_CALIBRATION) Low Power Mode (LP_MODE) VCAL Calibration (VCAL_CALIBRATION) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE) SLDO (SLDO) Data Transmission (DATA_TRANSMISSION)
MODULE/POST_PARYLENE_WARM	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Data Transmission (DATA_TRANSMISSION) Injection Capacitance (INJECTION_CAPACITANCE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Low Power Mode (LP_MODE)
MODULE/POST_PARYLENE_COLD	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) VCAL Calibration (VCAL_CALIBRATION) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) SLDO (SLDO) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/THERMAL_CYCLES	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Tuning (TUNING) Data Transmission (DATA_TRANSMISSION) SLDO (SLDO) ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE) Cold startup (COLD_STARTUP)
MODULE/LONG_TERM_STABILITY_TEST	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) SLDO (SLDO) Tuning (TUNING) ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/FINAL_WARM	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Undershunt Protection (UNDERSHUNT_PROTECTION) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Data Transmission (DATA_TRANSMISSION) Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Tuning (TUNING) Low Power Mode (LP_MODE) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/FINAL_COLD	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) Tuning (TUNING) Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Data Transmission (DATA_TRANSMISSION) Cold startup (COLD_STARTUP)
MODULE/FINAL_METROLOGY	Data Transmission (DATA_TRANSMISSION) ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) SLDO (SLDO) Injection Capacitance (INJECTION_CAPACITANCE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Injection Capacitance (INJECTION_CAPACITANCE) Analog Readback (ANALOG_READBACK)
MODULE/QC_STATUS
MODULE/UNHAPPY	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) Data Transmission (DATA_TRANSMISSION) VCAL Calibration (VCAL_CALIBRATION) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/NOTCONSIDEREDINYIELDS	ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) SLDO (SLDO) Undershunt Protection (UNDERSHUNT_PROTECTION) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Analog Readback (ANALOG_READBACK) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Low Power Mode (LP_MODE) Injection Capacitance (INJECTION_CAPACITANCE) Data Transmission (DATA_TRANSMISSION)
MODULE/GRAVEYARD
MODULE/COMPLETE
MODULE/RECEPTION	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Data Transmission (DATA_TRANSMISSION) Tuning (TUNING)
MODULE/TAB_CUTTING	Minimal Health Test (MIN_HEALTH_TEST)
LLS/PRE_TC_WARM	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Low Power Mode (LP_MODE) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
LLS/PRE_TC_COLD	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
LLS/POST_TC_WARM	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
LLS/POST_TC_COLD	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
LLS/RECEPTION	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
OB_LOADED_MODULE_CELL/INIT
OB_LOADED_MODULE_CELL/ASSEMBLY
OB_LOADED_MODULE_CELL/THERMAL_CYCLES
OB_LOADED_MODULE_CELL/FINAL_WARM	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
OB_LOADED_MODULE_CELL/FINAL_COLD	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
OB_LOADED_MODULE_CELL/THERMAL_COLD
OB_LOADED_MODULE_CELL/THERMAL_WARM
OB_LOADED_MODULE_CELL/ENVELOPE_CHECK
OB_LOADED_MODULE_CELL/QC_STATUS
OB_LOADED_MODULE_CELL/UNHAPPY
OB_LOADED_MODULE_CELL/COMPLETE
OB_LOADED_MODULE_CELL/RECEPTION	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) SLDO (SLDO)
OB_LOADED_MODULE_CELL/TAB_CUTTING	Minimal Health Test (MIN_HEALTH_TEST)
OB_LOADED_MODULE_CELL/PIGTAIL_INSERTION
TEST_AFTER_LOADED_LOCAL_SUPPORT_ASSEMBLY	OB:Loaded local support QC electrical connectivity (OBLoadedLocalSupportQC_ElectricalConnectivity) OB:Loaded local support QC electrical performance (OBLoadedLocalSupportQC_ElectricalPerformance) OB:Loaded local support reception at the integration site (OBLoadedLocalSupport_IntegrationSite) OB:Loaded local support QC electrical low power (OBLoadedLocalSupport_QCElectricalLowPower)
TEST_JM_OEC_FE

20UPGFC0142445

MODULE/POST_PARYLENE_WARM

Component Information

Wafer

Properties

Comments

Test: ANALOG_READBACK QC Passed

(Stage: MODULE/POST_PARYLENE_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Results

Attachments

RAW Results Record

ProductionDB Record

Current Stage: Post-Parylene Warm

Candidate TestRuns of this Stage

Past QC Stages and Results

Wirebond Protection (alt) (MODULE/WIREBOND_PROTECTION)

Parylene Unmasking (MODULE/PARYLENE_UNMASKING)

Parylene Coating (MODULE/PARYLENE_COATING)

Parylene Masking (MODULE/PARYLENE_MASKING)

Initial Cold (MODULE/INITIAL_COLD)

QC cross-check (module swapping) (MODULE/QC_CROSSCHECK)

Initial Warm (MODULE/INITIAL_WARM)

Wire Bonding (MODULE/WIREBONDING)

Bare module to module PCB assembly (MODULE/ASSEMBLY)

Initial state to associate flex to bare module (MODULE/INIT)

Reception at ITk institute (BAREMODULERECEPTION)

Bare module assembly (BAREMODULEASSEMBLY)

Not to be used for detector (UNUSABLE)

Hybridisation (HYBRIDISATION)

Testing on wafer (TESTONWAFER)

All Registered QC Tests

All YARR Scans

Config Revisions

Stage: MODULE/POST_PARYLENE_WARM

Mode: warm

Mode: cold

Mode: LP

Check QC Flow

Back to top page of this component
