20UPGFC0142426

MODULE/POST_PARYLENE_WARM

Component Information

Serial Number	20UPGFC0142426
ProdDB ID	aa84b0…c4845d
LocalDB ID	660dc829ec873d003545b081
Component Type	fe_chip
Parents	20UPGM23211141 20UPGB43200202
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Wafer serial number	None
Target Iref trim	None
Target Iref trim version	None

Comments

Test: ANALOG_READBACK QC Passed

(Stage: MODULE/POST_PARYLENE_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	a month ago
component ObjectId	660dc829ec873d003545b081
Stage	MODULE/POST_PARYLENE_WARM
Test Type	ANALOG_READBACK
Institute ObjectId
User Name	None
ObjectId of this record	69016cbaaa4113d5eec4d14e
ObjectId of RAW record	69016cb1aa4113d5eec4d12b
Tags	ganymede_4

Results

Key	Data
DCSdata	{}
MEASUREMENT_VERSION	2.7.0rc1.dev3
QC_LAYER	L2
INSTITUTION	LBNL_PIXEL_MODULES
AR_TEMP_NTC	19.186
AR_TEMP_EXT	20.004
AR_TEMP_ASLDO	28.918
AR_TEMP_DSLDO	30.718
AR_TEMP_ACB	28.349
AR_TEMP_NF_ASLDO	1.259
AR_TEMP_NF_DSLDO	1.258
AR_TEMP_NF_ACB	1.258
AR_TEMP_POLY_TOP	-999
AR_TEMP_POLY_BOTTOM	-999
AR_TEMP_NF_TOP	-999
AR_TEMP_NF_BOTTOM	-999
AR_IREF	3.9e-06
AR_GADC	0.833
AR_VCALDAC	0.834
AR_VREFCORE	0.465
AR_VREFOVP	2.021
AR_NOMINAL_SETTINGS	[3.9e-06, 9.04e-05, 5.05e-05, 4.3e-06, 4e-05, 1.98e-05, 0.0, 4.07e-05, 7.34e-05, -999, 0.0, 0.0, 4.68e-05, 6.47e-05, 5.17e-05, 8.79e-05, 6.49e-05, 7.42e-05, 8.69e-05, 8.79e-05, 6.66e-05, 4.72e-05, 4.75e-05, 6.5e-05, 4.71e-05, 4.74e-05, -999, -999, 0.6274557, 0.0432982, 0.9102747, 0.2984603, 0.8325074, -999, -999, 0.8338688, 1.2217728, 0.1185654, 0.1135844, 0.0367351, 0.0386581, 0.0411659, 0.2467064, 0.2453884, 0.2526724, 0.6287824, -999, 0.6274664, -999, 0.5939254, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, 0.0174426, 0.4654074, 2.0212248, 1.5074896, 1.2277768, 0.6066384, 0.9929296, 1.5140256, 1.2138808, 0.5971714]
AR_VDDA_VS_TRIM	[1.037, 1.062, 1.085, 1.11, 1.135, 1.16, 1.181, 1.208, 1.228, 1.254, 1.276, 1.301, 1.324, 1.351, 1.374, 1.4]
AR_VDDD_VS_TRIM	[1.023, 1.047, 1.072, 1.096, 1.122, 1.147, 1.17, 1.195, 1.216, 1.239, 1.264, 1.289, 1.314, 1.339, 1.364, 1.389]
AR_VDDA_TRIM	7
AR_VDDD_TRIM	7
AR_ROSC_SLOPE	[751.5443736899495, 1143.1801165030338, 740.4721974339794, 1151.6775392235097, 821.7612919682815, 1379.7019760658325, 960.3666719095587, 1415.1312042007316, 1167.1223069862585, 1168.7792185042379, 1350.7456966587647, 1354.1363178532888, 1192.9353977789278, 1189.4975292528134, 1362.2212905253598, 1361.4764036511424, 1375.1240882572124, 1386.2139705993532, 1606.9037192592937, 1596.8181130880157, 1346.257725083556, 1341.1735744283715, 1659.5665485929867, 1669.4163143211654, 838.3405611769715, 846.4501376856683, 1016.6825994735283, 1014.4091568736095, 1008.8832022091093, 1007.1392135092582, 1133.8377172259113, 1193.0999864188818, 1137.506378402553, 1190.115674986811, 1552.0729516857398, 1547.674177999139, 1553.7044212153983, 1555.2590509391543, 1553.1298506101327, 1550.1670835910797, 1549.8544201384977, 1553.1277053244585]
AR_ROSC_OFFSET	[-428.5704642041456, -642.2067948178448, -437.02405464106727, -662.2454070381734, -536.7141151595358, -905.3559842262367, -659.1642065947863, -955.0207773919655, -688.7834166829664, -693.0640340694227, -789.4107508117481, -790.0394331425933, -725.0568481842682, -719.3629638844886, -815.8597527652369, -816.1123655683901, -908.3006073283102, -921.2224848209388, -1070.1633858729426, -1068.0926261298798, -926.8008840090123, -931.51425749614, -1127.4185123488978, -1134.6443648449688, -530.1198411981426, -535.3615683039079, -645.5473429173411, -647.5987460023166, -629.1960686052624, -632.6105508184702, -537.7830847224018, -544.2259309543105, -600.1927291562216, -636.7373897158584, -1033.8524000167047, -1027.0090524157958, -1031.1153496113575, -1035.6481764463451, -1027.9982617728426, -1025.9555651860007, -1025.2626179257604, -1031.3624258438815]
AR_ROSC_MAX_RESIDUAL	[3.0515632935150236, 4.933469429376905, 2.7263448108162516, 4.789325633892985, 1.9634362570828128, 3.1432744893135114, 1.865911688182631, 3.2791177444787833, 4.290493830887272, 4.361678831027742, 5.086486896239354, 5.133339260203031, 4.008157278416219, 4.08821139565797, 4.801305668980439, 4.808474479911731, 2.8235540780036463, 2.8709461915547076, 3.1381694237417306, 2.9135580983605815, 2.490699285307932, 2.232129332821992, 3.381935604497069, 3.30320430636989, 2.1819367834148657, 2.2420938629526797, 2.5269037473427693, 2.5451987420258, 2.787559107358388, 2.786959363167029, 5.339193383945505, 5.942735775844156, 4.368998130667325, 4.442109574261718, 3.033614507530612, 2.8750323148509414, 3.0542007850173083, 3.0304244292343534, 3.0668940332824235, 3.117957415772393, 3.093998567610252, 3.047369147098969]
AR_VDDD_SATURATION	-1.0
AR_VDDA_SATURATION	-1.0
AR_IREF_TRIM	8
ANALYSIS_VERSION	mqat v2.7.0rc3
YARR_VERSION	v1.5.5
MEASUREMENT_DATE	2025-10-28T23:45:35.000+00:00
MEASUREMENT_DURATION	722

Attachments

Filename	Contents
output.log	Download
0x22c5a.log	Download

RAW Results Record

Download RAW

_id

69016cb1aa4113d5eec4d12b

raw

serialNumber

testType

runNumber

results

subtestType

stage

component

dbVersion

address

sys

20UPGFC0142426

ANALOG_READBACK

69016caed580dc54bc3220c0

DCSdata

SensorVoltage	-79.99
SensorCurrent	-3.40545e-05
ModuleNTC	19.9113

Measurements

Vmux0

X	False
Unit	V
Values	0.84995

Vmux3

X	False
Unit	V
Values	0.434377

Vmux4

X	False
Unit	V
Values	0.628329

Vmux5

X	False
Unit	V
Values	0.136008

Vmux6

X	False
Unit	V
Values	0.131027

Vmux7

X	False
Unit	V
Values	0.0541777

Vmux8

X	False
Unit	V
Values	0.0561007

Vmux9

X	False
Unit	V
Values	0.0586085

Vmux10

X	False
Unit	V
Values	0.264149

Vmux11

X	False
Unit	V
Values	0.262831

Vmux12

X	False
Unit	V
Values	0.270115

Vmux13

X	False
Unit	V
Values	0.646225

Vmux15

X	False
Unit	V
Values	0.644909

Vmux17

X	False
Unit	V
Values	0.611368

Vmux31

X	False
Unit	V
Values	0.48285

Vmux32

X	False
Unit	V
Values	0.624417

Vmux33

X	False
Unit	V
Values	0.394315

Vmux34

X	False
Unit	V
Values	0.631331

Vmux35

X	False
Unit	V
Values	0.624081

Vmux36

X	False
Unit	V
Values	0.265675

Vmux37

X	False
Unit	V
Values	0.395949

Vmux38

X	False
Unit	V
Values	0.624383

Vmux39

X	False
Unit	V
Values	0.614614

Vmux63

X	False
Unit	V
Values	0.158653

Vmux30

X	False
Unit	V
Values	0.0174426

Imux0

X	False
Unit	V
Values	0.054119

Imux1

X	False
Unit	V
Values	0.918518

Imux2

X	False
Unit	V
Values	0.519839

Imux3

X	False
Unit	V
Values	0.0577511

Imux4

X	False
Unit	V
Values	0.415098

Imux5

X	False
Unit	V
Values	0.213224

Imux6

X	False
Unit	V
Values	0.0150172

Imux7

X	False
Unit	V
Values	0.422169

Imux8

X	False
Unit	V
Values	0.748519

Imux10

X	False
Unit	V
Values	0.0150218

Imux11

X	False
Unit	V
Values	0.0150191

Imux12

X	False
Unit	V
Values	0.482725

Imux13

X	False
Unit	V
Values	0.66167

Imux14

X	False
Unit	V
Values	0.531867

Imux15

X	False
Unit	V
Values	0.894073

Imux16

X	False
Unit	V
Values	0.664366

Imux17

X	False
Unit	V
Values	0.757043

Imux18

X	False
Unit	V
Values	0.884312

Imux19

X	False
Unit	V
Values	0.494591

Imux20

X	False
Unit	V
Values	0.681181

Imux21

X	False
Unit	V
Values	0.486977

Imux22

X	False
Unit	V
Values	0.489731

Imux23

X	False
Unit	V
Values	0.664689

Imux24

X	False
Unit	V
Values	0.485778

Imux25

X	False
Unit	V
Values	0.489051

Imux28

X	False
Unit	V
Values	0.314097

Imux29

X	False
Unit	V
Values	0.0350672

Imux30

X	False
Unit	V
Values	0.434709

Imux31

X	False
Unit	V
Values	0.148792

Imux63

X	False
Unit	V
Values	0.0150013

Metadata

FirmwareVersion

FirmwareIdentifier

ChannelConfig

SoftwareVersion

ChipConfigs

ITKPIXV2

GlobalConfig

AiRegionRow	0
AuroraActiveLanes	1
AuroraAltOutput0	0
AuroraAltOutput1	0
AuroraCBSend	0
AuroraCBWait0	4095
AuroraCBWait1	0
AuroraCCSend	3
AuroraCCWait	25
AuroraEnPrbs	0
AuroraInitWait	32
AuroraSendAlt	0
AutoRead0	134
AutoRead1	135
AutoRead2	137
AutoRead3	138
AutoRead4	140
AutoRead5	151
AutoRead6	152
AutoRead7	156
BcidCnt	0
BitFlipErrCnt	0
BitFlipWngCnt	0
CapMeasEn	0
CapMeasEnPar	0
CdrClkSel	0
CdrCp	40
CdrCpBuff	200
CdrCpFd	400
CdrPhaseDetSel	0
CdrVco	1023
CdrVcoBuff	500
ChSyncLockThr	31
ChipIdSense	0
Clk160En	7
Clk40En	7
ClkAuroraEn	7
ClkDataMergeEn	7
CmdErrCnt	0
CmlBias0	800
CmlBias1	400
CmlBias2	0
DataDecodingValues	0
DataEnBcid	0
DataEnBinaryRo	0
DataEnCrc	0
DataEnL1id	0
DataEnRaw	0
DataMaxHits	0
DataMaxTot	0
DataMergeEn	0
DataMergeEnBond	0
DataMergeEnClkGate	0
DataMergeFixedMode	0
DataMergeGpoSel	0
DataMergeInMux0	0
DataMergeInMux1	1
DataMergeInMux2	2
DataMergeInMux3	3
DataMergeInPol	0
DataMergeManChoice	0
DataMergeManMode	0
DataMergeOutMux0	2
DataMergeOutMux1	3
DataMergeOutMux2	0
DataMergeOutMux3	1
DataMergeSelClk	0
DataReadDelay	0
DiffComp	500
DiffFbCapEn	0
DiffLcc	200
DiffLccEn	1
DiffPreComp	350
DiffPreampL	550
DiffPreampM	550
DiffPreampR	550
DiffPreampT	550
DiffPreampTL	550
DiffPreampTR	550
DiffTh1L	350
DiffTh1M	350
DiffTh1R	350
DiffTh2	50
DiffVff	60
EfuseConfig	3855
EfuseReadData0	23041
EfuseReadData1	8748
EfuseWriteData0	0
EfuseWriteData1	0
EnChipId	0
EnCoreCol0	65535
EnCoreCol1	65535
EnCoreCol2	65535
EnCoreCol3	63
EnCoreColCal0	0
EnCoreColCal1	0
EnCoreColCal2	0
EnCoreColCal3	0
EnHitsRemoval0	0
EnHitsRemoval1	0
EnHitsRemoval2	0
EnHitsRemoval3	0
EnIsoHitsRemoval0	0
EnIsoHitsRemoval1	0
EnIsoHitsRemoval2	0
EnIsoHitsRemoval3	0
ErrWngMask	0
EvenMask	0
FineDelayClk	0
FineDelayData	0
GatedHitOrCnt0	0
GatedHitOrCnt1	0
GcrDefaultConfig	44149
GcrDefaultConfigB	21386
GlobalConfigSeuCnt	0
GlobalPulseConf	0
GlobalPulseWidth	10
GpCmosDs	0
GpCmosEn	1
GpCmosRoute	34
GpLvdsBias	7
GpLvdsEn	15
GpLvdsPad0	0
GpLvdsPad1	1
GpLvdsPad2	33
GpLvdsPad3	35
GpValReg	5
HitOrCnt0	0
HitOrCnt1	0
HitOrCnt2	0
HitOrCnt3	0
HitOrMask0	0
HitOrMask1	0
HitOrMask2	0
HitOrMask3	0
InjAnaMode	0
InjDigEn	0
InjFineDelay	5
InjVcalHigh	200
InjVcalMed	200
InjVcalRange	1
IrefTrimSense	0
Latency	500
LinComp	110
LinCompTa	110
LinFc	20
LinGdacL	408
LinGdacM	408
LinGdacR	408
LinKrumCurr	50
LinLdac	100
LinPreampL	300
LinPreampM	300
LinPreampR	300
LinPreampT	300
LinPreampTL	300
LinPreampTR	300
LinRefKrum	300
LockLossCnt	0
MonAdcTrim	0
MonSensAcbDem	0
MonSensAcbEn	0
MonSensAcbSelBias	0
MonSensSldoAnaDem	0
MonSensSldoAnaEn	0
MonSensSldoAnaSelBias	0
MonSensSldoDigDem	0
MonSensSldoDigEn	0
MonSensSldoDigSelBias	0
MonitorEnable	1
MonitorI	63
MonitorV	32
MonitoringDataAdc	0
NtcDac	100
NumOfEventsInStream	0
OddMask	0
PixAutoRow	1
PixBroadcast	0
PixConfMode	1
PixDefaultConfig	40162
PixDefaultConfigB	25373
PixEnSeuCount	0
PixHitSampleMode	0
PixPortal	1285
PixRegionCol	199
PixRegionRow	0
PixelSeuCntCnt	0
PtotCoreColEn0	0
PtotCoreColEn1	0
PtotCoreColEn2	0
PtotCoreColEn3	0
RdWrFifoErrCnt	0
ReadTrigCnt	0
ReadTrigLatency	0
RingOscAClear	0
RingOscAEn	0
RingOscAOut	0
RingOscARoute	0
RingOscBClear	0
RingOscBEnBl	0
RingOscBEnBr	0
RingOscBEnCapA	0
RingOscBEnFf	0
RingOscBEnLvt	0
RingOscBOut	0
RingOscBRoute	0
RstCoreCol0	0
RstCoreCol1	0
RstCoreCol2	0
RstCoreCol3	0
SelfTrigDeadtime	64
SelfTrigDelay	512
SelfTrigDigThr	1
SelfTrigDigThrEn	0
SelfTrigEn	0
SelfTrigMulti	4
SelfTrigPattern	65534
SerEnLane	15
SerEnTap	1
SerInvTap	1
SerSelOut0	3
SerSelOut1	3
SerSelOut2	1
SerSelOut3	3
ServiceBlockEn	1
ServiceBlockPeriod	50
SkippedTrigCnt	0
SldoEnUndershuntA	0
SldoEnUndershuntD	0
SldoTrimA	8
SldoTrimD	8
TotEn6b4b	0
TotEn80	0
TotEnPtoa	0
TotEnPtot	0
TotPtotLatency	500
TrigCnt	0
TruncTimeoutConf	0
TwoLevelTrig	0
VrefIn	1
VrefRsensBot	0
VrefRsensTop	0

Parameter

ADCcalPar	9.0 0.192 10000.0
ChipId	12
EnforceNameIdCheck	True
InjCap	7.457
IrefTrim	7
KSenseInA	20978.426
KSenseInD	21688.3
KSenseShuntA	21578.0
KSenseShuntD	22308.0
KShuntA	983.924
KShuntD	984.174
Name	0x22c5a
NfACB	1.2575891
NfASLDO	1.2590461
NfDSLDO	1.2582034
NtcCalPar	0.0007489 0.0002769 7.0595e-08
VcalPar	15.692 0.201

SoftwareType

ChipID

Name

0x22c5a

Institution

LBNL_PIXEL_MODULES

ModuleSN

20UPGM23211141

TimeStart

1761695135

TimeEnd

1761695857

useCalibAdc

False

comment

property

YARR_VERSION	v1.5.5
ANALOG_READBACK_MEASUREMENT_VERSION	2.7.0rc1.dev3

AR_VMEAS

MODULE/POST_PARYLENE_WARM

660dc829ec873d003545b081

1.01

64657cef8d79bac1f3f005c0

mts	2025-10-29 01:24:00.889000
cts	2025-10-29 01:24:00.889000
rev	0

20UPGFC0142426

ANALOG_READBACK

69016caed580dc54bc3220c1

DCSdata

SensorVoltage	-79.99
SensorCurrent	-3.18705e-05
ModuleNTC	19.9991

Measurements

Vmux2

X	False
Unit	V
Values	0.148141 0.148141 0.148141 0.148141 0.148141 0.148141 0.148141 0.148141 0.148141 0.148141 0.148141 0.148141 0.148141 0.148141 0.148141 0.148141 0.148141 0.148141 0.148141 0.148141 0.148141 0.148141 0.148141 0.148141 0.148141 0.148141 0.148141 0.148141 0.148141 0.148141 0.148141 0.148141

Vmux30

X	False
Unit	V
Values	0.0174391 0.0174391 0.0174391 0.0174391 0.0174391 0.0174391 0.0174391 0.0174391 0.0174391 0.0174391 0.0174391 0.0174391 0.0174391 0.0174391 0.0174391 0.0174391 0.0174391 0.0174391 0.0174391 0.0174391 0.0174391 0.0174391 0.0174391 0.0174391 0.0174391 0.0174391 0.0174391 0.0174391 0.0174391 0.0174391 0.0174391 0.0174391

Imux9

X	False
Unit	V
Values	0.119409 0.119409 0.119409 0.119409 0.119409 0.119409 0.119409 0.119409 0.119409 0.119409 0.119409 0.119409 0.119409 0.119409 0.119409 0.119409 0.119409 0.119409 0.119409 0.119409 0.119409 0.119409 0.119409 0.119409 0.119409 0.119409 0.119409 0.119409 0.119409 0.119409 0.119409 0.119409

Imux63

X	False
Unit	V
Values	0.0149963 0.0149963 0.0149963 0.0149963 0.0149963 0.0149963 0.0149963 0.0149963 0.0149963 0.0149963 0.0149963 0.0149963 0.0149963 0.0149963 0.0149963 0.0149963 0.0149963 0.0149963 0.0149963 0.0149963 0.0149963 0.0149963 0.0149963 0.0149963 0.0149963 0.0149963 0.0149963 0.0149963 0.0149963 0.0149963 0.0149963 0.0149963

Vmux14

X	False
Unit	V
Values	0.231435 0.2303 0.230635 0.230947 0.231991 0.23117 0.231088 0.231262 0.231258 0.230737 0.231218 0.230364 0.232247 0.231391 0.231738 0.23121 0.319951 0.320014 0.320019 0.32001 0.31992 0.319965 0.319951 0.319945 0.31991 0.319972 0.319921 0.319972 0.319871 0.319951 0.319903 0.319896

Vmux16

X	False
Unit	V
Values	0.22916 0.23019 0.227968 0.229335 0.230409 0.229818 0.229171 0.229574 0.229482 0.230234 0.22943 0.228386 0.230055 0.228318 0.229082 0.22999 0.318691 0.318569 0.318738 0.318644 0.318562 0.318604 0.318674 0.318633 0.318649 0.318582 0.318633 0.318701 0.318582 0.318695 0.318704 0.318629

Vmux18

X	False
Unit	V
Values	0.238187 0.237634 0.237432 0.236839 0.237575 0.237961 0.237201 0.237751 0.238026 0.236611 0.236889 0.239074 0.23722 0.236859 0.237376 0.237943 0.325968 0.325964 0.325969 0.326079 0.326026 0.326009 0.32604 0.32601 0.325987 0.326121 0.326094 0.325972 0.32608 0.326101 0.326038 0.325984

MonSensSldoAnaSelBias

X	False
Unit	-
Values	0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

MonSensSldoDigSelBias

X	False
Unit	-
Values	0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

MonSensAcbSelBias

X	False
Unit	-
Values	0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1 1

MonSensSldoAnaDem

X	False
Unit	-
Values	0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

MonSensSldoDigDem

X	False
Unit	-
Values	0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

MonSensAcbDem

X	False
Unit	-
Values	0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

TExtExtNTC

X	False
Unit	C
Values	20.0043 20.0043 20.0043 20.0043 20.0043 20.0043 20.0043 20.0043 20.0043 20.0043 20.0043 20.0043 20.0043 20.0043 20.0043 20.0043 20.0043 20.0043 20.0043 20.0043 20.0043 20.0043 20.0043 20.0043 20.0043 20.0043 20.0043 20.0043 20.0043 20.0043 20.0043 20.0043

Metadata

FirmwareVersion

FirmwareIdentifier

ChannelConfig

SoftwareVersion

ChipConfigs

ITKPIXV2

GlobalConfig

AiRegionRow	0
AuroraActiveLanes	1
AuroraAltOutput0	0
AuroraAltOutput1	0
AuroraCBSend	0
AuroraCBWait0	4095
AuroraCBWait1	0
AuroraCCSend	3
AuroraCCWait	25
AuroraEnPrbs	0
AuroraInitWait	32
AuroraSendAlt	0
AutoRead0	134
AutoRead1	135
AutoRead2	137
AutoRead3	138
AutoRead4	140
AutoRead5	151
AutoRead6	152
AutoRead7	156
BcidCnt	0
BitFlipErrCnt	0
BitFlipWngCnt	0
CapMeasEn	0
CapMeasEnPar	0
CdrClkSel	0
CdrCp	40
CdrCpBuff	200
CdrCpFd	400
CdrPhaseDetSel	0
CdrVco	1023
CdrVcoBuff	500
ChSyncLockThr	31
ChipIdSense	0
Clk160En	7
Clk40En	7
ClkAuroraEn	7
ClkDataMergeEn	7
CmdErrCnt	0
CmlBias0	800
CmlBias1	400
CmlBias2	0
DataDecodingValues	0
DataEnBcid	0
DataEnBinaryRo	0
DataEnCrc	0
DataEnL1id	0
DataEnRaw	0
DataMaxHits	0
DataMaxTot	0
DataMergeEn	0
DataMergeEnBond	0
DataMergeEnClkGate	0
DataMergeFixedMode	0
DataMergeGpoSel	0
DataMergeInMux0	0
DataMergeInMux1	1
DataMergeInMux2	2
DataMergeInMux3	3
DataMergeInPol	0
DataMergeManChoice	0
DataMergeManMode	0
DataMergeOutMux0	2
DataMergeOutMux1	3
DataMergeOutMux2	0
DataMergeOutMux3	1
DataMergeSelClk	0
DataReadDelay	0
DiffComp	500
DiffFbCapEn	0
DiffLcc	200
DiffLccEn	1
DiffPreComp	350
DiffPreampL	550
DiffPreampM	550
DiffPreampR	550
DiffPreampT	550
DiffPreampTL	550
DiffPreampTR	550
DiffTh1L	350
DiffTh1M	350
DiffTh1R	350
DiffTh2	50
DiffVff	60
EfuseConfig	3855
EfuseReadData0	23041
EfuseReadData1	8748
EfuseWriteData0	0
EfuseWriteData1	0
EnChipId	0
EnCoreCol0	65535
EnCoreCol1	65535
EnCoreCol2	65535
EnCoreCol3	63
EnCoreColCal0	0
EnCoreColCal1	0
EnCoreColCal2	0
EnCoreColCal3	0
EnHitsRemoval0	0
EnHitsRemoval1	0
EnHitsRemoval2	0
EnHitsRemoval3	0
EnIsoHitsRemoval0	0
EnIsoHitsRemoval1	0
EnIsoHitsRemoval2	0
EnIsoHitsRemoval3	0
ErrWngMask	0
EvenMask	0
FineDelayClk	0
FineDelayData	0
GatedHitOrCnt0	0
GatedHitOrCnt1	0
GcrDefaultConfig	44149
GcrDefaultConfigB	21386
GlobalConfigSeuCnt	0
GlobalPulseConf	0
GlobalPulseWidth	10
GpCmosDs	0
GpCmosEn	1
GpCmosRoute	34
GpLvdsBias	7
GpLvdsEn	15
GpLvdsPad0	0
GpLvdsPad1	1
GpLvdsPad2	33
GpLvdsPad3	35
GpValReg	5
HitOrCnt0	0
HitOrCnt1	0
HitOrCnt2	0
HitOrCnt3	0
HitOrMask0	0
HitOrMask1	0
HitOrMask2	0
HitOrMask3	0
InjAnaMode	0
InjDigEn	0
InjFineDelay	5
InjVcalHigh	200
InjVcalMed	200
InjVcalRange	1
IrefTrimSense	0
Latency	500
LinComp	110
LinCompTa	110
LinFc	20
LinGdacL	408
LinGdacM	408
LinGdacR	408
LinKrumCurr	50
LinLdac	100
LinPreampL	300
LinPreampM	300
LinPreampR	300
LinPreampT	300
LinPreampTL	300
LinPreampTR	300
LinRefKrum	300
LockLossCnt	0
MonAdcTrim	0
MonSensAcbDem	0
MonSensAcbEn	0
MonSensAcbSelBias	0
MonSensSldoAnaDem	0
MonSensSldoAnaEn	0
MonSensSldoAnaSelBias	0
MonSensSldoDigDem	0
MonSensSldoDigEn	0
MonSensSldoDigSelBias	0
MonitorEnable	1
MonitorI	63
MonitorV	32
MonitoringDataAdc	0
NtcDac	100
NumOfEventsInStream	0
OddMask	0
PixAutoRow	1
PixBroadcast	0
PixConfMode	1
PixDefaultConfig	40162
PixDefaultConfigB	25373
PixEnSeuCount	0
PixHitSampleMode	0
PixPortal	1285
PixRegionCol	199
PixRegionRow	0
PixelSeuCntCnt	0
PtotCoreColEn0	0
PtotCoreColEn1	0
PtotCoreColEn2	0
PtotCoreColEn3	0
RdWrFifoErrCnt	0
ReadTrigCnt	0
ReadTrigLatency	0
RingOscAClear	0
RingOscAEn	0
RingOscAOut	0
RingOscARoute	0
RingOscBClear	0
RingOscBEnBl	0
RingOscBEnBr	0
RingOscBEnCapA	0
RingOscBEnFf	0
RingOscBEnLvt	0
RingOscBOut	0
RingOscBRoute	0
RstCoreCol0	0
RstCoreCol1	0
RstCoreCol2	0
RstCoreCol3	0
SelfTrigDeadtime	64
SelfTrigDelay	512
SelfTrigDigThr	1
SelfTrigDigThrEn	0
SelfTrigEn	0
SelfTrigMulti	4
SelfTrigPattern	65534
SerEnLane	15
SerEnTap	1
SerInvTap	1
SerSelOut0	3
SerSelOut1	3
SerSelOut2	1
SerSelOut3	3
ServiceBlockEn	1
ServiceBlockPeriod	50
SkippedTrigCnt	0
SldoEnUndershuntA	0
SldoEnUndershuntD	0
SldoTrimA	8
SldoTrimD	8
TotEn6b4b	0
TotEn80	0
TotEnPtoa	0
TotEnPtot	0
TotPtotLatency	500
TrigCnt	0
TruncTimeoutConf	0
TwoLevelTrig	0
VrefIn	1
VrefRsensBot	0
VrefRsensTop	0

Parameter

ADCcalPar	9.0 0.192 10000.0
ChipId	12
EnforceNameIdCheck	True
InjCap	7.457
IrefTrim	7
KSenseInA	20978.426
KSenseInD	21688.3
KSenseShuntA	21578.0
KSenseShuntD	22308.0
KShuntA	983.924
KShuntD	984.174
Name	0x22c5a
NfACB	1.2575891
NfASLDO	1.2590461
NfDSLDO	1.2582034
NtcCalPar	0.0007489 0.0002769 7.0595e-08
VcalPar	15.692 0.201

SoftwareType

ChipID

Name

0x22c5a

Institution

LBNL_PIXEL_MODULES

ModuleSN

20UPGM23211141

TimeStart

1761699638

TimeEnd

1761701038

useCalibAdc

False

comment

property

YARR_VERSION	v1.5.5
ANALOG_READBACK_MEASUREMENT_VERSION	2.7.0rc1.dev3

AR_TEMP

MODULE/POST_PARYLENE_WARM

660dc829ec873d003545b081

1.01

64657cef8d79bac1f3f005c0

mts	2025-10-29 01:24:00.889000
cts	2025-10-29 01:24:00.889000
rev	0

20UPGFC0142426

ANALOG_READBACK

69016caed580dc54bc3220c2

DCSdata

SensorVoltage	-79.992
SensorCurrent	-3.34525e-05
ModuleNTC	19.9965

Measurements

Vmux34

X	False
Unit	V
Values	0.535795 0.548541 0.560137 0.572512 0.584786 0.597418 0.608094 0.621324 0.631374 0.644295 0.655654 0.667782 0.679588 0.692983 0.704565 0.717574

Vmux38

X	False
Unit	V
Values	0.52891 0.540866 0.553256 0.565604 0.578441 0.590827 0.602613 0.614807 0.625364 0.637092 0.649279 0.661919 0.674534 0.687007 0.699586 0.712101

Vmux30

X	False
Unit	V
Values	0.0174375 0.0174375 0.0174375 0.0174375 0.0174375 0.0174375 0.0174375 0.0174375 0.0174375 0.0174375 0.0174375 0.0174375 0.0174375 0.0174375 0.0174375 0.0174375

Vmux33

X	False
Unit	V
Values	0.394458 0.394458 0.394341 0.394399 0.394361 0.394351 0.394417 0.394299 0.394256 0.394234 0.394097 0.393976 0.393715 0.393411 0.39295 0.392107

Vmux37

X	False
Unit	V
Values	0.395963 0.395921 0.395923 0.395998 0.396038 0.396025 0.396055 0.396028 0.39601 0.395816 0.395644 0.395435 0.394768 0.394027 0.392697 0.389938

Imux63

X	False
Unit	V
Values	0.0150025 0.0150025 0.0150025 0.0150025 0.0150025 0.0150025 0.0150025 0.0150025 0.0150025 0.0150025 0.0150025 0.0150025 0.0150025 0.0150025 0.0150025 0.0150025

Imux28

X	False
Unit	V
Values	0.312984 0.313242 0.313352 0.313598 0.313649 0.313801 0.313946 0.314085 0.314084 0.314179 0.314128 0.31394 0.313674 0.313004 0.312013 0.310217

Imux29

X	False
Unit	V
Values	0.0557321 0.0517155 0.0488717 0.0458322 0.0431703 0.040809 0.0385793 0.0365823 0.035161 0.0335591 0.0331399 0.0335096 0.0360014 0.0418624 0.0518006 0.0712269

Imux30

X	False
Unit	V
Values	0.432322 0.433132 0.433661 0.434132 0.434316 0.434601 0.434832 0.434784 0.43467 0.434333 0.433722 0.432377 0.430485 0.427165 0.422381 0.413662

Imux31

X	False
Unit	V
Values	0.196748 0.190473 0.184279 0.177975 0.17105 0.164959 0.159193 0.153118 0.148661 0.14411 0.141088 0.140426 0.144262 0.154892 0.173185 0.213934

SldoTrimA

X	False
Unit	-
Values	0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

SldoTrimD

X	False
Unit	-
Values	0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

ROSC0

X	False
Unit	MHz
Values	334.867 355.8 374.733 395.0 416.0 434.933 454.4 472.533 488.267 505.8 523.6 542.067 560.0 577.267 593.0 609.2

ROSC1

X	False
Unit	MHz
Values	518.667 550.6 579.467 610.533 642.667 671.6 700.8 728.467 752.467 780.0 806.533 834.667 861.4 887.6 911.333 935.733

ROSC2

X	False
Unit	MHz
Values	315.933 336.0 354.667 374.467 394.667 413.4 432.4 450.467 465.933 483.8 500.867 519.2 537.133 554.2 569.533 586.0

ROSC3

X	False
Unit	MHz
Values	507.533 539.667 568.867 599.8 631.867 660.867 690.467 718.933 742.733 770.067 797.2 825.333 852.4 879.467 902.8 927.8

ROSC4

X	False
Unit	MHz
Values	301.267 322.667 342.467 363.667 385.467 405.933 426.667 446.733 464.133 484.0 503.867 524.067 544.267 564.133 581.933 600.133

ROSC5

X	False
Unit	MHz
Values	501.6 537.4 570.8 606.4 643.267 677.267 712.333 746.067 774.867 808.2 841.0 875.467 909.467 942.733 973.067 1003.87

ROSC6

X	False
Unit	MHz
Values	321.067 345.6 368.467 393.067 418.533 441.867 466.533 489.867 509.933 533.2 556.133 580.133 604.333 627.667 648.533 670.467

ROSC7

X	False
Unit	MHz
Values	488.267 525.133 558.867 595.333 633.067 668.133 704.067 738.6 768.467 802.467 836.733 871.667 906.6 940.6 971.4 1003.07

ROSC8

X	False
Unit	MHz
Values	498.133 529.4 558.933 590.267 622.0 652.333 680.867 710.667 734.733 762.267 790.2 817.867 846.2 873.2 898.4 923.6

ROSC9

X	False
Unit	MHz
Values	495.4 526.8 556.333 587.933 619.333 650.2 678.6 708.667 732.267 760.267 788.133 815.667 844.067 870.933 896.333 921.6

ROSC10

X	False
Unit	MHz
Values	584.0 620.4 654.667 690.667 727.4 762.933 795.733 830.6 858.2 890.2 922.533 954.2 986.933 1018.07 1047.33 1076.6

ROSC11

X	False
Unit	MHz
Values	586.8 623.133 657.4 693.867 730.867 766.2 799.533 834.2 861.333 893.667 926.0 958.067 990.933 1021.93 1051.2 1080.67

ROSC12

X	False
Unit	MHz
Values	489.0 520.333 550.4 582.133 614.2 645.733 674.867 704.933 729.6 757.6 786.267 814.467 844.2 871.267 897.667 923.867

ROSC13

X	False
Unit	MHz
Values	490.933 522.4 552.267 584.4 616.333 647.4 676.333 706.267 730.933 759.6 787.6 816.133 845.0 872.6 898.8 924.333

ROSC14

X	False
Unit	MHz
Values	569.733 606.267 640.4 677.0 714.067 749.267 782.667 817.267 845.467 877.733 910.067 942.6 975.4 1007.07 1036.93 1066.67

ROSC15

X	False
Unit	MHz
Values	568.933 604.933 639.267 676.0 713.133 748.133 781.667 816.067 844.067 876.467 909.133 941.267 974.4 1005.73 1035.73 1065.27

ROSC16

X	False
Unit	MHz
Values	495.133 529.733 562.533 598.2 634.933 669.467 703.0 737.8 766.467 799.2 832.8 865.933 900.267 933.067 964.267 995.6

ROSC17

X	False
Unit	MHz
Values	493.4 528.267 561.6 597.667 634.2 669.6 702.933 738.467 766.8 799.733 834.0 867.4 902.2 934.867 966.533 997.867

ROSC18

X	False
Unit	MHz
Values	570.067 610.467 648.8 690.533 732.8 773.533 812.4 853.2 886.533 924.8 964.4 1002.93 1043.4 1081.8 1118.4 1154.73

ROSC19

X	False
Unit	MHz
Values	562.333 602.0 640.533 681.267 723.333 763.867 802.467 843.333 876.0 914.267 953.2 992.0 1032.07 1070.47 1107.0 1143.27

ROSC20

X	False
Unit	MHz
Values	447.667 481.4 513.533 548.067 583.4 618.0 650.267 684.4 712.4 744.6 777.533 810.133 843.8 876.0 906.8 937.667

ROSC21

X	False
Unit	MHz
Values	438.067 471.933 503.733 537.6 572.933 607.133 639.267 673.533 701.0 733.2 766.0 798.533 832.4 865.133 895.333 926.4

ROSC22

X	False
Unit	MHz
Values	566.667 608.333 648.0 690.133 734.333 776.867 816.667 859.667 893.667 933.267 973.867 1013.93 1055.33 1094.73 1132.6 1170.33

ROSC23

X	False
Unit	MHz
Values	569.667 611.333 651.2 694.2 738.267 780.867 820.733 863.933 898.267 938.267 978.867 1019.33 1061.07 1101.07 1138.87 1176.8

ROSC24

X	False
Unit	MHz
Values	324.333 346.267 366.533 388.133 410.733 432.533 452.733 474.067 491.333 511.133 531.467 551.733 572.6 592.533 611.0 629.533

ROSC25

X	False
Unit	MHz
Values	327.533 349.267 369.867 392.133 414.6 436.333 456.8 478.6 495.867 516.133 536.667 557.067 577.667 598.8 616.467 635.4

ROSC26

X	False
Unit	MHz
Values	390.867 417.067 441.8 468.467 495.6 521.6 546.4 572.267 593.067 617.133 641.867 666.2 691.667 715.733 738.4 761.267

ROSC27

X	False
Unit	MHz
Values	386.467 412.533 437.267 464.133 490.867 517.2 541.333 567.533 588.267 612.533 636.933 661.4 686.533 710.467 733.067 756.2

ROSC28

X	False
Unit	MHz
Values	398.867 425.133 449.667 476.2 503.133 529.2 553.667 579.333 600.067 624.467 648.6 673.133 697.733 721.467 743.733 766.2

ROSC29

X	False
Unit	MHz
Values	393.8 419.667 444.333 470.8 497.933 523.933 548.267 573.933 594.4 618.8 643.067 667.2 691.933 715.933 738.067 760.267

ROSC30

X	False
Unit	MHz
Values	612.867 644.4 673.933 705.0 736.333 766.067 793.6 823.133 846.2 873.2 899.933 926.8 953.333 979.133 1002.73 1026.47

ROSC31

X	False
Unit	MHz
Values	666.067 699.267 730.667 763.333 796.467 828.267 857.4 888.133 912.533 940.733 968.933 996.933 1024.93 1051.67 1076.27 1101.4

ROSC32

X	False
Unit	MHz
Values	556.2 586.933 615.8 646.467 677.267 707.333 734.733 763.867 787.0 814.533 841.6 868.4 895.733 922.067 946.4 971.0

ROSC33

X	False
Unit	MHz
Values	573.6 605.533 635.533 667.333 699.533 731.067 759.8 790.267 814.733 843.2 871.467 899.733 928.667 956.067 981.6 1007.13

ROSC34

X	False
Unit	MHz
Values	550.333 589.533 626.8 666.467 707.267 747.267 784.267 823.8 856.133 893.333 931.0 968.8 1007.47 1044.87 1079.67 1115.27

ROSC35

X	False
Unit	MHz
Values	553.067 591.8 628.867 668.867 709.2 748.8 785.733 825.133 857.133 894.733 932.267 969.867 1008.6 1045.8 1080.8 1116.27

ROSC36

X	False
Unit	MHz
Values	554.733 594.067 631.2 671.0 712.067 751.667 788.933 828.6 860.467 898.067 935.867 973.6 1012.53 1050.0 1084.67 1120.07

ROSC37

X	False
Unit	MHz
Values	551.933 591.133 628.4 668.133 709.2 748.4 786.333 826.067 858.067 895.467 933.4 971.333 1009.8 1047.13 1082.2 1118.0

ROSC38

X	False
Unit	MHz
Values	557.133 596.6 633.333 673.667 714.6 754.067 791.667 831.333 862.933 900.467 938.333 976.067 1014.87 1051.53 1086.93 1122.8

ROSC39

X	False
Unit	MHz
Values	556.133 595.133 632.4 672.533 713.267 752.8 790.2 829.8 861.8 898.933 936.6 974.133 1012.73 1050.07 1084.87 1120.47

ROSC40

X	False
Unit	MHz
Values	556.6 595.733 632.867 672.733 713.267 753.133 790.533 830.067 861.933 899.133 937.267 974.533 1012.73 1050.27 1085.53 1120.6

ROSC41

X	False
Unit	MHz
Values	553.8 593.0 630.333 670.2 711.133 750.733 788.333 828.067 859.733 896.933 934.8 972.467 1011.2 1048.8 1083.73 1119.2

Metadata

FirmwareVersion

FirmwareIdentifier

ChannelConfig

SoftwareVersion

ChipConfigs

ITKPIXV2

GlobalConfig

AiRegionRow	0
AuroraActiveLanes	1
AuroraAltOutput0	0
AuroraAltOutput1	0
AuroraCBSend	0
AuroraCBWait0	4095
AuroraCBWait1	0
AuroraCCSend	3
AuroraCCWait	25
AuroraEnPrbs	0
AuroraInitWait	32
AuroraSendAlt	0
AutoRead0	134
AutoRead1	135
AutoRead2	137
AutoRead3	138
AutoRead4	140
AutoRead5	151
AutoRead6	152
AutoRead7	156
BcidCnt	0
BitFlipErrCnt	0
BitFlipWngCnt	0
CapMeasEn	0
CapMeasEnPar	0
CdrClkSel	0
CdrCp	40
CdrCpBuff	200
CdrCpFd	400
CdrPhaseDetSel	0
CdrVco	1023
CdrVcoBuff	500
ChSyncLockThr	31
ChipIdSense	0
Clk160En	7
Clk40En	7
ClkAuroraEn	7
ClkDataMergeEn	7
CmdErrCnt	0
CmlBias0	800
CmlBias1	400
CmlBias2	0
DataDecodingValues	0
DataEnBcid	0
DataEnBinaryRo	0
DataEnCrc	0
DataEnL1id	0
DataEnRaw	0
DataMaxHits	0
DataMaxTot	0
DataMergeEn	0
DataMergeEnBond	0
DataMergeEnClkGate	0
DataMergeFixedMode	0
DataMergeGpoSel	0
DataMergeInMux0	0
DataMergeInMux1	1
DataMergeInMux2	2
DataMergeInMux3	3
DataMergeInPol	0
DataMergeManChoice	0
DataMergeManMode	0
DataMergeOutMux0	2
DataMergeOutMux1	3
DataMergeOutMux2	0
DataMergeOutMux3	1
DataMergeSelClk	0
DataReadDelay	0
DiffComp	500
DiffFbCapEn	0
DiffLcc	200
DiffLccEn	1
DiffPreComp	350
DiffPreampL	550
DiffPreampM	550
DiffPreampR	550
DiffPreampT	550
DiffPreampTL	550
DiffPreampTR	550
DiffTh1L	350
DiffTh1M	350
DiffTh1R	350
DiffTh2	50
DiffVff	60
EfuseConfig	3855
EfuseReadData0	23041
EfuseReadData1	8748
EfuseWriteData0	0
EfuseWriteData1	0
EnChipId	0
EnCoreCol0	65535
EnCoreCol1	65535
EnCoreCol2	65535
EnCoreCol3	63
EnCoreColCal0	0
EnCoreColCal1	0
EnCoreColCal2	0
EnCoreColCal3	0
EnHitsRemoval0	0
EnHitsRemoval1	0
EnHitsRemoval2	0
EnHitsRemoval3	0
EnIsoHitsRemoval0	0
EnIsoHitsRemoval1	0
EnIsoHitsRemoval2	0
EnIsoHitsRemoval3	0
ErrWngMask	0
EvenMask	0
FineDelayClk	0
FineDelayData	0
GatedHitOrCnt0	0
GatedHitOrCnt1	0
GcrDefaultConfig	44149
GcrDefaultConfigB	21386
GlobalConfigSeuCnt	0
GlobalPulseConf	0
GlobalPulseWidth	10
GpCmosDs	0
GpCmosEn	1
GpCmosRoute	34
GpLvdsBias	7
GpLvdsEn	15
GpLvdsPad0	0
GpLvdsPad1	1
GpLvdsPad2	33
GpLvdsPad3	35
GpValReg	5
HitOrCnt0	0
HitOrCnt1	0
HitOrCnt2	0
HitOrCnt3	0
HitOrMask0	0
HitOrMask1	0
HitOrMask2	0
HitOrMask3	0
InjAnaMode	0
InjDigEn	0
InjFineDelay	5
InjVcalHigh	200
InjVcalMed	200
InjVcalRange	1
IrefTrimSense	0
Latency	500
LinComp	110
LinCompTa	110
LinFc	20
LinGdacL	408
LinGdacM	408
LinGdacR	408
LinKrumCurr	50
LinLdac	100
LinPreampL	300
LinPreampM	300
LinPreampR	300
LinPreampT	300
LinPreampTL	300
LinPreampTR	300
LinRefKrum	300
LockLossCnt	0
MonAdcTrim	0
MonSensAcbDem	0
MonSensAcbEn	0
MonSensAcbSelBias	0
MonSensSldoAnaDem	0
MonSensSldoAnaEn	0
MonSensSldoAnaSelBias	0
MonSensSldoDigDem	0
MonSensSldoDigEn	0
MonSensSldoDigSelBias	0
MonitorEnable	1
MonitorI	63
MonitorV	32
MonitoringDataAdc	0
NtcDac	100
NumOfEventsInStream	0
OddMask	0
PixAutoRow	1
PixBroadcast	0
PixConfMode	1
PixDefaultConfig	40162
PixDefaultConfigB	25373
PixEnSeuCount	0
PixHitSampleMode	0
PixPortal	1285
PixRegionCol	199
PixRegionRow	0
PixelSeuCntCnt	0
PtotCoreColEn0	0
PtotCoreColEn1	0
PtotCoreColEn2	0
PtotCoreColEn3	0
RdWrFifoErrCnt	0
ReadTrigCnt	0
ReadTrigLatency	0
RingOscAClear	0
RingOscAEn	0
RingOscAOut	0
RingOscARoute	0
RingOscBClear	0
RingOscBEnBl	0
RingOscBEnBr	0
RingOscBEnCapA	0
RingOscBEnFf	0
RingOscBEnLvt	0
RingOscBOut	0
RingOscBRoute	0
RstCoreCol0	0
RstCoreCol1	0
RstCoreCol2	0
RstCoreCol3	0
SelfTrigDeadtime	64
SelfTrigDelay	512
SelfTrigDigThr	1
SelfTrigDigThrEn	0
SelfTrigEn	0
SelfTrigMulti	4
SelfTrigPattern	65534
SerEnLane	15
SerEnTap	1
SerInvTap	1
SerSelOut0	3
SerSelOut1	3
SerSelOut2	1
SerSelOut3	3
ServiceBlockEn	1
ServiceBlockPeriod	50
SkippedTrigCnt	0
SldoEnUndershuntA	0
SldoEnUndershuntD	0
SldoTrimA	8
SldoTrimD	8
TotEn6b4b	0
TotEn80	0
TotEnPtoa	0
TotEnPtot	0
TotPtotLatency	500
TrigCnt	0
TruncTimeoutConf	0
TwoLevelTrig	0
VrefIn	1
VrefRsensBot	0
VrefRsensTop	0

Parameter

ADCcalPar	9.0 0.192 10000.0
ChipId	12
EnforceNameIdCheck	True
InjCap	7.457
IrefTrim	7
KSenseInA	20978.426
KSenseInD	21688.3
KSenseShuntA	21578.0
KSenseShuntD	22308.0
KShuntA	983.924
KShuntD	984.174
Name	0x22c5a
NfACB	1.2575891
NfASLDO	1.2590461
NfDSLDO	1.2582034
NtcCalPar	0.0007489 0.0002769 7.0595e-08
VcalPar	15.692 0.201

SoftwareType

ChipID

Name

0x22c5a

Institution

LBNL_PIXEL_MODULES

ModuleSN

20UPGM23211141

TimeStart

1761695857

TimeEnd

1761699637

useCalibAdc

False

comment

property

YARR_VERSION	v1.5.5
ANALOG_READBACK_MEASUREMENT_VERSION	2.7.0rc1.dev3

AR_VDD

MODULE/POST_PARYLENE_WARM

660dc829ec873d003545b081

1.01

64657cef8d79bac1f3f005c0

mts	2025-10-29 01:24:00.889000
cts	2025-10-29 01:24:00.889000
rev	0

20UPGFC0142426

ANALOG_READBACK

69016caed580dc54bc3220c3

DCSdata

Measurements

IrefTrimSense

X	False
Unit	-
Values	8.0

Metadata

FirmwareVersion

FirmwareIdentifier

ChannelConfig

SoftwareVersion

ChipConfigs

ITKPIXV2

GlobalConfig

AiRegionRow	0
AuroraActiveLanes	1
AuroraAltOutput0	0
AuroraAltOutput1	0
AuroraCBSend	0
AuroraCBWait0	4095
AuroraCBWait1	0
AuroraCCSend	3
AuroraCCWait	25
AuroraEnPrbs	0
AuroraInitWait	32
AuroraSendAlt	0
AutoRead0	134
AutoRead1	135
AutoRead2	137
AutoRead3	138
AutoRead4	140
AutoRead5	151
AutoRead6	152
AutoRead7	156
BcidCnt	0
BitFlipErrCnt	0
BitFlipWngCnt	0
CapMeasEn	0
CapMeasEnPar	0
CdrClkSel	0
CdrCp	40
CdrCpBuff	200
CdrCpFd	400
CdrPhaseDetSel	0
CdrVco	1023
CdrVcoBuff	500
ChSyncLockThr	31
ChipIdSense	0
Clk160En	7
Clk40En	7
ClkAuroraEn	7
ClkDataMergeEn	7
CmdErrCnt	0
CmlBias0	800
CmlBias1	400
CmlBias2	0
DataDecodingValues	0
DataEnBcid	0
DataEnBinaryRo	0
DataEnCrc	0
DataEnL1id	0
DataEnRaw	0
DataMaxHits	0
DataMaxTot	0
DataMergeEn	0
DataMergeEnBond	0
DataMergeEnClkGate	0
DataMergeFixedMode	0
DataMergeGpoSel	0
DataMergeInMux0	0
DataMergeInMux1	1
DataMergeInMux2	2
DataMergeInMux3	3
DataMergeInPol	0
DataMergeManChoice	0
DataMergeManMode	0
DataMergeOutMux0	2
DataMergeOutMux1	3
DataMergeOutMux2	0
DataMergeOutMux3	1
DataMergeSelClk	0
DataReadDelay	0
DiffComp	500
DiffFbCapEn	0
DiffLcc	200
DiffLccEn	1
DiffPreComp	350
DiffPreampL	550
DiffPreampM	550
DiffPreampR	550
DiffPreampT	550
DiffPreampTL	550
DiffPreampTR	550
DiffTh1L	350
DiffTh1M	350
DiffTh1R	350
DiffTh2	50
DiffVff	60
EfuseConfig	3855
EfuseReadData0	23041
EfuseReadData1	8748
EfuseWriteData0	0
EfuseWriteData1	0
EnChipId	0
EnCoreCol0	65535
EnCoreCol1	65535
EnCoreCol2	65535
EnCoreCol3	63
EnCoreColCal0	0
EnCoreColCal1	0
EnCoreColCal2	0
EnCoreColCal3	0
EnHitsRemoval0	0
EnHitsRemoval1	0
EnHitsRemoval2	0
EnHitsRemoval3	0
EnIsoHitsRemoval0	0
EnIsoHitsRemoval1	0
EnIsoHitsRemoval2	0
EnIsoHitsRemoval3	0
ErrWngMask	0
EvenMask	0
FineDelayClk	0
FineDelayData	0
GatedHitOrCnt0	0
GatedHitOrCnt1	0
GcrDefaultConfig	44149
GcrDefaultConfigB	21386
GlobalConfigSeuCnt	0
GlobalPulseConf	0
GlobalPulseWidth	10
GpCmosDs	0
GpCmosEn	1
GpCmosRoute	34
GpLvdsBias	7
GpLvdsEn	15
GpLvdsPad0	0
GpLvdsPad1	1
GpLvdsPad2	33
GpLvdsPad3	35
GpValReg	5
HitOrCnt0	0
HitOrCnt1	0
HitOrCnt2	0
HitOrCnt3	0
HitOrMask0	0
HitOrMask1	0
HitOrMask2	0
HitOrMask3	0
InjAnaMode	0
InjDigEn	0
InjFineDelay	5
InjVcalHigh	200
InjVcalMed	200
InjVcalRange	1
IrefTrimSense	0
Latency	500
LinComp	110
LinCompTa	110
LinFc	20
LinGdacL	408
LinGdacM	408
LinGdacR	408
LinKrumCurr	50
LinLdac	100
LinPreampL	300
LinPreampM	300
LinPreampR	300
LinPreampT	300
LinPreampTL	300
LinPreampTR	300
LinRefKrum	300
LockLossCnt	0
MonAdcTrim	0
MonSensAcbDem	0
MonSensAcbEn	0
MonSensAcbSelBias	0
MonSensSldoAnaDem	0
MonSensSldoAnaEn	0
MonSensSldoAnaSelBias	0
MonSensSldoDigDem	0
MonSensSldoDigEn	0
MonSensSldoDigSelBias	0
MonitorEnable	1
MonitorI	63
MonitorV	32
MonitoringDataAdc	0
NtcDac	100
NumOfEventsInStream	0
OddMask	0
PixAutoRow	1
PixBroadcast	0
PixConfMode	1
PixDefaultConfig	40162
PixDefaultConfigB	25373
PixEnSeuCount	0
PixHitSampleMode	0
PixPortal	1285
PixRegionCol	199
PixRegionRow	0
PixelSeuCntCnt	0
PtotCoreColEn0	0
PtotCoreColEn1	0
PtotCoreColEn2	0
PtotCoreColEn3	0
RdWrFifoErrCnt	0
ReadTrigCnt	0
ReadTrigLatency	0
RingOscAClear	0
RingOscAEn	0
RingOscAOut	0
RingOscARoute	0
RingOscBClear	0
RingOscBEnBl	0
RingOscBEnBr	0
RingOscBEnCapA	0
RingOscBEnFf	0
RingOscBEnLvt	0
RingOscBOut	0
RingOscBRoute	0
RstCoreCol0	0
RstCoreCol1	0
RstCoreCol2	0
RstCoreCol3	0
SelfTrigDeadtime	64
SelfTrigDelay	512
SelfTrigDigThr	1
SelfTrigDigThrEn	0
SelfTrigEn	0
SelfTrigMulti	4
SelfTrigPattern	65534
SerEnLane	15
SerEnTap	1
SerInvTap	1
SerSelOut0	3
SerSelOut1	3
SerSelOut2	1
SerSelOut3	3
ServiceBlockEn	1
ServiceBlockPeriod	50
SkippedTrigCnt	0
SldoEnUndershuntA	0
SldoEnUndershuntD	0
SldoTrimA	8
SldoTrimD	8
TotEn6b4b	0
TotEn80	0
TotEnPtoa	0
TotEnPtot	0
TotPtotLatency	500
TrigCnt	0
TruncTimeoutConf	0
TwoLevelTrig	0
VrefIn	1
VrefRsensBot	0
VrefRsensTop	0

Parameter

ADCcalPar	9.0 0.192 10000.0
ChipId	12
EnforceNameIdCheck	True
InjCap	7.457
IrefTrim	7
KSenseInA	20978.426
KSenseInD	21688.3
KSenseShuntA	21578.0
KSenseShuntD	22308.0
KShuntA	983.924
KShuntD	984.174
Name	0x22c5a
NfACB	1.2575891
NfASLDO	1.2590461
NfDSLDO	1.2582034
NtcCalPar	0.0007489 0.0002769 7.0595e-08
VcalPar	15.692 0.201

SoftwareType

ChipID

Name

0x22c5a

Institution

LBNL_PIXEL_MODULES

ModuleSN

20UPGM23211141

TimeStart

1761699637

TimeEnd

1761699638

comment

property

YARR_VERSION	v1.5.5
ANALOG_READBACK_MEASUREMENT_VERSION	2.7.0rc1.dev3

AR_REGISTER

MODULE/POST_PARYLENE_WARM

660dc829ec873d003545b081

1.01

64657cef8d79bac1f3f005c0

mts	2025-10-29 01:24:00.889000
cts	2025-10-29 01:24:00.889000
rev	0

rawHash

6a89e1ddb2b047b736df07ed0aecd124

stage

MODULE/POST_PARYLENE_WARM

ProductionDB Record

{}

Current Stage: Post-Parylene Warm

Test Type	Local Result
ADC Calibration (ADC_CALIBRATION)	TestRun Present
Analog Readback (ANALOG_READBACK)	TestRun Present
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No TestRun!
Undershunt Protection (UNDERSHUNT_PROTECTION)	No TestRun!
SLDO (SLDO)	TestRun Present
VCAL Calibration (VCAL_CALIBRATION)	TestRun Present
Data Transmission (DATA_TRANSMISSION)	TestRun Present
Injection Capacitance (INJECTION_CAPACITANCE)	TestRun Present
Minimal Health Test (MIN_HEALTH_TEST)	TestRun Present
Tuning (TUNING)	TestRun Present
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	TestRun Present
Low Power Mode (LP_MODE)	TestRun Present

Candidate TestRuns of this Stage

LDB ID	TestRun Code	QC Passed	Inspector	Measurement Date	Analysis Date	Analysis Version	Tags	QC Registration
69433e…206201	PIXEL_FAILURE_ANALYSIS	Pass	None	N/A	5 days ago	2.7.0	No tags
693a07…5f363f	ADC_CALIBRATION	Pass	None	a week ago	a week ago	2.7.0	ganymede_4	Selected
6920d5…a9c4af	DATA_TRANSMISSION	Pass	None	a month ago	a month ago	2.7.0	ganymede_4
6920d5…0bad33	LP_MODE	Pass	None	a month ago	a month ago	2.7.0	ganymede_4
6920c8…7f3935	INJECTION_CAPACITANCE	Pass	None	a month ago	a month ago	2.7.0	ganymede_4
6920c6…a9c354	VCAL_CALIBRATION	Pass	None	a month ago	a month ago	2.7.0	ganymede_4
6920c4…22bc54	SLDO	Pass	None	a month ago	a month ago	2.7.0	ganymede_4
6920bc…22bb07	ANALOG_READBACK	Pass	None	a month ago	a month ago	2.7.0	ganymede_4
6920a2…a57119	ADC_CALIBRATION	Pass	None	a month ago	a month ago	2.7.0	ganymede_4
690e82…2edf60	DATA_TRANSMISSION	Pass	None	a month ago	a month ago	2.7.0	No tags
690e82…2edf0d	PIXEL_FAILURE_ANALYSIS	Pass	None	N/A	a month ago	2.7.0	No tags
690e82…2ede3d	TUNING	Pass	None	N/A	a month ago	2.7.0	No tags
690e82…2eddaa	MIN_HEALTH_TEST	Pass	None	N/A	a month ago	2.7.0	No tags
690e82…2edd67	INJECTION_CAPACITANCE	Pass	None	a month ago	a month ago	2.7.0	No tags
690e82…2edd3f	LP_MODE	Pass	None	a month ago	a month ago	2.7.0	No tags
690e82…2edcca	ANALOG_READBACK	Pass	None	a month ago	a month ago	2.7.0	No tags
690e82…2edc76	VCAL_CALIBRATION	Pass	None	a month ago	a month ago	2.7.0	No tags
690e82…2edc42	SLDO	Pass	None	a month ago	a month ago	2.7.0	No tags
690e81…2edc1e	ADC_CALIBRATION	Pass	None	a month ago	a month ago	2.7.0	No tags
690e80…69127c	PIXEL_FAILURE_ANALYSIS	Pass	None	N/A	a month ago	2.7.0	No tags
690e80…2edb0f	TUNING	Pass	None	N/A	a month ago	2.7.0	No tags
690e7f…9b5f22	MIN_HEALTH_TEST	Pass	None	N/A	a month ago	2.7.0	No tags
690ac4…f94a43	DATA_TRANSMISSION	Pass	None	a month ago	a month ago	2.7.0	ganymede_4
690ac4…aced9d	LP_MODE	Pass	None	a month ago	a month ago	2.7.0	ganymede_4
690ac3…f949cf	INJECTION_CAPACITANCE	Pass	None	a month ago	a month ago	2.7.0	ganymede_4
690abd…99320a	VCAL_CALIBRATION	Pass	None	a month ago	a month ago	2.7.0	ganymede_4
690aba…aceb9e	SLDO	Pass	None	a month ago	a month ago	2.7.0	ganymede_4
690ab2…acea56	ANALOG_READBACK	Pass	None	a month ago	a month ago	2.7.0	ganymede_4
690a98…f948a7	ADC_CALIBRATION	Pass	None	a month ago	a month ago	2.7.0	ganymede_4
690a93…f94827	ADC_CALIBRATION	Pass	None	a month ago	a month ago	2.7.0	ganymede_4
6902dc…f69a8e	DATA_TRANSMISSION	Pass	None	a month ago	a month ago	2.7.0	ganymede_4
6902dc…6daa01	LP_MODE	Pass	None	a month ago	a month ago	2.7.0	ganymede_4
6902db…f69999	INJECTION_CAPACITANCE	Pass	None	a month ago	a month ago	2.7.0	ganymede_4
6902da…f69878	VCAL_CALIBRATION	Pass	None	a month ago	a month ago	2.7.0	ganymede_4
6902d7…f69824	SLDO	Pass	None	a month ago	a month ago	2.7.0	ganymede_4
6902cf…f69627	ANALOG_READBACK	Pass	None	a month ago	a month ago	2.7.0	ganymede_4
6902b4…6da885	ADC_CALIBRATION	Pass	None	a month ago	a month ago	2.7.0	ganymede_4
6902a4…b313ce	ADC_CALIBRATION	Pass	None	a month ago	a month ago	2.7.0rc3	ganymede_4
690178…c4d43e	DATA_TRANSMISSION	Pass	None	a month ago	a month ago	2.7.0rc3	ganymede_4
690178…c4d415	LP_MODE	Pass	None	a month ago	a month ago	2.7.0rc3	ganymede_4
690177…c4d3c3	INJECTION_CAPACITANCE	Pass	None	a month ago	a month ago	2.7.0rc3	ganymede_4
690176…c4d2fd	VCAL_CALIBRATION	Pass	None	a month ago	a month ago	2.7.0rc3	ganymede_4
690173…513a84	SLDO	Pass	None	a month ago	a month ago	2.7.0rc3	ganymede_4
69016c…c4d14e	ANALOG_READBACK	Pass	None	a month ago	a month ago	2.7.0rc3	ganymede_4
690155…5a847a	ADC_CALIBRATION	Pass	None	a month ago	a month ago	2.7.0rc3	ganymede_4

Past QC Stages and Results

Wirebond Protection (alt) (MODULE/WIREBOND_PROTECTION)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Parylene Unmasking (MODULE/PARYLENE_UNMASKING)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Parylene Coating (MODULE/PARYLENE_COATING)

Parylene Masking (MODULE/PARYLENE_MASKING)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Initial Cold (MODULE/INITIAL_COLD)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

QC cross-check (module swapping) (MODULE/QC_CROSSCHECK)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	Registered	Registered
Analog Readback (ANALOG_READBACK)	Registered	Registered
Data Transmission (DATA_TRANSMISSION)	Registered	Registered
Injection Capacitance (INJECTION_CAPACITANCE)	Registered	Registered
Low Power Mode (LP_MODE)	Registered	Registered
Minimal Health Test (MIN_HEALTH_TEST)	Registered	Registered
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	Registered	Registered
SLDO (SLDO)	Registered	Registered
Tuning (TUNING)	Registered	Registered
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	Registered	Registered

Initial Warm (MODULE/INITIAL_WARM)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	Registered	Registered
Analog Readback (ANALOG_READBACK)	Registered	Registered
Data Transmission (DATA_TRANSMISSION)	Registered	Registered
Injection Capacitance (INJECTION_CAPACITANCE)	Registered	Registered
Low Power Mode (LP_MODE)	Registered	Registered
Minimal Health Test (MIN_HEALTH_TEST)	Registered	Registered
Overvoltage Protection (OVERVOLTAGE_PROTECTION)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	Registered	Registered
SLDO (SLDO)	Registered	Registered
Tuning (TUNING)	Registered	Registered
Undershunt Protection (UNDERSHUNT_PROTECTION)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	Registered	Registered

Wire Bonding (MODULE/WIREBONDING)

Test	Local Result	ProdDB Record
ADC Calibration (ADC_CALIBRATION)	No result	N/A
Analog Readback (ANALOG_READBACK)	No result	N/A
Data Transmission (DATA_TRANSMISSION)	No result	N/A
Injection Capacitance (INJECTION_CAPACITANCE)	No result	N/A
Low Power Mode (LP_MODE)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A
Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)	No result	N/A
SLDO (SLDO)	No result	N/A
Tuning (TUNING)	No result	N/A
VCAL Calibration (VCAL_CALIBRATION)	No result	N/A

Bare module to module PCB assembly (MODULE/ASSEMBLY)

Initial state to associate flex to bare module (MODULE/INIT)

Reception at ITk institute (BAREMODULERECEPTION)

Test	Local Result	ProdDB Record
Analog Readback (ANALOG_READBACK)	No result	N/A
Minimal Health Test (MIN_HEALTH_TEST)	No result	N/A

Bare module assembly (BAREMODULEASSEMBLY)

Not to be used for detector (UNUSABLE)

Hybridisation (HYBRIDISATION)

Testing on wafer (TESTONWAFER)

Test	Local Result	ProdDB Record
Electrical FE chip tests (FECHIP_TEST)	Registered	Registered

LocalDB Test ID	Stage	Test Name	Inspector	Measurement Date	Analysis Date	Tags	QC Registration
69433e…206201	MODULE/POST_PARYLENE_WARM	PIXEL_FAILURE_ANALYSIS	None	N/A	5 days ago	No tags
693a07…5f363f	MODULE/POST_PARYLENE_WARM	ADC_CALIBRATION	None	a week ago	a week ago	ganymede_4	Selected
6920d5…a9c4af	MODULE/POST_PARYLENE_WARM	DATA_TRANSMISSION	None	a month ago	a month ago	ganymede_4
6920d5…0bad33	MODULE/POST_PARYLENE_WARM	LP_MODE	None	a month ago	a month ago	ganymede_4
6920c8…7f3935	MODULE/POST_PARYLENE_WARM	INJECTION_CAPACITANCE	None	a month ago	a month ago	ganymede_4
6920c6…a9c354	MODULE/POST_PARYLENE_WARM	VCAL_CALIBRATION	None	a month ago	a month ago	ganymede_4
6920c4…22bc54	MODULE/POST_PARYLENE_WARM	SLDO	None	a month ago	a month ago	ganymede_4
6920bc…22bb07	MODULE/POST_PARYLENE_WARM	ANALOG_READBACK	None	a month ago	a month ago	ganymede_4
6920a2…a57119	MODULE/POST_PARYLENE_WARM	ADC_CALIBRATION	None	a month ago	a month ago	ganymede_4
690e82…2edf60	MODULE/POST_PARYLENE_WARM	DATA_TRANSMISSION	None	a month ago	a month ago	No tags
690e82…2edf0d	MODULE/POST_PARYLENE_WARM	PIXEL_FAILURE_ANALYSIS	None	N/A	a month ago	No tags
690e82…2ede3d	MODULE/POST_PARYLENE_WARM	TUNING	None	N/A	a month ago	No tags
690e82…2eddaa	MODULE/POST_PARYLENE_WARM	MIN_HEALTH_TEST	None	N/A	a month ago	No tags
690e82…2edd67	MODULE/POST_PARYLENE_WARM	INJECTION_CAPACITANCE	None	a month ago	a month ago	No tags
690e82…2edd3f	MODULE/POST_PARYLENE_WARM	LP_MODE	None	a month ago	a month ago	No tags
690e82…2edcca	MODULE/POST_PARYLENE_WARM	ANALOG_READBACK	None	a month ago	a month ago	No tags
690e82…2edc76	MODULE/POST_PARYLENE_WARM	VCAL_CALIBRATION	None	a month ago	a month ago	No tags
690e82…2edc42	MODULE/POST_PARYLENE_WARM	SLDO	None	a month ago	a month ago	No tags
690e81…2edc1e	MODULE/POST_PARYLENE_WARM	ADC_CALIBRATION	None	a month ago	a month ago	No tags
690e80…69127c	MODULE/POST_PARYLENE_WARM	PIXEL_FAILURE_ANALYSIS	None	N/A	a month ago	No tags
690e80…2edb0f	MODULE/POST_PARYLENE_WARM	TUNING	None	N/A	a month ago	No tags
690e7f…9b5f22	MODULE/POST_PARYLENE_WARM	MIN_HEALTH_TEST	None	N/A	a month ago	No tags
690ac4…f94a43	MODULE/POST_PARYLENE_WARM	DATA_TRANSMISSION	None	a month ago	a month ago	ganymede_4
690ac4…aced9d	MODULE/POST_PARYLENE_WARM	LP_MODE	None	a month ago	a month ago	ganymede_4
690ac3…f949cf	MODULE/POST_PARYLENE_WARM	INJECTION_CAPACITANCE	None	a month ago	a month ago	ganymede_4
690abd…99320a	MODULE/POST_PARYLENE_WARM	VCAL_CALIBRATION	None	a month ago	a month ago	ganymede_4
690aba…aceb9e	MODULE/POST_PARYLENE_WARM	SLDO	None	a month ago	a month ago	ganymede_4
690ab2…acea56	MODULE/POST_PARYLENE_WARM	ANALOG_READBACK	None	a month ago	a month ago	ganymede_4
690a98…f948a7	MODULE/POST_PARYLENE_WARM	ADC_CALIBRATION	None	a month ago	a month ago	ganymede_4
690a93…f94827	MODULE/POST_PARYLENE_WARM	ADC_CALIBRATION	None	a month ago	a month ago	ganymede_4
6902dc…f69a8e	MODULE/POST_PARYLENE_WARM	DATA_TRANSMISSION	None	a month ago	a month ago	ganymede_4
6902dc…6daa01	MODULE/POST_PARYLENE_WARM	LP_MODE	None	a month ago	a month ago	ganymede_4
6902db…f69999	MODULE/POST_PARYLENE_WARM	INJECTION_CAPACITANCE	None	a month ago	a month ago	ganymede_4
6902da…f69878	MODULE/POST_PARYLENE_WARM	VCAL_CALIBRATION	None	a month ago	a month ago	ganymede_4
6902d7…f69824	MODULE/POST_PARYLENE_WARM	SLDO	None	a month ago	a month ago	ganymede_4
6902cf…f69627	MODULE/POST_PARYLENE_WARM	ANALOG_READBACK	None	a month ago	a month ago	ganymede_4
6902b4…6da885	MODULE/POST_PARYLENE_WARM	ADC_CALIBRATION	None	a month ago	a month ago	ganymede_4
6902a4…b313ce	MODULE/POST_PARYLENE_WARM	ADC_CALIBRATION	None	a month ago	a month ago	ganymede_4
690178…c4d43e	MODULE/POST_PARYLENE_WARM	DATA_TRANSMISSION	None	a month ago	a month ago	ganymede_4
690178…c4d415	MODULE/POST_PARYLENE_WARM	LP_MODE	None	a month ago	a month ago	ganymede_4
690177…c4d3c3	MODULE/POST_PARYLENE_WARM	INJECTION_CAPACITANCE	None	a month ago	a month ago	ganymede_4
690176…c4d2fd	MODULE/POST_PARYLENE_WARM	VCAL_CALIBRATION	None	a month ago	a month ago	ganymede_4
690173…513a84	MODULE/POST_PARYLENE_WARM	SLDO	None	a month ago	a month ago	ganymede_4
69016c…c4d14e	MODULE/POST_PARYLENE_WARM	ANALOG_READBACK	None	a month ago	a month ago	ganymede_4
690155…5a847a	MODULE/POST_PARYLENE_WARM	ADC_CALIBRATION	None	a month ago	a month ago	ganymede_4
68d573…87c4d3	MODULE/QC_CROSSCHECK	PIXEL_FAILURE_ANALYSIS	DanielAceves	N/A	3 months ago	No tags	Selected
68d572…87c39b	MODULE/QC_CROSSCHECK	TUNING	DanielAceves	N/A	3 months ago	No tags	Selected
68d571…87c328	MODULE/QC_CROSSCHECK	MIN_HEALTH_TEST	DanielAceves	N/A	3 months ago	No tags	Selected
68d56a…87c18d	MODULE/QC_CROSSCHECK	INJECTION_CAPACITANCE	DanielAceves	3 months ago	3 months ago	No tags	Selected
68d56a…87c169	MODULE/QC_CROSSCHECK	DATA_TRANSMISSION	DanielAceves	3 months ago	3 months ago	No tags	Selected
68d56a…87c1b9	MODULE/QC_CROSSCHECK	LP_MODE	DanielAceves	3 months ago	3 months ago	No tags	Selected
68d569…87c131	MODULE/QC_CROSSCHECK	VCAL_CALIBRATION	DanielAceves	3 months ago	3 months ago	No tags	Selected
68d569…87c0fd	MODULE/QC_CROSSCHECK	SLDO	DanielAceves	3 months ago	3 months ago	No tags	Selected
68d569…87c085	MODULE/QC_CROSSCHECK	ANALOG_READBACK	DanielAceves	3 months ago	3 months ago	No tags	Selected
68d569…87c049	MODULE/QC_CROSSCHECK	ADC_CALIBRATION	DanielAceves	3 months ago	3 months ago	No tags	Selected
68c09c…33bc38	MODULE/INITIAL_WARM	PIXEL_FAILURE_ANALYSIS	DanielAceves	N/A	3 months ago	No tags	Selected
68c09c…33bb00	MODULE/INITIAL_WARM	TUNING	DanielAceves	N/A	3 months ago	No tags	Selected
68c09b…33ba99	MODULE/INITIAL_WARM	MIN_HEALTH_TEST	DanielAceves	N/A	3 months ago	No tags	Selected
68c09a…33b842	MODULE/INITIAL_WARM	INJECTION_CAPACITANCE	DanielAceves	3 months ago	3 months ago	No tags	Selected
68c09a…33b81a	MODULE/INITIAL_WARM	DATA_TRANSMISSION	DanielAceves	3 months ago	3 months ago	No tags	Selected
68c09a…33b872	MODULE/INITIAL_WARM	LP_MODE	DanielAceves	3 months ago	3 months ago	No tags	Selected
68c09a…33b7de	MODULE/INITIAL_WARM	VCAL_CALIBRATION	DanielAceves	3 months ago	3 months ago	No tags	Selected
68c09a…33b7a6	MODULE/INITIAL_WARM	SLDO	DanielAceves	3 months ago	3 months ago	No tags	Selected
68c099…33b600	MODULE/INITIAL_WARM	ANALOG_READBACK	DanielAceves	3 months ago	3 months ago	No tags	Selected
68bf12…3381fb	MODULE/INITIAL_WARM	ADC_CALIBRATION	DanielAceves	3 months ago	3 months ago	No tags	Selected
660dc9…45b71c	TESTONWAFER	FECHIP_TEST	DimaManeuski	N/A	a year ago	No tags	Selected

Run	Date	Test Type	Stage	User	Site	Tags	Status
145	a week ago	std_analogscan	MODULE/POST_PARYLENE_WARM	pixqc	jittereel.dhcp.lbl.gov	MHT	Pass
144	a week ago	std_digitalscan	MODULE/POST_PARYLENE_WARM	pixqc	jittereel.dhcp.lbl.gov	MHT	Pass
127	a month ago	std_analogscan	MODULE/POST_PARYLENE_WARM	pixqc	jittereel.dhcp.lbl.gov	MHT	Pass
124	a month ago	std_digitalscan	MODULE/POST_PARYLENE_WARM	pixqc	jittereel.dhcp.lbl.gov	MHT	Pass
4441	a month ago	std_mergedbumpscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	PFA	Pass
4437	a month ago	std_discbumpscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	PFA	Pass
4433	a month ago	std_noisescan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	PFA	Pass
4429	a month ago	std_totscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	PFA	Pass
4425	a month ago	std_thresholdscan_hd	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	PFA	Pass
4421	a month ago	std_analogscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	PFA	Pass
4417	a month ago	std_digitalscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	PFA	Pass
4413	a month ago	std_totscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	TUN	Pass
4409	a month ago	std_thresholdscan_hd	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	TUN	Pass
4405	a month ago	std_tune_pixelthreshold	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	TUN	Pass
4401	a month ago	std_tune_globalthreshold	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	TUN	Pass
4397	a month ago	std_tune_globalpreamp	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	TUN	Pass
4393	a month ago	std_tune_globalthreshold	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	TUN	Pass
4389	a month ago	std_totscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	TUN	Pass
4385	a month ago	std_thresholdscan_hr	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	TUN	Pass
4381	a month ago	std_totscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	MHT	Pass
4377	a month ago	std_thresholdscan_hr	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	MHT	Pass
4373	a month ago	std_analogscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	MHT	Pass
4369	a month ago	std_digitalscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	MHT	Pass
4358	a month ago	std_analogscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	MHT	Pass
4354	a month ago	std_digitalscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	MHT	Pass
4314	a month ago	std_analogscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	MHT	Pass
4310	a month ago	std_digitalscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	MHT	Pass
4292	a month ago	std_totscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	MHT	Pass
4291	a month ago	std_thresholdscan_hr	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	MHT	Pass
4290	a month ago	std_analogscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	MHT	Pass
4288	a month ago	std_digitalscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	MHT	Pass
4125	a month ago	std_analogscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	MHT	Pass
4124	a month ago	std_digitalscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	MHT	Pass
4056	a month ago	std_analogscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	MHT	Pass
4055	a month ago	std_digitalscan	MODULE/POST_PARYLENE_WARM	fhartanto	jittereel.dhcp.lbl.gov	MHT	Pass

Stage: MODULE/POST_PARYLENE_WARM

Mode: warm

Index	Revision ID	Timestamp	Message
HEAD	693a...8791df	a week ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^1	693a...a355af	a week ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^2	693a...5f3648	a week ago	config revision by ADC-CALIBRATION with RAW data 693a077b9a818808f85f3638 and analysis result 693a07829a818808f85f363f
HEAD^3	6920...0c216e	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^4	6920...52b8c0	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: pixqc)
HEAD^5	6920...a9c4b7	a month ago	config revision by DATA-TRANSMISSION with RAW data 6920d5f037aa05c57ea9c4a8 and analysis result 6920d5f737aa05c57ea9c4af
HEAD^6	6920...7f393d	a month ago	config revision by INJECTION-CAPACITANCE with RAW data 6920c82259eb6194df7f392a and analysis result 6920c82859eb6194df7f3935
HEAD^7	6920...a9c35c	a month ago	config revision by VCAL-CALIBRATION with RAW data 6920c6cc37aa05c57ea9c314 and analysis result 6920c6d637aa05c57ea9c354
HEAD^8	6920...22bc5c	a month ago	config revision by SLDO with RAW data 6920c443debdf73f4322bc49 and analysis result 6920c449debdf73f4322bc54
HEAD^9	6920...22bb18	a month ago	config revision by ANALOG-READBACK with RAW data 6920bc2adebdf73f4322bac1 and analysis result 6920bc3fdebdf73f4322bb07
HEAD^10	6920...a57121	a month ago	config revision by ADC-CALIBRATION with RAW data 6920a247b3abf5df24a57112 and analysis result 6920a24db3abf5df24a57119
HEAD^11	690d...a271c7	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^12	690d...cc11f4	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^13	690d...6f1937	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^14	690d...1df719	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^15	690d...f9a654	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^16	690d...5bdf99	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^17	690d...15748b	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^18	690d...e750f6	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^19	690d...9ee3e6	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^20	690d...6d9f27	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^21	690d...dbc222	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^22	690d...6f4752	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^23	690d...399f75	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^24	690c...861baa	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^25	690c...f84bb7	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^26	690c...07d6ce	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^27	690c...753489	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^28	690b...b878ae	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^29	690b...a9e708	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^30	690b...411cd4	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^31	690b...95de04	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^32	690a...94165c	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^33	690a...3f197c	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^34	690a...12a536	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^35	690a...dd4944	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^36	690a...f94a4a	a month ago	config revision by DATA-TRANSMISSION with RAW data 690ac4aa9e9eb4cb71f94a3c and analysis result 690ac4af9e9eb4cb71f94a43
HEAD^37	690a...f949d6	a month ago	config revision by INJECTION-CAPACITANCE with RAW data 690ac3889e9eb4cb71f949c4 and analysis result 690ac38e9e9eb4cb71f949cf
HEAD^38	690a...993211	a month ago	config revision by VCAL-CALIBRATION with RAW data 690abd463d2fe659a49931fb and analysis result 690abd4c3d2fe659a499320a
HEAD^39	690a...aceba5	a month ago	config revision by SLDO with RAW data 690abaca2ee93469f0aceb93 and analysis result 690abacf2ee93469f0aceb9e
HEAD^40	690a...acea5d	a month ago	config revision by ANALOG-READBACK with RAW data 690ab2ba2ee93469f0acea33 and analysis result 690ab2c22ee93469f0acea56
HEAD^41	690a...f948ae	a month ago	config revision by ADC-CALIBRATION with RAW data 690a98099e9eb4cb71f948a0 and analysis result 690a980f9e9eb4cb71f948a7
HEAD^42	690a...f9482e	a month ago	config revision by ADC-CALIBRATION with RAW data 690a93be9e9eb4cb71f94820 and analysis result 690a93c49e9eb4cb71f94827
HEAD^43	6902...5d4119	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^44	6902...f69a95	a month ago	config revision by DATA-TRANSMISSION with RAW data 6902dc551f6a7995c5f69a87 and analysis result 6902dc5a1f6a7995c5f69a8e
HEAD^45	6902...f699a0	a month ago	config revision by INJECTION-CAPACITANCE with RAW data 6902db1e1f6a7995c5f6998e and analysis result 6902db231f6a7995c5f69999
HEAD^46	6902...f6987f	a month ago	config revision by VCAL-CALIBRATION with RAW data 6902da011f6a7995c5f69869 and analysis result 6902da071f6a7995c5f69878
HEAD^47	6902...f6982b	a month ago	config revision by SLDO with RAW data 6902d7711f6a7995c5f69819 and analysis result 6902d7771f6a7995c5f69824
HEAD^48	6902...f6962e	a month ago	config revision by ANALOG-READBACK with RAW data 6902cf5a1f6a7995c5f69604 and analysis result 6902cf631f6a7995c5f69627
HEAD^49	6902...6da88c	a month ago	config revision by ADC-CALIBRATION with RAW data 6902b40c96387c76c66da87e and analysis result 6902b41196387c76c66da885
HEAD^50	6902...b313d5	a month ago	config revision by ADC-CALIBRATION with RAW data 6902a416487f80dab6b313c7 and analysis result 6902a41c487f80dab6b313ce
HEAD^51	6901...e298c8	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^52	6901...a21082	a month ago	Submitted by YARR-dbAccessor (hostname: jittereel.dhcp.lbl.gov, user: fhartanto)
HEAD^53	6901...c4d447	a month ago	config revision by DATA-TRANSMISSION with RAW data 69017865aa4113d5eec4d437 and analysis result 6901786aaa4113d5eec4d43e
HEAD^54	6901...c4d3cc	a month ago	config revision by INJECTION-CAPACITANCE with RAW data 69017755aa4113d5eec4d3b8 and analysis result 6901775aaa4113d5eec4d3c3
HEAD^55	6901...c4d306	a month ago	config revision by VCAL-CALIBRATION with RAW data 6901763eaa4113d5eec4d2ee and analysis result 69017644aa4113d5eec4d2fd
HEAD^56	6901...513a8d	a month ago	config revision by SLDO with RAW data 690173d686d87b18ae513a79 and analysis result 690173dc86d87b18ae513a84
HEAD^57	6901...c4d157	a month ago	config revision by ANALOG-READBACK with RAW data 69016cb1aa4113d5eec4d12b and analysis result 69016cbaaa4113d5eec4d14e
HEAD^58	6901...5a8483	a month ago	config revision by ADC-CALIBRATION with RAW data 69015579ac6cbf99785a8473 and analysis result 6901557eac6cbf99785a847a
HEAD^59	68da...6a2aef	3 months ago	downloaded from ITkPD : code = 5ea7898868cef1375ad3afe5649f3a81, description = {"_id":"689e40368428c598c032e343","serialNumber":"20UPGFC0142426","stage":"MODULE/INITIAL_WARM","branch":"warm","current_revision_id":"68c09b910a735050c64b7214"}

Mode: cold

Index	Revision ID	Timestamp	Message
HEAD	68da...6a2af1	3 months ago	downloaded from ITkPD : code = 4e499dc1a7f5fe023dc412bab456a3b0, description = {"_id":"689e40368428c598c032e34b","serialNumber":"20UPGFC0142426","stage":"MODULE/INITIAL_WARM","branch":"cold","current_revision_id":"68bf12f38428c598c03382a2"}

Mode: LP

Index	Revision ID	Timestamp	Message
HEAD	6920...0bad34	a month ago	config revision by LP-MODE with RAW data 6920d5a8948273b4430bad23 and analysis result 6920d5ac948273b4430bad33
HEAD^1	690a...aced9e	a month ago	config revision by LP-MODE with RAW data 690ac43f2ee93469f0aced96 and analysis result 690ac4422ee93469f0aced9d
HEAD^2	6902...6daa02	a month ago	config revision by LP-MODE with RAW data 6902dc1c96387c76c66da9fa and analysis result 6902dc2096387c76c66daa01
HEAD^3	6901...c4d416	a month ago	config revision by LP-MODE with RAW data 6901782faa4113d5eec4d40e and analysis result 69017833aa4113d5eec4d415
HEAD^4	68da...6a2af3	3 months ago	downloaded from ITkPD : code = a0d469fcc034f1b269fb21cc90f1434d, description = {"_id":"689e40368428c598c032e353","serialNumber":"20UPGFC0142426","stage":"MODULE/INITIAL_WARM","branch":"LP","current_revision_id":"68c09a678428c598c033b873"}

Stage	Tests
TESTONWAFER	Electrical FE chip tests (FECHIP_TEST)
HYBRIDISATION
UNUSABLE
BAREMODULEASSEMBLY
BAREMODULERECEPTION	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK)
MODULE/INIT
MODULE/ASSEMBLY
MODULE/WIREBONDING	ADC Calibration (ADC_CALIBRATION) Data Transmission (DATA_TRANSMISSION) VCAL Calibration (VCAL_CALIBRATION) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) SLDO (SLDO) Low Power Mode (LP_MODE) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/INITIAL_WARM	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Low Power Mode (LP_MODE) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) Data Transmission (DATA_TRANSMISSION) Injection Capacitance (INJECTION_CAPACITANCE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
MODULE/QC_CROSSCHECK	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Low Power Mode (LP_MODE) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) Data Transmission (DATA_TRANSMISSION) Injection Capacitance (INJECTION_CAPACITANCE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
MODULE/INITIAL_COLD	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Injection Capacitance (INJECTION_CAPACITANCE) Tuning (TUNING) Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Low Power Mode (LP_MODE) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) Data Transmission (DATA_TRANSMISSION)
MODULE/PARYLENE_MASKING	ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) SLDO (SLDO) Low Power Mode (LP_MODE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE) Data Transmission (DATA_TRANSMISSION)
MODULE/PARYLENE_COATING
MODULE/PARYLENE_UNMASKING	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Tuning (TUNING) Data Transmission (DATA_TRANSMISSION) ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) SLDO (SLDO) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE)
MODULE/WIREBOND_PROTECTION	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Tuning (TUNING) ADC Calibration (ADC_CALIBRATION) Low Power Mode (LP_MODE) VCAL Calibration (VCAL_CALIBRATION) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE) SLDO (SLDO) Data Transmission (DATA_TRANSMISSION)
MODULE/POST_PARYLENE_WARM	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Data Transmission (DATA_TRANSMISSION) Injection Capacitance (INJECTION_CAPACITANCE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Low Power Mode (LP_MODE)
MODULE/POST_PARYLENE_COLD	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) VCAL Calibration (VCAL_CALIBRATION) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) SLDO (SLDO) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/THERMAL_CYCLES	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Tuning (TUNING) Data Transmission (DATA_TRANSMISSION) SLDO (SLDO) ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE) Cold startup (COLD_STARTUP)
MODULE/LONG_TERM_STABILITY_TEST	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) SLDO (SLDO) Tuning (TUNING) ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) Analog Readback (ANALOG_READBACK) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/FINAL_WARM	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Undershunt Protection (UNDERSHUNT_PROTECTION) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Data Transmission (DATA_TRANSMISSION) Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Tuning (TUNING) Low Power Mode (LP_MODE) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/FINAL_COLD	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Undershunt Protection (UNDERSHUNT_PROTECTION) Tuning (TUNING) Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Data Transmission (DATA_TRANSMISSION) Cold startup (COLD_STARTUP)
MODULE/FINAL_METROLOGY	Data Transmission (DATA_TRANSMISSION) ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) SLDO (SLDO) Injection Capacitance (INJECTION_CAPACITANCE) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Injection Capacitance (INJECTION_CAPACITANCE) Analog Readback (ANALOG_READBACK)
MODULE/QC_STATUS
MODULE/UNHAPPY	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) Data Transmission (DATA_TRANSMISSION) VCAL Calibration (VCAL_CALIBRATION) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) Injection Capacitance (INJECTION_CAPACITANCE)
MODULE/NOTCONSIDEREDINYIELDS	ADC Calibration (ADC_CALIBRATION) VCAL Calibration (VCAL_CALIBRATION) SLDO (SLDO) Undershunt Protection (UNDERSHUNT_PROTECTION) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Analog Readback (ANALOG_READBACK) Overvoltage Protection (OVERVOLTAGE_PROTECTION) Low Power Mode (LP_MODE) Injection Capacitance (INJECTION_CAPACITANCE) Data Transmission (DATA_TRANSMISSION)
MODULE/GRAVEYARD
MODULE/COMPLETE
MODULE/RECEPTION	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Data Transmission (DATA_TRANSMISSION) Tuning (TUNING)
MODULE/TAB_CUTTING	Minimal Health Test (MIN_HEALTH_TEST)
LLS/PRE_TC_WARM	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Low Power Mode (LP_MODE) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
LLS/PRE_TC_COLD	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
LLS/POST_TC_WARM	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
LLS/POST_TC_COLD	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
LLS/RECEPTION	Minimal Health Test (MIN_HEALTH_TEST) Analog Readback (ANALOG_READBACK) SLDO (SLDO) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
OB_LOADED_MODULE_CELL/INIT
OB_LOADED_MODULE_CELL/ASSEMBLY
OB_LOADED_MODULE_CELL/THERMAL_CYCLES
OB_LOADED_MODULE_CELL/FINAL_WARM	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
OB_LOADED_MODULE_CELL/FINAL_COLD	ADC Calibration (ADC_CALIBRATION) Analog Readback (ANALOG_READBACK) SLDO (SLDO) VCAL Calibration (VCAL_CALIBRATION) Injection Capacitance (INJECTION_CAPACITANCE) Low Power Mode (LP_MODE) Data Transmission (DATA_TRANSMISSION) Minimal Health Test (MIN_HEALTH_TEST) Tuning (TUNING) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS)
OB_LOADED_MODULE_CELL/THERMAL_COLD
OB_LOADED_MODULE_CELL/THERMAL_WARM
OB_LOADED_MODULE_CELL/ENVELOPE_CHECK
OB_LOADED_MODULE_CELL/QC_STATUS
OB_LOADED_MODULE_CELL/UNHAPPY
OB_LOADED_MODULE_CELL/COMPLETE
OB_LOADED_MODULE_CELL/RECEPTION	Minimal Health Test (MIN_HEALTH_TEST) Pixel Failure Analysis (PIXEL_FAILURE_ANALYSIS) SLDO (SLDO)
OB_LOADED_MODULE_CELL/TAB_CUTTING	Minimal Health Test (MIN_HEALTH_TEST)
OB_LOADED_MODULE_CELL/PIGTAIL_INSERTION
TEST_AFTER_LOADED_LOCAL_SUPPORT_ASSEMBLY	OB:Loaded local support QC electrical connectivity (OBLoadedLocalSupportQC_ElectricalConnectivity) OB:Loaded local support QC electrical performance (OBLoadedLocalSupportQC_ElectricalPerformance) OB:Loaded local support reception at the integration site (OBLoadedLocalSupport_IntegrationSite) OB:Loaded local support QC electrical low power (OBLoadedLocalSupport_QCElectricalLowPower)
TEST_JM_OEC_FE

20UPGFC0142426

MODULE/POST_PARYLENE_WARM

Component Information

Wafer

Properties

Comments

Test: ANALOG_READBACK QC Passed

(Stage: MODULE/POST_PARYLENE_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Results

Attachments

RAW Results Record

ProductionDB Record

Current Stage: Post-Parylene Warm

Candidate TestRuns of this Stage

Past QC Stages and Results

Wirebond Protection (alt) (MODULE/WIREBOND_PROTECTION)

Parylene Unmasking (MODULE/PARYLENE_UNMASKING)

Parylene Coating (MODULE/PARYLENE_COATING)

Parylene Masking (MODULE/PARYLENE_MASKING)

Initial Cold (MODULE/INITIAL_COLD)

QC cross-check (module swapping) (MODULE/QC_CROSSCHECK)

Initial Warm (MODULE/INITIAL_WARM)

Wire Bonding (MODULE/WIREBONDING)

Bare module to module PCB assembly (MODULE/ASSEMBLY)

Initial state to associate flex to bare module (MODULE/INIT)

Reception at ITk institute (BAREMODULERECEPTION)

Bare module assembly (BAREMODULEASSEMBLY)

Not to be used for detector (UNUSABLE)

Hybridisation (HYBRIDISATION)

Testing on wafer (TESTONWAFER)

All Registered QC Tests

All YARR Scans

Config Revisions

Stage: MODULE/POST_PARYLENE_WARM

Mode: warm

Mode: cold

Mode: LP

Check QC Flow

Back to top page of this component
