20UPGFC0142213

MODULE/FINAL_WARM

Component Information

Serial Number	20UPGFC0142213
ProdDB ID	5c7256…5efefb
LocalDB ID	660d7cadec873d0035450fdb
Component Type	fe_chip
Parents	20UPGM23210292 20UPGB43200160
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Wafer serial number	None
Target Iref trim	None
Target Iref trim version	None

Comments

Test: ANALOG_READBACK QC Passed

(Stage: MODULE/FINAL_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	a week ago
component ObjectId	660d7cadec873d0035450fdb
Stage	MODULE/FINAL_WARM
Test Type	ANALOG_READBACK
Institute ObjectId
User Name	None
ObjectId of this record	6a28b5e13b97c76890e92562
ObjectId of RAW record	6a28b5d93b97c76890e9253f
Tags	titan_4

Results

Key	Data
DCSdata	{}
MEASUREMENT_VERSION	2.8.0
QC_LAYER	L2
INSTITUTION	LBNL_PIXEL_MODULES
AR_TEMP_NTC	21.018
AR_TEMP_EXT	20.002
AR_TEMP_ASLDO	30.982
AR_TEMP_DSLDO	33.075
AR_TEMP_ACB	29.976
AR_TEMP_NF_ASLDO	1.261
AR_TEMP_NF_DSLDO	1.261
AR_TEMP_NF_ACB	1.26
AR_TEMP_POLY_TOP	-999
AR_TEMP_POLY_BOTTOM	-999
AR_TEMP_NF_TOP	-999
AR_TEMP_NF_BOTTOM	-999
AR_IREF	3.8e-06
AR_GADC	0.803
AR_VCALDAC	0.81
AR_VREFCORE	0.461
AR_VREFOVP	1.983
AR_NOMINAL_SETTINGS	[3.8e-06, 8.65e-05, 4.65e-05, 4e-06, 3.92e-05, 2e-05, -0.0, 3.93e-05, 6.92e-05, -999, -0.0, -0.0, 4.56e-05, 6.38e-05, 5.03e-05, 8.54e-05, 6.39e-05, 7.66e-05, 8.66e-05, 8.54e-05, 6.68e-05, 4.72e-05, 4.76e-05, 6.59e-05, 4.79e-05, 4.83e-05, -999, -999, 0.6348075, 0.0751808, 0.9064553, 0.6591196, 0.8028946, -999, -999, 0.8095472, 1.2090232, 1.2101196, 0.1106776, 0.0809923, 0.0380533, 0.0404163, 0.2437586, 0.2501706, 0.2467126, 0.6244466, -999, 0.6211136, -999, 0.5876366, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, 0.0176004, 0.4614866, 1.9834233, 1.5027824, 1.2092032, 0.6001256, 0.9845704, 1.5068904, 1.2031432, 0.5944256]
AR_VDDA_VS_TRIM	[0.988, 1.014, 1.038, 1.062, 1.087, 1.112, 1.135, 1.159, 1.185, 1.209, 1.232, 1.256, 1.28, 1.306, 1.328, 1.352]
AR_VDDD_VS_TRIM	[1.012, 1.037, 1.061, 1.085, 1.107, 1.131, 1.155, 1.18, 1.204, 1.229, 1.252, 1.278, 1.299, 1.325, 1.35, 1.377]
AR_VDDA_TRIM	9
AR_VDDD_TRIM	8
AR_ROSC_SLOPE	[744.078283451478, 1153.5984570954877, 742.1895899485882, 1163.214921670169, 814.5718851018283, 1386.2485368303073, 972.1414998280047, 1428.6629350311443, 1168.6748488181915, 1158.1251858539663, 1363.6913357431972, 1365.088495293411, 1195.1356921360195, 1192.905972561365, 1373.27101244402, 1374.9919244589678, 1374.5969854894822, 1344.8178272586558, 1629.317316194081, 1622.1511661766167, 1366.8598165673225, 1355.5487498587477, 1677.7093948701888, 1689.9286361150334, 848.1367770758904, 833.972121269908, 1020.5748306395271, 1017.2494275476745, 1014.6224272586197, 1011.0909667820082, 1148.5188656699281, 1212.1933463785906, 1128.488583343229, 1203.20297506569, 1562.1716842227765, 1555.8010522722934, 1562.4526047771458, 1573.3199317015699, 1558.1620368860295, 1561.2302844663132, 1559.4703556625054, 1565.8057100137341]
AR_ROSC_OFFSET	[-414.8595344660418, -644.9684757763979, -437.26143181159534, -666.6990458883738, -529.0473513189193, -904.7808090412863, -663.7145126619124, -957.9034648887429, -685.7602566200871, -679.7711176080326, -790.2973862758382, -801.5296249006537, -729.9493872758417, -719.194533065283, -818.4300851799079, -812.7026008010928, -918.2192431694991, -896.5271214944125, -1073.4979141017307, -1073.9896427210012, -931.7463808492128, -919.7491708423619, -1136.632600003757, -1134.2955993308246, -526.9708196658395, -519.3371377500647, -638.0109561062054, -638.9161371121407, -634.1290701329799, -632.367643362888, -536.8567701419471, -549.8165385247273, -600.294750094055, -636.0742380207543, -1032.2903279215398, -1029.2177479124302, -1042.4290884223724, -1034.8466811130243, -1035.2157666349622, -1029.9207910194784, -1025.7641211081666, -1027.7436934803266]
AR_ROSC_MAX_RESIDUAL	[3.108052738877448, 4.78134017588313, 2.8657990885487203, 5.016850012304699, 1.9141506925776042, 3.432435981644522, 2.063874878304682, 3.3363535392484627, 4.56287160134939, 4.409361681336102, 5.476463667262276, 5.624526218420231, 3.9993094050019042, 4.276311122377663, 4.828429010157073, 4.838633573020876, 3.19017442753412, 2.8172606733915107, 3.4855700848040363, 3.4935938530806716, 2.854733869052984, 3.074668225523761, 3.4793370558325964, 3.93940855153198, 2.374970349510779, 2.4490306448896773, 2.894838658906222, 2.6459951186553785, 3.0291603376543548, 2.8680218010574876, 5.696543521932693, 6.018434241726397, 4.470225121558709, 4.8784122377036505, 3.6066319778825267, 3.4585739556201265, 3.425488722364676, 3.1057220253171196, 3.30738395054169, 3.3952144589351905, 3.67339500755265, 3.656856234234595]
AR_VDDD_SATURATION	-1.0
AR_VDDA_SATURATION	-1.0
AR_IREF_TRIM	7
ANALYSIS_VERSION	mqat v2.9.0
YARR_VERSION	v1.6.0
MEASUREMENT_DATE	2026-06-10T00:10:53.000+00:00
MEASUREMENT_DURATION	377
