Database for ITk Pixel Module

Serial Number	20UPGFC0141785
ProdDB ID	852e13…07d605
LocalDB ID	660d23755d9bdc0035fd9434
Component Type	fe_chip
Parents	20UPGM24211044 20UPGB43200222
Children	No match.
Flags

Item	Value
Target Iref trim	11
Target Iref trim version	1
Wafer serial number	None

Key	Data
QC Passed	True
Date	3 months ago
component ObjectId	660d23755d9bdc0035fd9434
Stage	MODULE/INITIAL_WARM
Test Type	TUNING
Institute ObjectId
User Name	DavidJiang
ObjectId of this record	68dc53f112752b66da90e3d1
ObjectId of RAW record	None
Tags	No tags

Key	Data
ANALYSIS_VERSION	mqat v2.6.4
MEASUREMENT_DATE	2025-09-30T21:32:03.000+00:00
MEASUREMENT_DURATION	665
MEASUREMENT_VERSION	None
YARR_VERSION	v1.5.5
TUNING_TUNED_NOISE_95_HIGH	123.546
TUNING_TUNED_NOISE_95_LOW	81.973
TUNING_TUNED_NOISE_MEAN	102.119
TUNING_TUNED_NOISE_SIGMA	10.982
TUNING_TUNED_TDAC_MEAN	-1.2
TUNING_TUNED_TDAC_SIGMA	4.036
TUNING_TUNED_THRESHOLD_95_HIGH	1565.776
TUNING_TUNED_THRESHOLD_95_LOW	1436.422
TUNING_TUNED_THRESHOLD_FAILED_FITS	1
TUNING_TUNED_THRESHOLD_MEAN	1503.2
TUNING_TUNED_THRESHOLD_SIGMA	34
TUNING_TUNED_TOT_95_HIGH	10.06
TUNING_TUNED_TOT_95_LOW	5.08
TUNING_TUNED_TOT_MEAN	7.3
TUNING_TUNED_TOT_SIGMA	0.3
TUNING_UNTUNED_NOISE_95_HIGH	120.436
TUNING_UNTUNED_NOISE_95_LOW	80.757
TUNING_UNTUNED_NOISE_MEAN	99.98
TUNING_UNTUNED_NOISE_SIGMA	10.806
TUNING_UNTUNED_TDAC_MEAN	0
TUNING_UNTUNED_TDAC_SIGMA	0
TUNING_UNTUNED_THRESHOLD_95_HIGH	2926.138
TUNING_UNTUNED_THRESHOLD_95_LOW	1740.31
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	58
TUNING_UNTUNED_THRESHOLD_MEAN	2308.574
TUNING_UNTUNED_THRESHOLD_SIGMA	303

Filename	Contents
0x229d9_L2_warm.json	Download
output.log	Download
0x229d9.log	Download
20UPGFC0141785_MODULE__INITIAL_WARM_TUNING.zip	Download
