Component Information

Serial Number 20UPGFC0141720
ProdDB ID  fb475e…ee95d8
LocalDB ID 660d232deeb7490035a47187
Component Type fe_chip
Parents 20UPGM24211150  20UPGB43200224 
Children No match.
Flags
Wafer
  Wafer Probing

 Properties

Item Value
Target Iref trim 6
Target Iref trim version 1
Wafer serial number None

 Comments

Scan Result: std_discbumpscan / run 1133 (Stage: MODULE/FINAL_COLD)
(ObjectId: 660d232deeb7490035a47187)


Result Plots

EnMask

OccupancyMap

MeanTotMap-0

SigmaTotMap-0

MeanTotDist-0

SigmaTotDist-0

TagDist

MeanTagMap-0


Details

Scan

Key Data
runNumber 1133
testType std_discbumpscan
stage MODULE/FINAL_COLD
component 20UPGM24211150
20UPGFC0141755
20UPGFC0141626
20UPGFC0141734
20UPGFC0141720
startTime 2026-05-13 20:13:13
finishTime 2026-05-13 20:14:48
user pixqc
site jittereel.dhcp.lbl.gov
targetCharge -1
targetTot -1
FeDataProcessorLog 0x2293a: {'Any errors': 0, 'Chip tag bitflips': 0, 'Chip unrecognized tags': 0, 'Corrupt streams': 0, 'Split events count': 0, 'Unfinished streams (no EOS)': 0, 'Unfinished streams (w/ EOS)': 0}
0x22998: {'Any errors': 0, 'Chip tag bitflips': 0, 'Chip unrecognized tags': 0, 'Corrupt streams': 0, 'Split events count': 0, 'Unfinished streams (no EOS)': 0, 'Unfinished streams (w/ EOS)': 0}
0x229a6: {'Any errors': 1, 'Chip tag bitflips': 0, 'Chip unrecognized tags': 0, 'Corrupt streams': 0, 'Split events count': 0, 'Unfinished streams (no EOS)': 1, 'Unfinished streams (w/ EOS)': 0}
0x229bb: {'Any errors': 2, 'Chip tag bitflips': 0, 'Chip unrecognized tags': 0, 'Corrupt streams': 0, 'Split events count': 1, 'Unfinished streams (no EOS)': 2, 'Unfinished streams (w/ EOS)': 0}
ctrlStatus channel_configuration: 16x1
fe_chip_type: RD53A/B/C
firmware_hash: 0x7b14549
firmware_identifier: 0x1030242
firmware_vers: v1.5.0
fmc_card_type: Ohio Card (Display Port)
fpga_card: Trenz TEF1001_R1
lpm_status: 0
rx_speed: 1280Mbps
exec -r /opt/local/pixqc/common_configs/specCfg-rd53b-16x1-setup3.json -c /opt/local/pixqc/20UPGM24211150/20UPGM24211150_L2_cold.json -o /opt/local/pixqc/20UPGM24211150/data -W PFA -s /opt/local/pixqc/qc_software/YARR/configs/scans/itkpixv2/std_discbumpscan.json
stopwatch analysis: 478
config: 1168
processing: 0
scan: 86886
yarr_version build_flags:
build_time: 2026-03-06 00:03:45 UTC
build_type:
git_branch: HEAD
git_date: 2026-03-02 18:18:35 +0000
git_hash: ceab17cbc44ec321798e7456f1368aa297f71f91
git_subject: Merge branch 'yarr_version_update' into 'master'
git_tag: v1.5.6
QC False
