Component Information

Serial Number	20UPGFC0141720
ProdDB ID	fb475e…ee95d8
LocalDB ID	660d232deeb7490035a47187
Component Type	fe_chip
Parents	20UPGM24211150 20UPGB43200224
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Target Iref trim	6
Target Iref trim version	1
Wafer serial number	None

Comments

Test: PIXEL_FAILURE_ANALYSIS QC Passed

(Stage: MODULE/FINAL_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	a month ago
component ObjectId	660d232deeb7490035a47187
Stage	MODULE/FINAL_WARM
Test Type	PIXEL_FAILURE_ANALYSIS
Institute ObjectId
User Name	None
ObjectId of this record	6a03e49cdc6089db7173ba08
ObjectId of RAW record	None
Tags	No tags

Results

Key	Data
DCSdata	{}
QC_LAYER	L2
PIXEL_FAILURE_ANY_ERRORS	{'digitalscan': 0, 'analogscan': 0, 'thresholdscan_hd': 0, 'noisescan': 0, 'mergedbumpscan': 0, 'discbumpscan': 0, 'all': 0}
PIXEL_FAILURE_SOURCE_SCAN_DONE	False
PIXEL_FAILURE_COLUMN_DISABLED	0
PIXEL_FAILURE_DEAD_DIGITAL	0
PIXEL_FAILURE_BAD_DIGITAL	0
PIXEL_FAILURE_DEAD_ANALOG	0
PIXEL_FAILURE_BAD_ANALOG	1
PIXEL_FAILURE_TUNING_BAD	2
PIXEL_FAILURE_HIGH_ENC	0
PIXEL_FAILURE_HIGH_NOISE	1
PIXEL_FAILURE_MERGED_BUMPS	0
PIXEL_FAILURE_DISCONNECTED_BUMPS_ZERO_BIAS_SCAN	-1
PIXEL_FAILURE_DISCONNECTED_BUMPS_XTALK_SCAN	0
PIXEL_FAILURE_DISCONNECTED_BUMPS_SOURCE_SCAN	-1
PIXEL_FAILURE_ELECTRICALLY_FAILED	4
PIXEL_FAILURE_DISCONNECTED_PIXELS	0
PIXEL_FAILURE_DISC_PIXEL_ALL_ELEC	0
PIXEL_FAILURE_FAILING_PIXELS	4
ANALYSIS_VERSION	mqat v2.8.1
YARR_VERSION	v1.5.6
MEASUREMENT_DATE	2026-05-13T07:46:28.000+00:00
MEASUREMENT_DURATION	678

Attachments

Filename	Contents
output.log	Download
0x22998.log	Download
20UPGFC0141720_MODULE__FINAL_WARM_PIXEL-FAILURE-ANALYSIS.zip	Download
