Database for ITk Pixel Module

Serial Number	20UPGFC0141720
ProdDB ID	fb475e…ee95d8
LocalDB ID	660d232deeb7490035a47187
Component Type	fe_chip
Parents	20UPGM24211150 20UPGB43200224
Children	No match.
Flags

Item	Value
Target Iref trim	6
Target Iref trim version	1
Wafer serial number	None

Key	Data
QC Passed	True
Date	a month ago
component ObjectId	660d232deeb7490035a47187
Stage	MODULE/POST_PARYLENE_WARM
Test Type	PIXEL_FAILURE_ANALYSIS
Institute ObjectId
User Name	Simpson,Liana Rae
ObjectId of this record	691b7453d7bf966e0aaef9e7
ObjectId of RAW record	None
Tags	No tags

Key	Data
ANALYSIS_VERSION	mqat v2.7.1
MEASUREMENT_DATE	2025-10-31T21:48:27.000+00:00
MEASUREMENT_DURATION	500
YARR_VERSION	v1.5.5
PIXEL_FAILURE_BAD_ANALOG	0
PIXEL_FAILURE_BAD_DIGITAL	0
PIXEL_FAILURE_COLUMN_DISABLED	0
PIXEL_FAILURE_DEAD_ANALOG	0
PIXEL_FAILURE_DEAD_DIGITAL	0
PIXEL_FAILURE_DISCONNECTED_BUMPS_SOURCE_SCAN	-1
PIXEL_FAILURE_DISCONNECTED_BUMPS_XTALK_SCAN	0
PIXEL_FAILURE_DISCONNECTED_BUMPS_ZERO_BIAS_SCAN	-1
PIXEL_FAILURE_DISCONNECTED_PIXELS	0
PIXEL_FAILURE_DISC_PIXEL_ALL_ELEC	0
PIXEL_FAILURE_ELECTRICALLY_FAILED	4
PIXEL_FAILURE_FAILING_PIXELS	4
PIXEL_FAILURE_HIGH_ENC	0
PIXEL_FAILURE_HIGH_NOISE	2
PIXEL_FAILURE_MERGED_BUMPS	0
PIXEL_FAILURE_SOURCE_SCAN_DONE	False
PIXEL_FAILURE_TUNING_BAD	2

Filename	Contents
output.log	Download
0x22998.log	Download
20UPGFC0141720_MODULE__POST_PARYLENE_WARM_PIXEL-FAILURE-ANALYSIS.zip	Download

Expand ProductionDB Record
