Database for ITk Pixel Module

Serial Number	20UPGFC0141704
ProdDB ID	6c6e84…1f5592
LocalDB ID	660d23185d9bdc0035fd939b
Component Type	fe_chip
Parents	20UPGM24211149 20UPGB43200223
Children	No match.
Flags

Item	Value
Target Iref trim	11
Target Iref trim version	1
Wafer serial number	None

Key	Data
QC Passed	True
Date	2 months ago
component ObjectId	660d23185d9bdc0035fd939b
Stage	MODULE/INITIAL_WARM
Test Type	ADC_CALIBRATION
Institute ObjectId
User Name	DanielAceves
ObjectId of this record	68dd8afb12752b66da90ecfd
ObjectId of RAW record	68dd8af912752b66da90ecf6
Tags	No tags

Key	Data
ANALYSIS_VERSION	mqat v2.6.4
MEASUREMENT_DATE	2025-10-01T18:09:27.000+00:00
MEASUREMENT_DURATION	95
MEASUREMENT_VERSION	2.6.0
YARR_VERSION	v1.5.5
ADC_ANAGND30_MEAN	0.017
ADC_ANAGND30_STD	3.469446951953614e-18
ADC_CALIBRATION_LINEARITY	0.3
ADC_CALIBRATION_OFFSET	10
ADC_CALIBRATION_SLOPE	0.2

Filename	Contents
output.log	Download

_id

68dd8af912752b66da90ecf6

raw

serialNumber

testType

runNumber

results

subtestType

stage

component

dbVersion
