20UPGFC0141683

MODULE/POST_PARYLENE_WARM

Component Information

Serial Number 20UPGFC0141683
ProdDB ID  a2e1f8…49d4bb
LocalDB ID 660d2308eeb7490035a47137
Component Type fe_chip
Parents 20UPGM23211302  20UPGB43200210 
Children No match.
Flags
Wafer
  Wafer Probing

 Properties

Item Value
Wafer serial number None
Target Iref trim None
Target Iref trim version None

 Comments


Test: PIXEL_FAILURE_ANALYSIS QC Passed

(Stage: MODULE/POST_PARYLENE_WARM)


Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key Data
QC Passed True
Date 3 months ago
component ObjectId 660d2308eeb7490035a47137
Stage MODULE/POST_PARYLENE_WARM
Test Type PIXEL_FAILURE_ANALYSIS
Institute ObjectId
User Name None
ObjectId of this record 68b9e566f3be1a579225543c
ObjectId of RAW record None
Tags No tags

Results

Key Data
DCSdata {}
QC_LAYER L2
PIXEL_FAILURE_SOURCE_SCAN_DONE False
PIXEL_FAILURE_COLUMN_DISABLED 3072
PIXEL_FAILURE_DEAD_DIGITAL 0
PIXEL_FAILURE_BAD_DIGITAL 0
PIXEL_FAILURE_DEAD_ANALOG 0
PIXEL_FAILURE_BAD_ANALOG 2
PIXEL_FAILURE_TUNING_BAD 10
PIXEL_FAILURE_HIGH_ENC 3
PIXEL_FAILURE_HIGH_NOISE 1
PIXEL_FAILURE_MERGED_BUMPS 0
PIXEL_FAILURE_DISCONNECTED_BUMPS_ZERO_BIAS_SCAN -1
PIXEL_FAILURE_DISCONNECTED_BUMPS_XTALK_SCAN 0
PIXEL_FAILURE_DISCONNECTED_BUMPS_SOURCE_SCAN -1
PIXEL_FAILURE_ELECTRICALLY_FAILED 3088
PIXEL_FAILURE_DISCONNECTED_PIXELS 0
PIXEL_FAILURE_DISC_PIXEL_ALL_ELEC 3072
PIXEL_FAILURE_FAILING_PIXELS 3088
ANALYSIS_VERSION mqat v2.6.4
YARR_VERSION v1.5.5
MEASUREMENT_DATE 2025-09-04T14:08:47.000+00:00
MEASUREMENT_DURATION 2781
