20UPGFC0141676

MODULE/FINAL_COLD

Component Information

Serial Number 20UPGFC0141676
ProdDB ID  f82a19…1efbc6
LocalDB ID 660d22c9eeb7490035a4709f
Component Type fe_chip
Parents 20UPGM24210397  20UPGB43200228 
Children No match.
Flags
Wafer
  Wafer Probing

 Properties

Item Value
Target Iref trim 6
Target Iref trim version 1
Wafer serial number None

 Comments

Date Commented by on which Component Comment
2 days ago pixel (Lawrence Berkeley National Lab - pixel modules) MODULE
20UPGM24210397 		sign-off at MODULE/FINAL_WARM; appended flags: []; next stage: MODULE/FINAL_COLD; comment: Failed LP mode. Want to investigate further.

Test: MIN_HEALTH_TEST QC Passed

(Stage: MODULE/FINAL_COLD)


Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key Data
QC Passed True
Date a day ago
component ObjectId 660d22c9eeb7490035a4709f
Stage MODULE/FINAL_COLD
Test Type MIN_HEALTH_TEST
Institute ObjectId
User Name None
ObjectId of this record 6a2ae2993437adbb7d745839
ObjectId of RAW record None
Tags No tags

Results

Key Data
DCSdata {}
QC_LAYER L2
MIN_HEALTH_ANY_ERRORS {'digitalscan': 0, 'analogscan': 1, 'thresholdscan_hr': 287, 'totscan': 2, 'all': 290}
MIN_HEALTH_THRESHOLD_MEAN 2366.93
MIN_HEALTH_THRESHOLD_SIGMA 377.77
MIN_HEALTH_NOISE_MEAN 91.17
MIN_HEALTH_NOISE_SIGMA 11.39
MIN_HEALTH_TOT_MEAN 10.28
MIN_HEALTH_TOT_SIGMA 2.46
MIN_HEALTH_COLUMN_DISABLED 0
MIN_HEALTH_DEAD_DIGITAL 0
MIN_HEALTH_BAD_DIGITAL 0
MIN_HEALTH_DEAD_ANALOG 1
MIN_HEALTH_BAD_ANALOG 0
MIN_HEALTH_THRESHOLD_FAILED_FITS 208
MIN_HEALTH_HIGH_ENC 7
MIN_HEALTH_BAD_ANALOG_INTEGRATED 1
MIN_HEALTH_THRESHOLD_FAILED_FITS_INDEPENDENT 209
MIN_HEALTH_HIGH_ENC_INDEPENDENT 7
ANALYSIS_VERSION mqat v2.9.0
YARR_VERSION v1.6.0
MEASUREMENT_DATE 2026-06-11T11:45:08.000+00:00
MEASUREMENT_DURATION 369

Attachments

Filename Contents
output.log Download
0x2296c.log Download
20UPGFC0141676_MODULE__FINAL_COLD_MIN-HEALTH-TEST.zip Download
