20UPGFC0141676

MODULE/FINAL_COLD

Component Information

Serial Number 20UPGFC0141676
ProdDB ID  f82a19…1efbc6
LocalDB ID 660d22c9eeb7490035a4709f
Component Type fe_chip
Parents 20UPGM24210397  20UPGB43200228 
Children No match.
Flags
Wafer
  Wafer Probing

 Properties

Item Value
Target Iref trim 6
Target Iref trim version 1
Wafer serial number None

 Comments

Date Commented by on which Component Comment
2 days ago pixel (Lawrence Berkeley National Lab - pixel modules) MODULE
20UPGM24210397 		sign-off at MODULE/FINAL_WARM; appended flags: []; next stage: MODULE/FINAL_COLD; comment: Failed LP mode. Want to investigate further.

Test: TUNING QC Passed

(Stage: MODULE/FINAL_COLD)


Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key Data
QC Passed True
Date a day ago
component ObjectId 660d22c9eeb7490035a4709f
Stage MODULE/FINAL_COLD
Test Type TUNING
Institute ObjectId
User Name None
ObjectId of this record 6a2ae2792da0f186923e1681
ObjectId of RAW record None
Tags No tags
Tuning Config Associated FE Config

Results

Key Data
DCSdata {}
QC_LAYER L2
TUNING_UNTUNED_THRESHOLD_MEAN 2365.632
TUNING_UNTUNED_THRESHOLD_95_LOW 1682.578
TUNING_UNTUNED_THRESHOLD_95_HIGH 3168.2
TUNING_UNTUNED_THRESHOLD_SIGMA 377.751
TUNING_UNTUNED_TDAC_MEAN 0.0
TUNING_UNTUNED_TDAC_SIGMA 0.0
TUNING_UNTUNED_NOISE_MEAN 91.064
TUNING_UNTUNED_NOISE_SIGMA 11.424
TUNING_UNTUNED_NOISE_95_LOW 71.459
TUNING_UNTUNED_NOISE_95_HIGH 113.061
TUNING_UNTUNED_THRESHOLD_FAILED_FITS 163
TUNING_TUNED_THRESHOLD_MEAN 1497.2
TUNING_TUNED_THRESHOLD_95_LOW 1429.661
TUNING_TUNED_THRESHOLD_95_HIGH 1559.737
TUNING_TUNED_THRESHOLD_SIGMA 37.0
TUNING_TUNED_TDAC_MEAN -1.1
TUNING_TUNED_TDAC_SIGMA 4.703
TUNING_TUNED_NOISE_MEAN 91.437
TUNING_TUNED_NOISE_SIGMA 10.944
TUNING_TUNED_NOISE_95_LOW 71.805
TUNING_TUNED_NOISE_95_HIGH 113.306
TUNING_TUNED_TOT_MEAN 7.5
TUNING_TUNED_TOT_SIGMA 0.3
TUNING_TUNED_TOT_95_LOW 5.0
TUNING_TUNED_TOT_95_HIGH 11.22
TUNING_TUNED_THRESHOLD_FAILED_FITS 4
TUNING_ANY_ERRORS {'tune_globalthreshold': 6, 'thresholdscan_hr': 378, 'tune_pixelthreshold': 37, 'thresholdscan_hd': 54, 'totscan': 0, 'all': 475}
ANALYSIS_VERSION mqat v2.9.0
YARR_VERSION v1.6.0
MEASUREMENT_DATE 2026-06-11T12:07:46.000+00:00
MEASUREMENT_DURATION 662
