20UPGFC0141672

MODULE/COMPLETE

Component Information

Serial Number	20UPGFC0141672
ProdDB ID	fbff2f…d2706b
LocalDB ID	660d22c1eeb7490035a47078
Component Type	fe_chip
Parents	20UPGM24211044 20UPGB43200222
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Target Iref trim	8
Target Iref trim version	1
Wafer serial number	None

Comments

Test: TUNING QC Passed

(Stage: MODULE/POST_PARYLENE_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	a month ago
component ObjectId	660d22c1eeb7490035a47078
Stage	MODULE/POST_PARYLENE_WARM
Test Type	TUNING
Institute ObjectId
User Name	DavidJiang
ObjectId of this record	691b59eed7bf966e0aaef407
ObjectId of RAW record	None
Tags	No tags

Results

Key	Data
ANALYSIS_VERSION	mqat v2.7.1
MEASUREMENT_DATE	2025-10-30T19:41:09.000+00:00
MEASUREMENT_DURATION	867
YARR_VERSION	v1.5.5
TUNING_TUNED_NOISE_95_HIGH	127.308
TUNING_TUNED_NOISE_95_LOW	85.895
TUNING_TUNED_NOISE_MEAN	105.908
TUNING_TUNED_NOISE_SIGMA	11.059
TUNING_TUNED_TDAC_MEAN	-1.3
TUNING_TUNED_TDAC_SIGMA	4.156
TUNING_TUNED_THRESHOLD_95_HIGH	1564.424
TUNING_TUNED_THRESHOLD_95_LOW	1431.468
TUNING_TUNED_THRESHOLD_FAILED_FITS	3
TUNING_TUNED_THRESHOLD_MEAN	1500.1
TUNING_TUNED_THRESHOLD_SIGMA	36
TUNING_TUNED_TOT_95_HIGH	10.19
TUNING_TUNED_TOT_95_LOW	5.27
TUNING_TUNED_TOT_MEAN	7.5
TUNING_TUNED_TOT_SIGMA	0.3
TUNING_UNTUNED_NOISE_95_HIGH	124.719
TUNING_UNTUNED_NOISE_95_LOW	84.341
TUNING_UNTUNED_NOISE_MEAN	103.749
TUNING_UNTUNED_NOISE_SIGMA	11.196
TUNING_UNTUNED_TDAC_MEAN	0
TUNING_UNTUNED_TDAC_SIGMA	0
TUNING_UNTUNED_THRESHOLD_95_HIGH	2887.297
TUNING_UNTUNED_THRESHOLD_95_LOW	1640.742
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	66
TUNING_UNTUNED_THRESHOLD_MEAN	2236.099
TUNING_UNTUNED_THRESHOLD_SIGMA	316.905

Attachments

Filename	Contents
0x22968_L2_warm.json	Download
output.log	Download
0x22968.log	Download
20UPGFC0141672_MODULE__POST_PARYLENE_WARM_TUNING.zip	Download
