20UPGFC0141644

MODULE/QC_STATUS

Component Information

Serial Number	20UPGFC0141644
ProdDB ID	130d53…64afe1
LocalDB ID	660d2294eeb7490035a47028
Component Type	fe_chip
Parents	20UPGM24210028 20UPGB43200226
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Target Iref trim	5
Target Iref trim version	1
Wafer serial number	None

Comments

Test: MIN_HEALTH_TEST QC Passed

(Stage: MODULE/FINAL_COLD)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	4 weeks ago
component ObjectId	660d2294eeb7490035a47028
Stage	MODULE/FINAL_COLD
Test Type	MIN_HEALTH_TEST
Institute ObjectId
User Name	None
ObjectId of this record	6a05ff4a8d85d0e79d6cd5aa
ObjectId of RAW record	None
Tags	No tags

Results

Key	Data
DCSdata	{}
QC_LAYER	L2
MIN_HEALTH_ANY_ERRORS	{'digitalscan': 0, 'analogscan': 6, 'thresholdscan_hr': 1642, 'totscan': 27, 'all': 1675}
MIN_HEALTH_THRESHOLD_MEAN	2435.35
MIN_HEALTH_THRESHOLD_SIGMA	379.34
MIN_HEALTH_NOISE_MEAN	91.65
MIN_HEALTH_NOISE_SIGMA	12.02
MIN_HEALTH_TOT_MEAN	10.22
MIN_HEALTH_TOT_SIGMA	2.48
MIN_HEALTH_COLUMN_DISABLED	0
MIN_HEALTH_DEAD_DIGITAL	0
MIN_HEALTH_BAD_DIGITAL	0
MIN_HEALTH_DEAD_ANALOG	1
MIN_HEALTH_BAD_ANALOG	435
MIN_HEALTH_THRESHOLD_FAILED_FITS	286
MIN_HEALTH_HIGH_ENC	5
MIN_HEALTH_BAD_ANALOG_INTEGRATED	436
MIN_HEALTH_THRESHOLD_FAILED_FITS_INDEPENDENT	287
MIN_HEALTH_HIGH_ENC_INDEPENDENT	5
ANALYSIS_VERSION	mqat v2.8.1
YARR_VERSION	v1.5.6
MEASUREMENT_DATE	2026-05-14T09:06:37.000+00:00
MEASUREMENT_DURATION	471
