20UPGFC0141644

MODULE/QC_STATUS

Component Information

Serial Number	20UPGFC0141644
ProdDB ID	130d53…64afe1
LocalDB ID	660d2294eeb7490035a47028
Component Type	fe_chip
Parents	20UPGM24210028 20UPGB43200226
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Target Iref trim	5
Target Iref trim version	1
Wafer serial number	None

Comments

Test: TUNING QC Failed

(Stage: MODULE/FINAL_COLD)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	False
Date	4 weeks ago
component ObjectId	660d2294eeb7490035a47028
Stage	MODULE/FINAL_COLD
Test Type	TUNING
Institute ObjectId
User Name	None
ObjectId of this record	6a05ff380077847aebf6fc57
ObjectId of RAW record	None
Tags	No tags
Tuning Config	Associated FE Config

Results

Key	Data
DCSdata	{}
QC_LAYER	L2
TUNING_UNTUNED_THRESHOLD_MEAN	2435.392
TUNING_UNTUNED_THRESHOLD_95_LOW	1743.292
TUNING_UNTUNED_THRESHOLD_95_HIGH	3237.189
TUNING_UNTUNED_THRESHOLD_SIGMA	379.252
TUNING_UNTUNED_TDAC_MEAN	0.0
TUNING_UNTUNED_TDAC_SIGMA	0.0
TUNING_UNTUNED_NOISE_MEAN	91.592
TUNING_UNTUNED_NOISE_SIGMA	11.921
TUNING_UNTUNED_NOISE_95_LOW	72.02
TUNING_UNTUNED_NOISE_95_HIGH	114.895
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	301
TUNING_TUNED_THRESHOLD_MEAN	1496.5
TUNING_TUNED_THRESHOLD_95_LOW	1421.401
TUNING_TUNED_THRESHOLD_95_HIGH	1557.176
TUNING_TUNED_THRESHOLD_SIGMA	45.0
TUNING_TUNED_TDAC_MEAN	2.3
TUNING_TUNED_TDAC_SIGMA	5.296
TUNING_TUNED_NOISE_MEAN	92.121
TUNING_TUNED_NOISE_SIGMA	11.014
TUNING_TUNED_NOISE_95_LOW	72.748
TUNING_TUNED_NOISE_95_HIGH	113.899
TUNING_TUNED_TOT_MEAN	7.4
TUNING_TUNED_TOT_SIGMA	0.3
TUNING_TUNED_TOT_95_LOW	5.0
TUNING_TUNED_TOT_95_HIGH	11.07
TUNING_TUNED_THRESHOLD_FAILED_FITS	3
TUNING_ANY_ERRORS	{'tune_globalthreshold': 517, 'thresholdscan_hr': 1501, 'tune_pixelthreshold': 54, 'thresholdscan_hd': 170, 'totscan': 0, 'all': 2242}
ANALYSIS_VERSION	mqat v2.8.1
YARR_VERSION	v1.5.6
MEASUREMENT_DATE	2026-05-14T09:23:25.000+00:00
MEASUREMENT_DURATION	776

Attachments

Filename	Contents
output.log	Download
0x2294c.log	Download
20UPGFC0141644_MODULE__FINAL_COLD_TUNING.zip	Download
