20UPGFC0141644

MODULE/QC_STATUS

Component Information

Serial Number 20UPGFC0141644
ProdDB ID  130d53…64afe1
LocalDB ID 660d2294eeb7490035a47028
Component Type fe_chip
Parents 20UPGM24210028  20UPGB43200226 
Children No match.
Flags
Wafer
  Wafer Probing

 Properties

Item Value
Target Iref trim 5
Target Iref trim version 1
Wafer serial number None

 Comments

Scan Result: std_tune_globalthreshold / run 937 (Stage: MODULE/QC_CROSSCHECK)
(ObjectId: 660d2294eeb7490035a47028)


Result Plots

OccupancyMap-0

OccupancyDist-0

OccupancyMap-1

OccupancyDist-1

OccupancyMap-2

OccupancyDist-2

OccupancyMap-3

OccupancyDist-3

OccupancyMap-4

OccupancyDist-4

OccupancyMap-5

OccupancyDist-5

OccupancyMap-6

OccupancyDist-6

OccupancyMap-7

OccupancyDist-7

OccupancyMap-8

OccupancyDist-8

OccupancyMap-9

OccupancyDist-9

OccupancyMap-10

OccupancyDist-10

OccupancyMap-11

OccupancyDist-11

OccupancyMap-12

OccupancyDist-12

OccupancyMap-13

OccupancyDist-13

OccupancyMap-14

OccupancyDist-14

OccupancyMap-15

OccupancyDist-15

OccupancyMap-16

OccupancyDist-16

OccupancyMap-17

OccupancyDist-17

OccupancyMap-18

OccupancyDist-18

OccupancyMap-19

OccupancyDist-19


Details

Scan

Key Data
runNumber 937
testType std_tune_globalthreshold
stage MODULE/QC_CROSSCHECK
component 20UPGM24210028
20UPGFC0141644
20UPGFC0141658
20UPGFC0141766
20UPGFC0141752
startTime 2026-05-11 20:32:21
finishTime 2026-05-11 20:33:02
user pixqc
site jittereel.dhcp.lbl.gov
targetCharge 1700
targetTot -1
FeDataProcessorLog 0x2294c: {'Any errors': 166, 'Chip tag bitflips': 0, 'Chip unrecognized tags': 0, 'Corrupt streams': 84, 'Split events count': 31, 'Unfinished streams (no EOS)': 80, 'Unfinished streams (w/ EOS)': 2}
0x2295a: {'Any errors': 9, 'Chip tag bitflips': 0, 'Chip unrecognized tags': 0, 'Corrupt streams': 5, 'Split events count': 1, 'Unfinished streams (no EOS)': 4, 'Unfinished streams (w/ EOS)': 0}
0x229b8: {'Any errors': 1, 'Chip tag bitflips': 0, 'Chip unrecognized tags': 0, 'Corrupt streams': 1, 'Split events count': 0, 'Unfinished streams (no EOS)': 0, 'Unfinished streams (w/ EOS)': 0}
0x229c6: {'Any errors': 21, 'Chip tag bitflips': 0, 'Chip unrecognized tags': 0, 'Corrupt streams': 6, 'Split events count': 2, 'Unfinished streams (no EOS)': 15, 'Unfinished streams (w/ EOS)': 0}
ctrlStatus channel_configuration: 16x1
fe_chip_type: RD53A/B/C
firmware_hash: 0x7b14549
firmware_identifier: 0x1030242
firmware_vers: v1.5.0
fmc_card_type: Ohio Card (Display Port)
fpga_card: Trenz TEF1001_R1
lpm_status: 0
rx_speed: 1280Mbps
exec -r /opt/local/pixqc/common_configs/specCfg-rd53b-16x1-setup4.json -c /opt/local/pixqc/20UPGM24210028/20UPGM24210028_L2_warm.json -o /opt/local/pixqc/20UPGM24210028/data -W TUN -s /opt/local/pixqc/qc_software/YARR/configs/scans/itkpixv2/std_tune_globalthreshold.json -t 1700
stopwatch analysis: 802
config: 1169
processing: 0
scan: 32859
yarr_version build_flags:
build_time: 2026-03-06 00:03:45 UTC
build_type:
git_branch: HEAD
git_date: 2026-03-02 18:18:35 +0000
git_hash: ceab17cbc44ec321798e7456f1368aa297f71f91
git_subject: Merge branch 'yarr_version_update' into 'master'
git_tag: v1.5.6
QC False
environment False
plots
passed True
