20UPGFC0141635

MODULE/THERMAL_CYCLES

Component Information

Serial Number	20UPGFC0141635
ProdDB ID	ee064e…870071
LocalDB ID	660d2281eeb7490035a46fd2
Component Type	fe_chip
Parents	20UPGM23211331 20UPGB43200208
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Wafer serial number	None
Target Iref trim	None
Target Iref trim version	None

Comments

Test: ANALOG_READBACK QC Passed

(Stage: MODULE/POST_PARYLENE_WARM)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	a month ago
component ObjectId	660d2281eeb7490035a46fd2
Stage	MODULE/POST_PARYLENE_WARM
Test Type	ANALOG_READBACK
Institute ObjectId
User Name	None
ObjectId of this record	6902cfe260809c59eae8cce7
ObjectId of RAW record	6902cfda60809c59eae8ccc4
Tags	ganymede_4

Results

Key	Data
DCSdata	{}
MEASUREMENT_VERSION	2.7.0rc1.dev4
QC_LAYER	L2
INSTITUTION	LBNL_PIXEL_MODULES
AR_TEMP_NTC	17.463
AR_TEMP_EXT	19.953
AR_TEMP_ASLDO	29.689
AR_TEMP_DSLDO	31.534
AR_TEMP_ACB	29.391
AR_TEMP_NF_ASLDO	1.263
AR_TEMP_NF_DSLDO	1.263
AR_TEMP_NF_ACB	1.261
AR_TEMP_POLY_TOP	-999
AR_TEMP_POLY_BOTTOM	-999
AR_TEMP_NF_TOP	-999
AR_TEMP_NF_BOTTOM	-999
AR_IREF	3.8e-06
AR_GADC	0.789
AR_VCALDAC	0.791
AR_VREFCORE	0.463
AR_VREFOVP	1.967
AR_NOMINAL_SETTINGS	[3.8e-06, 8.25e-05, 4.5e-05, 3.8e-06, 3.81e-05, 1.86e-05, 0.0, 3.63e-05, 6.84e-05, -999, 0.0, 0.0, 4.53e-05, 6.28e-05, 5.01e-05, 8.35e-05, 6.25e-05, 7.33e-05, 8.27e-05, 8.35e-05, 6.4e-05, 4.81e-05, 4.5e-05, 6.45e-05, 4.75e-05, 4.65e-05, -999, -999, 0.6351992, 0.0826435, 0.9198352, 0.3247559, 0.7890569, -999, -999, 0.7906878, 1.2042178, 0.1106629, 0.1073729, 0.0381589, 0.0373, 0.0376975, 0.2322259, 0.2370079, 0.2402979, 0.6266909, -999, 0.6225929, -999, 0.5801649, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, -999, 0.0171851, 0.4633099, 1.9671572, 1.4918556, 1.2043938, 0.5955759, 0.9680236, 1.4945276, 1.1679278, 0.5767709]
AR_VDDA_VS_TRIM	[1.006, 1.033, 1.056, 1.083, 1.102, 1.129, 1.152, 1.178, 1.203, 1.23, 1.254, 1.279, 1.299, 1.325, 1.348, 1.375]
AR_VDDD_VS_TRIM	[0.98, 1.004, 1.027, 1.049, 1.075, 1.098, 1.12, 1.143, 1.166, 1.192, 1.214, 1.237, 1.261, 1.284, 1.309, 1.333]
AR_VDDA_TRIM	8
AR_VDDD_TRIM	9
AR_ROSC_SLOPE	[762.1713817576032, 1173.4311078421683, 751.5213565979282, 1176.7628519370523, 809.5181096742808, 1373.9748845387799, 971.054551992435, 1407.4695844974606, 1182.5801895521574, 1182.3567214859793, 1384.845258420116, 1378.6340819525562, 1205.5748407036606, 1205.3477140327689, 1385.3236837460315, 1383.9551925530247, 1353.6088929350012, 1352.7379685475833, 1606.730361121187, 1606.8018294610738, 1371.5487506591683, 1349.8107396952491, 1677.6461631104225, 1665.7948404728502, 845.8549338856491, 837.5706611844398, 1025.2233926821023, 1012.7512851842422, 1012.4100106142898, 1015.1059958681554, 1167.5137209649522, 1229.6723258698623, 1136.4177566668588, 1202.7975921624786, 1542.7337937989032, 1545.5740593891544, 1540.6010193710304, 1534.3971945057624, 1544.8276320826699, 1546.534696448638, 1539.9149624674242, 1541.7995831906053]
AR_ROSC_OFFSET	[-447.6416934965278, -691.9744253349443, -457.7033922963111, -700.0584276134668, -538.6346271275315, -910.1331922844851, -680.3597498981594, -967.0372744075868, -718.4361585304725, -722.498566840803, -843.1177924085812, -844.188934212508, -754.4919036308742, -745.9253959110309, -845.8331827649249, -855.4931374956806, -914.3904032072923, -912.7214965710799, -1073.950742234714, -1073.5170311785291, -954.4874982146961, -939.7297110948034, -1150.0052006085812, -1147.4992802436093, -544.5194453114476, -533.469675739837, -658.4668351875098, -657.364301129785, -645.5281764249997, -646.6025709323608, -596.1685598094369, -605.009778617003, -637.3953180322701, -667.336399407436, -1029.2851867437228, -1026.5008996057536, -1033.9699882003122, -1030.0244393150592, -1029.2049462980142, -1036.9324315602769, -1028.1643720990983, -1028.4135728664035]
AR_ROSC_MAX_RESIDUAL	[2.432282221130952, 3.8413705234208333, 2.1190292993313937, 3.6146743187218644, 1.065673373517568, 1.9071930672201716, 1.0118731685114535, 1.8414463116531452, 3.185692364767696, 3.1033022874277867, 3.7543331026141833, 3.6105638894517607, 2.8572512044767158, 2.920966934579459, 3.481038710255599, 3.363163762450087, 1.4025147795045594, 1.4678939660886146, 1.7277371139398274, 1.686603084586107, 1.478868944439147, 1.2974625797170143, 1.7157617838073058, 1.6939566659187684, 1.4839020835506933, 1.4212150007994369, 1.6438877243060548, 1.4340818186451358, 1.710187669819965, 1.8345359960111542, 4.154107843490152, 4.824375908526381, 2.810483027631834, 3.1329550368074313, 1.8096510436187998, 1.654808038816134, 1.5470636604197083, 1.638943842693358, 1.6416118156731396, 1.6760240336431835, 1.7091089622764284, 1.696291963258617]
AR_VDDD_SATURATION	-1.0
AR_VDDA_SATURATION	-1.0
AR_IREF_TRIM	8
ANALYSIS_VERSION	mqat v2.7.0
YARR_VERSION	v1.5.5
MEASUREMENT_DATE	2025-10-30T00:41:51.000+00:00
MEASUREMENT_DURATION	856
