Database for ITk Pixel Module

Serial Number	20UPGFC0141626
ProdDB ID	916777…b04f86
LocalDB ID	660d226e5d9bdc0035fd91e2
Component Type	fe_chip
Parents	20UPGM24211150 20UPGB43200224
Children	No match.
Flags

Item	Value
Target Iref trim	7
Target Iref trim version	1
Wafer serial number	None

Key	Data
QC Passed	True
Date	2 months ago
component ObjectId	660d226e5d9bdc0035fd91e2
Stage	MODULE/INITIAL_WARM
Test Type	TUNING
Institute ObjectId
User Name	DanielAceves
ObjectId of this record	68dd90f312752b66da90ef51
ObjectId of RAW record	None
Tags	No tags

Key	Data
ANALYSIS_VERSION	mqat v2.6.4
MEASUREMENT_DATE	2025-10-01T19:58:54.000+00:00
MEASUREMENT_DURATION	689
MEASUREMENT_VERSION	None
YARR_VERSION	v1.5.5
TUNING_TUNED_NOISE_95_HIGH	123.444
TUNING_TUNED_NOISE_95_LOW	82.157
TUNING_TUNED_NOISE_MEAN	102.262
TUNING_TUNED_NOISE_SIGMA	11.254
TUNING_TUNED_TDAC_MEAN	-1.3
TUNING_TUNED_TDAC_SIGMA	4.133
TUNING_TUNED_THRESHOLD_95_HIGH	1565.007
TUNING_TUNED_THRESHOLD_95_LOW	1437.232
TUNING_TUNED_THRESHOLD_FAILED_FITS	1
TUNING_TUNED_THRESHOLD_MEAN	1503.2
TUNING_TUNED_THRESHOLD_SIGMA	34
TUNING_TUNED_TOT_95_HIGH	10.02
TUNING_TUNED_TOT_95_LOW	5.13
TUNING_TUNED_TOT_MEAN	7.3
TUNING_TUNED_TOT_SIGMA	0.3
TUNING_UNTUNED_NOISE_95_HIGH	121.409
TUNING_UNTUNED_NOISE_95_LOW	80.941
TUNING_UNTUNED_NOISE_MEAN	100.554
TUNING_UNTUNED_NOISE_SIGMA	11.513
TUNING_UNTUNED_TDAC_MEAN	0
TUNING_UNTUNED_TDAC_SIGMA	0
TUNING_UNTUNED_THRESHOLD_95_HIGH	3010.425
TUNING_UNTUNED_THRESHOLD_95_LOW	1796.865
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	96
TUNING_UNTUNED_THRESHOLD_MEAN	2375.237
TUNING_UNTUNED_THRESHOLD_SIGMA	308

Filename	Contents
0x2293a_L2_warm.json	Download
output.log	Download
0x2293a.log	Download
20UPGFC0141626_MODULE__INITIAL_WARM_TUNING.zip	Download
