20UPGFC0141593

MODULE/FINAL_COLD

Component Information

Serial Number 20UPGFC0141593
ProdDB ID  f38ec4…e1813c
LocalDB ID 660d224f5d9bdc0035fd91ae
Component Type fe_chip
Parents 20UPGM24210397  20UPGB43200228 
Children No match.
Flags
Wafer
  Wafer Probing

 Properties

Item Value
Target Iref trim 11
Target Iref trim version 1
Wafer serial number None

 Comments

Date Commented by on which Component Comment
2 days ago pixel (Lawrence Berkeley National Lab - pixel modules) MODULE
20UPGM24210397 		sign-off at MODULE/FINAL_WARM; appended flags: []; next stage: MODULE/FINAL_COLD; comment: Failed LP mode. Want to investigate further.

Test: PIXEL_FAILURE_ANALYSIS QC Passed

(Stage: MODULE/FINAL_WARM)


Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key Data
QC Passed True
Date 2 days ago
component ObjectId 660d224f5d9bdc0035fd91ae
Stage MODULE/FINAL_WARM
Test Type PIXEL_FAILURE_ANALYSIS
Institute ObjectId
User Name None
ObjectId of this record 6a29b12c66f3d07de1017954
ObjectId of RAW record None
Tags No tags

Results

Key Data
DCSdata {}
QC_LAYER L2
PIXEL_FAILURE_ANY_ERRORS {'digitalscan': 0, 'analogscan': 0, 'thresholdscan_hd': 0, 'noisescan': 0, 'mergedbumpscan': 0, 'discbumpscan': 0, 'all': 0}
PIXEL_FAILURE_SOURCE_SCAN_DONE False
PIXEL_FAILURE_COLUMN_DISABLED 0
PIXEL_FAILURE_DEAD_DIGITAL 0
PIXEL_FAILURE_BAD_DIGITAL 0
PIXEL_FAILURE_DEAD_ANALOG 0
PIXEL_FAILURE_BAD_ANALOG 1
PIXEL_FAILURE_TUNING_BAD 13
PIXEL_FAILURE_HIGH_ENC 2
PIXEL_FAILURE_HIGH_NOISE 1
PIXEL_FAILURE_MERGED_BUMPS 0
PIXEL_FAILURE_DISCONNECTED_BUMPS_ZERO_BIAS_SCAN -1
PIXEL_FAILURE_DISCONNECTED_BUMPS_XTALK_SCAN 26
PIXEL_FAILURE_DISCONNECTED_BUMPS_SOURCE_SCAN -1
PIXEL_FAILURE_ELECTRICALLY_FAILED 17
PIXEL_FAILURE_DISCONNECTED_PIXELS 26
PIXEL_FAILURE_DISC_PIXEL_ALL_ELEC 26
PIXEL_FAILURE_FAILING_PIXELS 43
ANALYSIS_VERSION mqat v2.9.0
YARR_VERSION v1.6.0
MEASUREMENT_DATE 2026-06-10T10:46:25.000+00:00
MEASUREMENT_DURATION 665

Attachments

Filename Contents
output.log Download
0x22919.log Download
20UPGFC0141593_MODULE__FINAL_WARM_PIXEL-FAILURE-ANALYSIS.zip Download

ProductionDB Record

{}

 Current Stage: Final Cold

Test Type Local Result
ADC Calibration
(ADC_CALIBRATION)		 TestRun Present
Analog Readback
(ANALOG_READBACK)		 TestRun Present
SLDO
(SLDO)		 TestRun Present
VCAL Calibration
(VCAL_CALIBRATION)		 TestRun Present
Injection Capacitance
(INJECTION_CAPACITANCE)		 TestRun Present
Low Power Mode
(LP_MODE)		 No TestRun!
Overvoltage Protection
(OVERVOLTAGE_PROTECTION)		 No TestRun!
Undershunt Protection
(UNDERSHUNT_PROTECTION)		 No TestRun!
Tuning
(TUNING)		 TestRun Present
Minimal Health Test
(MIN_HEALTH_TEST)		 TestRun Present
Pixel Failure Analysis
(PIXEL_FAILURE_ANALYSIS)		 TestRun Present
Data Transmission
(DATA_TRANSMISSION)		 TestRun Present
Cold startup
(COLD_STARTUP)		 No TestRun!

 Candidate TestRuns of this Stage

LDB ID TestRun Code QC Passed Inspector Measurement Date Analysis Date Analysis Version Tags QC Registration
6a29ec…8e9aae TUNING Pass None N/A 2 days ago 2.9.0 No tags Selected
6a29ec…cd3ebf PIXEL_FAILURE_ANALYSIS Pass None N/A 2 days ago 2.9.0 No tags Selected
6a29eb…cd3df6 MIN_HEALTH_TEST Pass None N/A 2 days ago 2.9.0 No tags Selected
6a29e9…8e9a0f DATA_TRANSMISSION Pass None 3 days ago 2 days ago 2.9.0 ganymede_1 Selected
6a29b1…017a2f MIN_HEALTH_TEST Pass None N/A 2 days ago 2.9.0 No tags
6a29b1…017954 PIXEL_FAILURE_ANALYSIS Pass None N/A 2 days ago 2.9.0 No tags
6a29b0…79508b TUNING Pass None N/A 2 days ago 2.9.0 No tags
6a29b0…e9290b PIXEL_FAILURE_ANALYSIS Pass None N/A 2 days ago 2.9.0 No tags
6a29b0…df213a MIN_HEALTH_TEST Pass None N/A 2 days ago 2.9.0 No tags
6a28c8…017795 VCAL_CALIBRATION Pass None 3 days ago 3 days ago 2.9.0 ganymede_1 Selected
6a28c8…017792 LP_MODE Fail None 3 days ago 3 days ago 2.9.0 ganymede_1 Selected
6a28c4…e92715 INJECTION_CAPACITANCE Pass None 3 days ago 3 days ago 2.9.0 ganymede_1 Selected
6a28c0…794d22 SLDO Pass None 3 days ago 3 days ago 2.9.0 ganymede_1 Selected
6a28b5…189b16 ANALOG_READBACK Pass None 3 days ago 3 days ago 2.9.0 ganymede_1 Selected
6a289a…794bd8 ADC_CALIBRATION Pass None 3 days ago 3 days ago 2.9.0 ganymede_1 Selected
