20UPGFC0141593

MODULE/FINAL_COLD

Component Information

Serial Number	20UPGFC0141593
ProdDB ID	f38ec4…e1813c
LocalDB ID	660d224f5d9bdc0035fd91ae
Component Type	fe_chip
Parents	20UPGM24210397 20UPGB43200228
Children	No match.
Flags

Wafer

Wafer Probing

Properties

Item	Value
Target Iref trim	11
Target Iref trim version	1
Wafer serial number	None

Comments

Date	Commented by	on which Component	Comment
2 days ago	pixel (Lawrence Berkeley National Lab - pixel modules)	MODULE 20UPGM24210397	sign-off at MODULE/FINAL_WARM; appended flags: []; next stage: MODULE/FINAL_COLD; comment: Failed LP mode. Want to investigate further.

Test: TUNING QC Passed

(Stage: MODULE/QC_CROSSCHECK)

Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key	Data
QC Passed	True
Date	4 weeks ago
component ObjectId	660d224f5d9bdc0035fd91ae
Stage	MODULE/QC_CROSSCHECK
Test Type	TUNING
Institute ObjectId
User Name	None
ObjectId of this record	6a074d2c8a277601d030455f
ObjectId of RAW record	None
Tags	No tags
Tuning Config	Associated FE Config

Results

Key	Data
DCSdata	{}
QC_LAYER	L2
TUNING_UNTUNED_THRESHOLD_MEAN	2447.851
TUNING_UNTUNED_THRESHOLD_95_LOW	1819.313
TUNING_UNTUNED_THRESHOLD_95_HIGH	3146.321
TUNING_UNTUNED_THRESHOLD_SIGMA	338.775
TUNING_UNTUNED_TDAC_MEAN	0.0
TUNING_UNTUNED_TDAC_SIGMA	0.0
TUNING_UNTUNED_NOISE_MEAN	105.239
TUNING_UNTUNED_NOISE_SIGMA	11.838
TUNING_UNTUNED_NOISE_95_LOW	84.717
TUNING_UNTUNED_NOISE_95_HIGH	127.358
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	71
TUNING_TUNED_THRESHOLD_MEAN	1497.7
TUNING_TUNED_THRESHOLD_95_LOW	1425.647
TUNING_TUNED_THRESHOLD_95_HIGH	1564.943
TUNING_TUNED_THRESHOLD_SIGMA	37.0
TUNING_TUNED_TDAC_MEAN	-1.3
TUNING_TUNED_TDAC_SIGMA	3.865
TUNING_TUNED_NOISE_MEAN	106.104
TUNING_TUNED_NOISE_SIGMA	11.555
TUNING_TUNED_NOISE_95_LOW	85.281
TUNING_TUNED_NOISE_95_HIGH	128.411
TUNING_TUNED_TOT_MEAN	7.4
TUNING_TUNED_TOT_SIGMA	0.3
TUNING_TUNED_TOT_95_LOW	5.25
TUNING_TUNED_TOT_95_HIGH	10.13
TUNING_TUNED_THRESHOLD_FAILED_FITS	3
TUNING_ANY_ERRORS	{'tune_globalthreshold': 0, 'thresholdscan_hr': 0, 'tune_pixelthreshold': 0, 'thresholdscan_hd': 0, 'totscan': 0, 'all': 0}
ANALYSIS_VERSION	mqat v2.8.1
YARR_VERSION	v1.5.6
MEASUREMENT_DATE	2026-05-15T06:19:24.000+00:00
MEASUREMENT_DURATION	659
