Database for ITk Pixel Module

Serial Number	20UPGFC0141593
ProdDB ID	f38ec4…e1813c
LocalDB ID	660d224f5d9bdc0035fd91ae
Component Type	fe_chip
Parents	20UPGM24210397 20UPGB43200228
Children	No match.
Flags

Item	Value
Target Iref trim	11
Target Iref trim version	1
Wafer serial number	None

Key	Data
QC Passed	True
Date	a month ago
component ObjectId	660d224f5d9bdc0035fd91ae
Stage	MODULE/POST_PARYLENE_WARM
Test Type	TUNING
Institute ObjectId
User Name	Simpson,Liana Rae
ObjectId of this record	691b999ed7bf966e0aaefe47
ObjectId of RAW record	None
Tags	No tags

Key	Data
ANALYSIS_VERSION	mqat v2.7.1
MEASUREMENT_DATE	2025-10-31T17:55:09.000+00:00
MEASUREMENT_DURATION	1376
YARR_VERSION	v1.5.5
TUNING_TUNED_NOISE_95_HIGH	128.988
TUNING_TUNED_NOISE_95_LOW	85.309
TUNING_TUNED_NOISE_MEAN	106.407
TUNING_TUNED_NOISE_SIGMA	11.648
TUNING_TUNED_TDAC_MEAN	-1.3
TUNING_TUNED_TDAC_SIGMA	3.892
TUNING_TUNED_THRESHOLD_95_HIGH	1565.331
TUNING_TUNED_THRESHOLD_95_LOW	1424.747
TUNING_TUNED_THRESHOLD_FAILED_FITS	3
TUNING_TUNED_THRESHOLD_MEAN	1497.4
TUNING_TUNED_THRESHOLD_SIGMA	37
TUNING_TUNED_TOT_95_HIGH	10.07
TUNING_TUNED_TOT_95_LOW	5.11
TUNING_TUNED_TOT_MEAN	7.3
TUNING_TUNED_TOT_SIGMA	0.3
TUNING_UNTUNED_NOISE_95_HIGH	127.352
TUNING_UNTUNED_NOISE_95_LOW	84.547
TUNING_UNTUNED_NOISE_MEAN	105.126
TUNING_UNTUNED_NOISE_SIGMA	11.926
TUNING_UNTUNED_TDAC_MEAN	0
TUNING_UNTUNED_TDAC_SIGMA	0
TUNING_UNTUNED_THRESHOLD_95_HIGH	3131.334
TUNING_UNTUNED_THRESHOLD_95_LOW	1805.121
TUNING_UNTUNED_THRESHOLD_FAILED_FITS	79
TUNING_UNTUNED_THRESHOLD_MEAN	2433.223
TUNING_UNTUNED_THRESHOLD_SIGMA	338.221

Filename	Contents
0x22919_L2_warm.json	Download
output.log	Download
0x22919.log	Download
20UPGFC0141593_MODULE__POST_PARYLENE_WARM_TUNING.zip	Download
