20UPGFC0134227

MODULE/INITIAL_WARM

Component Information

Serial Number 20UPGFC0134227
ProdDB ID  a38e82…a3dc80
LocalDB ID 65d90fc8ba853e0042670bc7
Component Type fe_chip
Parents 20UPIM13602236  20UPGB43000013 
Children No match.
Flags
Wafer
  Wafer Probing

 Properties

Item Value
Wafer serial number None

 Comments


Test: SLDO QC Failed

(Stage: MODULE/INITIAL_WARM)


Basic View Only: custom view for this TestRun is not prepared.

Metadata

Key Data
QC Passed False
Date a year ago
component ObjectId 65d90fc8ba853e0042670bc7
Stage MODULE/INITIAL_WARM
Test Type SLDO
Institute ObjectId
User Name None
ObjectId of this record 67045027255e35fff1827422
ObjectId of RAW record 67045023255e35fff1827415
Tags No tags

Results

Key Data
ANALYSIS_VERSION mqat v2.2.8.dev28
MEASUREMENT_VERSION 2.2.7.dev19
QC_LAYER L2
INSTITUTION LBNL_PIXEL_MODULES
SLDO_LINEARITY 0.122
SLDO_VINA_VIND -0.0
SLDO_VDDA 1.2
SLDO_VDDD 1.19
SLDO_VINA 1.465
SLDO_VIND 1.467
SLDO_VOFFS 0.99
SLDO_IINA 0.686
SLDO_IIND 0.876
SLDO_IREF 3.7
SLDO_ISHUNTA 0.168
SLDO_ISHUNTD 0.163
SLDO_ANALOG_OVERHEAD 0.324
SLDO_DIGITAL_OVERHEAD 0.229
SLDO_VI_SLOPE 0.08
SLDO_VI_OFFSET 0.938
SLDO_NOM_INPUT_CURRENT 5.88

Attachments

Filename Contents
output.log Download
0x20c53.log Download

RAW Results Record

Download RAW
_id67045023255e35fff1827415
raw
serialNumbertestTypesubtestTyperesultsstagecomponentdbVersionaddresssys
20UPGFC0134227SLDO
property
YARR_VERSIONv1.5.2
SLDO_MEASUREMENT_VERSION2.2.7.dev19
comment
Measurements
Temperature
XFalse
UnitC
Values
  • 60.5752
  • 61.2131
  • 61.3345
  • 61.1591
  • 60.7866
  • 60.2595
  • 59.5729
  • 58.7494
SetCurrent
XFalse
UnitA
Values
  • 8.0
  • 7.8
  • 7.6
  • 7.3999999999999995
  • 7.199999999999999
  • 7.0
  • 6.8
  • 6.6
Current
XTrue
UnitA
Values
  • 8.0
  • 7.8
  • 7.6
  • 7.4
  • 7.2
  • 7.0
  • 6.8
  • 6.6
Vmux30
XFalse
UnitV
Values
  • 0.0338329
  • 0.0331643
  • 0.0323785
  • 0.0315422
  • 0.0306829
  • 0.0297972
  • 0.0288959
  • 0.0279847
Vmux33
XFalse
UnitV
Values
  • 0.428084
  • 0.423584
  • 0.418868
  • 0.414133
  • 0.409265
  • 0.404353
  • 0.399319
  • 0.394183
Vmux37
XFalse
UnitV
Values
  • 0.428909
  • 0.424242
  • 0.419577
  • 0.414773
  • 0.409955
  • 0.404999
  • 0.399979
  • 0.394853
Vmux34
XFalse
UnitV
Values
  • 0.637097
  • 0.635997
  • 0.63514
  • 0.634308
  • 0.633882
  • 0.632436
  • 0.631544
  • 0.62999
Vmux38
XFalse
UnitV
Values
  • 0.63025
  • 0.629347
  • 0.628621
  • 0.627918
  • 0.626939
  • 0.625598
  • 0.624882
  • 0.623349
Vmux36
XFalse
UnitV
Values
  • 0.281618
  • 0.281052
  • 0.280196
  • 0.279287
  • 0.278371
  • 0.277417
  • 0.27645
  • 0.275368
Vmux32
XFalse
UnitV
Values
  • 0.621115
  • 0.620139
  • 0.619114
  • 0.618184
  • 0.61734
  • 0.616205
  • 0.61556
  • 0.614453
Imux0
XFalse
UnitV
Values
  • 0.0679737
  • 0.0672479
  • 0.0664799
  • 0.0656527
  • 0.0647845
  • 0.0639162
  • 0.0630109
  • 0.0621066
Imux28
XFalse
UnitV
Values
  • 0.428552
  • 0.41737
  • 0.406081
  • 0.394835
  • 0.383452
  • 0.371853
  • 0.360064
  • 0.347995
Imux29
XFalse
UnitV
Values
  • 0.168402
  • 0.15692
  • 0.145481
  • 0.134347
  • 0.12321
  • 0.111833
  • 0.100563
  • 0.0892215
Imux30
XFalse
UnitV
Values
  • 0.536345
  • 0.52247
  • 0.508513
  • 0.494569
  • 0.480414
  • 0.465924
  • 0.451377
  • 0.436474
Imux31
XFalse
UnitV
Values
  • 0.179877
  • 0.164116
  • 0.150393
  • 0.137362
  • 0.12398
  • 0.111164
  • 0.0990405
  • 0.087397
Imux63
XFalse
UnitV
Values
  • 0.0314113
  • 0.030661
  • 0.0298512
  • 0.0290056
  • 0.0281372
  • 0.0272545
  • 0.0263541
  • 0.0254482
Metadata
FirmwareVersion
FirmwareIdentifier
ChannelConfig
SoftwareVersion
ChipConfigs
ITKPIXV2
GlobalConfig
AuroraActiveLanes1
CdrClkSel0
CmlBias0800
CmlBias1400
CmlBias20
SerEnTap1
SerInvTap1
MonitorEnable1
MonitorI63
MonitorV32
ServiceBlockEn1
ServiceBlockPeriod50
DiffLcc200
DiffLccEn1
DiffPreComp350
DiffPreampL550
DiffPreampM550
DiffPreampR550
DiffPreampT550
DiffPreampTL550
DiffPreampTR550
DiffVff60
EnCoreCol065535
EnCoreCol165535
EnCoreCol265535
EnCoreCol363
DataMergeOutMux00
DataMergeOutMux11
DataMergeOutMux22
DataMergeOutMux33
SerEnLane15
SerSelOut01
SerSelOut13
SerSelOut23
SerSelOut33
SldoTrimA10
SldoTrimD9
Parameter
ADCcalPar
  • 9.0
  • 0.182
  • 10000.0
Name0x20c53
ChipId15
InjCap7.947000000000001
NfDSLDO1.2547280380921086
NfASLDO1.2558993594769552
NfACB1.2526567990579285
VcalPar
  • 13.911
  • 0.197
IrefTrim7
KSenseInA21255.751
KSenseInD21313.367
KSenseShuntA26316.644095238094
KSenseShuntD26387.97819047619
KShuntA993.706
KShuntD969.254
SoftwareType
ChipID15
Name0x20c53
InstitutionLBNL_PIXEL_MODULES
ModuleSN20UPGM23602236
AverageTemperature60.4562875
TimeStart1728335391
TimeEnd1728335893
MODULE/INITIAL_WARM65d90fc8ba853e0042670bc71.0164657cef8d79bac1f3f005c0
mts2024-10-07 21:18:27.583000
cts2024-10-07 21:18:27.583000
rev0
rawHash781fc349712be96b6db895bab1ac9f6f
stageMODULE/INITIAL_WARM
